Launch TS971 User manual

V1.00.000
2018-01-25

LAUNCH TS971 User’s Manual
1
Copyright reserved!
Without written agreement from Launch Tech Co., Ltd (Hereinafter
refer to "LAUNCH"), any company or person is not allowed to copy
and duplicate this user manual in any format (electronic, mechanical,
video, record or other formats).
The user manual is designed only for LAUNCH products. Any
consequence caused by using this user manual to guide other device
operation is not under the responsibility of LAUNCH. All examples in
this user manual are subject to change without notice.
LAUNCH and its branches do not bear any responsibility for the fees
and expenses of the device damage and loss due to personal or third
party accident, misuse and abuse of the device, unauthorized change
and repair, or any operation and maintenance not following LAUNCH
standard.
LAUNCH is not responsible for the device damage or problem due to
the usage of any optional parts or consumables instead of LAUNCH
original products or LAUNCH recognized products.
Formal statement:
Other product names mentioned in this user manual are aimed to
describe the device usage. The registered trademarks still belong to
the original company.

LAUNCH TS971 User’s Manual
2
Registered trademark
LAUNCH has registered its trademark in China and a number of
other countries, logo is LAUNCH. In those countries where LAUNCH
trademark, service mark, domain name, icon and company name are
not yet registered, LAUNCH claims the ownership of unregistered
trademark, service mark, domain name, icon and company name.
Trademarks of the other products and company names mentioned in
this user manual still belong to original registered company. Without
written agreement from the owner, no person is allowed to use the
trademark, service mark, domain name, icon and company name of
LAUNCH or of other mentioned companies. You can visit
http://www.x431.com to learn LAUNCH products; Or visit
http://www.cnlaunch.com or write to Customer Service Center of
LAUNCH TECH CO., LTD at Launch Industrial Park, North of Wuhe
Rd., Banxuegang, Longgang, Shenzhen, P. R. China, to get contact
with LAUNCH for the written agreement on the usage of the User
Manual.
Attentions for ECU Operations
When ignition is on, do not disconnect the vehicle internal electric
device, to avoid damage to the ECU or to the device.
Do not place magnetic objects near the ECU, to avoid failures of
the circuit and components in the ECU.

LAUNCH TS971 User’s Manual
3
Disconnect the ECU system before any welding operation.
Be careful for the operation near the ECU or sensor, to avoid
damage to the ECU and sensor.
Properly connect the ECU harness connector, to avoid damage to
the electronic components inside the ECU, such as the
integrated circuit.
Attentions for Device Usage
This device is a precision electronic instrument. Be sure no impact
during using.
Take the device carefully, to avoid collision.
Turn the ignition to OFF position when insert or remove the OBD
connector.
If the vehicle is not going to be used for a week or more, to ensure
that the battery holds its charge well, it is recommended to
unplug the connector.
In the use of the product, it is not recommended to use
communication functions, such as telephone and SMS, which
may lead to interruption of program data communication. If this
occurs, please operate the related functions again.

LAUNCH TS971 User’s Manual
4
Packing list
USB cable*1
Charger*1
Memory card*1
OBDII cable*1
User Manual*1
Magnet*1(Note: The magnet is only used to activate the tire pressure
sensors equipped by part old vehicle models. When using, please
put the magnet near to the gas nozzle while receiving the signal sent
from the sensor with the device.)
Suitcase*1
Card reader*1
OBD extension cable*1 (optional, LAUNCH part No.: 105022311,
contact LAUNCH and dealers for the purchase)

LAUNCH TS971 User’s Manual
5
Table of Contents
I. Product Overview ..............................................................6
II. TS971 Function Key Guide ..............................................6
III. Product Specification .......................................................7
IV. Features ..........................................................................8
V. Main Menu Function Introduction.....................................9
VI. Charge and Boot .......................................................... 38
VII. Register and Upgrade ................................................. 40

LAUNCH TS971 User’s Manual
6
I. Product Overview
TS971 integrates diagnostic functions of a variety of car models, with
TPMS trouble light reset, sensor ID, battery status, tire pressure and
temperature read, TPMS sensor activation and matching as well. It
better meets the needs of auto repair shop, tire assembly line,
individual owner and tire repair shop to diagnose, activate and match
the TPMS system and the tire pressure sensors.
II. TS971 Function Key Guide

