Ledj Slimline 3HEX12 Series User manual

Order codes:
LEDJ71 - Black housing
LEDJ71A - White housing
Slimline 3HEX12 Series
3 x 12W 6-in-1 colour LEDs
(RGBAWUV)
User Manual
Optional
IR remote
Order ref:
LEDJ90F
Convection
cooled,
no fan!

www.prolight.co.uk Slimline 3HEX12 Series User Manual 2
Safety advice
WARNING
FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL
CAREFULLY BEFORE YOUR INITIAL START-UP!
• Beforeyourinitialstart-up,pleasemakesurethatthereisnodamagecausedduringtransportation.
• Shouldtherebeanydamage,consultyourdealeranddonotusetheequipment.
• Tomaintaintheequipmentingoodworkingconditionandtoensuresafeoperation,itisnecessary
fortheusertofollowthesafetyinstructionsandwarningnoteswritteninthismanual.
• Pleasenotethatdamagescausedbyusermodicationstothisequipmentarenotsubjecttowarranty.
IMPORTANT:
The manufacturer will not accept liability for any resulting damages caused by the non-observance
of this manual or any unauthorised modication to the equipment.
OPERATING DETERMINATIONS
Ifthisequipmentisoperatedinanyotherway,thanthosedescribedinthismanual,theproductmaysufferdamageand
thewarrantybecomesvoid.Incorrectoperationmayleadtodangere.g:short-circuit,burnsandelectricshocksetc.
Donotendangeryourownsafetyandthesafetyofothers!
Incorrectinstallationorusecancauseseriousdamagetopeopleand/orproperty.
• Neverletthepowercablecomeintocontactwithother
cables.Handlethepowercableandallmainsvoltage
connectionswithparticularcaution!
• Neverremovewarningorinformativelabelsfromtheunit.
• Donotopentheequipmentanddonotmodifytheunit.
• Donotconnectthisequipmenttoadimmerpack.
• Donotswitchtheequipmentonandoffinshortintervals,
asthiswillreducethesystem’slife.
• Onlyusetheequipmentindoors.
• Donotexposetoammablesources,liquidsorgases.
• Alwaysdisconnectthepowerfromthemainswhen
equipmentisnotinuseorbeforecleaning!Onlyhandle
thepower-cablebytheplug.Neverpullouttheplugby
pullingthepower-cable.
• Makesurethattheavailablevoltageisbetween
110~240V,50/60Hz.
• Makesurethatthepowercableisnevercrimpedor
damaged.Checktheequipmentandthepowercable
periodically.
• Iftheequipmentisdroppedordamaged,disconnectthe
mainspowersupplyimmediatelyandhaveaqualied
engineerinspecttheequipmentbeforeoperatingagain.
• Iftheequipmenthasbeenexposedtodrastic
temperatureuctuation(e.g.aftertransportation),
donotconnectpowerorswitchitonimmediately.
Thearisingcondensationmightdamagetheequipment.
Leavetheequipmentswitchedoffuntilithasreached
roomtemperature.
• Ifyourproductfailstofunctioncorrectly,stopuse
immediately.Packtheunitsecurely(preferablyinthe
originalpackingmaterial),andreturnittoyourProLight
dealerforservice.
• Onlyusefusesofsametypeandrating.
• Repairs,servicingandpowerconnectionmustonlybe
carriedoutbyaqualiedtechnician.THISUNITCONTAINS
NOUSERSERVICEABLEPARTS.
• WARRANTY:Oneyearfromdateofpurchase.
CAUTION!
KEEP THIS EQUIPMENT
AWAY FROM RAIN,
MOISTURE AND LIQUIDS
CAUTION!
TAKE CARE USING
THIS EQUIPMENT!
HIGH VOLTAGE-RISK
OF ELECTRIC SHOCK!!

