LED World WiFi-104 User manual

This product is intended to be installed and serviced by a qualied licensed electrician. Install in
accordance with the National Electric Code, and local regulations.
Only power with a regulated (listed) constant voltage Class 2 power supply (12-24V DC).
Ensure applicable wire is installed between driver, xture, and any controls in between. When choosing
wire, factor in voltage drop, amperage rating and type (in-wall rated, wet location rated, etc.).
Inadequate wire installation could overheat wires and cause re.
This product is rated for indoor installation and only for dry locations.
Do not modify this product beyond the instructions in this guide or the warranty will be voided.
Wiring diagrams in this installation guide for basic installations. Please carefully review your installation
before proceeding
Safety & Warnings
Before you begin, read all warnings and installation instructions.
1. Product Parameter:
WiFi-104 is a versatile RGB color control lighting system.
Through WiFi function and mobile devices, the wi-104
can control various types of RGB LED lighting products VIA
iOS or Android.
WiFi-104 lighting control system integrates four functional
controls including; dimming, color temperature adjusting,
RGB and RGBW (that can be set as single color
temperature). The 104 can control up to 12 zones areas
using the optional wireless R4-5A Zone Receiving
controller.
Communication Standard
Input Voltage
Max Current Load
Max Output Power
Product Size
Weight(G.W.)
Wi-Fi, 802.11 b/g/n Protocol
DC12V~DC24V (Use only with Class 2 listed regulated power supply)
4A x4CH Max
192W/384W (12V/24V)
L128 × W73 × H45 mm
290g
WiFi-104 control system supports direct connection or by router:
In directly connection, mobile phone, IOS and Android can directly control the WiFi-104 controller + R4-
5A/R4-CC wireless control, without any third party of network equipment. Included is a 2.4G RF remote
(M12) if software is not used.
WiFi Control Distance
Working Temperature
Package Size
100m (Distance of cross-eyed)
-20°C ~ 40°C
WiFi-104 Controller
L135 x W80 x H64mm
WiFi-104 WiFi Lighting Control System
1LED World Inc. | #130 10615 48 ST SE | CALGARY, AB T2C 2B7 | CANADA
Copyright © 2015 LED WORLD INC™. All Rights Reserved. We are not responsible for errors or omissions. Product and specications subject to change without notice. Registered trademarks are owned by their respective registers, or licensee(s).

WiFi-104 Wi-Controller
2. Conguration Diagram
www.ledworldlighting.com
Working Voltage
Transmitting Frequency
Remote Distance
Dimensions
Weight(G.W.)
DC3V (CR2032 button battery)
2.4GHz
30m (Distance of cross-eyed)
L 104 × W 60 × H 9 mm
290g
M12 Remote Control
127.6mm
73mm
RUN
RX/TX
LIN K
EXT K EYSSI DMATCH SCENE
Power Input / LED Output Learning ID
Key
Scene
Indicators
44.5mm
3. Controller Operating Instructions
RUN
RX/TX
LINK
EXT KE YSSIDMATCH FUN
ANTENNA installation instruction
1). Install / Uninstall ANTENNA
Rotate Antenna clockwise to install. To uninstall rotate
Antenna anti-clockwise
2). Light Indicator Instructions
ŸRUN : It ashes quickly about 25s during the electric
initialization. Flashes once per second after
initialization
ŸLINK: It keeps on when the mobile device
connected with WiFi controller, and turns off when
disconnected
R4-5A Constant Voltage Zone Receiver
Wireless Frequency
Input Voltage
Max Output Power
Remote Distance
2.4GHz
DC5V~DC24V
5A × 4CH Max 20A
100W/240W (12V/24V)
50m (Distance of cross-eyed)
Max Current Load
Working Temperature
Product Size
Weight(G.W.)
-20°C ~ 40°C
L 175 × W 44 × H 30 mm
110g
Manufacturer
Interface SSID Code
Switch
2LED World Inc. | #130 10615 48 ST SE | CALGARY, AB T2C 2B7 | CANADA
Copyright © 2015 LED WORLD INC™. All Rights Reserved. We are not responsible for errors or omissions. Product and specications subject to change without notice. Registered trademarks are owned by their respective registers, or licensee(s).

