Laser MID-782 User guide

QUICK OPERATION GUIDE MID-782
1
Note:
eStreet
Maps does
not need an
internet or
satellite
connection
to operate.

QUICK OPERATION GUIDE MID-782
2
TABLE OF CONTENTS
APPEARANCE AND BUTTONS 4
ACCESSORIES 5
TURNING ON AND OFF 5
BATTERY CHARGING 5
RUN TIME 5
5 POINT TOUCH-SCREEN 5
SLEEP MODE _________ 5
LOCK / UNLOCK 6
HOME SCREEN ICONS 6
VIEW ALL APPS__ 7
APP ICONS 7
WIDGETS 8
NOTIFICATION MENU BAR 8
SHORTCUT MENU BAR 8
SETTINGS - WI-FI 9
SETTINGS - BLUETOOTH 10
CONNECTING TO A PC / MAC VIA USB 10
eSTREET DIRECTORY 11
NAVIGATOR____________________________ 16
EBOOK DRM (ALDIKO) 17
WHY CREATE A GOOGLE ACCOUNT 19
GOOGLE PLAY APP 19
SPECIFICATIONS 19
FAQ 20
WARRANTY INFORMATION________________ 21

QUICK OPERATION GUIDE MID-782
3
IMPORTANT SAFETY INSTRUCTIONS AND PRECAUTIONS
Read all instructions carefully before use.
Retain this manual for future reference.
Use this product only in the manner described.
Only use a water-dampened soft-cloth to clean the surface of this product.
The following will damage this product: wateror moisture ingress, exposure to
prolonged extreme heat or cold; excessive humidity, dust or sandy.
It is recommended to thoroughly charge the device for the first time. Subsequent
charges can be as needed. During charging, or extended use, the product may become
warm.
There are no user serviceable parts in this product.
Un-authorizedattempts to dismantle or repair this product will void product warranty
and may result in dangerous electric shock.
Remove data cable by pulling it from the plug, not from the cord.

QUICK OPERATION GUIDE MID-782
4
APPEARANCE AND BUTTONS:
Number
Description
1 Reset Button
2 HDMI output
3 Micro USB interface (Data Transfer,Charging, USB Storage flash drive).
4 Stereo Earphone Socket (3.5mm Jack)
5 On / OFF button (*Press and hold to turn ON and OFF)
6 Rear mounted camera
7 Built in Speaker
8 Micro SD card slot. (Supports cards up to 32GB)
9 Front mounted camera
6
5
4
3
1
2
7
9
8

QUICK OPERATION GUIDE MID-782
5
OR
ACCESSORIES
1 x 7” MID-782, 1 x DC Power Adaptor with USB socket, 1 x Micro USB/DATA cable, 1 x User
Guide
TURNING ON AND OFF
To turn ON, PRESS and HOLD the POWER button until the screen turns ON.
To turn OFF, PRESS and HOLD the POWER button until the power screen appears. Then select
Power Off.
Note:At any time you can press the POWER BUTTON to enter Snooze mode or to wake from Snooze
mode.
BATTERY CHARGING
You can charge your MID-782 using the supplied DC Power Adaptor and USB/DATA cable.
You will be alerted when the battery charge falls below 15%. If the battery is completely
depleted the MID-782 will automatically turn off.
Note:Ifthe battery has been completely exhausted, it may take a few minutes to switch the MID-782
on once charging has begun. The MID-782can be used during charging however this may increase
the time needed to fully charge the battery.
RUN TIME
Run time of portable devices such as this MID-782can be extendedby reducing the screen
brightness, turning off Bluetooth function, turning off the Location function, turning off WiFi
when not in use, turning off Apps that are not required and manually turning the screen off
using the power button when not in use.
5 POINT TOUCH-SCREEN
The MID-782 has 5 different touch screen behaviours.
1-TAP Tap once to select or start a function, option or application
2- TAP and HOLD Tap and hold to select or start a function
3-DRAG and DROP Tap then drag an item and drop it to a location
4-DOUBLE TAP Double Tap an item twice to select or start a function
5-SLIDE/SWIPE Tap then slide an item up, down, left or right
SLEEP MODE
During prolonged inactive use where no buttons have been pressed, the screen will turn off
automatically to conserve power. Press the POWER button to wake the MID-782.
Note: This can be adjusted in Display option under Settings.

