Ledlite Lttp5wifi User manual

12.5cm

11.5cm

12mm

12V

R G B CW

≥5m

3m 120°

1.5cm

7cm

3cm

2700K

6500K

CCT+/-

Random Mode

Selector button

ON/OFF Button

Static monochrome

buttons

(15 colour choices)

Dimming buttons Switch back and forth

2 different colours

User Instructions

Please read these instructions and retain them for future reference.

Important information

It is recommended that the strips are installed by a qualified

electrician ensuring the installation complies with current IEE

wiring regulations & local building control.

These products are designed for connection to a 220-240V

mains supply.

• Input: 220-240 V/AC, 50/60 Hz

• Output Voltage: DC 12V

• Power: 4.8W/m

• Adapter: DC 12V, 2A, 24W

• Length: 5m

• Strip Width: 12mm

• IP Rating: IP65

• Silicone Gel coating

• Self-adhesive Tape for Easy Installation

Speciﬁcations:

Package Contains:

• 1 x 5m Reel of Self-adhesive Tape

• 1 x 12V/DC UK Power Adaptor

• 1 x WiFi Smart Controller

• 1 x 24 Key Remote Control

• Cut to size in 10cm intervals

• 30 x 3 LEDs/m (RGB+W+WW)

• Luminous Flux: 400-450lm/m

• RGB & CCT (2700-6500K) full control

• Dimmable through the APP

• Control Type: Remote and APP

• App Control: 2.4Ghz WiFi using Smart Life APP

• Compatible with Amazon Alexa & Google Home

0 0

• Working Temperature: -25 C~40 C

SCAN THE QR CODE

to download the APP

or search "Smart Life"

on your App Store

or Android Market

by Mobile Phone.

Dimensions:

LTTP5WIFI

Smart Wi-Fi LED Strip 5m kit

RGB & CCT (2700K-6500K)

Installation:

1. Precautions:

• Ensure the installation surface is clear of dirt or dust and clean it thoroughly before use.

• Do not twist the LED strip

• The LED strip has excellent flexibility but requires the bending to be over 60 and the diameter

to be no smaller than 30 mm. All bends need to sweep round, do not use sharp corners (Fig. 1).

CAUTION – Twisting, pressing on LEDs, over-bending the strip, cutting at non-cut points,

incorrectly powering the strip will invalidate the warranty.

IR Remote Control Functions:

3. Tape fitting:

• Remove the self-adhesive backing tape from the strip gradually during installation.

Do not remove it all at once to avoid the strip becoming entangled and sticking to itself.

• Stick the LED strip to the mounting surface by pressing on the strip (Fig. 3).

4. Connect the tape to the supplied adaptor and plug in.

5. Control the tape using the phone APP (see next page for instructions) or the IR remote control.

2. Cutting the tape:

• Unplug the power supply before cutting.

• Measure the tape needed and use sharp scissors to cut it at the marked 10cm intervals (Fig. 2).

Fig. 1

Fig. 2

Fig. 3

● Control Distance: up to 6m

● Random Mode selector button

● Brightness and speed adjustments

● Battery Type: CR2025 (included)

● Replacing the Battery:

150cm

500cm

10cm

90LEDs/m

LTTP5WIFI - Smart Wi-Fi Lamps APP Instructions

After downloading the free Smart Life App from Apple Store or Play Store create

a new account by following these steps:

1. Press "Login"

2. Select Your country code, enter the e-mail address or phone number you want

to use to login and press "Obtain verification code"

3. Enter the code received by e-mail or phone, set your personal password and

press "Completed". Now you can access the pages for the creation of your

Smart Home.

To add your new device open Smart Life APP on "My Home" page, press"+"

in the upper right corner and then " Lighting Devices".

The Application offers two different procedures to add your device:

EZ and AP mode.

Please use the default EZ mode. If it fails, please try again or use AP mode.

Make sure your new device is in EZ mode, otherwise reset it by switching on

light and, after 10 seconds, switching it off then on 3 times. The light will start

blinking quickly (about 3 times per second).