www.prolight.co.uk Slimline 3HEX12 Series User Manual 3
Product overview & technical specications
Housing3x12W6-in-1colourLEDs,theSlimline3HEX12givessmoothcolourmixingfromrichsaturatedhues
tosubtlepastelshades.Theseunitshaverugged,allmetalhousingandmeasureonly124mmindepthforeasy
transportationandinstallation.Theyarealsoconvectioncooledforsilentoperationandfeaturea30°beam
angle.The4pushbuttonLEDmenuoroptionalIRremotealloweasyaccesstothefunctionsincludingDMX,
master/slave,soundactiveandstandalone.
•3x12W6-in-1colourLEDs(RGBAWUV)
•Beamangle:30°(eldangle:35°)
•1.2kHzrefreshrate
•DMXchannels:2/3/3/4/4/5/6or9selectable
•Staticcolour,colourchange,colourfade,autorun,
soundactiveandmaster/slavemodes
•0-100%dimmingwithvariablestrobe
•Bracketallowsformultipleriggingand
oorstandingapplications
•Rearcontrolpanelandrubberfeetallowthe
paneltositatontheoorforuplighting
•4pushbuttonmenuwithLEDdisplay
•SideentryXLRandpowerconnections
•IECpowerin/outsockets
•3-pinXLRin/outsockets
•Convectioncooled
•OptionalIRremote(LEDJ90F)
Slimline 3HEX12 Series
Specications Slimline 3HEX12
Powerconsumption 45W
Powersupply 110~240V,50/60Hz
Fuse F1A250V
Dimensions 185x175x124mm
Weight 1.7kg
Ordercode LEDJ71-Blackhousing
Ordercode LEDJ71A-Whitehousing
0m 1m 2m 3m 4m 5m
30° - Lux 3160 864 397
30°
223 128
175mm 124mm
185mm

www.prolight.co.uk Slimline 3HEX12 Series User Manual 4
Technical specications
01-Bracket
02-Brackettighteningknobs
03-Earthpoint
04-LEDdisplay
05-Functionbuttons
06-DMXinputsocket
07-DMXoutputsocket
08-IECpowerinsocket
09-IECpoweroutsocket
10-FuseF1A250V Inthebox:1 x xture,
1 x power cable &
1 x user manual
0810 09 03 07 06
ENTER DOWN
MODE
UP
SLIMLINE 3HEX12
www.prolight.co.uk
POWER IN POWER OUT DMX OUT DMX IN
02
04
05
01
PUSH

www.prolight.co.uk Slimline 3HEX12 Series User Manual 5
Operating instructions
DMX channel mode:
OperatinginaDMXcontrolmodeenvironmentgivestheuserthegreatestexibilitywhenitcomesto
customisingorcreatingashow.Inthismodeyouwillbeabletocontroleachindividualtraitofthexture
andeachxtureindependently.
ToaccesstheDMXchannelmode,pressthe“MODE”buttonontherearoftheunittoshow-CH
ontheLEDdisplay.Nowpressthe“ENTER”buttonandusethe“UP”and“DOWN”buttonstosetthe
desiredDMXaddress.Nowpressthe“ENTER”buttontochooseoneofthe2,3,3,4,4,5,6or9DMX
channelmodes.Usethe“UP”and“DOWN”buttons,andpressthe“ENTER”buttontoconrmthesetting.
Toexitoutofanyoftheaboveoptions,pressthe“MODE”button.
Channel Value Function
1000-255 Masterdimmer(0-100%)
2
000-255colourmacro
000-016 Red
017-033 Green
034-050 Blue
051-067 White
068-084 Amber
085-101 UV
102-118 Yellow(R-255,G-200,A-255)
119-135 Cyan(G-255,B-255)
136-152 Lavender(R-170,B-210)
153-169 Brightgreen(G-255,A-180)
170-186 Magenta(R-255,B-90,UV-255)
187-203 Turquoise(G-255,B-180,UV-255)
204-220 Orange(R-200,A-200)
221-237 Coolwhite(R-70,G-190,B-255,A-200)
238-255 Warmwhite(R-230,G-255,B-255,A-255,W-255)
2 channel mode:

