Lavex 944BJ1235G User manual

INSTRUCTION
MANUAL
WET/DRY VACUUM CLEANER
#944BJ1235G
READ ENTIRE MANUAL BEFORE USE
Lavex Janitorial • 2205 Old Philadelphia Pike • Lancaster, PA 17602
06/2020

INSTRUCTION MANUAL  2
PRODUCT FEATURES
1) Easily cleans both wet and dry messes
2) Slots on base provide convenient item storage
3) Drain on bottom of unit allows for easy water drainage
PART DESCRIPTIONS
HANDLE
SWITCH
BARREL
CAP
TOP COVER
TANK LOCK
CORD
& PLUG
TANK
BASE
AIR INLET
MOUTH
WHEELS

INSTRUCTION MANUAL  3
PART DESCRIPTIONS
HOSE ASSEMBLY WANDS
HARD FLOOR
BRUSH
CREVICE
NOZZLE
ROUND
BRUSH
FILTER
Use the right accessories for the right situation:
Round brush for
bookshelves, tables,
and windows, etc.
Crevice nozzle
for crevices, and
corners etc.
Hard floor brush
is best for floors
and carpets

INSTRUCTION MANUAL  4
SAFETY INSTRUCTIONS
1) Ensure that power supply is
the same as rated values
on label.
2) Do not use around
combustible substances
to avoid fire hazards.
3) Ensure that air inlet is not
clogged in order to avoid
motor damage.
4) This unit is not designed to
collect combustible or
explosive objects in order to
avoid fire and safety hazards -
cigarettes, gasoline,
flammable chemicals, etc.
5) This unit is not designed to
collect sharp objects - Do not
vacuum nails, screws, etc.
6) Do not use on fine powders
which can attach to the filter
and cause blockages, such as
calcium carbonate or
graphite-based substances.
7) The unit should always remain
upright while in operation to
avoid motor damage.
8) Warning: In case of water
flowing from air outlet, do not
tip the unit over and keep water
away from the motor to
avoid damage.
9) Turn o the machine and
remove the plug each time after
using or when being repaired.
10) Keep unit away from high
temperatures and harsh
sunlight for prolonged periods
to avoid warping or distortion
of the plastic.
11) Do not walk on or pull unit
by vacuum hose in order to
avoid damage.
12) Keep top of unit away from
water, and do not wash with
water, in order to avoid
motor damage.
13) If damaged, the power cord
must only be replaced by a
certified repair center.
14) Remove filter when
absorbing large amounts of
water to avoid any potential
safety valve malfunctions.

INSTRUCTION MANUAL  5
OPERATION METHOD
1) Insert hose connector into inlet mouth as pictured below,
and ensure that the connector is fastened tightly.
2) Press the connector button as picture shows and pull the
connector out when you want to pull hose
connector from this machine.
3) Insert hose connector into the blowing mouth, as picture
shows, when you want to use its blowing function.
4) Accessories can be connected
to unit as shown
1) Ensure that the unit is plugged into a power outlet.
2) Turn power switch to ‘on’ position.
‘I’ is the on position, ‘O’ is the o position.
3) Adjust the airflow using the sliding switch.
HOSE CONNECTION
OPERATION

INSTRUCTION MANUAL  6
Item # Wattage Voltage
944BJ1235G 1200W 100-120V
PROTECTIVE DEVICE INSTRUCTIONS
Special instructions concerning protective device
1) Protective device begins to work when water tank is full. Suction will be turned o, and an
indication sound will occur. If this happens, electricity should be cut o, and water should
be drained. After water is drained, the unit will return to normal operation.
2) Ensure that power is turned o and vacuum head is removed before tipping over unit
to empty.
3) While the protective device is engaged, do not turn the power on for any reason.
This may cause motor damage and fire. Ensure that water is removed from the unit before
resuming use.
MAINTENANCE
TANK CLEANING PROCESS
When tank is full, ensure that unit is turned o and unplugged before emptying and cleaning tank.
1) Unfasten the locking knob and lift up the top cover.
2) Take o the filter bag and clean the dust from the dust barrel.
3) Install the filter bag back and place the top cover.
FILTER BAG CLEANING
Run warm water through filter to remove remaining dust and debris.
Dry filter before placing back in unit.
1) Take o filter.
2) Wash.
3) Dry.
TECHNICAL DATA