WiFi-104 Wi-Controller
4. ios/Android application instructions:
1). Download Application:
www.ledworldlighting.com
Channel Color
RUN
RX/T X
LINK
EXT KEY SSIDMATCH SC ENE
5
4
6
3
7
2
8
1
9
0
A
F
B
E
C
D
3). SSID Number Setting
Set the controller's SSID number with code switch, SSID
number range from WiFi-104-SSID-0 to WiFi-104-SSID-F.
which means our product could set 16 isolated LAN in
the same area. The controller will re-enter initialization
status once the code switch changes. RUN indicator
light will ash quickly about 25 seconds, mobile device
need to search and connect WiFi again after
Initialization nished.
4). MATCH Key and SCENE Key
Short press MATCH key and WiFi controller
will begin its learning ID status for the
standard M12 remote. Short press SCENE
key sequentially to the user-saved scene
modes, 4 scene total.
Restore factory settings/Delete password
Long press MATCH key and SCENE key
simultaneously more than 2 seconds, the
m a c h i n e w i l l b a c k t o t h e d e f a u l t
parameter, including the parameters of
changing modes, zones, group parameters
Scene Interface
RUN
RX/TX
LINK
EXT KEY SSIDMATCHSCENE
SCENE
SCENE Key and MATCH Key
Scene Save
Scene 2
Scene 3
Scene 4
Back
Scene 1
MATCH
14:17 PM 100%
and network parameters. In default parameters: Only the 1st zone is present, default RGBW mode, the
changing mode is RGB skipping, the brightest is white, no groups, network SSID is WiFi-104-SSID-X (X is the
actual coding switch corresponding SSID values), WiFi-104 controller restore as directly connect and the
connection password is blank.
scan to download android app
scan to download ios app
Avail able on t he
App Store
ANDROID APP ON
Google play
2). How to operate the Application:
A). Network connection setting :
WiFi-104 support 2 connection modes: Directly
connection as router or connect by additional router.
ŸConnecting WiFi controller as a router
Go to mobile device's WiFi setting, Search the
available WiFi Network. From the list select WiFi
Network, appended with SSID-Number.(As Legend-1),
(no password is set by default).
Apple WiFi connectionAndroid WiFi connection
WL AN settings
WL AN
Connect to WiFi-104-SSID-0
Network notification
Auto Connect
WiFi-104-SSID-0
TP-008
ACW1F
Notify me when an open network is
available
set the way of network’s connection
Connected
Remembered, secured with WPA/
WPA2 PSK
Remembered
WL AN ne tworks
16:07 14:17 PM
Wi-Fi
Settings
Wi-Fi
Other...
Ask to jin Networks
Known networks will be joined automatically.
if no known networks are available, you will
have to manually select a network.
CHOOSE A NET WORK.. .
WiFi-104-SSID-0
WiFi-104-SSID-1
100%
(Legend-1)
3LED World Inc. | #130 10615 48 ST SE | CALGARY, AB T2C 2B7 | CANADA
Copyright © 2015 LED WORLD INC™. All Rights Reserved. We are not responsible for errors or omissions. Product and specications subject to change without notice. Registered trademarks are owned by their respective registers, or licensee(s).

www.ledworldlighting.com
ŸConnect WiFi-104 with a additional router:
a). Connect to the WiFi-104 controller, as same procedure as (A)
b). Click WiFi-104 application icon to start the app. The app will search and list the working WiFi controller
automatically
WiFi-104 Wi-Controller
1Network
Zone
WiFi-104-SSID-2
32:AA:3C:7E:B4:DB
Disco nnect ed
2
Devic e List
234
56 7
1
8
10 11 12 9
WiFi-104 -SSID-0
32:AA:3C :7E:B4:DA
Network
Zone
Conne ct to WiF i-10 4-SSI D-1
(Legend 2-1) ( -2-2)
1Network
Zone
WiFi-104-SSID-1
32:AA:3C :7E:B4:DB
Conne ct to TP-L INK1
2
Devic e List
234
56 7
1
8
10 11 12 9
WiFi-104-SSID-0
32:AA:3C :7E:B4:DA
Network
Zone
Conne ct to TP-L INK1
1Network
Zone
WiFi-104-SSID-2
32:AA:3C :7E:B4:DD
Conne ct to TP-L INK1
Connected with additional router
Connected with WiFi-104 as a router
Delete WiFi-104 controller list
Disconnected WiFi-104 controller
Network interface
Zone function interface
Change the interface background
Connected Router Name
Connected WiFi-104
search button for the WiFi-104 controller
Active WiFi-104
Workable zone NO
14:17 PM 100% 14:17 PM 100%
(Legend 2-2)
c). Click “Network” key to enter Network interface(as legend-3-1). Turn ON "connect to existing LAN" option
and app will search the available WiFi SSID list. Choose the available router to connect (Note : Do not
choose WiFi-104 controller)(as legend-3-2 )
Repeat the a-b-c steps if you are connecting multiple WiFi-104 controller to same wireless router.
d). Exit WiFi-104 application, go to mobile wireless network setting, choose the wireless router to connect.
