LD LDMAUI28MIX User manual

USER´S MANUAL
BEDIENUNGSANLEITUNG
MANUEL D`UTILISATION
MANUAL DE USUARIO
INSTRUKCJA OBSŁUGI
MANUALE D‘ USO
ALL IN ONE ARRAY SYSTEM
WITH 3-CHANNEL MIXER
LDMAUI28MIX

Introduction
The MIX version is the especially versatile variant of the MAUI28: expanded connection and control capabilities
make this compact PA-System the ideal all-round solution for solo entertainers, DJs, and presentations; the
elegant look is also suitable for permanent use in sophisticated surroundings.
An XLR-jack combo socket serves as the microphone input. The high-impedance jack input for instruments such
as a guitar, or the mini-jack for connecting MP3 players are activated with a slide switch. For mixers, computer,
and other line-level signal sources, e.g., keyboards, the LD MAUI28MIX system has RCA and combo sockets.
Of course, the various input channels can be used simultaneously. The channel volumes, master volume, and
subwoofer level can be adjusted individually using separate controls.
Reliable functioning is ensured by a built-in dual limiter and the protection circuit. The intelligent plug & play
design with special plug-in connectors makes the system extremely fast and simple to set up and take down.
The 5-way Class AB amplification drives the individual frequency ranges separately for perfectly balanced
reproduction with a homogenous, natural sound and wide dynamic range. The wide horizontal dispersion angle
of 120° and extremely high resistance to feedback make separate monitors unnecessary.
2
ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESpAñoLpoLSKIITALIANo
You‘ve made the right choice!
We have designed this product to operate reliably over many years. LD Systems stands for this with its name and
many years of experience as a manufacturer of high-quality audio products.
Please read this User‘s Manual carefully, so that you can begin making optimum use of your LD Systems product
quickly.
You can find more information about LD SYSTEMS at our Internet site WWW.LD-SYSTEMS.COM

LDMAUI28MIX
COMpACT ACTIvE COLUMN pA SySTEM
wITh BUILT-IN 3-ChANNEL MIxER
3
ITALIANOPOLSKIESPAÑOL
FRANCAISFRANCAIS FRANCAISFRANCAIS FRANCAISDEUTSCHENGLISH

4
ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESpAñoLpoLSKIITALIANo
PREVENTIVE MEASURES:
1. Please read these instructions carefully.
2. Keep all information and instructions in a safe place.
3. Follow the instructions.
4. Observe all safety warnings. Never remove safety warnings or other information from the equipment.
5. Use the equipment only in the intended manner and for the intended purpose.
6. Use only sufficiently stable and compatible stands and/or mounts (for fixed installations). Make certain that wall
mounts are properly installed and secured. Make certain that the equipment is installed securely and cannot fall down.
7. During installation, observ e the applicable safety regulations for your country.
8. Never install and operate the equipment near radiators, heat registers, ovens or other sources of heat. Make
certain that the equipment is always installed so that is cooled sufficiently and cannot overheat.
9. Never place sources of ignition, e.g., burning candles, on the equipment.
10. Ventilation slits must not be blocked.
11. Do not use this equipment in the immediate vicinity of water (does not apply to special outdoor equipment -
in this case, observe the special instructions noted below. Do not expose this equipment to flammable materials,
fluids or gases.
12. Make certain that dripping or splashed water cannot enter the equipment. Do not place containers filled with
liquids, such as vases or drinking vessels, on the equipment.
13. Make certain that objects cannot fall into the device.
14. Use this equipment only with the accessories recommended and intended by the manufacturer.
15. Do not open or modify this equipment.
16. After connecting the equipment, check all cables in order to prevent damage or accidents, e.g., due to
tripping hazards.
17. During transport, make certain that the equipment cannot fall down and possibly cause property damage and
personal injuries.
18. If your equipment is no longer functioning properly, if fluids or objects have gotten inside the equipment or
if it has been damaged in anot her way, switch it off immediately and unplug it from the mains outlet (if it is a
powered device). This equipment may only be repaired by authorized, qualified personnel.
19. Clean the equipment using a dry cloth.
20. Comply with all applicable disposal laws in your country. During disposal of packaging, please separate
plastic and paper/cardboard.
21. Plastic bags must be kept out of reach of children.
FOR EQUIPMENT THAT CONNECTS TO THE POWER MAINS:
22. CAUTION: If the power cord of the device is equipped with an earthing contact, then it must be connected to
an outlet with a protective ground. Never deactivate the protective ground of a power cord.
23. If the equipment has been exposed to strong fluctuations in temperature (for example, after transport), do
not switch it on immediately. Moisture and condensation could damage the equipment. Do not switch on the
equipment until it has reached room temperature.
24. Before connecting the equipment to the power outlet, first verify that the mains voltage and frequency match
the values specified on the equipment. If the equipment has a voltage selection switch, connect the equipment to
the power outlet only if the equipment values and the mains power values match. If the included power cord or
power adapter does not fit in your wall outlet, contact your electrician.
25. Do not step on the power cord. Make certain that the power cable does not become kinked, especially at the
mains outlet and/or power adapter and the equipment connector.
26. When connecting the equipment, make certain that the power cord or power adapter is always freely
accessible. Always disconnect the equipment from the power supply if the equipment is not in use or if you want