www.prolight.co.uk Slimline 3HEX12 Series User Manual 6
Operating instructions
Channel Value Function
1000-255 Red(0-100%)
2000-255 Green(0-100%)
3000-255 Blue(0-100%)
Channel Value Function
1000-255 Masterdimmer(0-100%)
2000-255 Flash(speed0-100%,1Hz-20Hz)
3000-004 Blackout
005-010 Red
011-015 Green
016-020 Blue
021-025 White
026-030 Amber
031-035 UV
036-040 Yellow(R-255,G-200,A-255)
041-045 Cyan(G-255,B-255)
046-050 Lavender(R-170,B-210)
051-055 Brightgreen(G-255,A-180)
056-060 Magenta(R-255,B-90,UV-255)
061-065 Turquoise(G-255,B-180,UV-255)
066-070 Orange(R-200,A-200)
071-075 Coolwhite(R-70,G-190,B-255,A-200)
076-080 Warmwhite(R-230,G-255,B-255,A-255,W-255)
081-150 Colourjumpingspeed
Slowest(081)changesevery8secs
Fastest(150)changesevery0.3secs
151-220 Colourfadingspeed
Slowest(151)changesevery8secs
Fastest(220)changesevery0.3secs
221-255 Soundcontrol(micsensitivity)
3 channel mode 1:
3 channel mode 2:
Channel Value Function
1000-255 Red(0-100%)
2000-255 Green(0-100%)
3000-255 Blue(0-100%)
4000-255 White(0-100%)
Channel Value Function
1000-255 Red(0-100%)
2000-255 Green(0-100%)
3000-255 Blue(0-100%)
4000-255 Amber(0-100%)
Channel Value Function
1000-255 Red(0-100%)
2000-255 Green(0-100%)
3000-255 Blue(0-100%)
4000-255 White(0-100%)
5 000-255 Amber(0-100%)
Channel Value Function
1000-255 Red(0-100%)
2000-255 Green(0-100%)
3000-255 Blue(0-100%)
4000-255 White(0-100%)
5 000-255 Amber(0-100%)
6 000-255 UV(0-100%)
4 channel mode 1: 4 channel mode 2:
5 channel mode: 6 channel mode:

www.prolight.co.uk Slimline 3HEX12 Series User Manual 7
Operating instructions
Channel Value Function
1000-255 Masterdimmer(0-100%)
2000-255 Flash(speed0-100%,1Hz-20Hz)
3000-255 Red(0-100%)
4000-255 Green(0-100%)
5 000-255 Blue(0-100%)
6 000-255 White(0-100%)
7 000-255 Amber(0-100%)
8000-255 UV(0-100%)
9 000-004 Blackout
005-010 Red
011-015 Green
016-020 Blue
021-025 White
026-030 Amber
031-035 UV
036-040 Yellow(R-255,G-200,A-255)
041-045 Cyan(G-255,B-255)
046-050 Lavender(R-170,B-210)
051-055 Brightgreen(G-255,A-180)
056-060 Magenta(R-255,B-90,UV-255)
061-065 Turquoise(G-255,B-180,UV-255)
066-070 Orange(R-200,A-200)
071-075 Coolwhite(R-70,G-190,B-255,A-200)
076-080 Warmwhite(R-230,G-255,B-255,A-255,W-255)
081-150 Colourchangespeed
Slowest(081)changesevery8secs
Fastest(150)changesevery0.3secs
151-220 Colourfadingspeed
Slowest(151)changesevery8secs
Fastest(220)changesevery0.3secs
221-255 Soundcontrol(micsensitivity)
9 channel mode:

www.prolight.co.uk Slimline 3HEX12 Series User Manual 8
RGBAWUV colour mix mode:
Inthismodeyoucansetthexturetoanycolourandanybrightness.
Toaccessthecolourmixmode,pressthe“MODE”buttonontherearoftheunittoshow C1--
with3digitsafterontheLEDdisplay.Pressthe“ENTER”buttontoconrm.
TheC1representsred,C2=green,C3=blue,C4=white,C5=amber,C6=UVandCF0=strobe.
The2digitsafterarethebrightnesssettingfrom 00~99,orthestrobespeedifinCF0.
For example:
Ifyouset1,2,3,4,5and6alltozero,yourunitwillhavenoLEDslitup(blackout).
IfyousetC100toC199and2,3,4,5and6tozero,yourunitwillshowonlyredLEDs.
Pressthe“ENTER”buttontoconrmthesettingandmovetothenextcolour.
Toexitoutofanyoftheaboveoptions,pressthe“MODE”button.
Colour fade mode:
Toaccessthecolourfademodepress“ENTER”untilthedisplayshowsFA--ontheLEDdisplay.
Toadjustthespeedusethe“UP”and“DOWN”buttonstoselectanyvaluefromFA00~FA99.
Toselectthestrobemodepress“ENTER”,theLEDdisplaywillchangetoFF--,usingthe“UP”and
“DOWN”buttonstoselectanyvaluefromFF00~FF99.
Value: 00 - 99 (00 = low, 99 = high)
Toexitoutofanyoftheaboveoptions,pressthe“MODE”button.
Colour change mode:
Toaccessthecolourchangemodepress“ENTER”untilJU--showsontheLEDdisplay.Toadjust
thespeedusethe“UP”and“DOWN”buttonstoselectanyvaluefromJA00~JA99.Toselectthe
strobemodepress“ENTER”,thedisplaywillchangetoJF--,usingthe“UP”and“DOWN”buttons
toselectanyvaluefromJF00~JF99.
Value: 00 - 99 (00 = low, 99 = high)
Toexitoutofanyoftheaboveoptions,pressthe“MODE”button.
Master/slave mode:
Tosetthemasterunit,pressthe“MODE”buttonontherearofthemasterunitthenselectyour
desiredprogram(soundactive,auto,staticcolour,colourmixoroneofthebuilt-inprograms).
Tosettheotherunitsinslavemode,pressthe“MODE”buttonontherearoftheunittoshowSLAU
ontheLEDdisplayandpressthe“ENTER”buttontoconrmthesetting.Theunitswillnowrunin
sequencewiththemasterunit.
Toexitoutofanyoftheaboveoptions,pressthe“MODE”button.
PleaseensurethatallslaveunitsaresettothesameDMXchannelmodeasthemasterunit.
Operating instructions

