LEGRAND Tynetec AidCall Alarm Pullcord User manual

DocNo.FM0466issueFPage1
169MHzTelecareDevices
AlarmPullcord
__________________________________________________________________________________________________________


CompatiblewithReachat‐homealarms,Adventxtwardencall
andAltecResponselocalcareralarms
Ceilingmountedmomentaryactionswitch
2.7metreorangecordwith2triangulargrips
Anti‐ligaturesafetybreak
Lowbatterywarning
Dimensions:87mmdiameterx35mmdeep
Weight:85grams
ProductCode:ZXT435


WhereshouldAlarmPullcordsbefitted?

Alarmpullcordsshouldbeceilingmountedinbathrooms,alongsidethe
bedoranywherepersonalpendantsarenotusuallyworn.

Theycanalsobeusedtospeedtheinstallationinhomeswhereit
wouldbedifficultortimeconsumingtowireastandardpullcord.

Anemergencycallismadebysimplypullingthecordonce.

FixingsRequired

2suitablelengthscrews(1½”typical)
Plasterboardcavityfixingsmayberequired.


ToolsRequired

Becarefulwhenusingstepladders–alwaysfacethedirectionyouareworking.
Adrillmayberequiredifcavityfixingsarebeingused.
Alwaysmakesurethecorrectdrillbitsandscrewdriversareused.

Installation

1. Removethecoverbytwistingitoffthebase.
2. Selectthebestlocationandsecurelyfixthebasetotheceilingwith2screws.
Note:thealarmpullcordisnotdesignedforwallmounting.
3. Ifpossiblescrewintoawoodenjoist,ifnotcavityfixingswillberequired.
4. Knotthecordsoonetriangleiswithinnormalreachandtheotherjustabovefloorlevel.
5. Cutofftheexcesscord.

RegisteringtheAlarmPullcord

ItisnecessarytoregisteranalarmpullcordontotheReachat‐homealarmunit,Adventxtwardencall
orAltecResponse.Seethefollowingpagesforhowtoputeachoftheseproductsintoregistrationmode.
 
Therangeofallradiodevicescanbeaffectedbytheworkingenvironment‐alwaystakecareduringinstallationand
performseveraltestcallsfromallextremesofthebuilding.

BatteryLife

ThealarmpullcordcontainsalonglifeLithiumbattery.Thebatteryischeckedonceaday,ifthevoltagefallsandstaysbelowa
presetlevelfor7consecutivedaysalowbatteryalertisautomaticallytransmitted.Oncealowbatterycallisreceivedthealarm
pullcordshouldbereplacedwithin7days.AlarmpullcordsmustbereturnedtoTynetec/Aidcallforbatteryreplacement.

DetailedinformationonbatterymanagementforallTynetec/Aidcallproductsisavailable‐requestDocNo.FM0630.

Maintenance

Alarmpullcordshouldbeactivatedonceamonthtocheckthebatteryandverifyoperation.





Tynetec andAidcallare businessunitsofLegrandElectricLtd
Unit10CowleyRoad,BlythRiversideBusinessPark,Blyth
Northumberland,NE245TF.Tel:01670352371Fax:01670362807
Email:[email protected]Web:www.tynetec.co.uk

DocNo.FM0466issueFPage2
RegisteringanAlarmPullcordontoaReachat‐homealarmunit

1.PuttheReachunitintoradiodevicelearnmode…

     









2.Activatethealarmpullcord…


  











3.Exitradiodevicelearnmode…


     









4.CheckwiththeControlCentrethatitisconvenienttoperformatestcall,pulltheorangecordandconfirmtheyreceivea
pullcordalarmcall.


DeletinganAlarmPullcordfromaReachat‐homealarmunit

Enter1670usingthekeypadontherearoftheReachunit–thefrontlightwillFLASHFASTGREENandtheunitwillannounce
“ProgramMode‐Ready”.
Enter#041andtheReachwillannounce“DeleteRadioDevice”followedbya“Beep”.
Enterthe8digitalarmpullcordIDtobedeleted;afterthe“Beep”press#toexit.
PressthekeytoexitProgramMode;theunitwillsounda“Double‐Beep”andthefrontlightwillreturntoSTEADYGREEN.


The8digitIDcanbefoundonalabelonthebackofthealarmpullcord–itwillalwaysstartwith12xxxxxx





TheinstructionsgivenaboveforthestandardReachproductalsoappliestotheReachPlus,ReachPlusGSM
andReachUltramodels.Refertotheinstructionbookletsprovidedwiththeseproductsformoreinformation
onprogrammingandtestingradiodevices.












PulltheorangecordonceandtheReachwillannounce“Pullcord”.
“Trigger
Radio
Device”
PressandHOLDtheGREENbuttonontheReachunit.

WhenthefrontlightFLASHESFASTGREENreleasethe
buttonandtheReachwillannounce“TriggerRadioDevice”.