Start WiFi-104 application again, device will list interface as legend-2-2. Complete the same steps to
connect to the additional router.
Network
Back
User setting
Wireless mode
Connect to existing LAN
Change SSID and password
Network
Back
Available wireless LAN networks
TP-LINK1
WiFi-104-SSID-0
WiFi 104 SSID 1- - -
User setting
Wireless mode
Connect to existing LAN
Change SSID and password
WiFi-104-SSID-2
WiFi-104-SSID-3
WiFi-104-SSID-4
(Legend 3-1)
Network interface
(Legend 3-2)
14:17 PM 100% 14:17 PM 100%
Note: In this connection mode, to avoid the mobile device automatically connect to WiFi-104 after
the setting has completed, please click “workable WiFi-104". On dialog box click "Forget this network"
or "Cancel save".
WL AN settings
WL AN
Connect to WiFi-104-SSID-0
Network notification
Auto C onn ect
WiFi-104-S SID-0
TP-008
ACW1 F
Notify me when an open network is
available
set the way of network’s connection
Connected
Remembered, secured with WPA/
WPA2 PSK
Remembered
WL AN n etwo rks
16:07
WiFi-104-SSID-0
Cancel Forget Disconnect
Status
Connected
Signal strength
Excellent
Link speed
65Mbps
Security
Open
IP address
10.10.100.103
14:17 PM
WiFi-104-SSID-0
Wi- F i
For g e t t h i s N e tn w ork
IP ADDR ESS
100%
DHCP BootP Static
IP Addr ess
Subnet Mas k
Router
DNS
Search Dom ain s
10.10.100.103
255.255.255.0
10.10.100.254
10.10.100.254
Hi_flying
Cancel saved WiFi-104 connection information
4LED World Inc. | #130 10615 48 ST SE | CALGARY, AB T2C 2B7 | CANADA
Copyright © 2015 LED WORLD INC™. All Rights Reserved. We are not responsible for errors or omissions. Product and specications subject to change without notice. Registered trademarks are owned by their respective registers, or licensee(s).

www.ledworldlighting.com WiFi-104 Wi-Controller
B). Main interface ( 5 types total)
G255 R255 B25 5 W25 5
W
80% 8 0%
Name
Long press to turn off single zone or group
Mode
Device Scene
Group On/off
2 3 456
78
RGBW
1
RGB CT1 RGB
RGBW
10 11 12
9
RGBW DIM
Group 1 Grou p2 Group3
DIM
DIM RGBW RGBW
CT2
RGBW Value
5 Main interfaces
White Value
Brightness Value
Color Bar
Zone Selection
Group Interface Mode Interface Scene Interface
Main Switch
Group Selection
Device List Interface
14:17 PM 100%
Name
Long press to turn off single zone or group
ModeDevice Scene
Group On/off
2 3 456
78
RGBW
1
RGB CT1 RGB
RGBW
10 11 12
9
RGBW DIM
Group1 Group2 Group3
DIM
DIM RGBW RGBW
100%
W255
CT2
14:17 PM 100%
40%
WW
135120
NW
Name
Long press to turn off single zone or group
ModeDevice Scene
Group On/off
2 3 456
78
RGBW
1
RGB CT1 RGB
RGBW
10 11 12
9
RGBW DIM
Group1 Group2 Group3
DIM
DIM RGBW RGBW
CT2
14:17 PM 100%
40%
WW
15 NW 240 C W 0
Name
Long press to turn off single zone or group
ModeDevice Scene
Group On/off
2 3 456
78
RGBW
1
RGB CT1 RGB
RGBW
10 11 12
9
RGBW DIM
Group1 Group2 Group3
DIM
DIM RGBW RGBW
CT2
14:17 PM 100%
G255 R255 B2 55
40%
Name
Long press to turn off single zone or group
ModeDevice Scene
Group On/off
2 3 456
78
RGBW
1
RGB CT1 RGB
RGBW
10 11 12
9
RGBW DIM
Group1 Group2 Group3
DIM
DIM RGBW RGBW
CT2
14:17 PM 100%
G255 R255 B2 55 W2 55
W
80% 80 %
Name
Long press to turn off single zone or group
ModeDevice Scene
Group On/off
2 3 456
78
RGBW
1
RGB CT1 RGB
RGBW
10 11 12
9
RGBW DIM
Group1 Group2 Group3
DIM
DIM RGBW RGBW
CT2
14:17 PM 100%
C). The learning method of Zone control
ŸTurn on zone control
Click “Zone” on the Device list, Enter Zone set interface. According to the lighting control requirements, turn
on multiple zone, select the light type and naming zone.