5
ITALIANOPOLSKIESPAÑOL
FRANCAISFRANCAIS FRANCAISFRANCAIS FRANCAISDEUTSCHENGLISH
SAFETY:
to clean the equipment. Always unplug the power cord and power adapter from the power outlet at the plug or
adapter and not by pulling on the cord. Never touch the power cord and power adapter with wet hands.
27. Whenever possible, avoid switching the equipment on and off in quick succession because otherwise this
can shorten the useful life of the equipment.
28. IMPORTANT INFORMATION: Replace fuses only with fuses of the same type and rating. If a fuse blows repea-
tedly, please contact an authorised service centre.
29. To disconnect the equipment from the power mains completely, unplug the power cord or power adapter
from the power outlet.
30. If your device is equipped with a Volex power connector, the mating Volex equipment connector must be
unlocked before it can be removed. However, this also means that the equipment can slide and fall down if
the power cable is pulled, which can lead to personal injuries and/or other damage. For this reason, always be
careful when laying cables.
31. Unplug the power cord and power adapter from the power outlet if there is a risk of a lightning strike or
before extended periods of disuse.
CAUTION
RISK OF ELECTRIC S HOCK
DO NOT OPEN
CAUTION:
Never remove the cover, because otherwise there may be a risk of electric shock. There are no user serviceable
parts inside. Have repairs carried out only by qualified service personnel.
The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user
to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of
sufficient magnitude to constitute a risk of electrical shock.
The exclamation mark within an equilateral triangle is intended to alert the user to the presence of
important operating and maintenance instructions.
CAUTION – HIGH VOLUME LEVELS WITH AUDIO PRODUCTS!
This equipment is intended for professional use. Therefore, commercial use of this equipment is subject to the
respectively applicable national accident prevention rules and regulations. As a manufacturer, Adam Hall is
obligated to notify you formally about the existence of potential health risks.
Hearing damage due to high volume and prolonged exposure: When in use, this product is capable of producing
high sound-pressure levels (SPL) that can lead to irreversible hearing damage in performers, employees, and
audience members. For this reason, avoid prolonged exposure to volumes in excess of 90 dB.
CAUTION! IMPORTANT INFORMATION ABOUT LIGHTING PRODUCTS
1. Do not look into the beam from a distance of less than 40 cm.
2. Do not stare into the beam for extended periods at short-to-medium distances.
3. Do not view the beam directly with optical instruments such as magnifiers.
4. Under some circumstances, stroboscopic effects may trigger epileptic seizures in sensitive individuals! For this
reason, persons who suffer from epilepsy should always avoid places where strobe lights are used.

