Lauda DCS2 User manual

LAUDA DR. R. WOBSER
GMBH & CO. KG
P.O.Box 1251
Germany
97912 Lauda-Königshofen
valid from serie B02
09/03
YAME0017
Phone: (+49) (0)9343/ 503-0
Fax : +49) (0)9343/ 503-222
e-mail info@lauda.de
Internet http://www.lauda.de
Operating instruction
DigiCal Digital Thermometer
DCS 2


DigiCal DCS 2
YAME0017/ 09.10.03 Safety notes 3
Safety notes:
Before operating the equiqment please read carefully all the instructions and safety
notes.
If you have any questions please phone us!
Follow the instructions on setting up, operation etc. This is the only way to avoid
incorrect operation of the equipment and to ensure full warranty protection.
• Transport the equipment with care!
• Equipment and ist internal parts can be damaged:
− by dropping
− by shock.
• Equipment should only be operated by technically qualified personnel!
• Do not start up the equipment if
− it is damaged or leaking
− the supply cable is damaged.
• Switch off the equipment and pull out the mains plug for:
− servicing or repair
− before moving the equipment!
• Have the equipment serviced or repaired by properly qualified personnel only!
The Operating Instructions include additional safety notes which are identified by a
triangle with an exclamation mark. Carefully read the instructions and follow them
accurately! Disregarding the instructions may have serious consequences, such as
damage to the equipment, damage to property or injury to personnel!
We reserve the right to make technical alterations!

DigiCal DCS 2
4 Contents YAME0017/09.10.03
Content
1. Control and functional elements.............................................................................................6
2. Handling / Introduction ............................................................................................................ 8
2.1 General advice................................................................................................................................... 8
2.2 Operation........................................................................................................................................... 8
2.3 Switching on and off........................................................................................................................... 8
2.4 Menu.................................................................................................................................................. 9
2.4.1 Measuring unit switching °C and °F -
Tlhr
............................................................................. 10
2.4.2 Difference temperature –
Khl1
.............................................................................................. 10
2.4.3 Calibration function -
B@K
........................................................................................................ 11
2.4.3.1 Encoded Calibration -
mO0
...............................................................................................12
2.4.3.2 Calibration by physical standard references -
mO1
............................................................13
2.4.3.3 DIN-Ccalibration DIN IEC 60751 - [
mEE
..........................................................................13
2.4.4 Printer port activation / deactivation -
OpDl
............................................................................ 14
2.4.5 Selection / Channel activation -
Bgl
..................................................................................... 15
2.4.6 Analogue output -
c@B
............................................................................................................ 16
2.5 Recalling the memory data (HOLD MAX MIN AVE) .......................................................................... 17
2.6 Measuring rate (FAST-Modus) ......................................................................................................... 17
2.7 AUTO-OFF-Function........................................................................................................................ 17
3. Power supply..........................................................................................................................18
4. Error codes.............................................................................................................................18
5. Technical data ........................................................................................................................ 19
6. RS232 interface protocol....................................................................................................... 20
7. Connector layout.................................................................................................................... 21
7.1 Connector layout Pt100 4-wire.......................................................................................................... 21
7.2 RS232 PC-adapter cable (Connector layout).................................................................................... 21
8. Data of probe-calibration.......................................................................................................22
9. Accessories............................................................................................................................ 23
10. Ordering spares...................................................................................................................... 23

DigiCal DCS 2
YAME0017/ 09.10.03 Explanation of signs 5
Explanation of signs:
Danger: This symbol is used where there may be injury to
personnel through incorrect handling.
☞Note: Here spezial attention is drawn to some aspect. May
include reference to danger.
þ
Reference: Refers to additional information in other sections.

