LawnMaster BL805E 1201 User manual

Operator′s Manual
2 Speed - 8 Amp Electric Blower BL805E 1201
EN p. 2
CAUTION: To reduce the risk of injury, the user must read and understand the operator's manual before
using this product.

2 ― English
TABLE OF CONTENTS /TABLA DE CONTENIDOS
INTRODUCTION / INTRODUCCIÓN
This tool has many features for making its use more pleasant and enjoyable. Safety, performance, and
dependability have been given top priority in the design of this product making it easy to maintain and operate.
* * *
Esta herramienta tiene muchas funciones para hacerla más agradable y cómoda de usar. Se ha dado máxima
prioridad a la seguridad, rendimiento y confiabilidad en las etapas de diseño de este producto para que sea fácil
de utilizar y mantener.
ENGLISH
■ Introduction.................................................................................................................................... 2
■ Important safety instructions ....................................................................................................... 3-4
■ Specic safety rules ...................................................................................................................... 5
■ Symbols ........................................................................................................................................ 6
■ Features ........................................................................................................................................ 7
■ Electrical information ..................................................................................................................... 8
■ Assembly ....................................................................................................................................... 9
■ Operation ..................................................................................................................................... 10
■ Care and maintenance ................................................................................................................ 11
■ Troubleshooting ........................................................................................................................... 11
■ Warranty ...................................................................................................................................... 12
■ Illustrated parts list ................................................................................................................. 13-14

3 ― English
IMPORTANT SAFETY INSTRUCTIONS
WARNING!
TO REDUCE THE RISK OF FIRE,
ELECTRIC SHOCK OR INJURY:
■ Do not operate power tools in explosive
environments (such as in the presence of
ammable liquids, gases, or dust), or use to
pick up ammable or combustible liquids,
Power tools create sparks which may ignite
the dust or fumes.
■ To reduce the risk of electric shock, this
tool has a polarized plug ( one blade is wider
than the other ) and will require the use of a
polarized extension cord. The plug will t into
a polarized extension cord only one way. If
the plug does not t fully into the extension
cord, reverse the plug. If the plug still does
not t, obtain a correct polarized extension
cord. A polarized extension cord will require
the use of a polarized wall outlet. This plug
will t into the polarized wall outlet only one
way. If the plug does not t fully into the wall
outlet, reverse the plug. If the plug still does
not t, contact a qualied electrician to install
the proper wall outlet. Do not change the
equipment plug, extension cord receptacle,
or extension cord plug in any way.
■ Avoid body contact with grounded surfaces
such as pipes, radiators, ranges, and
refrigerators. There is an increased risk of
electric shock if your body is grounded.
■ Don’t expose power tools to rain or wet
conditions. Water entering a power tool will
increase the risk of electric shock.
■ Do not handle plug or tool with wet hands.
■ Use outdoor extension cords marked W-A,
W, SW-A, SOW-A, STW-A, STOW-A, SJW-A,
SJTW-A, or SJTOW-A. These cords are
rated for outdoor use and reduce the risk of
electric shock.
WARNING!
READ AND UNDERSTAND ALL
INSTRUCTIONS. Failure to follow all
instructions listed below may result in electric
shock, re, and/or serious personal injury.
■ Never allow children to operate the
equipment. Never allow adults to operate the
equipment without proper instruction.
■ Wear eye protection with side shields which
is marked to comply with ANSI Z87.1 as well
as hearing protection when operating this
product.
■ Always use face or dust mask if operation
is dusty.
■ Use extra care when cleaning on stairs.
■ Do not leave appliance plugged in. Unplug
from outlet when not in use and before
servicing.
■ Do not expose to rain, store indoors.
■ Use only as described in this manual.
Use only manufacturer’s recommended
attachments.
■ Keep hair, loose clothing, ngers and all
body parts away from openings and moving
parts.
■ Wear heavy long pants, long sleeves,
boots, and gloves. Avoid loose garments or
jewelry that could get caught in moving parts
of the machine or its motor.
■ Do not force tool. Use the correct tool for
your application. The correct tool will do the
job better and safer at the rate for which it is
designed.
■ Do not operate the equipment while
barefoot or when wearing sandals or similar
lightweight footwear. Wear protective
footwear that will protect your feet and
improve your footing on slippery surfaces.
■ Do not use on steps, a ladder, roof top,
tree, or other unstable support. Stable footing
on a solid surface enables better control of
the blower in unexpected situations.
■ Secure long hair so it is above shoulder
level to prevent entanglement in any moving
parts.
■ Keep rm footing and balance. Do not
overreach. Overreaching can result in loss of
balance.

