Lavex 274AFS3BAT User manual

User Manual
PLEASE READ ENTIRE MANUAL BEFORE USE 10/2023
13" 3 Gallon Walk-Behind
Auto Floor Scrubber
#274AFS3BAT
BATTERY-OPERATED

WWW.LAVEX.COM 2
User Manual
Table of Contents
General Safety Rules ....................................................................................................................... 3
Specific Safety Rules ....................................................................................................................... 4
Technical Specifications ................................................................................................................... 5
Installation Instructions ................................................................................................................... 6
Operation & Maintenance ................................................................................................................ 7
Safety Information ......................................................................................................................... 10
Component Structure...................................................................................................................... 11
Wiring Diagram ............................................................................................................................. 12
Brush Assembly Diagram.................................................................................................................. 13

WWW.LAVEX.COM 3
User Manual
General Safety Rules
WARNING: Read all safety warnings and instructions prior to use.
Failure to follow all warnings and instructions may result in electric shock, fire, and/or serious injury.
SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE.
The term “floor scrubber” in the warnings refers to your battery-operated floor scrubber.
1. WORK AREA SAFETY
a. Keep work area clean and well lit during operation.
b. Do not operate floor scrubber in explosive atmospheres, such as in the presence of flammable liquids,
gases, or dust.
c. Keep children and bystanders away while operating a floor scrubber to avoid potential injury.
2. ELECTRICAL SAFETY
a. Avoid body contact with grounded surfaces, such as pipes, radiators, ranges, and refrigerators.
b. Do not expose floor scrubbers to rain or wet conditions. Water entering the floor scrubber will increase the risk of
electric shock.
c. If operating a floor scrubber in a damp location is unavoidable, use a residual current device (RCD) protected
supply. Use of an RCD reduces the risk of electric shock.
3. PERSONAL SAFETY
a. Stay alert, watch what you are doing, and use common sense when operating a floor scrubber. Do not use a floor
scrubber while you are tired or under the influence of drugs, alcohol, or medication.
b. Always use appropriate personal protective equipment. Always wear eye protection. Protective equipment such as
a dust mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions can reduce
personal injuries.
c. Ensure the switch is in the o-position before connecting to power source, picking up, or carrying the tool.
Carrying floor scrubbers with your finger on the power switch may cause accidents.
d. Make sure that you are balanced and stable before operation. Keep proper footing and balance at all times.
This enables better control of the floor scrubber in unexpected situations.
e Dress properly. Do not wear loose clothing or jewelry. Keep your hair, clothing, and gloves away from moving
parts. Loose clothes, jewelry, or long hair can be caught in moving parts.
f. Always stay alert during machine operation. A lack of awareness while in use can cause severe injury.