The LD Systems MAUI28MIX all-in-one array system
consists of the following three components:
1. Subwoofer with integral electronics for all three
parts of the system and the multi-pin connector (see
Fig. 1) for the vertical array column.
2. The lower vertical array column with 8 x 3“
speakers and 2 multipin connectors, one each on the
top and bottom.
3. The upper vertical array column with 8 x 3“
speakers, the tweeter and a multipin connector on the
bottom.
Once the subwoofer is positioned in the room that
is to be filled with sound, the lower vertical array
column is plugged onto the subwoofer. Four sturdy
steel pins help ensure that the multipin connectors of
both speakers mate perfectly. Now the upper vertical
array column is simply plugged onto the lower column
according to the same principle. Special control
electronics use an LED to indicate that all parts of the
system are properly connected after the MAUI28MIX
array system is turned on.
SETUP:
6
ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESpAñoLpoLSKIITALIANo
1

CONNECTIONS, CONTROLS AND INDICATORS:
7
ITALIANOPOLSKIESPAÑOL
FRANCAISFRANCAIS FRANCAISFRANCAIS FRANCAISDEUTSCHENGLISH
1
23
4
5
6
7
89 10
11 12
13
14 15

CONNECTIONS, CONTROLS, AND INDICATORS:
1MIC INPUT
Balanced microphone input (XLR/ 6.3 mm jack combo) It is also possible to use an unbalanced microphone
cable (mono jack). The microphone input has a built-in 100Hz subsonic filter to suppress low-frequency noise.
NOTE: There is no phantom power on the microphone input.
2HI-Z INPUT
Input for acoustic or electric guitar. When using this input, Switch 4 must be set to the right-hand position
(HI-Z). This switches the channel to mono.
3MP3 INPUT
3.5 mm jack input for MP3 players. When using this input, Switch 4 must be set to the left-hand position
(MP3). This switches the channel to stereo.
4MP3 / HI-Z SWITCH
In the left-hand position, the MP3 input is active; in the right-hand position, the HI-Z input is active.
5LINE INPUT (LEFT / RIGHT) UNBALANCED
Unbalanced line input (RCA) for connecting an external audio source (e.g., laptop).
6LINE INPUT (LEFT / RIGHT) BALANCED
Balanced line input (XLR / 6.3 mm jack combo) for connection of an external audio source (e.g., mixer,
keyboard).
7MIX OUTPUT (LEFT / RIGHT) BALANCED
This balanced stereo XLR output is independent of the main level and provides the mix signal from the
microphone, HI-Z / MP3, and line input signals.
8MP3 / HI-Z
Volume control for the MP3 / HI-Z channel.
9MIC
Microphone input volume control.
10 LINE
Line in volume control
11 SUB LEVEL
Sets the relative volume of subwoofer and column speakers.
12 MAIN LEVEL
Overall volume adjustment. The subwoofer volume is also adjusted in accordance with the preset on the SUB
LEVEL level control.
8
ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESpAñoLpoLSKIITALIANo

13 INDICATOR LEDs
ON: Lights up once the system is switched on and properly connected to the power mains.
LOCKED: Special control electronics use this LED to indicate that all parts of the system are properly connected
after the system is turned on.
SIGNAL: Lights up as soon as an audio signal is present.
LIMIT: Lights up if the system is operating in the clipping range. Brief flashing is not a cause for concern,
since the internal audio limiter compensates for over-modulation. Permanent illumination should be avoided
by reducing the volume.
PROTECT: Lights up when one of the power amplifier protection circuits is active. To protect the power
amplifiers and the speakers, the speaker outputs are deactivated in protect mode. Once the source of the
trouble has been eliminated (e.g., overloading), after a short time, the power amplifier returns to normal
status, the Protect LED goes out, and the system is operational again.
14 POWER SOCKET
IEC power socket with built-in fuse holder.
IMPORTANT INFORMATION: Replace the fuse only with a fuse of the same type and rating. If the fuse blows
repeatedly, please contact an authorised service centre.
15 POWER
Illuminated on / off switch. Before switching the system on or off, always adjust the volume to zero (Main
Level all the way to the left).
CONNECTIONS, CONTROLS, AND INDICATORS:
9
ITALIANOPOLSKIESPAÑOL
FRANCAISFRANCAIS FRANCAISFRANCAIS FRANCAISDEUTSCHENGLISH

