LED Group Robus R8MTS User manual

Specification:
Installation:
Model No R8MTS
Operating mode maintained non-maintained
Lamp T5 8W fluorescent
Dimensions (L)345mmX(W)107mmX(H)77mm
Weight 0.9kg
Safety classification Class I, Must be earthed
Supply voltage 220-240V~ 50/60HZ
Discharge duration >3 hours after minimum 24Hr charge
Battery 3.6V 1.8Ah Ni-Cd cells
Battery life up to 4 years normal use
Operating ambient temperature 0oC~+25oC
Case material Polycarbonate
Diffuser material Polycarbonate
Ingress protection IP65
Connection Screw terminals
Suitable for mounting on a normally flammable surface
Green LED indicator indicates battery charging mode
Safety and performance in accordance with EN60598-1,EN60598-2-22
EN55015,EN61000-3-2,EN61000-3-3,EN61547
Suitable for indoor or outdoor use, wall or ceiling mounted
! Electrical products can cause death or injury, or damage to property. If in any doubt about
the installation or use of this product, consult a competent electrician.
1 Ensure mains supply is switched off before commencing installation.
2.Remove the front diffuser from the body by removing the 2 fixing screws.
3.Release the metal gear tray by unscrewing the screw and easing the plastic clips away from the
metal tray, lift the metal tray away from the base.
4.Knock out the intended cable entry hole suitable for your installation;Fit cable gland(if
weatherproofing necessary)
5. Mark appropriate fixing points on wall or ceiling; check that fixings will not impinge on concealed
cables of pipes before drilling holes.
6. Fix luminaire to the wall/ceiling using suitable screws.
7. Write installation date on battery and connect battery
8. Connect wires from unswitched supply to terminals on gear tray, brown to L,Blue to N and
green/yellow to earth (Non Maintained)；In the maintained emergency unit: for lamp always on ,
link terminal “L1” to terminal “L”. Lamp controlled by switch connect switched live wire to terminal
L1 and permanent live to L
Note: if “L1” terminal not connected, fitting works as non-maintained.
9. Reassemble gear tray, the tube and the diffuser.
10. Switch on suppy: the green led should come on indicating conrrect battery charge has
started. In the non-maintained unit, the lamp only lights if the mains supply fails; In the
maintained unit,the lamp will light(if switched live on),when the mains supply fails,battery
will operate lamp emergency mode.
Issue 1 080713
IP65 Maintained 8W BULKHEAD WITH
TEST SWITCH
Please read instructions before commencing installation and
retain for future reference.
R8MTS
1. Please note the requirement to dispose of Waste Electrical & Electronic Equipment separately from household waste (WEEE
marked with crossed out wheelie bin symbol).
2. Please consider your role in contributing to re-use and recycling by returning this product at end of life to a collection centre
for waste electrical equipment or a Civic Amenity site, or to a retail outlet from which you are purchasing a replacement.
3. This equipment may contain substances that are hazardous to health and the environment if disposed of carelessly. It is
important that it is separated from normal household waste and recycled in the WEEE chain
4. The “crossed out wheelie bin symbol” on a product indicates this equipment must not be disposed of in normal household
waste, but should be disposed of according to local WEEE regulations
The Installation must be carried out by an electrician
LED Group
Western Retail Park Tel: [phone]
Nangor Road Fax: [phone]
Dublin 12 Email: [email protected]
Ireland Website: www.led.ie
Page 1
ISO 9001:2008
Q UALIT Y ASSU RE D CO MPANY
Information for the Product user

The emergency lighting must be inspected and tested regularly in accordance with local
codes of practice.Note: in order to comply with the standard all emergency lighting should
be fully charged within 24 hours
The minimum recommended test schedule is as follows:
After installation, allow 24 hours to ensure full battery charge and then interrupt the
supply; check after 3 hours that tube is still lighting.
1. Daily check that charge indicator led is working
2. Monthly, interrupt mains for a short period and check tubes light, this is possible by
pressing and holding down the test switch
3. Six-monthly, check 1 hour duration
4.At the end of year 3 and subsequently every year, check 3 hour duration: batteries
must be replaced when they can no longer support 3 hour operation.
5. Complete record sheet on installation and retain in maintainance file.
6. Update file with ongoing test records for inspection by fire officer or
other duly authorised person
Testing:
Installation and Maintenance Record:
Installer
Installation Type
Installation test duration & Date
Signed
Month Test
Short
Short
Short
Short
Short
Short
Short
Short
Short
1Hr.
1Hr.
3Hr.
Short
1
2
3
4
5
6
7
8
9
10
11
12
Date
xxxxx xxxxx xxxxx xxxxx
xxxxx xxxxx xxxxx xxxxx xxxxx xxxxx
1st Year
Signed Date Signed Date Signed Date Signed Date
2st Year 3st Year 4st Year 5st Year
The Installation must be carried out by an electrician
LED Group
Western Retail Park Tel: [phone]
Nangor Road Fax: [phone]
Dublin 12 Email: [email protected]
Ireland Website: www.led.ie
Page 2
ISO 9001:2008
Q UALIT Y ASSU RE D CO MPANY

Installation diagram:
The Installation must be carried out by an electrician
LED Group
Western Retail Park Tel: [phone]
Nangor Road Fax: [phone]
Dublin 12 Email: [email protected]
Ireland Website: www.led.ie
Page 3
ISO 9001:2008
Q UALIT Y ASSU RE D CO MPANY
Figure 1 Figure 2
Figure 3
Mark appropriate fixing points
Dia 20mm
Test switch
Switch on supply
Maintained: The green LED and Tube should come on,
if press the test switch, the Tube will dim;
Non-maintained: The green LED should come on,
if press the test switch, the Tube will come on.
This situation shows normal installation
265mm
Figure 4
Figure 5 Figure 6
L1
77mm
107mm
345mm
Red +
Black -
From
battery
N
L
L1
Non-maintained maintained
Brown
Y/G
Blue
N
L
Brown
Y/G
Blue