Note : Default WiFi-104 controller works as NO.1 zone, which can select if to connect lights. If not, sub-
control can be replaced as the rst zone.
ZONE N AM E LIN K
Zone Set
TYPE
Back
CON TR OL LE R1 D IM
1
CON TR OL LE R2
CON TR OL LE R3
CON TR OL LE R4
CON TR OL LE R5
CON TR OL LE R6
CON TR OL LE R7
CON TR OL LE R8
CON TR OL LE R9
CON TR OL LE R10
CON TR OL LE R11
CON TR OL LE R12
Ct1
Ct2
RGB
RGB W
RGB W
RGB W
RGB W
RGB W
RGB W
RGB W
NON E
2
3
4
5
6
7
8
9
10
11
12
ZONE N AM E LIN K
Zone Set
TYPE
Back
CON TR OL LE R1 D IM
1
CON TR OL LE R2
CON TR OL LE R3
CON TR OL LE R4
CON TR OL LE R5
CON TR OL LE R6
CON TR OL LE R7
CON TR OL LE R8
CON TR OL LE R9
CON TR OL LE R10
CON TR OL LE R11
CON TR OL LE R12
Ct1
Ct2
RGB
RGB W
RGB W
RGB W
RGB W
RGB W
RGB W
RGB W
NON E
2
3
4
5
6
7
8
9
10
11
12
9
10
11
12
13
14
15
Select type
Cancel
DIM
CT1
CT2
RGB
RGBW
Devic e List
234
56 7
1
8
10 11 12 9
WiFi-104-SS ID-0
32:AA:3C:7E :B4:DA
Network
Zone
Conne ct to Wi Fi-10 4-SSI D-1
Zone
Return
Type
Turn on
Turn off
Zone Set InterfaceDevice List Interface Select Type Interface
Zone name
Zone number
14:17 PM 100% 14:17 PM 100% 14:17 PM 100%
ŸLearning ID
Short press "ID learning button" on the receiver, the running light go ash to keeps on. Then select
the zone number on the software interface and touch the color bar for 2-3 seconds. Long buzzer
means (meantime the running light returns to ash), zone control and master control matched
G152 R87 B2 55 W2 55
W
80% 8 0%
Name
Long press to turn off single zone or group
Mode
Device Scene
Group On/off
2 3 456
78
RGBW
1
RGB CT1 R GB
RGBW
10 11 12
9
RGBW DIM
Group1 Grou p2 Group3
DIM
DIM RGBW RG BW
CT2
14:17 PM 100%
2
3
Zone number
Color Bar
1
ID learning button
ŸCancelling ID
Long press” ID learning button” for 5 seconds, If success, Buzzer will sound long and louder
5LED World Inc. | #130 10615 48 ST SE | CALGARY, AB T2C 2B7 | CANADA
Copyright © 2015 LED WORLD INC™. All Rights Reserved. We are not responsible for errors or omissions. Product and specications subject to change without notice. Registered trademarks are owned by their respective registers, or licensee(s).

www.ledworldlighting.com WiFi-104 Wi-Controller
D). Group
ŸGroup can control several zones at the same time, and several zones can adjust color, color
temperature and brightness together.
ŸYou can set upto 3 groups, all zones at the same groups must be the same type, and one zone can
belong to multiple groups simultaneously.
ŸSelect the group, then the corresponding group will appear in the main interface
ŸIt will automatically cancel the relevant zone group settings as you changed the type or set up
enabled status of the zone at the Zone Set interface.