QUICK OPERATION GUIDE MID-782
6
LOCK / UNLOCK
When the MID-782 is in sleep mode, press the POWER button to show the unlock screen.
TAP and HOLD the LOCKED padlock icon, dragit to the UN-LOCKED padlock icon, then release.
Note:Some of the following images may be differentfrom the actual product supplied.
HOME SCREEN ICONS
Number
Icon Function
1 Open web browser /Voice command
2 “Swipe Down” Notification Menu Bar
3 “Swipe Down” Shortcut Menu Bar
4
View all apps
5
Increase Volume
6
Open a list of recently used applications
7
Home screen
8 Back button
9
Decrease Volume
1
3
4
5
6
7
8
9
2

QUICK OPERATION GUIDE MID-782
7
VIEW ALL APPS
Press to view all the installed apps on your tablet
APPS ICONS
Note:Some of the following images may be different
from the actual product supplied.
Icon
Function
Browser: Internet browser
Calendar: Create and manage daily, weekly and monthly events, set alarm
clocks. Note: A Google account is required
Camera: Take and view pictures and video
Clock: Access alarm clock settings and time display
Downloads: Manage downloaded content
E-mail: e-mail access
File Manager: Access all pictures, video, music, sound clips and other files saved
on the device and SD card
Music: Music player
Web Browser: Open Chrome web browser
Settings: View settings menu
Sound Recorder: Recordsound using the microphone
Videos: Video player

QUICK OPERATION GUIDE MID-782
8
WIDGETS
Users can add or remove Widget program icons (shortcuts) from the desktop as well as move
them to different desktop screens.
To adda Widget, press and hold the desired widget, drag and drop it to the desired position
on the desktop.
To delete an icon, press and hold the icon until the “X” icon appears at the top LEFT of the
screen. Drag the icon to the “X” and then release to delete.
NOTIFICATION MENU BAR
Swipe down over the Notification Menu Bar (top left of the screen) to bring up any
notifications you may have.
SHORTCUT MENU BAR
Swipe down over the Short cut Menu Bar to view
items such as:
Battery charge, Settings, WiFi, Bluetooth, Location,
Audio Profiles, Brightness, Rotation Locked,
ScreenShot, CastScreen.
PRESS AND
HOLD THE
MAIN
SCREEN

QUICK OPERATION GUIDE MID-782
9
SETTINGS
Wi-Fi
Note:a WiFi connection is required ifconnecting to the internet (for email, Play Store or web
browsing)
When WiFi is turned on it will automatically scan for all available WiFi networks
Tap the desired NETWORK name. If this NETWORK connects successfully, “Connected”
will appear. If the NETWORK is encrypted, enter the password then tap “Connect”.
Your MID-782 will indicate when the NETWORK connection is ready for use when the
WiFi icon appears on the top right notification bar.

QUICK OPERATION GUIDE MID-782
10
Bluetooth
When Bluetooth is turned on, it will automatically scan for all available Bluetooth devices.
Tap the desired Bluetooth device (example shown above). If connection is successful,
“Connected” will appear.
CONNECTING TO A PC / MAC VIA USB
Connect the USB cable to your MID-782 and PC/MAC, making sure you are using the correct
MICRO USB cable supplied.

