GL-2xxx and GL-3xxx Series LED Search Lights
Larson Electronics, LLC
Phone: [phone]
Fax: [phone] www.larsonelectronics.com
1 of 3
LED Search Light - 12-24V DC, 460,000 Candela - Permanent Mount -
White Housing
Instruction Manual
Thank you for your purchase of a GL-2xxx or GL-3xxx series LED search light from Larson Electronics.
WARNING
Standard Warning (General)
WARNING:
READ CAREFULLY BEFORE INSTALLING FIXTURE. RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE.
CRITICAL SAFETY INSTRUCTIONS:
•INSTALLATION SHOULD ONLY BE CONDUCTED BY A QUALIFIED ELECTRICIAN IN ACCORDANCE WITH NEC AND ANY
RELEVANT LOCAL BUILDING CODES.
•RISK OF FIRE OR ELECTRIC SHOCK. FIXTURE INSTALLATION REQUIRES KNOWLEDGE OF FIXTURE'S ELECTRICAL
SYSTEMS. IF NOT QUALIFIED, CONTACT A QUALIFIED ELECTRICIAN.
•BE CERTAIN ELECTRICAL POWER IS OFF BEFORE AND DURING INSTALLATION AND MAINTENANCE.
•MAKE SURE THE SUPPLY VOLTAGE IS THE SAME AS THE FIXTURE'S RATED VOLTAGE.
•TO PREVENT WIRING DAMAGE OR ABRASION, DO NOT EXPOSE WIRING TO EDGES OF SHEET METAL OR SHARP
OBJECTS. SUITABLE FOR DAMP LOCATIONS.
SAFETY NOTICE
•If replacing LED module, the LED module
connector should be connected correctly
for positive and negative wires.
RED and BLUE: Positive (+)
BLACK and BROWN: Negative (-)
•FCC RULE Part. 15.21：Changes or
modifications not expressly approved by
the party responsible for compliance could
void the user’s authority to operate the
equipment.
•This device complies with Part 15 of the
FCC Rules. Operation is subject to the
following two conditions: (1) this device
may not cause harmful interference, and
(2) this device must accept any
interference received, including
interference that may cause undesired
operation.
•This searchlight is a Radio Frequency (RF)
device which operates on Channel 433.92
MHz. It will send out RF energy when it is
in operation.
1. RF energy may affect some electronic
equipment.
2. Some electronic equipment on vehicles
or boats may be affected by RF energy.
IMPORTANT NOTICE
If searchlight DC power is disconnected (wires
disconnected from battery or power supply switched
off), after reconnecting to power, make sure to turn on
the searchlight using the wireless or wired remote, to
make a full 360° rotation, in order to reset the home
position memory.
SAVE THESE INSTRUCTIONS

GL-2xxx and GL-3xxx Series LED Search Lights
Larson Electronics, LLC
Phone: [phone]
Fax: [phone] www.larsonelectronics.com
2 of 3
MAINTENANCE
Caution: To avoid personal injury, disconnect power to the light and allow the unit to cool down before
performing maintenance.
Warning: No user serviceable parts inside of fixture. Risk of electric shock. Removal of the lens will void
the warranty.
1. Perform visual,mechanical and electrical inspections on a regular basis.We recommend routine
checks to be made on a yearly basis. Frequency of use and environment shoulddetermine this. It is
recommendedto follow an Electrical Preventive Maintenance Program as described in NFPA 70B:
Recommendedpractice for Electrical Equipment.
2. The lens should be cleaned periodically as neededto ensure continued photometric performance.
Clean the lens with a damp, non-abrasive,lint-free cloth. If not sufficient, use mild soapor a liquid
cleaner.
3. Do not operate if the lens is cracked or damaged. All fasteners shouldbe properly seated.
USE AND CARE
Unauthorized modification may impair the function and/or safety of this device and could affect the life of the equipment.
Always check for damaged or worn out parts before using the device. Store it in a secure place out of the reach of
children when not in use.Inspect for good working condition prior to storage and before re-use.
REPLACEMENT PARTS
The GL-2xxx and GL-3xxx Series LED Search Lights are designed to provide years of reliable performance. Should the
need for replacement parts arise, please contact Larson Electronics.
THESE INSTRUCTIONS MAY NOT COVER ALL DETAILS OR VARIATIONS OF THIS PRODUCT FOR YOUR EQUIPMENT OR INSTALLATION REQUIREMENTS.
SHOULD FURTHER INFORMATION NOT COVERED BY THESE INSTRUCTIONS BE REQUIRED, PLEASE CONTACT LARSON ELECTRONICS BY EMAIL AT
SAL[email protected] OR BY PHONE AT 1-877-348-9680 FOR FURTHER ASSISTANCE.
PLEASE VISIT LARSONELECTRONICS.COM FOR WARRANTY AND RETURN INFORMATION.
Magnetic Warning
•PEOPLE WITH PACEMAKERS SHOULD CONSULT THEIR PHYSICIAN(S) BEFORE USE.
ELECTROMAGNETIC FIELDS IN CLOSE PROXIMITY TO HEART PACEMAKER COULD CAUSE
PACEMAKER INTERFERENCE OR PACEMAKER FAILURE.
•KEEP FINGERS AWAY FROM MAGNET WHEN MOUNTING AS INJURY COULD OCCUR.

GL-2xxx and GL-3xxx Series LED Search Lights
Larson Electronics, LLC
Phone: [phone]
Fax: [phone] www.larsonelectronics.com
3 of 3
MOUNTING TEMPLATE - SEARCH LIGHT
PLEASE NOTE: If you obtain this mounting template from the Larson Electronics website or any other
electronic form, make sure to verify the dimensions of it with an accurate measuring device before using.
Duplicate templates may not be at a true 1:1 scale. Take any deviations into account before drilling or
mounting the search light.
UNITS: mm/inches