Groups
Back
1
RGB
234
RGBW CT1
5
9
DIM
RGBW
6
10
7
11
8
12
RGB
RGBW
DIM
RGBW
RGBW
DIM
Group1 Group2 Group3
Only the same type of z one c an gro up
Group name Ent gr ou p nam e
Use this group
CT2
Group Selection
Group Name
Open the Group
Group Interface
Zone Selection
Group operations in main interface
G255 R255 B255 W2 55
W
80% 8 0%
Name
Long press to turn off single zone or group
Mode
Device Scene
Group On/off
2 3 456
78
RGBW
1
RGB CT1 R GB
RGBW
10 11 12
9
RGBW DI M
Group1 Group2 Group3
DIM
DIM RGBW R GBW
CT2
14:17 PM 100% 14:17 PM 100%
E). Mode Interface for RGB / RGBW Type
Mode
Back
Long pr ess can c hoos e to chan ge the cu rrent p attern type s
CustomDefault
2
4
40%
Set Play
23
Strob e
1
Jump
4
Fadein dimming
6
Gradu al
7
Strob e
5
Jump
8
Fadein dimming
Gradu al
10
Gradu al
11
Strob e
9
Jump
12
Fadein dimming
Combined cycle set to play
Cancel
2
Gradu al
3
Strob e
1
Jump
4
6
Gradu al
7
Strob e
5
Jump
8
10
Gradu al
11
Strob e
9
Jump
12
Fadein dimming
Fadein dimming
Fadein dimming
OK
Mode
Back
Long pr ess can c hoos e to chan ge the cu rrent p attern type s
CustomDefault
2
4
40%
Set Play
23
Strob e
1
Jump
4
Fadein dimming
6
Gradu al
7
Strob e
5
Jump
8
Fadein dimming
Gradu al
10
Gradu al
11
Strob e
9
Jump
12
Fadein dimming
Mode
Back
2
Gradual
3
Strobe
Long pr ess can c hoos e to chan ge the cu rrent p attern type s
CustomDefault
4
40%
W 40%
1
Jump
4
Slowly fade
The c urren t selec ted col or comb inati on
6
Gradual
7
Strobe
5
Jump
8
Slowly fade
10
Gradual
11
Strobe
9
Jump
12
Slowly fade
2Select Style
Cancel
Jump
Gradual
Strobe
Fadein dimming
Mode
Back
Long pr ess can c hoos e to chan ge the cu rrent p attern type s
CustomDefault
2
4
40%
Set Play
23
Strob e
1
Jump
4
Fadein dimming
6
Gradu al
7
Strob e
5
Jump
8
Fadein dimming
Gradu al
10
Gradu al
11
Strob e
9
Jump
12
Fadein dimming
Changing mode
preset changing mode
Speed Adjustment
Mode Interface
Brightness Adjustment
Play in a loop
Select the type of changing effect
(skipping/ash/smooth/fade)
14:17 PM 100% 14:17 PM 100% 14:17 PM 100% 14:17 PM 100%
F). DIY Interface
Mode
Back
Long pr ess can c hoos e to chan ge the cu rrent p attern types
CustomDefault
2
4
40%
Set Play
23
Strob e
1
Jump
4
Fadein dimming
6
Gradu al
7
Strob e
5
Jump
8
Fadein dimming
Gradu al
10
Gradu al
11
Strob e
9
Jump
12
Fadein dimming
Edit Back Apply
Select Color
Color Edit
Lon g press t o delet e singl e color
G255 R0B0
current color combination
Back Apply
Select Color
Color Edit
Lon g press t o delet e singl e color
G255 R255 B255
current color combination
Edit DIY Mode
DIY mode
Play single DIY Mode
Playback Loop
several DIY mode
DIY Mode interface
Save DIY
Color Frame
Edit single DIY Mode Edit single DIY Mode
14:17 PM 100% 14:17 PM 100% 14:17 PM 100%
G). Scene Interface
Scene
Scene 2
Scene 4
Back
Save
Play
Save
Play
Scene 3
Save
Play
Save
Scene 1
Save
Play
Scene
Scene 2
Scene 4
Back
Save
Play
Save
Play
Scene 3
Save
Play
Save
Scene 1
Save
Play
Scene
Scene 2
Scene 3
Scene 4
Back
Scene 1
Cancel OK
Scene name
Scene1
Photo Setting
Cancel
Use Cam era
Photo L ibr ary
Remov e Pho to
Scene Background
Click to change background
Play the scenes
Play the scenes
Saving the current scene
Change the scene background Save scene interface
14:17 PM 100% 14:17 PM 100% 14:17 PM 100%
Long
Press
Short
Press
combine changing mode
Long press color mode
to delete
6LED World Inc. | #130 10615 48 ST SE | CALGARY, AB T2C 2B7 | CANADA
Copyright © 2015 LED WORLD INC™. All Rights Reserved. We are not responsible for errors or omissions. Product and specications subject to change without notice. Registered trademarks are owned by their respective registers, or licensee(s).