www.prolight.co.uk Slimline 3HEX12 Series User Manual 9
Sound active mode:
Toaccessthesoundactivemode,pressthe“MODE”buttonontherearoftheunittoshowSU00
ontheLEDdisplay.Nowpressthe“ENTER”buttonandusethe“UP”and“DOWN”buttonstosetthe
soundsensitivitylevelfromSU.00~SU.99andpressthe“ENTER”buttontoconrmthesetting.
Value: 00 - 99 (00 = low, 99 = high)
Toexitoutofanyoftheaboveoptions,pressthe“MODE”button.
Auto run mode:
Toaccesstheautorunmode,pressthe“MODE”buttontoshowAUtOontheLEDdisplay.
Thexturewillthenautomaticallyscrollthroughcolourfadeandcolourchange.Thespeed/ashrate
isnotadjustable.
Pressthe“ENTER”buttontoconrmthesetting.
Toexitoutofanyoftheaboveoptions,pressthe“MODE”button.
Colour preset mode:
Toaccessthecolourpresetmode
press“ENTER”untilCn--shows
ontheLEDdisplay.Toadjustthe
colourusethe“UP”and“DOWN”
buttonstoselectanyvalue
fromCn01~Cn15.
Pressthe“ENTER”buttonto
conrmthesetting.
Toexitoutofanyoftheabove
options,pressthe“MODE”button.
Operating instructions
Staticcolourmode C1.00~C1.99R
C2.00~C2.99G
C3.00~C3.99B
C4.00~C4.99W
C5.00~C5.99A
C6.00~C6.99U
CF.00~CF.99Flash
Colourmacromode
Cn01-15
Cn01-Red
Cn02-Green
Cn03-Blue
Cn04-White
Cn05-Amber
Cn06-UV
Cn07-Yellow
Cn08-Lightblue
Cn09-Pink
Cn10-Lightgreen
Cn11-Rosepink
Cn12-Peacockblue
Cn13-Orange
Cn14-Pastelblue/white
Cn15-White
Colourchangingmode JU00~JU99(speed)
JF00~JF99(ash)
Colourfademode FA00~FA99(speed)
FF00~FF99(ash)
Automode AUTO
Slavemode SLAV
Soundactivemode SU00~SU99
DMXmode 2CH,3CH1,3CH2,4CH1,4CH2,5CH,
6CH,9CH
Addresssetting A001~A512
Menusystem