4 ― English
■ Turn off all controls before unplugging.
■ Do not allow to be used as a toy. Close
attention is necessary when used by or near
children.
■ Avoid accidental starting. Be sure the power
switch is not on before plugging in. Turn off
power switch before unplugging.
■ Do not use tool if switch does not turn it
on or off. Any tool that cannot be controlled
with the switch is dangerous and must be
repaired.
■ Do not use with damaged plug. If tool is not
working as it should or has been dropped,
damaged, left outdoors, or dropped into
water, take it to a qualied service dealer for
inspection and possible repair.
■ Do not leave the tool when plugged in.
Unplug from the power outlet when not in use,
before servicing, and before storing the tool.
Such preventative safety measures reduce
the risk of starting the tool accidentally.
■ Keep all bystanders, children, and pets at
least 50 ft. away.
■ Do not operate this unit when you are tired,
ill, upset or under the inuence of alcohol,
drugs, or medication.
■ Do not operate in poor lighting.
■ Keep all parts of your body away from any
moving parts and all hot surfaces of the unit.
■ Do not put any object into openings. Do not
use with any opening blocked; keep openings
free of dust, lint, hair, and anything that may
reduce air ow.
■ Check the work area before each use.
Remove all objects such as rocks, broken
glass, nails, wire, or string which can be
thrown or become entangled in the machine.
■ Never use blower near res, replaces, hot
ashes, barbecue pits, etc., which may cause
re to spread.
■ Do not pull or carry by cord, use cord as a
handle, close a door on a cord, or pull cord
around sharp edges or corners. Do not run
appliance over cord. Keep cord away from
heated surfaces.
■ Do not unplug by pulling on cord. To
unplug, grasp the plug, not the cord.
■ Do not handle plug or appliance with wet
hands.
■ Use only identical manufacturer’s
replacement parts and accessories. Use of
any other parts may create a hazard or cause
product damage.
■ In a double insulated appliance, two
systems of insulation are provided instead
of grounding. No grounding means is
provided on a double insulated appliance,
nor should a means for grounding be
added to the appliance. Servicing a double
insulated appliance requires extreme care
and knowledge of the system and should
be done only by qualied service personnel.
Replacement parts for a double insulated
appliance must be identical to the parts they
replace.
■ For household use only.
IMPORTANT SAFETY INSTRUCTIONS

5 ― English
■ Make sure your extension cord is in good
condition. When using an extension cord, be
sure to use one heavy enough to carry the
current your product will draw. A wire gauge
size (A.W.G.) of at least 14 is recommended
for an extension cord 50 feet or less in length.
If in doubt, use the next heavier gauge. The
smaller the gauge number, the heavier the
cord. An undersized cord will cause a drop
in line voltage resulting in loss of power and
overheating.
■ Do not point the blower nozzle in the
direction of people or pets.
■ Never place blower on any surface, except
a hard, clean surface when motor is running.
Gravel, sand, and other debris can be picked
up by the air inlet and thrown at the operator
or bystanders, causing possible serious
injuries.
■ Never run the unit without the proper
equipment attached. Always ensure the
blower tubes are installed.
■ When not in use, blower should be stored
indoors in a dry, locked up place—out of the
reach of children.
■ Maintain tool with care. Keep fan area
clean for best and safest performance. Follow
instructions for proper maintenance.
SPECIFIC SAFETY RULES
■ Do not attempt to clear clogs from tool
without rst unplugging it.
■ Do not pull or carry by cord, use cord as
a handle, or pull cord around sharp edges
or corners. Keep cord away from heated
surfaces.
■ Do not unplug by pulling on cord. To
unplug, grasp the plug, not the cord.
■ To reduce the risk of electrical shock, do not
expose to rain, do not use on wet surfaces.
Store indoors.
■ If the power supply cord is damaged, stop
using the unit.Take the unit to a qualied
service dealer for inspection and possible
repair.
■ Protect your lungs. Wear a face or dust
mask if the operation is dusty. Following this
rule will reduce the risk of serious personal
injury.
■ Save these
instructions.
Refer to them frequently and use them to
instruct others who may use this power tool.
If you loan someone this power tool, loan
them these instructions also.