FREQUENCY ALLOCATION:
TWEETERS
8,000 Hz - 20,000 Hz
Passive crossover
UPPER MIDS/TREBLE
500 Hz - 20,000 Hz
Amplifier power 50 W (RMS)
MIDS
170 Hz - 1,300 Hz
Amplifier power 50 W (RMS)
MIDS
170 Hz - 900 Hz
Amplifier power 50 W (RMS)
LOWER MIDS
170 Hz - 600 Hz
Amplifier power 50 W (RMS)
SUBWOOFER
45 Hz - 170 Hz
Amplifier power 200 W (RMS)
The LD MAUI28MIX has a five-way crossover that ensures a clear,
dynamic, and balanced sound throughout the frequency spectrum.
The array configuration ensures improved sound field coverage and
an especially balanced dispersion pattern throughout the venue.
10
ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESpAñoLpoLSKIITALIANo

POSITIONING:
Recommended minimum distance 3m
With a seated audience, it is advisable to maintain a minimum distance of approx. 3 metres between the MAUI28MIX
and the first row of seats in order to provide the listeners with an optimal listening experience.
11
ITALIANOPOLSKIESPAÑOL
FRANCAISFRANCAIS FRANCAISFRANCAIS FRANCAISDEUTSCHENGLISH

SETUP EXAMPLE:
Auxiliary unit Main unit
Setting when connecting multiple MAUI28MIX column systems in a chain:
1. Using XLR cables, connect the MIX OUTPUT (LEFT / RIGHT) of the main unit to the LINE INPUT (LEFT / RIGHT)
of the auxiliary unit. Connect the first auxiliary unit to the second auxiliary unit in the same manner (etc.).
2. Set the LINE volume knob(s) of the auxiliary unit(s) to maximum (knob all the way to the right).
3. To obtain the same volume from all units, simply set the MAIN LEVEL control of the main unit and the MAIN
LEVEL control(s) of the auxiliary unit(s) to the same position at the desired volume.
12
ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESpAñoLpoLSKIITALIANo
MAIN
LEVEL LINE
MAIN
LEVEL

TROUBLESHOOTING:
PROBLEM DISPLAY SOLUTION
System is not operational
although it is switched on.
Power switch and power LED do not
light up.
Check mains connection.
Disconnect the system from the
mains! Check the primary fuse of the
system and replace it if necessary. If
the fuse trips repeatedly, disconnect
the system from the power mains
and hand it over to an authorised
service centre.
Power switch, ON LED and Protect LED
light up.
System is overloaded. Reduce volume.
Protect LED goes out after a short
time; the system is operational again.
Protect LED remains lit even after
reduction of the volume.
Internal fault. Turn of the system,
disconnect it from the power mains,
and hand it over to an authorised
service centre.
HI-Z input is in use, but the
guitar is inaudible, although
both the HI-Z and Main
Level knobs are turned up.
Switch 4 is in the left-hand position
(MP3).
Reduce the volume of the guitar
channel and move the switch to the
right-hand position (HI-Z).
MP3 input is in use, but the
MP3 player is inaudible,
although both the MP3
and Main Level knobs are
turned up.
Switch 4 is in the right-hand position
(HI-Z).
Reduce the volume of the MP3
channel and move the switch to the
left-hand position (MP3).
Microphone signal distorted. Reduce the microphone channel
volume and increase the overall
volume (Main Level). Reduce the
volume of any additionally connected
audio source (e.g., keyboard) by the
same amount.
Guitar/MP3 signal distorted. Reduce the guitar/MP3 channel volume
and increase the overall volume (Main
Level). Reduce the volume of any
additionally connected audio source
(e.g., keyboard, microphone) by the
same amount.
Reduce the volume of the audio
source (e.g., guitar, MP3 player) and
increase the channel and/or overall
volume.
13
ITALIANOPOLSKIESPAÑOL
FRANCAISFRANCAIS FRANCAISFRANCAIS FRANCAISDEUTSCHENGLISH

TROUBLESHOOTING:
PROBLEM DISPLAY SOLUTION
Signal from line input
distorted.
Reduce the line channel volume and
increase the overall volume (Main
Level). Reduce the volume of any
additionally connected audio source
(e.g., keyboard, microphone) by the
same amount.
Reduce the volume of the audio
source (e.g., mixer increase the
channel and/or overall volume.
Overall signal distorted. Limit LED is always on. Reduce overall volume (MAIN LEVEL).
14
ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESpAñoLpoLSKIITALIANo

OPTIONAL ACCESSORIES:
LDM28SATBAG
Transport bag for MAUI28 and MAUI28MIX column speakers
LDM28SUBPC
Transport bag for MAUI28 and MAUI28MIX subwoofer
LDM28CB
Dolly for Maui28 and MAUI28MIX system
15
ITALIANOPOLSKIESPAÑOL
FRANCAISFRANCAIS FRANCAISFRANCAIS FRANCAISDEUTSCHENGLISH

Model name: LDMAUI28MIX
Product type: Complete PA System
Type: active
Colour: black
Max. SPL (continuous): 115 dB
Max. SPL (peak): 123 dB
Frequency response: 45 Hz - 20,000 Hz
Dispersion angle (H x V): 120° (horizontal)
Weight: 35 kg
Subwoofer
Woofer size: 2 x 8"
Woofer size: 2 x 203 mm
Woofer magnet: ferrite
Woofer brand: custom made
Cabinet type: bass-reflex, v-design
Cabinet material: 15 mm plywood
Cabinet surface: Dura Coat LX textured coating
Subwoofer dimensions (W x H x D): 390 x 450 x 510 mm
Subwoofer features: Ergonomic milled handles, custom-made multi-pin
connector for vertical array
Mid/Hi System
Midrange size: 16 x 3"
Midrange size: 16 x 76 mm
Midrange magnet: neodymium
Midrange brand: custom made
Tweeter size: 1"
Tweeter size: 25 mm
Tweeter magnet: ferrite
Tweeter brand: custom made
Speaker inputs: 1
Speaker input connections: Custom-made multi-pin
SPECIFICATIONS:
16
ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESpAñoLpoLSKIITALIANo

SPECIFICATIONS:
Mid/Hi system cabinet type: closed
Mid/Hi system cabinet material: aluminium
Mid/Hi system cabinet surface:: Paint
Mid/Hi system dimensions (W x H x D): 110 x 790 x 90 mm
Mid/Hi system features: Vertical array with 4-way amping and extremely broad
dispersion characteristic
Amplifier module
Amplifier: 5-way Class A/B
Amplifier power system (RMS) 400 W
Amplifier power subwoofer (RMS): 200 W
Amplifier power Mid/Hi (RMS): 4 x 50 W
Protection: dual limiter
Cooling system: aluminium heat sink
Controls: Main Level, Sub Level, Mic Level, Line Level, MP3 /
Hi-Z Level, Input Switch (Hi-Z / MP3), ON / OFF
Indicators: LEDs for: On, Locked, Signal, Limit, Protect
Power supply: transformer
Operating voltage: 220 V AC - 240 V AC, 50 - 60 Hz
Power consumption (max.) 600 VA
Line inputs: 2
Line input connectors: XLR/ 6.3 mm jack combo, RCA
Microphone inputs: 1
Microphone input connectors: XLR/ 6.3 mm jack combo
HI-Z inputs: 1 (alternative to MP3 player input)
HI-Z input connectors: 6.3 mm jack
MP3 player inputs: 1 (alternative to HI-Z input)
MP3 player input connectors: 3,5 mm stereo jack
Speaker outputs: 1
Speaker output connections: Custom-made multi-pin
Other features: 100-Hz high-pass filter in microphone channel
17
ITALIANOPOLSKIESPAÑOL
FRANCAISFRANCAIS FRANCAISFRANCAIS FRANCAISDEUTSCHENGLISH