DigiCal DCS 2
6 Control and functional elements YAME0017/09.10.03
1. Control and functional elements
DCS 2 front view
Measuring port for
channel 2 Temperature-Measuring probe
channel 1 (firmly connected)
Control panel (Keys) ON/OFF - switch Righthand
adjustable
base

DigiCal DCS 2
YAME0017/ 09.10.03 Handling / Introduction 7
DCS 2 rear view
Analogue outlput 0-1V
for channel 1 (red=plus) Analogue output 0-1V
for channel 2 (red=plus)
RS 232 Interface
(9 pins) Power
supply input
Temperature measuring probe
channel 1
(firmly connected)

DigiCal DCS 2
8 Handling / Introduction YAME0017/09.10.03
2. Handling / Introduction
2.1 General advice
☞• For cleaning the instrument please do not use abrasive cleaner but a dry or wet piece
of cloth.
• Please store the measuring instrument in a dry and clean place.
• Avoid any force like shocks or pressure to the instrument.
• Do not use force to connect the probe or interface plugs in. The interface plug differs
from the probe.
þ
• If no sensor is connected to the instrument while switching on „
mODl
“ will be
indicated on the display (
þ
chapter 4 Error codes )
2.2 Operation
Please kindly check if the provided mains plug unit is working
properly with your power supply,. The standard equipment is for
230V; 50/60Hz power supply. If your mains supply a different
voltage, you need the universal (all) mains unit (90-260V;
50/60Hz). Please connect first the measuring device with the
suitable mains plug unit (see picture on the back side of the
device) and then connect the mains plug with the mains supply
socket. (
þ
3 Power supply).
The measuring probe 1 is firmly connected to CH 1.
If you would like to connect a second measuring probe: Plug the
second probe into the socket CH 2 of the measuring device. The
connection sockets on the housing are marked accordingly a
CH 2, RS 232 or Analogue Out.
2.3 Switching on and off
By operating the ON/OFF-key the instrument will be switched on or off.
After switching on the instrument indicates a full segment test for 1,5 sec.
Afterwards the instrument shows the calibration-code and the adjusted measurement category for
channel 1 (e.g. [
mEE
for standard distinguishing line and P for Pt100).
In the following the calibration data of the second channel (if available) will be shown.
Fig 1: Example of channel information after switching on:
1
15E4
O
EEDa
Channel-1 calibration based on the calibration code of the probe..

DigiCal DCS 2
YAME0017/ 09.10.03 Handling / Introduction 9
Now the thermometer starts operating in measurement mode indicating the actual measurement
value. All instruments display the measurement value of channel 1 on the top display line (large
display line). Underneath the trending bargraph is shown. The second channel of our 2-channel
instruments would be displayed on the bottom line (small display line).
2.4 Menu
The adjustments of the instruments such as like the temperature unit, calibration of probes,
deactivation of channels and others are resulting from the structure of the menu.
You will reach into the main menu by pressing [ENTER/MENUE]. With the up and down keys
[] you can choose your required menu item.
Push [ESC] to be back in the measuring mode.
up and down keys [ ]
key [ESC]
key [ENTER/MENUE]
Menu structure
Press the key accordingly to pass through the menu in the displayed direction. Using the key it
can be started from the opposite direction at
c@B
.
Tlhr
for channel 1+2
Khl1
B@K
for channel 1+2
OpDl
Bgl
for channel 1+2
c@B
for channel 1+2
9B
T1-T2
mEE
mEE
mEE
c@Ha
9E
mO!
ml
ml
c@HD
mO1