www.prolight.co.uk Slimline 3HEX12 Series User Manual 10
Operating instructions
Optional IR remote functions:
Button functions:
DMX address examples:
Important notes:
• SettheDMXaddressoneachxturebeforepluggingintotheDMXcontroller
• TheIRremoteiscannotbeusedwhenthexture(s)arebeingcontrolledwithaDMXcontroller
• ThemaximumIRtransmitterdistanceis10m-PleasemakesurethatyouhavetheIRremoteaimed
directlyatthefrontpanelofeachxturetobeprogrammed
• Ifyoudonotpressthe“DMXMODE”buttonafteryouhavechangedtheDMXaddresswhenyou
powerdownthextureitwilllosetheaddressyouhaveset
01-SetstheLEDsintopoweronoroffmodes
02-Setsinautorun
03-Runsthebuilt-inprograms,usethe‘+’and‘-’
buttonstogothroughtheprograms
04-SetstheLEDstoashonandoff,usethe‘+’
and‘-’buttonstochangetheashfrequency
05-Setstherunspeed,usethe‘+’and‘-’buttons
tochangethedesiredspeed(note:onlyavailablein
thecolourchangeorcolourfademodes)
06-SetstheLEDsintoDMXmode
07-SetstheLEDsintosoundactivemode
08-SetstheLEDsintoslavemode
09-SetstheDMXaddressfortheLEDs
10-SetstheLEDscolour,usethe‘+’and‘-’
buttonstochangethebrightness
1 2 3
4 5 6 0
+
_
7 8 9
AR
D
FL
SL
SP
S
S PR
SA
RG B
WAUV
BLACKOUT DIMMING
FLASH
SLAVE
SPEED
SET ADDR
SELECT PROG
SOUND ACTIVE
AUTO RUN
DMX MODE
03
01
04
10
02 05
07 08
06 09
TosettheDMXaddress“245”;
• Pressthe“S”button,theredLEDswillcomeon,
youcannowstarttosettheDMXaddress
• Nowpressthe“2”button,thegreenLEDswill
comeon,thismeanstherstdigithasbeen
setat2
• Nowpressthe“4”button,theblueLEDswill
comeon,thismeanstheseconddigithasbeen
setat4
• Nowpressthe“5”button,andallofthe
R,G,B,A,WandUVLEDswillcomeon,
thethirddigit5hasbeenset.ThefullDMX
addresssettinghasbeenchanged
• Nowpressthe“DMXMODE”buttontosave
thenewaddressintothememory
TosettheDMXaddress“002”;
• Pressthe“S”button,theredLEDswillcomeon,
youcannowstarttosettheDMXaddress
• Nowpressthe“0”button,thegreenLEDswill
comeon,thismeanstherstdigithasbeen
setat0
• Nowpressthe“0”button,theblueLEDswill
comeon,thismeanstheseconddigithasbeen
setat0
• Nowpressthe“2”button,andallofthe
R,G,B,A,WandUVLEDswillcomeon,
thethirddigit2hasbeenset.ThefullDMX
addresssettinghasbeenchanged
• Nowpressthe“DMXMODE”buttontosave
thenewaddressintomemory
Optional
IR remote
Order code:
LEDJ90F

www.prolight.co.uk Slimline 3HEX12 Series User Manual 11
Setting the DMX address:
TheDMXmodeenablestheuseofauniversalDMXcontroller.Eachxturerequiresa“startaddress”
from1-512.Axturerequiringoneormorechannelsforcontrolbeginstoreadthedataonthechannel
indicatedbythestartaddress.Forexample,axturethatoccupiesoruses7channelsofDMXandwas
addressedtostartonDMXchannel100,wouldreaddatafromchannels:100,101,102,103,104,105
and106.Chooseastartaddresssothatthechannelsuseddonotoverlap.E.g.thenextunitinthe
chainstartsat107.
DMX 512:
DMX(DigitalMultiplex)isauniversalprotocolusedasaformofcommunicationbetweenintelligent
xturesandcontrollers.ADMXcontrollersendsDMXdatainstructionsformthecontrollertothexture.
DMXdataissentasserialdatathattravelsfromxturetoxtureviatheDATA“IN”andDATA“OUT”
XLRterminalslocatedonallDMXxtures(mostcontrollersonlyhaveadata“out”terminal).
DMX linking:
DMXisalanguageallowingallmakesandmodelsofdifferentmanufacturestobelinkedtogether
andoperatefromasinglecontroller,aslongasallxturesandthecontrollerareDMXcompliant.
ToensureproperDMXdatatransmission,whenusingseveralDMXxturestrytousetheshortest
cablepathpossible.TheorderinwhichxturesareconnectedinaDMXlinedoesnotinuencethe
DMXaddressing.Forexample;axtureassignedtoaDMXaddressof1maybeplacedanywherein
aDMXline,atthebeginning,attheend,oranywhereinthemiddle.Whenaxtureisassigneda
DMXaddressof1,theDMXcontrollerknowstosendDATAassignedtoaddress1tothatunit,
nomatterwhereitislocatedintheDMXchain.
DATA cable (DMX cable) requirements (for DMX operation):
ThisxturecanbecontrolledviaDMX-512protocol.TheDMXaddressissetonthebackoftheunit.
YourunitandyourDMXcontrollerrequireastandard3-pinXLRconnectorfordatainput/output,
seeimagebelow.
Also remember that DMX cable must be daisy chained and cannot be split.
DMX setup
FurtherDMXcablescanbe
purchasedfromallgoodsound
andlightingsuppliersor
ProLightConceptsdealers.
Pleasequote:
CABL10 – 2m
CABL11 – 5m
CABL12 – 10m