18
ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESpAñoLpoLSKIITALIANo
MANUFACTURER‘S WARRANTY
This warranty covers the Adam Hall, LD Systems, Defender, Palmer, and Cameo brands.
It applies to all products distributed by Adam Hall.
This warranty declaration does not affect the statutory warranty claims against the manufacturer, but expands
them with additional warranty claims vis-a-vis Adam Hall.
Adam Hall warrants that the Adam Hall product that you have purchased from Adam Hall or from an Adam Hall
authorized reseller is free from defects in materials or workmanship under normal use for a period of 2 or 5 years
(please inquire on a product-by-product basis) from the date of purchase.
The warranty period begins on the date on which the product was purchased, proof of which must be produced
(through presentation of the invoice or the delivery note with the date of purchase) in the event of a warranty claim.
Should products of the brands named above be in need of repair within the limited warranty period, you are entitled
to warranty service according to the terms and conditions stated here.
During the Limited Warranty Period, Adam Hall will repair or replace the defective component parts or the product.
In the event of repair or replacement during the Limited Warranty Period, the replaced original parts and/or pro-
ducts become property of Adam Hall.
In the unlikely event that the product which you purchased has a recurring failure, Adam Hall has the right, at its
discretion, to replace the defective product with another product, provided that the new product is at least equi-
valent to the product being replaced with regard to the technical specifications.
Adam Hall does not warrant that the operation of this product will be uninterrupted or error-free. Adam Hall is not
responsible for damage that occurs as a result of your failure to follow the instructions included with the Adam Hall
branded product. The manufacturer‘s warranty does not cover – expendable parts (e. g., rechargeable batteries)
- products from which the serial number has been removed or with a serial number that has been damaged as a
result of an accident - damage due to improper use, user error or other external reasons
- damage to devices operated outside the usage parameters stated in the documentation included with the product
- damage due to the use of replacement parts not manufactured, sold or recommended by Adam Hall,
- damage due to modification or servicing by anyone other than Adam Hall.
These terms and conditions constitute the complete and exclusive warranty agreement between you and Adam
Hall regarding the Adam Hall branded product you have purchased.
MANUFACTURER´S DECLARATIONS:

19
ITALIANOPOLSKIESPAÑOL
FRANCAISFRANCAIS FRANCAISFRANCAIS FRANCAISDEUTSCHENGLISH
MANUFACTURER´S DECLARATIONS:
LIMITATION OF LIABILITY
If your Adam Hall branded hardware product fails to work as warranted above, your sole and exclusive remedy
shall be repair or replacement. Adam Halls’ maximum liability under this limited warranty is expressly limited to
the lesser of the price you have paid for the product or the cost of repair or replacement of any components that
malfunction under conditions of normal use.
Adam Hall is not liable for any damages caused by the product or the failure of the product, including any lost
profits or savings or special, incidental, or consequential damages. Adam Hall is not liable for any claim made by
a third party or made by you for a third party.
This limitation of liability applies whether damages are sought, or claims are made, under this Limited Warranty
or as a tort claim (including negligence and strict product liability), a contract claim, or any other claim, and
cannot be rescinded or changed by anyone. This limitation of liability will be effective even if you have advised
Adam Hall or an authorized representative of Adam Hall of the possibility of any such damages, but not, however,
in the event of claims for damages in connection with personal injuries.
This manufacturer‘s warranty grants you specific rights; depending on jurisdiction (nation or state), you may be
be entitled to additional claims. You are advised to consult applicable state or national laws for a full determina-
tion of your rights.
REQUESTING WARRANTY SERVICE
To request warranty service for the product, contact Adam Hall or the Adam Hall authorized reseller from which
you purchased the product.
EC DECLARATION OF CONFORMITY
The equipment marketed by Adam Hall complies (where applicable) with the essential requirements and other
relevant specifications of Directives 1999/5/EC (R&TTE), 2004/108/EC (EMC) und 2006/95/EC (LVD). Additional
information can be found at www.adamhall.com.

20
ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESpAñoLpoLSKIITALIANo
MANUFACTURER´S DECLARATIONS:
PROPER DISPOSAL OF THIS PRODUCT
(Valid in the European Union and other European countries with waste separation)
This symbol on the product, or the documents accompanying the product, indicates that this appliance may not
be treated as household waste. This is to avoid environmental damage or personal injury due to uncontrolled
waste disposal. Please dispose of this product separately from other waste and have it recycled to promote
sustainable economic activity.
Household users should contact either the retailer where they purchased this product, or their local government
office, for details on where and how they can recycle this item in an environmentally friendly manner.
Business users should contact their supplier and check the terms and conditions of the purchase contract. This
product should not be mixed with other commercial wastes for disposal .
ENVIRONMENTAL PROTECTION AND ENERGY CONSERVATION
Energy conservation is an active contribution to environmental protection. Please turn off all unneeded electrical
devices. To prevent unneeded devices from consuming power in standby mode, disconnect the mains plug.
Adam Hall GmbH, all rights reserved. The technical data and the functional product characteristics can be subject
to modifications. The photocopying, the translation, and all other forms of copying of fragments or of the integrlity
of this user’s manual is prohibited.