www.ledworldlighting.com WiFi-104 Wi-Controller
5. WiFi Network SSID Name and Password Setting
In Device list interface, click “Network key” to enter Network interface, select “Change SSID and
Password” (Click” ” ) to enter User Setting. Type new SSID name and password . (Min: 8 Characters,
consist of 0-9, a-z and A-Z). Click “Apply” button to save the changes.
Network
Back
User setting
Wireless mode
Connect to existing LAN
Change SSID and password
14:17 PM 100%
User Setting
SSID
Passw ord
WiFi- 104- SSID- 0
Ent the new Password
Back
Restore factory setting s
Change the SSID name and password Apply
14:17 PM 100%
User Setting
Accoun
Change the account name and password
SSID
Passw ord
Ltech -WiF i-104 -0
Ent the new Password
Admin
Password
Restore factory setting s
Change the SSID name and password
Cancel OK
Change the SSID password
Ent the NEW Password
Ent the NEW Password again
Back
14:17 PM 100%
Device List
234
56 7
1
8
10 11 12 9
WiFi-104-SSID-0
32:AA:3C :7E:B4:DA
Network
Zone
Conne ct to WiF i-104 -SSID-1
14:17 PM 100%
1.Device Lists 2.Network interface 3.Change SSID name interface 4.Change SSID password
Note: In connection with WiFi-104 as a router, please exit software after changed the SSID name and
the password, then enter the mobile device system setting to reconnect the WiFi-104. In additional
wireless router connection, click in Device List interface to search again the WiFi-104 controller
after SSID name change.
Note: If you forget the WiFi network password, please simultaneously press : and more than 2s
to restore the factory default settings, It will wipe-out WiFi network password (More details on page 3
[Restore factory settings/Delete password]
SCENE
MATCH
6. Remote operating Instructions
Learning ID
Short press learning key in WiFi-104 controller. Long buzzer will sound, then press any keys on M12
remote, Long buzzer will sound again.
MATCH
Cancel ID
Long press learning key in WiFi-104 controller for more than 6s, long buzzer will sound. Which will
cancel ID (cancel all learned remotes with WiFi-104 ).
MATCH
Turn on zone
Short press to play scene
Long press to save scene
synchronization for 12 zones
Turn off zone
Short press to turn off all zones
Short press to turn on all zones
Long press to turn on the key tone
Long press to turn off keyt one
( Long press to decrease brightness,
under the mode of dimming or color temperature)
( Long press to increase brightness,
under the mode of dimming or color temperature)
7. Wiring Diagram
1). Connect to the zones controller and LED Lights (the same way of WiFi-104 connection)
Note : WiFi-104 default to rst zone, Master controller can choose whether connecting to LED Lights or
not. If not, use wireless control to instead of the rst zone.
Multiple partitions can be set to the same type or several types, such as all partitions are single color,
can be set to DIM dimmer light type, such as dimmer, color temperature, RGB, and other types of
lamps, different partition set to different types of lamps, the lamps connection diagram as follows:
7LED World Inc. | #130 10615 48 ST SE | CALGARY, AB T2C 2B7 | CANADA
Copyright © 2015 LED WORLD INC™. All Rights Reserved. We are not responsible for errors or omissions. Product and specications subject to change without notice. Registered trademarks are owned by their respective registers, or licensee(s).

