LAUNCH TECH X-431 Torque User manual

Version: V1.00.000
Revised date: Oct-19-2017
Statement:
All information, specifications and illustrations in this manual are based on the
latest information available at the time of release. LAUNCH reserves the rights
to make changes at any time without notice.

X-431 Torque User Manual
i
Copyright Information
Copyright © 2017 by LAUNCH TECH. CO., LTD. All rights reserved. No part of
this publication may be reproduced, stored in a retrieval system, or transmitted
in any form or by any means, electronic, mechanical, photocopying, recording or
otherwise, without the prior written permission of LAUNCH. The information
contained herein is designed only for the use of this unit. LAUNCH is not
responsible for any use of this information as applied to other units.
Neither LAUNCH nor its affiliates shall be liable to the purchaser of this unit or
third parties for damages, losses, costs, or expenses incurred by purchaser or
third parties as a result of: Accident, misuse, or abuse of this unit, or
unauthorized modifications, repairs, or alterations to this unit, or failure to strictly
comply with LAUNCH operating and maintenance instructions. LAUNCH shall
not be liable for any damages or problems arising from the use of any options or
any consumable products other than those designated as Original LAUNCH
Products or LAUNCH Approved Products by LAUNCH.
Trademark Information
LAUNCH is a registered trademark of LAUNCH TECH CO., LTD. (LAUNCH) in
China and other countries. All other LAUNCH trademarks, service marks,
domain names, logos, and company names referred to in this manual are either
trademarks, registered trademarks, service marks, domain names, logos,
company names of or are otherwise the property of LAUNCH or its affiliates. In
countries where any of the LAUNCH trademarks, service marks, domain names,
logos and company names are not registered, LAUNCH claims other rights
associated with unregistered trademarks, service marks, domain names, logos,
and company names. Other products or company names referred to in this
manual may be trademarks of their respective owners. You may not use any
trademark, service mark, domain name, logo, or company name of LAUNCH or
any third party without permission from the owner of the applicable trademark,
service mark, domain name, logo, or company name. You may contact LAUNCH
by visiting the website at www.cnlaunch.com, or writing to LAUNCH TECH. CO.,
LTD., Launch Industrial Park, North of Wuhe Avenue, Banxuegang, Bantian,
Longgang, Shenzhen, Guangdong, P.R.China, to request written permission to
use Materials on this manual for purposes or for all other questions relating to
this manual.

X-431 Torque User Manual
ii
Important Safety Precautions
Important: To avoid personal injury, property damage, or accidental damage to
the product, read all of the information in this section before using the product.
 Never collide, throw, or puncture X-431 Torque, and avoid falling, extruding
and bending it.
 Do not insert foreign objects into or place heavy objects on your device.
Sensitive components inside might cause damage.
 Do not use X-431 Torque in exceptionally cold or hot, dusty, damp or dry
environments.
 In places using X-431 Torque may cause interference or generate a potential
risk, please turn it off.
 X-431 Torque is a sealed unit. There are no end-user serviceable parts inside.
All internal repairs must be done by an authorized repair facility or qualified
technician. If there is any inquiry, please contact the dealer.
 Never place X-431 Torque into apparatus with strong electromagnetic field.
 Keep X-431 Torque far away from magnetic devices because its radiations
can damage the screen and erase the data stored on X-431 Torque.
 DANGER: Do not attempt to replace the internal rechargeable lithium battery.
Contact the dealer for factory replacement.
 CAUTION: Please use the included battery and charger. Risk of explosion if
the battery is replaced with an incorrect type.
 Do not disconnect power abruptly when X-431 Torque is being formatted or in
process of uploading or downloading. Or else it may result in program error.
 Do not delete unknown files or change the name of files or directories that
were not created by you, otherwise your X-431 Torque software might fail to
work.
 Be aware that accessing network resources can leave your X-431 Torque
vulnerable to computer viruses, hackers, spyware, and other malicious
activities that might damage your device, software or data. It is your
responsibility to ensure that you have adequate protection in the forms of
firewalls, antivirus software, and anti-spyware software and keep such
software up to date.

X-431 Torque User Manual
iii
Precautions on Using X-431 Torque
Before using this test equipment, please read the following safety information
carefully.
 Always perform automotive testing in a safe environment.
 If the diagnostic connector remains unused for a long period of time, it is
suggested to unplug the connector from vehicle’s DLC to conserve battery
power.
 Wear an ANSI-approved eye shield when testing or repairing vehicles.
 The vehicle shall be tested in a well-ventilated work area, as engines produce
various poisonous compounds (hydrocarbon, carbon monoxide, nitrogen
oxides, etc.)
 Do not connect or disconnect any test equipment while the ignition is on or
the engine is running.
 Put blocks in front of the drive wheels and never leave the vehicle unattended
while testing.
 Keep the test equipment dry, clean, free from oil, water or grease. Use a mild
detergent on a clean cloth to clear the outside of the equipment as
necessary.
 Do not drive the vehicle and operate the test equipment at the same time.
Any distraction may cause an accident.
 Keep clothing, hair, hands, tools, test equipment, etc. away from all moving or
hot engine parts.
 Before starting the engine, put the gear lever in the Neutral position (for
manual transmission) or in the Park (for automatic transmission) position to
avoid injury.
 To avoid damaging the test equipment or generating false data, please make
sure the vehicle battery is fully charged and the connection to the vehicle
DLC (Data Link Connector) is clear and secure.
 Automotive batteries contain sulfuric acid that is harmful to skin. In operation,
direct contact with the automotive batteries should be avoided. Keep the
ignition sources away from the battery at all times.
Precautions on Operating Vehicle’s ECU
 Do not disconnect battery or any wiring cables in the vehicle when the ignition
switch is on, as this could avoid damage to the sensors or the ECU.
 Do not place any magnetic objects near the ECU. Disconnect the power
supply to the ECU before performing any welding operations on the vehicle.

X-431 Torque User Manual
iv
 Use extreme caution when performing any operations near the ECU or
sensors. Ground yourself when you disassemble PROM, otherwise ECU and
sensors can be damaged by static electricity.
 When reconnecting the ECU harness connector, be sure it is attached firmly,
otherwise electronic elements, such as ICs inside the ECU, can be damaged.

X-431 Torque User Manual
v