QUICK OPERATION GUIDE MID-782
11
eSTREET DIRECTORY
Note: eStreet maps is like a pre-loaded “Gregory’s” map and does not need satellite or
internet connections to work. This is a fully featured mapping service with 3D effects
however it does not offer turn by turn verbal guidance.
Interacting with eSTREET Screens
Note: Each RED coloured arrow below resembles the movement of a finger (two in total)
for each screen movement.
Rotate screen clockwise or counter-clockwise.
Note: Tap the Compass reset icon to default the screen back to the true north position.
Tilt screen up or down
Zoom in or zoom out (Includes 3D imaging of key buildings)

QUICK OPERATION GUIDE MID-782
12
MENU features are accessed
from the MENU screen.
Once pressed, the following menu bar options will appear:
FIND LOCATION: Enter address, Saved Locations, Home,
Nearby POI (Search), Nearby POI Search.
JOURNEY DETAIL: (*if a start or finish address has been
inputted) Trip Details, Clear Trip Buttons
OPTIONS: Check for Map Updates, Show Help, About.
To navigate to a location, begin by
pressing the ENTER ADDRESS menu
option and keying in your details. Note:
The address auto fill will suggest options
as you type. Alternatively, use the target “cross-hairs” at the middle of the screen to
manually move through the mapping screens)
Target or select the correct address
from the drop down suggestions. The
selected address will now appear at
the top of the screen. (a)
a
b

QUICK OPERATION GUIDE MID-782
13
Press SET TRIP START (b). The address now
replaces SET TRIP START as confirmation (c)
To fill in the destination address, press the
MENU buttonagain and select ENTER
ADDRESS. Enter your details in the same
previous fashion. Press SET TRIP FINISH.
The address now replaces SET TRIP FINISH
as confirmation
Your MID will then plot
your route and add two
navigation specific MENU
options – Show Directions
and Cancel Trip
Press SHOW DIRECTIONS to view
turn by turn instructions
c

QUICK OPERATION GUIDE MID-782
14
You can use the SAVE button to use EACH
LOCATION you input, as either a HOME
address or to add it to your SAVED
LOCATIONS list.
Note: Access your HOME and SAVED
LOCATIONS directly from the MAIN
MENU
Press the HOME button to return you to this default
address, or press the SAVED LOCATIONS BUTTONS to
choose an address from your favourites list.
There are further search functions you can perform without knowing
the exact address of your desired destination. These are NEARBY POI
and NEARBY POI SEARCH.
NEARBY POI search provides places by default categories eg. Accommodation
NEARBY POI SEARCH search provides a manual input searchby name eg. LASER
Corporation

QUICK OPERATION GUIDE MID-782
15
To locate Nearby Points of Interest, select NEARBY POI
from the MAIN MENU. Select from the following
categories:
ATM/Bank/Exchange, Administrative Region, Airport,
Amusement or Holiday Park, Bar/Pub, Body of Water,
Book Shop, Building, Business/Industry etc
When each category is selected, they will
appear on the map as a blue “dot” landmark.
Select a location and press the SET TRIP
FINISH button and then the SET TRIP START as
covered above.
Or manually input your search name into
the NEARBY POI SEARCH option

QUICK OPERATION GUIDE MID-782
16
NAVIGATOR (PRE loaded App)
Try out the FREE GPS navigation app which has been pre-installed
onto this tablet.
If you would like a full professional navigation app, you can
subscribe to any of the leading map providers such as TomTom or
Metroview.
Note: When using Navigator for the first time you have the option to select from either the
FREE version or paid version.
Note: Ensure the “Location” function on the tablet is turned on otherwise you will not get a
GPS position.

QUICK OPERATION GUIDE MID-782
17
EBOOK DRM (ALDIKO)
Note:Aldiko supports purchased and borrowed eBooks.
Download Adobe Digital Editions (ADE) to your PC and set up your FREE account. Upon
purchasing or borrowing an eBook using ADE, it will then need to be transferred to your
MID-782.
From Adobe Digital Editions, right click the eBook you wish to transfer and select “ShowFile
in Explorer”.
View this YouTube video on purchasing eBooks. https://www.youtube.com/watch?v=AieWzAbpmjs
Then right click on the file and select “Copy”.

QUICK OPERATION GUIDE MID-782
18
Connect your MID-782 to the same PC you have loaded ADE and open Windows Explorer. If
connectedcorrectly yourMID-782 will be visible. Select theMID-782 by double-clicking it.
Then contents will appear on the right side of the Windows Explorer screen. Right click this
section and select paste. The file has now been transferred. Disconnected the MID-782,
open the ALDIKO App on yourMID-782 and select the top right “Settings” option.
Select ADOBE DRM then enter your username and
password and select “Sign in”.
Finally, locate the “File” which was just transferred, then click “Import”.