8
www.ledworldlighting.com WiFi-104 Wi-Controller
DC5V-24V
+
B
R
G
+
B
R
G
511
511
331
511
511
331 331
511
511
331
511
511
331 331
+
B
R
G
+
B
R
GZone 4
DC5V-24V
121
121 121
121
121 121
121
121
121
121 121
121
121 121
w
ww
121
121
cw
Zone 3
DC5V-24V
121
121 121
121
121 121
121
121
121
121 121
121
121 121
w ww
121
121
Zone 2
DC5V-24V
RUN
121
121 121
121
121 121
121
121
121
121 121
121
121 121
121
121
121
121
121
121
121
121
121
121
121
121 121
121
121 121
121
121
121
121 121
121
121 121
121
121
121
121 121
121
121 121
121
121
121
121 121
121
121 121
121
121
121
121 121
121
121 121
121
121
Zone 1
DC5V-24V
+
B
R
G
W
+
B
R
G
W
+
B
R
G
W
+
B
R
G
WZone 5
Single color strip
Nature white/Warm white strip
Nature white + Warm white + Cold white strip
RGB strip
RGBW strip
M12
WiFi -104
G255 R255 B2 55 W2 55
W
80% 80%
CONTROLLER1
Long press to turn off single zone or group
ModeDevice Scene
Group On/off
2 3 456
78
RGBW
1
RGB CT1 RGB
RGBW
10 11 12
9
RGBW DIM
Group1 Group2 Group3
DIM
DIM RGBW RGBW
CT2
Mobile phone
DIM
CT
CCT
RGB
RGBW
RUN R UN RUN RUN
LED World Inc. | #130 10615 48 ST SE | CALGARY, AB T2C 2B7 | CANADA
Warning: Input voltage must be identical to output voltage of the LED Fixture!
Exposed wire should not be more than 6- 8 mm long & solder tip (tinned). Do not allow Wires to
cross and insure all exposed wire is fully inserted into the screw terminals. Hand tighten screw
terminals. Use 22 to 16 AWG gauge wire for output terminals.
WIRE 6-8 MM (0.25-0.30")
Copyright © 2015 LED WORLD INC™. All Rights Reserved. We are not responsible for errors or omissions. Product and specications subject to change without notice. Registered trademarks are owned by their respective registers, or licensee(s).

www.ledworldlighting.com WiFi-104 Wi-Controller
3). Connect by a router
(Max 12 Zones)
R4-5A
R4-5A
R4-5A
R4-5A
R4-5A
R4-5A
R4-5A
R4-5A
R4-5A
R4-5A
R4-5A
zone 3
zone 4
zone 5
zone 6
zone 7
zone 8
zone 9
zone 10
zone 11
zone 12
zone 2
zone 1
(Max 12 Zones)
R4-5A
R4-5A
R4-5A
R4-5A
R4-5A
R4-5A
R4-5A
R4-5A
R4-5A
R4-5A
R4-5A
zone 3
zone 4
zone 5
zone 6
zone 7
zone 8
zone 9
zone 10
zone 11
zone 12
zone 2
zone 1
Multiple zone receiver R4-5A can be installed for each zone within effective range
A B
A B
Wireless
Router
9LED World Inc. | #130 10615 48 ST SE | CALGARY, AB T2C 2B7 | CANADA
2). Direct connection of WiFi-104 as router
(Max 12 Zones)
R4-5A
R4-5A
R4-5A
R4-5A
R4-5A
R4-5A
R4-5A
R4-5A
R4-5A
R4-5A
R4-5A
zone 3
zone 4
zone 5
zone 6
zone 7
zone 8
zone 9
zone 10
zone 11
zone
12
zone 2
zone 1
Copyright © 2015 LED WORLD INC™. All Rights Reserved. We are not responsible for errors or omissions. Product and specications subject to change without notice. Registered trademarks are owned by their respective registers, or licensee(s).

www.ledworldlighting.com WiFi-104 Wi-Controller
8. Limited Warranty
We provide lifelong technical assistance with this product
A 1-year Limited factory warranty from the date of purchase. The warranty is for free repair or
replacement and covers manufacturing faults only.
10 LED World Inc. | #130 10615 48 ST SE | CALGARY, AB T2C 2B7 | CANADA
4). Remote Distance Reference
Note: The following distance is measured at distance open environment, in an open environment
testing wireless distance will be reduced, please refer to our actual test distance before installation.
WiFi-104
Master controller
R4-5A/R4-CC
Slave controller
M12 Remote
50m
30m
100m100m
Mobile phone Router
Copyright © 2015 LED WORLD INC™. All Rights Reserved. We are not responsible for errors or omissions. Product and specications subject to change without notice. Registered trademarks are owned by their respective registers, or licensee(s).
1
9. Federal Communications Commission (FCC) Statement
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions:
This device may not cause harmful interference, and This device must accept any interference received, including
interference that may cause undesired operation.
Note: The manufactures is not responsible for any radio or tv interference caused by unauthorized modications to
this equipment. Such modications could void the user's authority to operate the equipment.