6 ― English
Safety AlertIndicates a potential personal injury hazard.
Read The Operator’s Manual To reduce the risk of injury, user must read and understand
operator’s manual before using this product.
Eye and Hearing Protection Always wear eye protection with side shields marked to comply
with ANSI Z87.1, along with hearing protection.
Wet Conditions Alert Do not expose to rain or use in damp locations.
Keep Bystanders Away Keep all bystanders at least 50 ft. away.
Long Hair Failure to keep long hair away from the air inlet could result in
personal injury
.
Blower Tubes Do not operate without tubes in place.
Loose Clothing Failure to keep loose clothing from being drawn into air intake
could result in personal injury
V
A
Hz
W
min
Volts Voltage
Amperes Current
Hertz Frequency (cycles per second)
Watt Power
Minutes Time
Alternating Current Type of current
Direct Current Type or a characteristic of current
Class II Construction Double-insulated construction
SYMBOLS
MEANING
DANGER:
The following signal words and meanings are intended to explain the levels of risk associated with this product.
SYMBOL SIGNAL
WARNING
CAUTION:
CAUTION:
Indicates an imminently hazardous situation, which, if not avoided, will result
in death or serious injury.
Indicates a potentially hazardous situation, which, if not avoided, could result
in death or serious injury.
Indicates a potentially hazardous situation, which, if not avoided, may result in
minor or moderate injury.
(Without Safety Alert Symbol) Indicates a situation that may result in property
damage.
Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper
interpretation of these symbols will allow you to operate the product better and safer.
SYMBOL NAME DESIGNATION/EXPLANATION
.

7 ― English
FEATURES
KNOW YOUR BLOWER
This product has many features for making its use
more pleasant and enjoyable. Safety, performance, and
dependability have been given top priority in the design
of this product making it easy to maintain and operate.
The safe use of this product requires an understanding
of the information on the tool and in this operator’s
manual as well as a knowledge of the project you
are attempting. Before use of this product, familiarize
yourself with all operating features and safety rules.
BLOWER TUBE
The blower tube can be easily installed on the blower
without any additional tools.
CORD RETAINER
A convenient cord retainer helps keep the extension
cord connection secure during blower operation.
TWO SPEEDS
This Blower is designed with two speeds to assist in
varying jobs.
PRODUCT SPECIFICATIONS
Voltage.................................................................................................................................................. 120V~ 60Hz
Amp ..................................................................................................................................................................... 8 A
Air Speed .................................................................................................. Low = 125 MPH / High = 160 MPH Max
Air Volume ................................................................................................. Low = 145 CFM / High = 180 CFM Max
Weight .............................................................................................................................................. 1.7 kg (3.8 lbs)

8 ― English
ELECTRICAL INFORMATION
DOUBLE
INSULATION
Double insulation is a concept in safety in electric
power tools, which eliminates the need for the usual
threewire grounded power cord. All exposed metal parts
are isolated from the internal metal motor components
with protecting insulation. Double insulated tools do not
need to be grounded.
ELECTRICAL CONNECTION
This product has a precision-built electric motor. It
should be connected to a power supply that is 120
volts, AC only (normal household current), 60 Hz.
NOTE: Servicing of a product with double insulation
requires extreme care and knowledge of the system
and should be performed only by a qualied service
technician. Take the unit to a qualied service dealer
for inspection and possible repair using only identical
replacement parts.
Make sure your extension cord is properly wired and
in good electrical condition.Always replace a damaged
extension cord or have it repaired by a qualied person
before use.
Keep extension cords away from sharp
objects,excessive heat and damp or wet areas.
Use a separate electrical circuit for your tools. This
circuit should comprise a wire of at least 12 gauge and
should be protected with a 15 A time-delayed fuse.
Before connecting the motor to the power line, make
sure the switch is in the OFF position and the electric
current is identical to that stamped on the motor
nameplate. Running at a lower voltage will damage the
motor.
Do not operate this product on direct current (DC).
A substantial voltage drop will cause a loss of power
and the motor will overheat. If your product does not
operate when plugged into an outlet, double-check the
power supply.
GFCI
Ground Fault Circuit Interrupter (GFCI) protection
should be provided on the circuit(s) or outlet(s) to be
used for the product.Receptacles are available having
built-in GFCI protection and may be used for this
measure of safety.
GUIDELINES FOR USING EXTENSION CORDS
USE THE PROPER EXTENSION CORD. Make sure
your extension cord is in good condition. When using
an extension cord, be sure to use one heavy enough to
carry the current your product will draw. An undersized
cord will cause overheating. The table below shows
the correct size to use depending on cord length and
nameplate ampere rating. If in doubt, use the next
heavier gauge. The smaller the gauge number, the
heavier the cord.
WARNING! The double insulated system is
intended to protect the user from shock resulting from
a break in the tool’s internal insulation. Observe all
normal safety precautions to avoid electrical shock.
WARNING! ALTHOUGH THIS TOOL IS
DOUBLE INSULATED, THE EXTENSION CORD AND
RECEPTACLE MUST STILL BE GROUNDED WHILE
IN USE TO PROTECT THE OPERATOR FROM
ELECTRICAL SHOCK.
WARNING! Check extension cords before
each use. If damaged replace immediately.
Never use product with a damaged cord since touching
the damaged area could cause electrical shock
resulting in serious injury.
Minimum Gauge for Extension Cords (AWG)
(when using 120V only)
Ampere Rating Total Length of Cord in Feet (meters)
More Than Not More Than 25' (7.6 m) 50' (15.2 m) 100' (30.4 m) 150' (45.7 m)
0 6 18 16 16 14
6 10 18 16 14 12
10 12 16 16 14 12
12 16 14 12 Not recommended

