The EasyIP Ecosystem
Vaddio®EasyIP products are designed to be used together. A basic EasyIP system includes an EasyIP
Decoder managing up to four EasyIP cameras. Typically the EasyIP system is powered by a PoE+ switch.
nEasyIP cameras deliver video in Vaddio's proprietary EasyIP format.
nThe decoder is required to convert the cameras' output signal to an IP and/or USB stream.
nThe decoder automatically detects EasyIP cameras on its own subnet.
nThe decoder does not recognize other types of cameras.
nThe decoder can manage cameras in its directory. The administrator adds cameras to the directory.
nCameras are not required to be on the same subnet as the decoder that manages them.
nEasyIP products require PoE+ power.
EasyIP Decoder
The decoder is the central component of any EasyIP installation. Its functions include
nVideo – pair with up to four cameras at a time, control the active camera via web interface, and decode
the camera's AV-over-IP signal.
nAudio – provide connections for two Vaddio microphones and a speaker.
nUSB streaming – UVC-compliant or client-custom USB streaming for conferencing applications.
EasyIP Cameras
EasyIP cameras may be installed anywhere on the network. They require only a PoE+ power connection.
An EasyIP Decoder is needed to decode the AV-over-IP signal.
PoE+ Switch
A PoE+ switch simplifies installation, eliminating the need for PoE+ power injectors and placing all the
connected products on the same subnet.
Caution
Do not connect the PoE+ switch to the network without guidance from an on-site network specialist.
Decoder Features
nUncompressed USB 3.0 streaming
nStreaming video resolutions up to 1080p/60
nFull-duplex audio streaming
nAudio inputs for two Vaddio microphones
nHDMI video output for local display
nUniversal Video Class (UVC) and Universal Audio Class (UAC) drivers supported in Windows®,
macOS®, and Linux operating systems, compatible with most UC conferencing applications
nIntegration-ready Telnet control
nPairs with up to four EasyIP 10 cameras on your network to provide control and manage streaming
nEnterprise-class IT administrative capabilities with full web controls for remote management
Camera Features
n2.14 Megapixel effective, native 1080p/60 full HD image sensor
n10x optical zoom, horizontal field of view of 67°
nResolutions up to 1080p/60
nPrecise pan and tilt movements at up to 90° per second
nIntegration-ready Telnet control
nPairs with an EasyIP Decoder, which provides video and audio connectivity and manages streaming
nJust one cable – the EasyIP connection to a PoE switch
nEnterprise-class IT administrative capabilities with full web controls for remote management