QUICK OPERATION GUIDE MID-782
19
WHY CREATE A GOOGLE ACCOUNT
Creating a Google account allows you to talk, chat, share, schedule, store, organize,
collaborate, discover, and createonline. A Google account also provides user level access to
Gmail, Google+ and YouTube which are all backed up online and accessible online via the
cloud.
GOOGLE PLAY APP
Open the GOOGLE PLAY STORE App and set up your account. If you have an existing
account select EXISTING, otherwise choose NEW to create a new account and follow the
set-up steps.
View our product training videos at: www.laserco.com.au/tablets/Tablet/MID-782
SPECIFICATIONS
Operation System: Android 4.4.2
Size 192 x 117 x 11.2mm
CPU processor speed: MTK Quad Core 1.6Ghz
Memory: 8GB
RAM: DDR3 512 MB
TF card: 128M-32G
Display screen: 7”(Capacitive multi-touch) TFT capacitive touch
Resolution: 1024 x 600
Battery and capacity: Rechargeable Built-in type polymer battery, 2800Mah
Camera Resolution: 0.3MP (Front mount), 2.0MP (Rear Mount)
Screen auto orientation: G-sensor 3D
Voice Recording Built-in microphone
Supported file types: Video format: avi, mov, mp4, 3gp, flv
Audio format: mp3, flac, aac, wav, m4a
(To play other formats, you will need to download the
App that supports the format you intend to play)

QUICK OPERATION GUIDE MID-782
20
FAQ
The HDMI output to my TV
doesn’t work Please make sure the HDMI output has been turned on under the Settings Menu (Settings > Display > HDMI > ON)
I can’t turn my MID-782ON?
1.Ensure your MID-782 is charged
2. Connect the power adaptor, and then check again after sufficient
charge time
3. Reset the device using the reset button
I can’t hear anything through
my headset, or the sound
quality is very bad
1.Please ensure volume is turned up
2. Check the music file on another device to make sure it is not damaged.
3. Try using another pair of headphones
I can’t copy files or play music
1.Please check the connection to you computer
2.Ensure there is enough spare memory
3.Check the USBcable is not damaged using another device
4.Check the USB connection is inserted correctly
My MID-782 displays a
network or service error
message
1. Check the strength of the WiFi signal
2. Check that the WiFi service is available and operating correctly
3. When using apps like Face Book and Google play (with a lot of
content) for the first time, a few extra minutes will be required to load all
the content.
My touch screen is slow and
not working correctly
1. Make sure theprotective film has been removed from the screen
2. Ensure that your fingers are dry and clean.
3. Restart your MID-782
4. Ensure the touch screen is not scratched or damaged
My MID-782 is frozen or a
severe error has occurred
1. Try closing Apps or resetting
2. Restore or reset the MID-782 to factory default settings.
3. Reset the device using the reset button
My MID-782 becomes hot
when is use or while charging
1. Someapplications can consume more power than others causing the
MID-782to become warm while in use or if used for extended amounts
of time. This is normal and won’t affect the life or performance of your
MID-782.
An error occurs when I open
my music files
1. Remove some files to make more storage space
2. Make sure the music files aren’t protected by digital rights
management (DRM). If the files have DRM protection, make sure that
youhave the license or key.
3. Make sure that file type is compatible.
The available memory on my
MID-782 is less than 8GB. Why
is that so?
Some of this space is required to pre-load Apps and other Software. Space
is required for the OS (Operating System).
My MID tablets internal
memory is almost full; can I
install or move the Apps to
external SD card?
Latest Android OS will only allow apps to be installed on internal
memory. To free up the internal space: 1) Uninstallsome un-used
apps. 2) Move photos, music or video files to SD card.
My tablet screen has cracked;
will it be covered by warranty? No, physical damage is not covered by warranty.