DigiCal DCS 2
10 Handling / Introduction YAME0017/09.10.03
2.4.1 Measuring unit switching °C and °F -
Tlhr
Tlhr
= Measuring unit
Measuring unit temperature (°C=Celsius, °F=Fahrenheit).
To change the measuring unit press [ENTER/MENUE]. Use the up and down keys [ ] to select
Tlhr
. Press again [ENTER/MENUE]. Of the left corner of the display appears a small 1, which
indicates the selected channel. For changing the channel use the up and down keys [ ].
Press [ENTER/MENUE] to confirm. On the right corner of the display appears °
B
or °
E
. Use the up
and down keys [ ] again to adjust the requested measuring unit and press [ENTER/MENUE] to
confirm.
Press [ESC] to get back to the measuring mode.
Display Keys Function
Tlhr
ENTER/MENUE
1
Tlhr
2
Tlhr
up and down keys [ ] select the channel 1 or 2
1
Tlhr
ENTER/MENUE
1
Tlhr
°
B
1
Tlhr
°
E
up and down keys [ ] select the measuring unit [
B
]or [°
E
]
ENTER/MENUE To keep the amended value
ESC To escape without retention
2.4.2 Temperature Difference–
Khl1
To display the difference between the two temperature channels push [ENTER/MENUE]. Use the up
and down keys [ ]to select
Khl1
. Push again [ENTER/MENUE]. On the right corner of the
display appears a T1–T2. Use the up and down keys [ ]to adjust the requested selection.
Push [ENTER/MENUE] to confirm.
Push [ESC] to be back in the measuring mode.
☞Both channel have to be activated for showing the difference temperature.

DigiCal DCS 2
YAME0017/ 09.10.03 Handling / Introduction 11
2.4.3 Calibration function -
B@K
☞Despite high quality manufacturing techniques, each probe is slightly different from
specified standards. To eliminate inaccuracies caused by exchanging or ageing of probes,
the instrument offer easy calibration functions which guarantee that the system accuracy
is always as good as if the instrument was specifically calibrated to the individual probes in
our laboratory.
The instruments offer three calibration options:
• [
mO0
]: LAUDA-factory calibration, encoded calibration with optimum accuracy.
Probe and electronics are being calibrated at the same time. Therefore the
accuracy reaches 0,03°C for temperature range –100°C to +150°C.
This calibration is stored as
mO0
calibration code.
Please note that the accuracy will be 0,05°C in case another probe is connected
that was calibrated without the electronics.
(This probe data can be read as a 2x4 digits code on the handle of the LAUDA
DigiCal probes and results from the 2-point-comparison method
mO0
.
• [
mO1
]: Calibration by physical standard references with the best possible system
accuracy for a user’s calibration (calibration with comparative standards: 1-point,
2-point or 3-point-comparison possible).
• [
mEE
]: Standard characteristic curve with a minimum system accuracy
(e.g. Pt100-resistance according DIN IEC 60751).
B@K
= calibration
Push [ENTER/MENUE] to calibrate the instrument with sensor. Use the up and down keys [ ]
to select
B@K
. Push again [ENTER/MENUE]. On the left corner the display appears a small 1, which
indicates the selected channel. For changing the channel use the up and down keys [ ]. Push
[ENTER/MENUE] to confirm..
Use the up and down keys [ ] to select the requested calibration option.
Display Keys Function
B@K
ENTER/MENUE
1
B@K
2
B@
up and down keys [ ] select the channel 1 or 2
1
B@
ENTER/MENUE
1
B@
mO0
mO1
[
mEE
up and down keys [ ] select the calibration mode
ENTER/MENUE To keep the amended value
ESC To escape without retention

DigiCal DCS 2
12 Handling / Introduction YAME0017/09.10.03
2.4.3.1 Encoded Calibration -
mO0
☞This calibrating function is only needed in case you would add another probe to the
second measuring channel.
Use the up and down keys [ ] to select
mO0
. Press [ENTER/MENUE] to confirm the requested
setting. On the bottom of the display appears a small 1, followed by a four-digit number
(Hex-Code /0..F). The number can be modified with the up key [ ]. For stepping to the next number
use the down key [ ]. If the requested number is complete then press [ENTER/MENUE] to confirm.
Now on the bottom of the display appears a small 2and after this number a second four-digit number
is displayed. For changing the number please follow the manual as before.
Press [ESC] to get back to the measuring mode.
Important!
After confirming
mO0
by pressing [ENTER/MENUE] the function
mO0
(encoded calibration) is
activated, even though you leave the menu by pressing the [ESC] key
Display-indication with active calibration code
mO0
:
The
B@K
–segment and the small 1on the left indicates to the user
that
mO0
is activated.