WWW.LAVEX.COM 4
User Manual
4. FLOOR SCRUBBER USE AND CARE
a. Use the correct floor scrubber for your application. The correct floor scrubber will do the job better and safer at
the rate for which it was designed.
b. Do not use the floor scrubber if the switch does not turn it on and o. Any floor scrubber that cannot be
controlled with the switch is dangerous and must be repaired.
c. Disconnect your floor scrubber from the power source before making any adjustments, changing accessories,
or storing the unit. Such preventive safety measures reduce the risk of starting the floor scrubber accidentally.
d. Store idle floor scrubbers out of the reach of children and do not allow persons unfamiliar with the floor scrubber
or these instructions to operate the floor scrubber.
e. Maintain floor scrubbers and accessories. Check for misalignment or binding of moving parts, breakage of parts,
and any other condition that may aect the floor scrubber’s operation. If damaged, have the floor scrubber
repaired before use. Accidents may be caused by poorly maintained floor scrubbers.
f. Only use the floor scrubber and accessories in accordance with these instructions. Always take into account the
working conditions and the work to be performed. Use of the floor scrubber for unintended functions could result
in hazardous situations.
g. Keep handles and grasping surfaces dry, clean, and free from oil and grease. Slippery handles and grasping
surfaces do not allow for safe handling and control of the tool in unexpected situations.
5. SERVICE
a. Have your floor scrubber serviced by a qualified repair person using only identical replacement parts. This will
ensure that the safety of the floor scrubber is maintained.
Specific Safety Rules
• For your safety, do not turn on your floor scrubber or try to use it until it is completely assembled according to these
instructions, and until you have completely read and understood this user manual.
• Always keep hands out of the path of floor scrubber. Avoid awkward hand positions where a sudden slip could cause your
hand to move into the floor scrubber.
• Make sure there are no nails or foreign objects in the area that is being cleaned.
• Protect your eyes. Always wear safety goggles while machine is in use to avoid potential eye damage.
• Everyday glasses only have impact resistant lenses and ARE NOT safety glasses. For your own protection, make sure your
safety glasses or goggles comply with the ANSI Z87.1 Safety Standard.
• Never use this floor scrubber without the provided GFCI.
• Always verify that the GFCI is working correctly before starting work.
• Replacement of the plug or the power cord shall always be carried out by the manufacturer or a designated
service organization.
• Keep liquid clear of the parts of the scrubber and away from persons in the working area.

WWW.LAVEX.COM 5
User Manual
Technical Specifications
Description Unit Data
Protection Level IPX 3
Operating Voltage V 12
Suction Motor W 220
Suction Vacuum mm / H2O 600
Brush Motor W 250
Brush Speed rpm 140
Solution Tank Capacity Gallon 3.1
Recovery Tank Capacity Gallon 3.4
Squeegee Width inch 18.5
Theoretical Working Eciency sq. ft. / hr 16,000
Brush Diameter inch 14
Cleaning Width inch 13.8
Brush Pressure kg.f 25
Maximum Gradient % 2
Minimum Turning Radius inch 23.6
Machine Dimension inch 16.5 x 16.1 x 35.4

WWW.LAVEX.COM 6
User Manual
Installation Instructions
ASSEMBLING THE SQUEEGEE
• Use two star nuts to attach squeegee assembly to revolving shaft.
ASSEMBLING THE BRUSH / PAD DRIVER
• Make sure that the scrubber is turned o.
• Adjust the handle to the full upright position.
• Lay machine on the floor with the bottom of the scrubber exposed.
• Align clutch plate with brush / pad driver and rotate 30 degrees to the left.
• To remove, rotate 30 degrees to the right.
ASSEMBLING THE BATTERY
• Connect external battery connector labeled "Charger Connection"
to the battery connector mounted to the scrubber.
Squeegee Lever
Fig. 2Fig. 1
Squeegee Assembly
Star Nut
Revolving Shaft
Star Nut
Three-blade
Plate
Rotate 30° to the left Rotate 30° to the right
Fig. 4Fig. 3

WWW.LAVEX.COM 7
User Manual
Operation & Maintenance
WARNING: Be sure to read and understand this manual in its entirety before operation.
Failure to do so may result in damage or injury.
PROPER SETUP AND PREPARATION
Ensure that all components are assembled tightly and secured, and that power source matches voltage of your unit.
WARNING: Do not operate this unit near flammable or combustible objects.
For Scrubbing or Polishing:
OPERATION
• Insert machine key and turn.
• Press the power button on the scrubber.
• Press the water button to activate the dispensing pump.
• Press the vacuum switch to activate the vacuum.
• Push squeegee lever down till squeegee is contacting the floor.
• Hold both brush motor switches in the handle to activate the motor.
• Walk slowly when cleaning and pay attention to potential obstacles.
Solution Tank
• Check that the brush / pad driver is properly attached to the scrubber.
• Confirm that the squeegee assembly is properly attached and moving freely with the scrubber.
PREPARATION
• Remove debris and any obstructions from cleaning surface before operation.
• Adjust handle to a comfortable position.
• Both hands should always be on the unit when in use.
• Fill solution tank with water or diluted detergent with a maximum temperature of 122°F.
• To extend machine life, use detergents with a neutral pH and low foam.

