LeCroy 4300B User manual

1
OPERATOR'S MANUAL
MODEL 4300B
CAMAC 16 CHANNEL,
FAST ENCODING &
READOUT ADC (FERA)
Revised
March, 1998
(ECO 1007)

2
Corporate Headquarters
700 Chestnut Ridge Road
Chestnut Ridge, NY 10977-6499
Tel: [phone] Fax: [phone]
E-mail: [e-mail]
[e-mail]
Copyright© March 1998. LeCroy™ is a registered trademark of
LeCroy Corporation. All rights reserved. Information in this
publication supersedes all earlier versions.
Innovators in Instrumentation

3
CE CONFORMITY
CONDITIONS FOR
CE CONFORMITY Since this product is a subassembly, it is the responsibility of the end
user, acting as the system integrator, to ensure that the overall system is
CE compliant. This product was demonstrated to meet CE conformity
using a CE compliant crate housed in an EMI/RFI shielded enclosure. It
is strongly recommended that the system integrator establish these
same conditions.

5
CAUTION
GENERAL Crate power should be turned off during insertion and removal of unit to
avoid possible damage caused by momentary misalignment of contacts.
See pocket in back of manual for schematics, parts list and additional
addenda with any changes to manual.

7
TABLE OF CONTENTS
General Information
Purpose 9
Unpacking and Inspection 9
Warranty 9
Product Assistance 9
Maintenance Agreements 9
Documentation Discrepancies 10
Software Licensing Agreement 10
Service Procedure 10
Front-Panel Diagram 11
1. Product Description
1.1 General 13
1.2 Specifications 13
1.3 Analog Inputs 14
1.4 Clear Function 14
1.5 External Gate Input (GATE) 15
1.6 ADC Pedestals 15
1.7 Test Function 15
1.8 Pedestal Memory 16
1.9 Status Register 16
1.10 ECL Port Output 18
1.11 ECL Port Readout Handshake 19
1.12 Halt of Readout on the ECL Port 20
1.13 CAMAC Readout 20
1.14 LAM Handling 21
1.15 FERA System Connections 21
1.16 Packaging and Power Requirements 22
2.0 Operating Instructions
2.1 General 31
2.2 CLEAR and GATE Functions 32
2.3 Charge to Time Converters 32
2.4 Test Circuit 33
2.5 Digital Interpolators 33
2.6 Real Time Counters 33
2.7 Clock Generators 34
2.8 Pedestal Memory 34
2.9 Data Compression and Readout Logic 34
2.10 ECL Port Readout Circuit 36
2.11 CAMAC Readout Circuit 36
2.12 CAMAC Functions Decoder 36
2.13 ADC Resolution Adjustment 36
3.0 List of Figures and Tables
1.1 Readout Timing Diagram 23
1.2 ECL Port Timing Diagram 24
1.3 FERA System Connections 25
1.4 Model 4301 FERA Driver Block Diagram 26
1.5 Localization of Removable Resistors & VGND-GND Jumper 27
1,1a Table: Status Register Format 28

8
1.1b Table: Readout Format 29
2.1 Model 4300B Block Diagram 38
2.2 Charge-to-Time Converter Block Diagram 39
2.3 Time-to-Digital Converter Blcok Diagram and Timing 40
4.0 Appendix
4.1 ECL Differntial I/O Levels 41
4.2 ECL Single-Ended I/O Levels 42

9
PURPOSE This manual is intended to provide instruction regarding the setup and
operation of the covered instruments. In addition, it describes the theory
of operation and presents other information regarding its functioning and
application.
UNPACKING AND
INSPECTION It is recommended that the shipment be thoroughly inspected immedi-
ately upon delivery. All material in the container should be checked
against the enclosed Packing List and shortages reported promptly.
If the shipment is damaged in any way, please notify the Customer
Service Department or the local field service office. If the damage is
due to mishandling during shipment, you may be requested to assist in
contacting the carrier in filing a damage claim.
WARRANTY LeCroy warrants its instrument products to operate within specifications
under normal use and service for a period of one year from the date of
shipment. Component products, replacement parts, and repairs are
warranted for 90 days. This warranty extends only to the originalpur-
chaser. Software is thoroughly tested, but is supplied "as is" with no
warranty of any kind covering detailed performance. Accessory products
not manufactured by LeCroy are covered by the original equipment
manufacturers' warranty only.
In exercising this warranty, LeCroy will repair or, at its option, replace any
product returned to the Customer Service Department or an
authorized service facility within the warranty period, provided that the
warrantor's examination discloses that the product is defective due to
workmanship or materials and has not been caused by misuse, neglect,
accident or abnormal conditions or operations.
The purchaser is responsible for the transportation and insurance
charges arising from the return of products to the servicing facility.
LeCroy will return all in-warranty products with transportation prepaid.
This warranty is in lieu of all other warranties, express or implied, includ-
ing but not limited to any implied warranty of merchantability, fitness, or
adequacy for any particular purpose or use. LeCroy shall not be liable
for any special, incidental, or consequential damages, whether incon-
tract, or otherwise.
PRODUCT ASSISTANCE Answers to questions concerning installation, calibration, and use of
LeCroy equipment are available from the Customer Service Department,
700 Chestnut Ridge Road, Chestnut Ridge, New York, 10977-6499,
[phone].
MAINTENANCE
AGREEMENTS LeCroy offers a selection of customer support services. For example,
Maintenance Agreements provide extended warranty that allows the
customer to budget maintenance costs after the initial warranty has
expired. Other services such as installation, training, on-site repair, and
addition of engineering improvements are available through specific
Supplemental Support Agreements. Please contact the Customer
Service Department for more information.
GENERAL INFORMATION