9 ― English
ASSEMBLY
UNPACKING
This product requires assembly.
■ Carefully remove the product and any accessories
from the box. Make sure that all items listed in the
packing list are included.
■ Inspect the product carefully to make sure no
breakage or damage occurred during shipping.
■ Do not discard the packing material until you have
carefully inspected and satisfactorily operated the
product.
■ If any parts are damaged or missing, do not operate
the blower. Return it for replacement to the retailer from
which it was purchased.
PACKING LIST
Blower
Blower Tube
Operator’s Manual
WARNING! Do not use this product if any
parts on the Packing List are already assembled to
your product when you unpack it. Parts on this list are
not assembled to the product by the manufacturer and
require customer installation. Use of a product that
may have been improperly assembled could result in
serious personal injury.
WARNING! If any parts are damaged or
missing do not operate this product until the parts are
replaced. Use of this product with damaged or missing
parts could result in serious personal injury.
WARNING! Do not attempt to modify this
product or create accessories not recommended
for use with this product. Any such alteration or
modication is misuse and could result in a hazardous
condition leading to possible serious personal injury.
ASSEMBLING THE BLOWER TUBE
See Figure 2.
Slide blower tube forward until the lock button clicks
into the top of the tube.
WARNING! Do not connect to power supply
until assembly is complete. Failure to comply could
result in accidental starting and possible serious
personal injury.

10 ― English
OPERATION
APPLICATIONS
You may use this product for the purposes listed below:
■ Clearing leaves and other yard debris from your lawn
■ Keeping decks, patios, garages and driveways free
from leaves, pine needles and other debris
STARTING/STOPPING THE BLOWER
See Figure 3-4.
■ Attach the outlet end of an extension cord to the plug
on the rear of the blower.
NOTE: Use only an approved outdoor extension cord
as described previously in this manual.
■ Route the extension cord through the side of the loop
located on the rear of the blower housing and place
underneath the cord retainer.
■ To start the blower, place the power switch in the I
position (If more power is desired, push power button
forward to second position(II) for more power).
■ To stop the blower, place the power switch in the OFF
position.
■ Use low speed for jobs requiring better control and
less air ow.
■ High speed best suitable for jobs requiring more air
speed and volume.
OPERATING THE BLOWER
See Figure 5.
■ To keep from scattering debris, blow around the outer
edges of a debris pile. Never blow directly into the
center of a pile.
■ To reduce sound levels, limit the number of pieces of
equipment used at any one time.
■ Use rakes and brooms to loosen debris before
blowing. In dusty conditions, slightly dampen surfaces
when water is available.
■ Watch out for children, pets, open windows, or freshly
washed cars, and blow debris safely away.
■ Hold the blower with the handle in your right hand.
(Proper operating position is shown in gure 5.)
■ Operate power equipment at reasonable hours only
— not early in the morning or late at night when people
might be disturbed. Comply with the times listed in local
ordinances.
■ After using blowers or other equipment, CLEAN UP!
Dispose of debris properly.
WARNING! Do not allow familiarity with
products to make you careless. Remember that a
careless fraction of a second is sufcient to inict
serious injury.
WARNING! Always wear eye protection with
side shields marked to comply with ANSI Z87.1, along
with hearing protection. Failure to do so could result
in objects being thrown into your eyes, resulting in
possible serious injury.
WARNING! Do not use any attachments or
accessories not recommended by the manufacturer of
this product. The use of attachments or accessories not
recommended can result in serious personal injury.