Younowhave1minutetoactivatethealarmpullcord.

PresstheGREENbuttonontheReachunit.

ThefrontlightwillreturntoSTEADYGREENandtheReach
isbackinnormaloperatingmode.


DocNo.FM0466issueFPage3
RegisteringanAlarmPullcordontoanAdventxtwardencallsystem

1.PuttheAdventxtsystemintoradiodevicelearnmode…
 
     
 












2.Activatethealarmpullcord…


  











3.ExittheAdventxtsystemradiodevicelearnmode…















4.Pulltheorangecordandcheckapullcordalarmcallisreportedonthewardencallsystem.


DeletinganAlarmPullcordfromanAdventxtwardencallsystem

PresstheLINEkeyandwaitforthe“Ready”prompt.
Enter5001followedbythekey.
Entertheflatnumberthealarmpullcordisbeingdeletedfromfollowedbythekey.
Activatethepullcordtobedeleted.
Waitforthe“PendantDisabled–EnterFlat”prompt.
Pressthe#keyandwaitforthe“Ready”prompt,thenpresstheLINEkeytocleartheconnection.






RefertotheAdventxtoperatorsmanual(DocNo.FM0420)providedwiththewardencallsystemformore
informationonprogrammingandtestingradiodevices.







UsingtheManager’sDECTtelephone;

PresstheLINEkeyandwaitforthe“Ready”prompt.

Enter5000followedbythekey.

Entertheflatnumberthealarmpullcordisbeinginstalledin
followedbythekey.

Younowhave1minutetoactivatethealarmpullcord.

“Ready”
UsingtheManager’sDECTtelephone;

Pressthe#keyandwaitforthe“Ready”prompt.

PresstheLINEkeytocleartheconnectionandthewardencallsystemis
nowbackinnormaloperatingmode.

Pulltheorangecordonce.

Waitforthe“EnterLocationCode”promptthenpress0(nolocation)
followedbythekey.

Waitforthe“PendantEnabled–EnterFlat”prompt.

“Ready”

DocNo.FM0466issueFPage4
RegisteringanAlarmPullcordontoanAltecResponselocalcareralarmunit

1.PuttheAltecResponseunitintoradiodevicelearnmode…


     
 











2.Activatethealarmpullcord…


  








 



3.ExittheAltecResponseradiodevicelearnmode…
















4.PulltheorangecordandcheckapullcordalarmisdisplayedontheAltecResponseunit.

DeletinganAlarmPullcordfromanAltecResponselocalcareralarmunit

PressENTERtoactivatethewake‐updisplaythenENTERagaintodisplaythemainmenu
PressENTERtoselectRadioDevices
PressthekeytoselectDeleteDevicethenpressENTER
Thedisplaywillpromptyouto“TriggertheSensor”
Activatethealarmpullcordtobedeleted‐thedisplaywillshowthedevicetypeandits8digitIDnumber
IfthisisthedeviceyouactivatedpressthekeytoselectDeletethenpressENTER
Ifit’sNOTthedeviceyouactivatedpresstheENTERkeytoselectRejectthentryagain
ToexitthemodeselectExitthenpresstheENTERkey.





RefertotheAltecResponseinstallationguide(DocNo.FM0548)providedwiththeportablealarmunitfor
moreinformationonprogrammingandtestingradiodevices.




TynetecandAidcalloperateapolicyofcontinuousimprovementandreservetherighttochangeproductspecificationswithoutnotice.
IfanyvariationtothedetailscontainedinthisdocumentaresuspectedpleasecontactTynetec’scustomersupportdepton01670352371.
Pulltheorangecordonce.

ThedisplaywillshowPullcordandthepullcord8digitIDnumber.
ChecktheIDiscorrect,pressthekeytoselectAcceptthenpressENTER.
Note:ifanotherdevicehasbeenpicked‐uppressENTERtoRejectandtryagain.
ThedisplaywillshowFlat,usethe&keystochoosethedwellingtype.
PressthekeytoselectNo:000000thenpresstheENTERkey.
Usethe&keystoselecteachdigitoftheflatnumberandthe&keys
tomovebetweendigitsthenpresstheENTERkey.
PresskeyseveraltimestoselectExitthenpresstheENTERkey.
Thedisplaywillpromptyouto“TriggertheSensor”again.
PressENTERtoactivatethewake‐updisplaythenENTERagaintodisplay
themainmenu.

PressENTERtoselectRadioDevices

PressENTERtoselectLearnDevice

Thedisplaywillpromptyouto“TriggertheSensor”.

Younowhave20secondstoactivatethealarmpullcord.
FromtheLearnDevicemenuselectExitthenpressENTER.

FromtheRadioDevicesmenuselectExitthenpressENTER.

Thedisplaywillreturntothewake‐upscreenandgoblankafter10seconds.

TheAltecResponseisnowbackinnormaloperatingmode.