www.prolight.co.uk Slimline 3HEX12 Series User Manual 12
Notice:
Besuretofollowthediagramsbelowwhenmakingyourowncables.Donotconnectthecables
shieldconductortothegroundlugorallowtheshieldconductortocomeincontactwiththeXLRs
outercasing.Groundingtheshieldcouldcauseashortcircuitanderraticbehaviour.
Special note:
Line termination:
Whenlongerrunsofcableareused,
youmayneedtouseaterminatoron
thelastunittoavoiderraticbehaviour.
Using a cable terminator will decrease
the possibilities of erratic behaviour.
(3-pin - Order ref: CABL9O, 5-pin - Order ref: CABL89)
5-pin XLR DMX connectors:
Somemanufacturesuse5-pinXLRconnectorsfordatatransmissioninplaceof3-pin.5-pinXLRxtures
maybeimplementedina3-pinXLRDMXline.Wheninsertingstandard5-pinXLRconnectorsintoa
3-pinlineacableadaptormustbeused.Thediagrambelowdetailsthecorrectcableconversion.
Terminationreducessignaltransmission
problemsandinterferance.itisalways
advisabletoconnectaDMXterminal,
(resistance120Ohm1/4W)betweenpin2
(DMX-)andpin3(DMX+)ofthelastxture.
5-pin XLR (socket)
Pin 1: GND (screen)
Pin 2: Signal (-)
Pin 3: Signal (+)
Pin 4: N/C
Pin 5: N/C
3-pin XLR (socket)
Pin 1: GND (screen)
Pin 2: Signal (-)
Pin 3: Signal (+)
3-pin XLR (socket)
Pin 1: GND (screen)
Pin 2: Signal (-)
Pin 3: Signal (+)
5-pin XLR (socket)
Pin 1: GND (screen)
Pin 2: Signal (-)
Pin 3: Signal (+)
Pin 4: N/C
Pin 5: N/C
DMX setup

www.prolight.co.uk Slimline 3HEX12 Series User Manual 13
WEEE notice
Correct Disposal of this Product
(Waste Electrical & Electronic Equipment)
(Applicable in the European Union and other European countries
with separate collection systems)
Thismarkingshownontheproductoritsliterature,indicatesthatitshouldnotbedisposedof
withotherhouseholdwastesattheendofitsworkinglife.Topreventpossibleharmtothe
environmentorhumanhealthfromuncontrolledwastedisposal,pleaseseparatethisfromother
typesofwastesandrecycleitresponsiblytopromotethesustainablereuseofmaterialresources.
Householdusersshouldcontacteithertheretailerwheretheypurchasedthisproduct,ortheir
localgovernmentofce,fordetailsofwhereandhowtheycantakethisitemforenvironmentally
saferecycling.
Businessusersshouldcontacttheirsupplierandcheckthetermsandconditionsofthe
purchasecontract.Thisproductshouldnotbemixedwithothercommercialwastesfordisposal.

www.prolight.co.uk Slimline 3HEX12 Series User Manual 14
Optional accessories
Pleasecontactyourlocalretailertopurchasetheseaccessories.
Tokeepup-to-dateonthelatestaccessoriesandproductrangeadditions
pleasevisitwww.prolight.co.uk
Optional Quad Case (Holds 4 x xtures)
Order code: CASE95
Optional IR remote
Order code: LEDJ90F
1 2 3
4 5 6 0
+
_
7 8 9
AR
D
FL
SL
SP
S
S PR
SA
RG B
WAUV
BLACKOUT DIMMING
FLASH
SLAVE
SPEED
SET ADDR
SELECT PROG
SOUND ACTIVE
AUTO RUN
DMX MODE

www.prolight.co.uk Slimline 3HEX12 Series User Manual 15

www.prolight.co.uk Slimline 7HEX6 Series User Manual 16