DigiCal DCS 2
YAME0017/ 09.10.03 Handling / Introduction 13
2.4.3.2 Calibration by physical standard references -
mO1
Use the up and down keys [ ] to select
mO1
. Press [ENTER/MENUE] to confirm. On the bottom
of the display appears
0 O
. To select between a 1-Point [
0 O
], a 2-Point [
1 O
]or 3-Point [
2 O
]-
calibration use the up and down keys [ ].
Example of a 1-Point calibration:
Press [ENTER/MENUE] to confirm. On the display appears
5m
. After the displayed measuring value is
stabile press [ENTER/MENUE]. App. 2 seconds later in the first display line appears
O 0
(measuring
value 1); in the second display line appears
cO
. (standing for decimal point).
Use the up and down keys [ ] to select the number of digits after decimal point:
cS
= two decimal digits
cO-
= one decimal digit (decimal point is jumping one digit to the right)
Press [ENTER/MENUE] to confirm. On the second line of the display appears
Rh
_. Use the up and
down keys [ ]to select the requested sign:
Rh
_ = reference standard shows a negative measuring value (below 0.00C°)
Rh
_
= reference standard shows a positive measuring value (above 0.00C°)
Press [ENTER/MENUE] to confirm. On the second line of the display appears
Ec /
. Use the up and
down keys [ ]to select the requested range:
Ec /
= below 100,00°C
Ec 0
= above 100,00°C
Press [ENTER/MENUE] to confirm. Now the display shows
//-//
. Please enter here the
temperature of your reference. To modify the value use the up key [ ]. For stepping to the next
number use the down key [ ].
If the requested value is complete then press [ENTER/MENUE].
Press [ESC] to get back to the measuring mode.
Important!
A break of the physical calibration
mO1
cannot be done by the [ESC]-button. Switching off the
instrument can only do a break of the physical calibration.
Display-indication with active calibration code
mO1
:
The
B@K
–segment and the small 2on the left indicates to the user
that
mO1
is activated.
2.4.3.3 DIN IEC-Calibration DIN IEC 60751 - [
mEE
Use the up and down keys [ ] to select [
mEE
. Press [ENTER/MENUE] to confirm.
Press [ESC] to be back in the measuring mode.

DigiCal DCS 2
14 Handling / Introduction YAME0017/09.10.03
2.4.4 Printer port activation / deactivation -
OpDl
OpDl
= Printer enable
Press [ENTER/MENUE] to activate or deactivate the printer port. Use the up and down keys [ ]
to select
OpDl
and press [ENTER/MENUE]. Use the up and down keys [ ] to activate
ml
or
deactivate
mEE
the requested adjustment and press [ENTER/MENUE] to confirm.
Press [ESC] to get back to the measuring mode.
Display Keys Function
OpDl
ENTER/MENUE
OpDl
ml
mEE
up and down keys [ ] activation or deactivation
ENTER/MENUE To keep the amended value
ESC To escape without retention

DigiCal DCS 2
YAME0017/ 09.10.03 Handling / Introduction 15
2.4.5 Selection / Channel activation -
Bgl
To activate or deactivate a measuring channel press [ENTER/MENUE]. Use the up and down keys
[] to select
BglK
and press [ENTER/MENUE]. On the left corner of the display appears a
small 1, which indicates the selected channel. For changing the channel use the up and down keys
[]. Press [ENTER/MENUE] to confirm. The second display line shows
ml
for activation or
mEE
for deactivation. Use the up and down keys [ ] again to activate
ml
or deactivate
mEE
the
requested measuring channel and press [ENTER/MENUE] to confirm.
Press [ESC] to get back to the measuring mode.
☞− In case that one channel would not be connected to a probe, the main display would
indicate
mODl
in the relevant line.
− There must be at least one active channel!
Display Keys Function
Bgl
ENTER/MENUE
1
Bgl
2
Bgl
up and down keys [ ] select the channel 1 or 2
1
BglK
ENTER/MENUE
1
Bgl
ml
mEE
up and down keys [ ] activation or deactivation
ENTER/MENUE To keep the amended value
ESC To escape without retention

