Lehigh E-Flex CapT2 User manual

E-Flex CapT2 Installation Guide F684
F684 R1.00 Lehigh Electric Products Co. 6265 Hamilton Blvd., Allentown, Pa. 18106 Tel: [phone] www.lehighdim.com
CAT5 Connection Schedule
Wire
Color
Description
1
White/Orange
+24V DC
2
Orange
+24V DC
3
White/Green
CAP1 Signal
4
Blue
CAP2 Signal
5
White/Blue
CAP3 Signal
6
Green
CAP4 Signal
7
White/Brown
COM
8
Brown
COM
Station Configuration
SW1 –CAPx Signal Selection
Each E-Flex relay panel (EFRP) has four discrete CapT signal inputs (CAP1-4) while the E-Flex room controller (EFRC) supports three
signal inputs (CAP1-3) which are then assigned to control selected zones. These input connections are made over a single Cat5 cable;
wires 3 thru 6 carry the CAPx signals (See CAT5 schedule above). The selection of which CAPx input a station will be connected to will
be made at the station using a rotary switch, SW1.
Note: Multiple stations can be set to connect to the same CAPx signal and stations can be connected to more than one E-Flex panel or
room controller.
SW1
CAPx Signal
0
CAP1
1
CAP2
2
CAP3
3
CAP4
SW2 –Preset Bank Select, LED Tracking
SW2 dip switch is used to select preset banks on select stations. The standard CapT2-7 (shown above) provides four preset banks 1-
4, 5-8, 9-12, and 13-16. This dip switch is also used to enable /disable LED tracking on the station. When enabled, the button LED
indicators track the last button pressed. When disabled the button LED indicators are lit only while pressed.
*CapT2-5 Button 1 Function.
Function
SW2-1
SW2-2
SW2-3
CapT2-2
CapT2-5
CapT2-7
Preset Bank 1
ON
ON
N/A
Full/Off
Full*
Preset 1-4
Preset Bank 2
OFF
ON
N/A
Preset 1/OFF
Preset 1*
Preset 5-8
Preset Bank 3
ON
OFF
N/A
Start/Stop Panic
Preset 16*
Preset 9-12
Preset Bank 4
OFF
OFF
N/A
ButtonX
ButtonX
Preset 13-16
Track Last
N/A
N/A
OFF
N/A
N/A
N/A
Lit on Press
N/A
N/A
ON
N/A
N/A
N/A
CapT2 wall stations for the E-Flex Lighting and Energy control system provide a
capacitive touch button interface in a Decora frame. CapT2 wall stations include button
layouts with up to 7-buttons for simple ON/OFF to a 4-preset recall with OFF, and
raise/lower control. The standard 4-preset recall layout is bank selectable via a dip
switch on the rear of the station and can be configured to recall presets 1-4, 5-8, 9-12,
or 13-16 from an E-Flex relay panel or E-Flex room controller. Station interconnects
using standard CAT5 cable.
Power: +24V DC
Unit Load: .25 (UL=50mA)
Cable Length: 300 Ft. maximum station to controller

E-Flex CapT2 Installation Guide F684
F684 R1.00 Lehigh Electric Products Co. 6265 Hamilton Blvd., Allentown, Pa. 18106 Tel: [phone] www.lehighdim.com
CapT2 Station Installation
Note: When connecting CapT2 stations to multiple E-Flex panels or room controllers only one of these can provide the +24V DC power
to the stations. A jumper is provided on the E-Flex panel/room controller to enable or disable 24V power to the CAT5 cable.
1. Ensure the E-Flex panel or room controller powering the stations is turned off at the circuit breaker.
2. If this is a multi-gang installation, use the 6 inch jumper to connect each of the stations.
3. Plug the CAT5 cable from the previous CapT2 station, E-Flex panel, or room controller into the RJ45 on the back
of the station. If multi-ganged plug into the end station. If daisy chaining, plug into the second RJ45 connector.
4. Mount the station(s) to the backbox using the two screws provided with the station.
5. Mount the faceplate.
6. Turn on the power to the E-Flex panel or room controller. Verify the power indicator LED is lit.
7. Follow with the proper configuration of the E-Flex panel or room controller and verify operation of each button.
For custom CapT2 stations, consult the factory drawings for specific operation.
Factory Pre-made Cat5 Cables:
C1676 –6 in.
C1277 –10 Ft.
C1274 –1 Ft.
C1278 –25 Ft.
C1275 –3 Ft.
C1279 –50 Ft.
C1276 –5 Ft.
C1280 –100 Ft.