11 ― English
CARE AND MAINTENANCE
TROUBLESHOOTING
GENERAL MAINTENANCE
Avoid using solvents when cleaning plastic parts. Most
plastics are susceptible to damage from various
types of commercial solvents and may be damaged by
their use. Use clean cloths to remove dirt, dust, oil,
grease, etc.
WARNING! When servicing, use only
identical replacement parts. Use of any other parts may
create a hazard or cause product damage.
WARNING! Always wear eye protection with
side shields marked to comply with ANSI Z87.1, along
with hearing protection. Failure to do so could result in
objects being thrown into your eyes, resulting in
possible serious injury.
WARNING! Before inspecting, cleaning or
servicing the machine, unplug the power cord and
wait for all moving parts to stop. Failure to follow these
instructions can result in serious personal injury or
property damage.
STORAGE (1 MONTH OR LONGER)
■ Clean all foreign materials from the blower.
■ Store indoors in a place that is out of reach of
children. Keep away from corrosive agents such as
garden chemicals and de-icing salts.
WARNING! Do not at any time let brake
uids, gasoline, petroleum-based products, penetrating
oils, etc., come in contact with plastic parts. Chemicals
can damage, weaken or destroy plastic, which may
result in serious personal injury.
PROBLEM
Motor fails to start when switch is
turned on.
Power cord is not plugged in or
connection is loose.
Household circuit breaker is tripped.
Plug in the power cord.
Check circuit breaker.
CAUSE REMEDY

12 ― English
WARRANTY
We take pride in producing a high quality, durable product. This Lawnmaster® product carries a
limited two (2) year warranty against defects in workmanship and materials from date of purchase
under normal household use. If product is to be used for commercial, industrial or rental use, a 30
day limited warranty will apply. Warranty does not apply to defects due to direct or indirect abuse,
negligence, misuse, accidents, repairs, or alterations and lack of maintenance.
Please keep your receipt/packing list as proof of purchase. This warranty gives you specic legal
rights, and you may have other rights, which vary from state to state. For product service call
Customer Service at [phone].
Items not covered by warranty :
1. Any part that has become inoperative due to misuse, commercial use, abuse, neglect, accident,
improper maintenance, or alteration;
2. The unit, if it has not been operated and/or maintained in accordance with the owner's manual;
3. Normal wear, except as noted below;
4. Routine maintenance items such as lubricants, blade sharpening;
5. Normal deterioration of the exterior nish due to use or exposure.
Transportation Chargers: Transportation chargers for the movement of any power equipment unit or
attachment are the responsibility of the purchaser. It is the purchaser’s responsibility to pay
transportation charges for any part submitted for replacement under this warranty unless such
return is requested in writing by LawnMaster.
SAVE YOUR RECEIPTS. THIS WARRANTY IS VOID WITHOUT THEM.

13 ― English
2 Speed - 8 Amp Blower – MODEL NUMBER BL805E 1201
The model number will be found on a label attached to the motor housing.

14 ― English
ITEM NO. PART NO. DESCRIPTION QTY
1 131009101 Motor Housing Assembly 1
2 131009102 Power Cord Assembly 1
3 131009103 Push Button 1
4 131009104 Impeller Assembly 1
5 131009105 Blower Tube 1
2 Speed - 8 Amp Blower – MODEL NUMBER BL805E 1201
The model number will be found on a label attached to the motor housing.

i
See this section for all of the gures referenced in the
operator’s manual.
Consulte esta sección para ver todas las guras mencionadas en el
manual del usuario.
A - ON/OFF switch(Interruptor de Encendido/Apagado)
B - Blower tube(Tubo de la sopladora)
C - Cord retainer(Enganche para el cable)
D - Plug(Enchufe)
Fig. 1
Fig. 2
A - Air outlet(Salida de aire)
B - Lock button(Botón de bloqueo)
C - Blower tube(Tubo de la sopladora)
B
A
C
D
A
C
B

ii
Fig. 3
Fig. 4 Fig. 5
A - Cord retainer(Enganche para el cable)
B - Loop(Collar)
C - Plug(Enchufe)
D - Extension cord(Cable alargador)
Off(Apagado)
Low Speed
(Velocidad baja)
High Speed
(Velocidad alta)
C
D
B
A