WWW.LAVEX.COM 8
User Manual
TO EMPTY WASTE WATER TANK
• Remove vacuum and drain hose from recovery tank housing.
• Lift waste water tank from scrubber frame.
• Pour waste water tank contents into appropriate sink or drain.
• Rinse waster water tank with clean water.
• Allow waste water tank to air dry.
• Place tank back on scrubber.
• Fasten vacuum hose and drain hose lids to waste water tank.
TO CHARGE THE BATTERY
• Plug included charging unit into appropriate 120 volt outlet.
• Plug the other end of the charging unit into the machine charging connection marked "Charging Connection".
A. Press the switches
manually
B. Operate the squeegee
lever manually
Squeegee
Lever
C. Hold the brush
motor switch

WWW.LAVEX.COM 9
User Manual
MAINTENANCE
To control the amount of water dispensed by the machine:
• Adjust water dispensing by using the ball valve on the front of the machine above the brush assembly.
To replace or rotate squeegee:
• Rotate star nuts counterclockwise to remove assembly from shaft.
• Remove seven hexagon screws to take out the front squeegee and metal retaining strip.
• Release squeegee clasp to loosen the rear squeegee assembly.
• Remove the rear squeegee.
• Check wear of squeegee and replace if needed. Squeegees have four sides and can be rotated before replacing.
Water Pipe Ball Valve
Star Nut
Retaining Metal
Strip Assembly
Front Squeegee
Front Retaining
Metal Strip Assembly
Rear Retaining
Metal Strip Assembly
Rear Squeegee
Squeegee Clasp
Star Nut
Hexagon
Socket
Screw
Quick Connector

WWW.LAVEX.COM 10
User Manual
Safety Information
Failure to follow the instructions below could lead to damage or personal injury.
1. This unit is for commercial janitorial use only, you must be trained before operating unit.
2. Do not operate unit unless it is completely assembled, and you have ensured that every component is
secured tightly.
3. Ensure that the unit is dry before performing maintenance or repairs.
4. Ensure that the unit is kept dry at all times during operation. Store unit in a dry area, and only perform cleaning with
a dry cloth.
5. Do not use unit near flammable objects, liquids, or vapors. Do not use flammable compounds to clean the unit.
6. Maintenance is to be performed by qualified professionals only.

WWW.LAVEX.COM 11
User Manual
Component Structure
(Brush Motor)
Overload Protector
(Vacuum Motor)
Overload Protector
Ball Valve Switch
Guided Pipe
Brush Motor Switch
Handle Adjustment Switch
Control Panel
Vacuum Hose
Suction Hose
Squeegee Lever
Recovery Tank Lid
Float Net
Recovery Tank
Handle Adjustment Assembly
Solenoid Valve
Solution Tank Frame
Suction Motor
Solution Tank
Solution Tank Lid
Battery Cover
Circuit Board
Brush Motor
Wheel
Brush Cover
Brush
Squeegee Assembly
1
1
6
6
11
11
16
16
2
2
7
7
12
12
12
17
17
3
3
8
8
13
13
13
18
18
18
21
21
21
4
4
9
9
14
14
19
19
22
22
22 5
5
10
10
15
15
20
20
23

WWW.LAVEX.COM 12
User Manual
Wiring Diagram
Charger
(Optional)
Battery
(Optional)
Brush Motor Vacuum Motor Solenoid Valve
Sprinkling Switch
PCB
PCB
ON/OFF Switch
Suction Switch
Brown
GND BAT

WWW.LAVEX.COM 13
User Manual
Brush Assembly Diagram
Brush Motor
1
2Brush Motor Plate
3
4
5
Brush Holder
Pulley
Strap
6
7
Protective Cover
Brush
