Lattice CertusPro-NX User manual

QuickART
CertusPro-NX Voice and
Vision Machine Learning Board
This document provides a brief introduction to the CertusPro-NX Voice and Vision
Machine Learning Board. The board is pre-programmed to demonstrate the Object
Detection Demo.
1
2
Check Kit Contents
The CertusPro-NX Voice and Vision Machine Learning Board kit contains the following
items:
CertusPro-NX Voice and Vision Machine Learning Board
Himax HM0360 camera sensor (U24)
Sony IMX258 camera sensor (CN1)
USB Cable for programming via PC (USB-A to USB 2 Micro-B)
USB Cable for video output (USB 3 Micro-B to USB-A)
Quick Start Guide
Preparing the Hardware and Running the Demonstration
Follow the steps below to prepare the hardware and start the pre-programmed demon-
stration.
Connect USB-A to USB 2 Micro-B cable to PC (J2). This will provide power to the
board.
Connect USB 3 Micro-B to USB-A cable from USB3 Video Out (J8) to PC
No jumpers need to be placed on the board
Ensure SWITCH0 of SW1 is ON to boot CYUSB3014 (U13) from I2C EEPROM
Install python virtualenv
$ pip install virtualenv
Create a virtual environment
$ python -m virtualenv lattice _ env
Activate the created environment
$ .\lattice _ env\Scripts\activate
Installing required packages
$ pip install -r requirements.txt
Run the app by typing the following
command shown $ python app.py
The app opens as shown on Fig. A
Cong USB (J2)
Parallel Cong
Header (J9)
Power
Indicator
LEDs
Input Buttons
PMOD0:1 (J4:5)
LoRes Himax
Monochrome
Camera
CY-USB-3013
(U13)
Input SwitchesHyperRAM (U8:9) PMOD2:3 (J6:7)
Indicator
LEDs
JTAG Header (J1)
MIPI DPHY
Expansion
Header (J12)
HiRes Sony
IMX Camera
USB3 Out (J8)
Fig. A

CertusPro-NX Voice and
Vision Machine Learning Board
3Done!
Congratulations! You have successfully demonstrated the Object Detection demo on the
CertusPro-NX Voice and Vision Machine Learning Board. This demo is intended to show
the basic functionality of the kit as shipped. This kit can be reprogrammed and/or connected
to additional hardware to demonstrate a number of solutions. To learn more about these
solutions and download full documentation for this kit, including schematics, visit the Lattice
website at: https://www.latticesemi.com/certuspro-nx-vvml-board.
Development with the Lattice CertusPro-NX FPGA is supported by Lattice Radiant
Software. You can learn more and download the latest version from the Lattice website at
www.latticesemi.com/radiant.
Additional Terms and Conditions Applicable to Lattice Programming and Development Hardware
Lattice device programmers, programming cables, socket adapters, and other hardware sold for use in conjunction with Lattice
software (“Programming Hardware”) and Lattice evaluation boards and development kits sold for use in conjunction with
evaluating Lattice products (“Development Hardware”) are designed and intended for use solely with semiconductor components
manufactured by Lattice Semiconductor Corporation. Programming and Development Hardware is warranted to meet Lattice
specications only for a period of ninety (90) days; in all other respects the terms and conditions of sale of Programming and
Development Hardware shall be Lattice’s standard terms and conditions set forth in Lattice’s Sales Order Acknowledgment.
Additionally, Lattice specications for Programming and Development Hardware limit their use to low-volume engineering
applications only, and not for volume production use. The warranty for Programming and Development Hardware will not apply to
any Programming or Development Hardware used in production, used with worn or improperly installed hardware, or used with
incompatible systems or components.
Technical Support
www.latticesemi.com/support
Copyright © 2021 Lattice Semiconductor Corporation. Lattice Semiconductor, L (stylized) Lattice Semiconductor Corp., Lattice
(design), Lattice Diamond, Radiant and iCE40 are either registered trademarks or trademarks of Lattice Semiconductor
Corporation in the United States and/or other countries. Other product names used in this publication are for identication
purposes only and may be trademarks of their respective companies.
QS063
Nov 2021
Press Play/Pause button to start the video playback. Press it again to pause the video
playback. The video loops until the app is closed or Play/Pause button is pressed.
Press Open Camera button to get the feed from the board’s camera to display in the
app window. If the board is detected, video from the board will be displayed as shown
below. If the board is not detected, it will show a message to check the connection of
the board.
Hold the board in such a way that the camera is facing the video playing on the monitor.
The demo output contains the bounding boxes for detected objects in each frame and
it displays the cumulative count of objects detected on the display.
Fig. B