LAUNCH TS971 User’s Manual
7
III. Product Specification
No. Item Range
1 Display screen 4inch TFT screen, resolution
320*480
2 OBD supply voltage 9-18V
3 USB supply voltage 5V
4 Battery Lithium-ion battery, 3100mAh,
3.7V
5 Activate sensor
frequency
125KHz
6 Receive sensor
frequency
315MHz/433MHz
7 Working temperature -10 to 50℃
8 Storage temperature -20 to 70℃
9 Storage humidity 10%~93%
10 Dimension 195x86x32mm
11 Weight <460g
12 Drop It won't be damaged in case of

LAUNCH TS971 User’s Manual
8
falling from 1 meter high.
13 Boot time <5s, time from pressing power
button to the main menu
14 Button response 1 second
15 Working hour A year and a half in power off
state.
5.5 hours in working condition.
IV. Features
Activate the TPMS sensors of most vehicle brands globally with right
protocols;
Read tire pressure, temperature sensor ID and battery level;
Duplicate or generate the new sensor ID after sensor replacement;
Rewrite the sensor position into the ECU after sensor rotation;
Help guide and software update subscription;
Search by make-mode-year;
Tested sensor history query;
Read and clear TPMS fault code.

LAUNCH TS971 User’s Manual
9
V. Main Menu Function Introduction
Boot into the main interface.
There are four sections: TPMS, Latest, Settings, Help.
"TPMS" is the main function of the device, including check sensor,
communicate with ECU via OBD.
"Latest" means the latest test records. Users can fast access the last
test.
"Settings" is to set up the system parameters, such as pressure unit,
temperature unit.
"Help" covers information on diagnostic socket, device, etc.
Switch the options via the four arrow keys .Enter the selected
option by the confirm button .
Battery level is displayed in the upper right corner. Charging .

LAUNCH TS971 User’s Manual
10
Picture 1: Main Interface
Car model selection
After entering TPMS, it is necessary to select the make/model.

LAUNCH TS971 User’s Manual
11

LAUNCH TS971 User’s Manual
12

LAUNCH TS971 User’s Manual
13
Picture 2: Car Model Selection
Use UP&DOWN keys to toggle each option successively. Use
LEFT&RIGHT keys to toggle the options by page.
Select make, model and year followed by function menu.
After car model selection, there are options of "Check Sensor" and
"OBDII".
Check Sensor: Communicate with tire pressure sensor. If check

LAUNCH TS971 User’s Manual
14
succeeded, corresponding ID, pressure and temperature will be
displayed.
OBDII: Use the OBD cable to connect the device with the vehicle
OBD connector. After entry, users can view the sensor ID stored in
the ECU. The sensor ID will be written into the ECU via learning.
Picture 3: Function Options

LAUNCH TS971 User’s Manual
15
Check Sensor

LAUNCH TS971 User’s Manual
16
Picture 4: Check Sensor Interface
Press button to exit.
Press button to trigger the sensor.
Press button to toggle between tires.

LAUNCH TS971 User’s Manual
17
During activation, there are icons like beside the tire,
which indicates it is activating.
Icon beside the tire means deflation is required.
Activation result:
：Activation succeeded.
：Activation failed.
Duplicate: Sensor with repeated ID.
After successful activation, it displays the sensor ID, pressure,
temperature and battery level, etc.
ID: Means the ID of this sensor.
P: Means the measured pressure of this sensor.
T: Means the tested temperature of this sensor.
B: Means the battery level of this sensor.
Notes ：
1. Select the specific vehicle make, model and year correctly.
2. Proper tool positioning is important to insure sensor activation.
Place the tool on the tire, at the TPMS sensor, pointed toward the
sensor location. Do NOT touch the metal rim. The tool needs to point
through the rubber at the sensor.
Tire pressure service data
RELEARN PROCEDURE: Description of the self-learning process.
PART # LOOKUP: Sensor OEM information.