DigiCal DCS 2
16 Handling / Introduction YAME0017/09.10.03
2.4.6 Analogue output scaling-
c@B
The DCS 2-Measuring instrument contains an analogue output (0-1Volt) for each channel. To get the
optimal resolution and accuracy it is possible to scale the analogue output by limiting the measuring
range.
Press [ENTER/MENUE] to change the measuring range (default_ 0..100). Use the up and down
keys [ ] to select
c@B
. Press [ENTER/MENUE] to confirm.
On the left corner of the display appears a small 1, which indicates the selected channel. For
changing the channel use the up and down keys [ ] .
Press again [ENTER/MENUE] to confirm. On the display appears
c@0a
.
To change between measuring range upper limit and measuring range lower limit use the up and
down keys [ ] .
c@0a
= Lower limit (default 00.00)
c@0D
= Upper limit (default 100.00)
Press [ENTER/MENUE] to confirm. Use the up and down keys [ ] to select the number of
digits after decimal point:
cO-
= two decimal digits
cO -
= one decimal digit (decimal point moves one digit to the right)
Press [ENTER/MENUE] to confirm. On the second line of the display appears
Rh^0
. Use the up
and down keys [ ] to select the requested range:
Rh^
= reference standard shows a negative measuring value (below 0,00C°)
Rh^0
= reference standard shows a positive measuring value (above 0,00C°)
Press [ENTER/MENUE] to confirm. On the second line of the display appears
Ec /
. Use the up
and down keys [ ] to select the requested range:
Ec /
= below 100,00C°
Ec 0
= above 100,00C°
Press [ENTER/MENUE] to confirm. On the display appears
//-//
. For changing the value use
the up key [ ] . For stepping to the next number use the down key [ ]. If the requested value is
complete then press [ENTER/MENUE] to confirm.
Press [ESC] to return to measuring mode.
For changing the upper measuring range please repeat the above procedure.
☞The adjustable measuring range limits are corresponding to the selected
measuring size.
DCS 2-menu Scale Meas. range °C Analogue signal
Lower limit dA1b 00.00 00,00°C 0,00Volt
Upper limit dA1E 10.00 10,00°C 1,000Volt

DigiCal DCS 2
YAME0017/ 09.10.03 Handling / Introduction 17
2.5 Recalling the memory data (HOLD MAX MIN AVE)
After pressing first time the key [HOLD MAX MIN AVE] the actual value will be hold on the top
display line (big display). pressing again the key [HOLD MAX MIN AVE] the saved maximum-,
minimum and average value will be displayed in the bottom display line (small display).
☞• Note for 2-channel instruments: First the MAX-MIN-AVE-values of channel 1 will
be displayed –afterwards the values of the channel 2 will be displayed. Is there
only one probe on a 2-channel instrument we suggest to deactivate the channel
without probe.
(
þ
2.4.5 Selection / Channel activation - Chnl)
• During the recall of the memory data the extremes (MAX MIN) and the average
value (AVE) will not be calculated or carried on.
Clearing the memory (MAX MIN AVE)
Press [CLEAR] key once to erase the stored maximum, minimum and average from memory. On the
display appears
Bp
.
After erasing the memory the instrument automatically switches back to measuring mode indicating
the actual measured value again.
2.6 Measuringrate (FAST-Mode)
Press [FAST/ ] key one to change the measuring rate. Now the measuring rate is app. 4
measurements per second. Press [FAST/ ] key again and the instrument is back in the standard
mode (1 measurement per second).
☞In the fast mode the battery consumption is three times higher than in the standard
mode.
2.7 AUTO-OFF-Function
c@mE
= Disable Auto-off
D@mE
= Enable Auto-off
Press [ESC/AUTO-OFF] key again. On the display appears
c@mE
Now the Auto-Off-function is
deactivated.
Press [ESC/AUTO-OFF] key once. On the display appears
D@mE
Now the instrument switches off
automatically after app. 30 minutes.
☞After switching off and on the instrument, the Auto-Off function is automatically
deactivated.