After resetting the device:

1. Press "Confirm light blinks rapidly" (Pic.1). A new page will open (Pic.2).

2. Enter the password of the WiFi network you are connected to and press

"OK" to connect. The WiFi network supported is 2.4Ghz (disable the 5Ghz

WiFi network).

When connecting the device, you can see the connection status as shown in

Picture 3. Once connected, a page will open as shown in Picture 4.

Select the location of the device in your smart home and press "Completed"

to access the control page of your new device.

Now your new light is ready to be controlled via the APP, even remotely.

If the Application shows the page as in Picture 5, it means that the light connection

has failed.

By pressing "Got it" you can try to connect it again in EZ mode or select the AP Mode

by pressing on the top right as shown in Picture 6.

To connect the device in AP mode switch the light on and, after 10 seconds, switch it

off then on 3 times until it flashes quickly (about 3 times per second). Continue

switching the light off then on 3 times and it will start flashing slowly (about once every

3 seconds). At this point press "Confirm light slowly blink" (Pic.7), enter the password

of the WiFi network you are connected to, press "OK" (Pic.8) and you will open the

page as shown in Picture 9. By pressing "Go connect" your mobile phone will take

you to the WiFi Setting page. Select the "Smartlife-XXX" network, go back to the

Smart Life APP and your new device will connect correctly.

After connecting the device, the control page will

be opened automatically.

Here you can do the following:

• Select the colour of the light.

• Change the colour of the white, from warm white

to cool white.

• Dim the light.

• Select one of the scenarios already created

for you.

• Use Schedule to program the switching on and

off at predefined times.

By pressing on the menu symbol at the top right

you can:

• Change the name of your device.

• Select the location of the device in your home.

• Check how to connect it to your voice control

device (Google Home or Amazon Alexa).

• Share control of the device with other family

members or friends.

• Create a group of multiple devices so that you

can control them together.

• Update the device firmware.

• Remove the device.

You can create an infinite number of Scenarios and Automations enabling other devices

to interact with each other.

By pressing "Smart" at the bottom centre of the home page and then "+" in the upper

right corner, you can choose whether to add a new scenario or a new automation.

• A Scenario is a set of commands assigned to the various devices that will be

activated simultaneously whenever you click on the created scenario or in the days

and hours programmed.

• An Automation is the execution of a specific command given to a device when a

specific condition has been activated.

"Me" is the page where you can change your

settings:

1. Your Profile.

2. Home Management.

3. Message Centre.

4. Additional services, such as the list of devices

that can be associated with the application

(Google Home, Amazon Alexa) in order to

control your home via voice commands.

5. Settings to activate push notifications and

other features.

You can share your devices with your family and friends who have downloaded the Smart Live APP and have a registered account. The people you share your devices with

will be able to control them, but they will not be able to add new devices to your home or delete any devices shared with them.

You have two different ways to share your devices:

A. Enter the page of your profile, press "Home Management" and "Share Devices" to enter the page where you can select the devices you want to share.

Enter the e-mail address used in the Smart Life APP by the user you want to share the devices with.

If you want to delete sharing with a user, place your finger on the user's name, drag to the left and then press "Delete".

B. Enter the menu of the device you want to add, press "Shared Devices" and enter the e-mai address used in the Smart Life APP by the user you want to share the devices with.

If you want to delete sharing with a user, place your finger on the user's name, drag to the left and then press "Delete".

Download the Smart Life APP

NO.1

Scan the QR code present on the packaging box or in the instructions to download the APP. You can also

search "Smart Life" in either App Store or Google Play to install the APP.

Add New Device - EZ Procedure Add New Device - EZ Procedure

Connection Failed Add New Device - AP Procedure

Device Control Device Menu

Creation of Scenarios and Automations Profile

Sharing Devices

Note: This item works only on a 2.4GHz WiFi network, not on a 5GHz WiFi network. Please consult the

manual of your router for settings.