10
DOCUMENTATION
DISCREPANCIES LeCroy is committed to providing state-of-the-art instrumentation and is
continually refining and improving the performance of its products. While
physical modifications can be implemented quite rapidly, the corrected
documentation frequently requires more time to produce. Consequently,
this manual may not agree in every detail with the accompanying product
and the schematics in the Service Documentation. There may be small
discrepancies in the values of components for the purposes of pulse
shape, timing, offset, etc., and, occasionally, minor logic changes.
Where any such inconsistencies exist, please be assured that the unit is
correct and incorporates the most up-to-date circuitry.
SOFTWARE LICENSING
AGREEMENT Software products are licensed for a single machine. Under this license
you may:
■Copy the software for backup or modification purposes in support of
your use of the software on a single machine.
■Modify the software and/or merge it into another program for your
use on a single machine.
■Transfer the software and the license to another party if the other
party accepts the terms of this agreement and you relinquish all
copies, whether in printed or machine readable form, including all
modified or merged versions.
SERVICE PROCEDURE Products requiring maintenance should be returned to the Customer
Service Department or authorized service facility. If under warranty,
LeCroy will repair or replace the product at no charge. The purchaser is
only responsible for the transportation charges arising from return of the
goods to the service facility. For all LeCroy products in need of repair
after the warranty period, the customer must provide a Purchase Order
Number before any inoperative equipment can be repaired or replaced.
The customer will be billed for the parts and labor for the repair as well
as for shipping. All products returned for repair should be identified by
the model and serial numbers and include a description of the defect or
failure, name and phone number of the user. In the case of products
returned, a Return Authorization Number is required and may be
obtained by contacting the Customer Service Department at (914) 578-
6030.

11
MODEL 4300B
FRONT-PANEL
Pull Down ON (LED
indicator) indicates
that pull down and
input resistors are
mounted on Command
bus (Sec. 1.15)
Command Bus
Analog Inputs
(Sec 1.3)
Not connected
Write Strobe (Sec. 1.11)
Readout Request (Sec. 1.11)
Clear (Sec. 1.4)
Gate (Sec. 1.5)
Write Acknowledge (Sec. 1.11)
Ground
Test Reference Voltage (Sec. 1.7)
Readout Enable (Sec. 1.11)
Readout Enable PASS (Sec. 1.11)
Common Virtual Ground
(Sec. 1.3)
Ground (Sec 1.3)
Pull Down on (LED
Indicator) indicates
that pull down
resistors are mounted
on the ECL output
Port (Sec. 1.15)
ECL output port
(Sec 1.10)
Last 2 pins not
connected

13
1.1 General The LeCroy Model 4300B FERA contains 16 independent charge-to-
digital converters with common GATE and common CLEAR.
Four basic factory options are available:
a. 8 or 9 bits with 100 ohm impedance
b. 8 or 9 bits with 50 ohm input impedance
c. 10 or 11 bits with 100 ohm input impedance
d. 10 or 11 bits with 50 ohm input impedance.
The options a, b and c are only produced for large quantities. The
resolution on each of the above versions may be adjusted via jumpers
and an internal potentiometer (see Section 2.13 for details).
1.2 Specifications
PRODUCT DESCRIPTION
LeCroy Input Resolution Conversion Range Sensitivity Digital Values
4300B Impedance Time Typical Typical Full Over
MOD Scale Flow
ohms bits µsec pC pC/count counts counts
100 100 8 1.8 128 0.5 255 2047
500 50
110 100 9 2.8 256 0.5 511 2047
510 50
200 100 10 4.8 256 0.25 1023 2047
600 50
210 100 11 8.5 480 0.25 1919 2047
610 50
An 8-bit register (Status Register) and a memory (Pedestal Memory),
containing the individual pedestal (or offset) values to be subtracted from
each ADC, allow different readout modes of the 16 digitized ADC values.
Both the Status Register and Pedestal Memory must be previously
loaded via CAMAC. Data may be read out either via the CAMAC
dataway or the ECL port. The state of the Status Register determines the
readout modes. The ECL port output, located on the front-panel, is first
activated and delivers ADC data sequentially in words of 16 bits (8 to 11
bits of data plus 4 subaddress) at differential ECL levels. When data are
ready to be read at the ECL port, the REQ output is activated.
In CAMAC mode, data are also read out in 16-bit words in either random
access or sequential CAMAC readout (Q stop mode). The CAMAC
readout can only be carried out after completion of ECL port readout.
When data are ready for readout via CAMAC dataway, a LAM may be
generated and there is a Q response to the readout function F(2). The
data read out mode via these two ports may be independently selected
and programmed to be in one of three states: 1) raw; 2) with the pedes-
tal subtracted; or 3) compacted, i.e., all data < 1 are eliminated (Zero
suppression).
A system for testing the 16 ADCs is incorporated in the Model 4300B.
The test is initiated by the CAMAC command F(25) A(0). This command
opens the ADC GATEs and applies, at the input of each one, a charge
proportional to the continuous voltage that must be given on the front
panel TRV input.