DigiCal DCS 2
18 Power supply / Error codes YAME0017/09.10.03
3. Power supply
For the power supply of the instrument a 9VDC source is required:
• 230V; 50/60Hz, Ref. No. EBE 042
• 90-260V; 50-60Hz, Ref. No. EBE 043
4. Error codes
By displaying the following error codes the instrument support the operation of the instrument.
Dppmp
Description
mODl
no probe or wrong probe is connected
rmGh
“too high“exceeding of the measuring range
rmKm
“too low“underflow of the measuring range

DigiCal DCS 2
YAME0017/ 09.10.03 Technical data 19
5. Technical data
Type: DigiCal DCS 2
Probe Ports 1 / 2 Pt100
Measuring range -200...+450°C
Accuracy
Pt 100 temperature probe with
manufacturer calibration
-200...–100°C: 0.05°C
-100...+150°C: 0.03°C
+150...+200°C: 0.05°C
>200°C: 0.1%
Resolution -200 bis +200°C with 0.01°C resolution
+200 bis +400°C with 0.1°C resolution
Outputs RS232 Interface (serial Printer can be connected)
2 analogue outputs 0-1 V (11-bit scalable)
Connectors DIN 8-pole
Allowable operating temp. 0°C ... +40°C
Display 2-line LCD
Housing plastic (ABS)
Dimensions 200 x 80 x 200 mm (BxHxL)
Weight 950 g
Power supply Power Supply 230V; 50/60Hz or optional 90-260V; 50/60Hz
DCS 2 Ref. No. LMD 018 (230V)
LMD 919 (90-260V)

DigiCal DCS 2
20 RS 232 interface protocol YAME0017/09.10.03
6. RS232 interface protocol
During the data transmission, the availability via PC of the the tension levels for RTS (=+12V) and
DTR (= -12V) must be assured by a software’s regulation code.
Parameter: Baudrate 2400 Baud
Datenbits 8
Stopbits 2
Parität None
To start the data transmission you have to send the following characters. The following index shows
you which value can be requested over the interface.
DCS 2
Measuring value 1 + 2 autom. recognize FC (hex)
Enabling the keyboard 0 (hex)
☞By sending the command FC(hex) you will get the complete data, the instrument lock
automatically the keyboard. To release the keyboard you have to send the command
0(hex).
The datas would be sent in the following format.
Datentyp = String
he length of the string depends on the instrument (a two-channel or one-channel instrument).
measuring value 1 unit measuring value 2 unit
LF CR
1 2 3 4 5 6
7
8 9 10 11
12
13
14
15
16
17
18
19
20 21 22 23 24 25 26
Example: Turbo Pascal Source-Code for initialisation of the RS232 interface
PROCEDURE V24oeffnen(com1,com2:Boolean); { initialisation of RS 232 }
VAR wert : Byte;
BEGIN
IF com1 THEN BEGIN { initialisation of COM 1 }
PORT [$3FB]:=128; { activate baud rate }
PORT [$3F8]:= 48; { baud rate - LSB, 2400 baud }
PORT [$3F9]:= 0; { baud rate - MSB }
PORT [$3FB]:= 7; { 8 Bits, No Parity, 2 Stop }
PORT [$3FC]:= 2; { DTR = 0, RTS = 1 }
Wert := PORT [$3F8] { receiving register empty }
END;
END
Table of contents
