Leica BIOSYSTEMS Aperio GT 450 Service manual

Aperio GT 450
IT Manager and
Lab Administrator Guide
MAN-0394, Revision E | March 2022

Aperio GT 450 IT Manager and Lab Administrator Guide, Revision E © Leica Biosystems Imaging, Inc. 20222
Aperio GT 450 IT Manager and Lab Administrator Guide
This manual applies to Aperio GT 450 Controller, Aperio GT 450 Console, and Aperio GT 450 SAM versions 1.1
and later
Copyright Notice
ÌCopyright © 2019-2022 Leica Biosystems Imaging, Inc. All Rights Reserved. LEICA and the Leica logo are registered trademarks of Leica
Microsystems IR GmbH. Aperio, GT, and GT 450 are trademarks of the Leica Biosystems Imaging, Inc. in the USA and optionally in other countries.
Other logos, product and/or company names might be trademarks of their respective owners.
ÌThis product is protected by registered patents. For a list of patents, contact Leica Biosystems.
Customer Resources
ÌFor the latest information on Leica Biosystems Aperio products and services, please visit www.LeicaBiosystems.com/Aperio.
Contact Information – Leica Biosystems Imaging, Inc.
Headquarters Customer Support General Information
Leica Biosystems Imaging, Inc.
1360 Park Center Drive
Vista, CA 92081
USA
Tel: [phone] (toll free)
Direct International Tel: [phone]
Contact your local support representative
with any query and service request.
https://www.leicabiosystems.com/service-
support/technical-support/
US/Canada Tel: [phone] (toll free)
Direct International Tel: [phone]
Email: [email protected]
For research use only. Not for use in diagnostic procedures.
23GT450, 23GT450SAM

Aperio GT 450 IT Manager and Lab Administrator Guide, Revision E © Leica Biosystems Imaging, Inc. 2022 3
Notices.................................................................................................................................... 5
Revision Record ...............................................................................................................................5
Intended Use...................................................................................................................................5
Cautions and Notes ..........................................................................................................................5
Symbols.........................................................................................................................................6
1 Introduction .................................................................................................................... 10
About This Guide............................................................................................................................ 11
Related Documents.........................................................................................................................12
Aperio GT 450 System Components....................................................................................................12
Deploying the Aperio GT 450 System ..................................................................................................12
Log Into SAM ................................................................................................................................13
The SAM User Interface...................................................................................................................14
2 Aperio GT 450 Network Architecture ........................................................................... 16
Aperio GT 450 Architecture...............................................................................................................16
General Information........................................................................................................................16
Network Bandwidth Requirements .....................................................................................................17
How the Aperio GT 450 Fits into Your Network......................................................................................17
Secure Access...............................................................................................................................17
Data Communication Pathways .........................................................................................................18
3 Conguring the Aperio GT 450 Scanner...................................................................... 21
General Instructions .......................................................................................................................21
Basic Scanner Settings ................................................................................................................22
Scanner System Information: Info Page............................................................................................23
Scanner System Information: Settings Page ......................................................................................24
Scanner Configuration Settings..........................................................................................................25
Images Page .................................................................................................................................27
Image File Name Format...............................................................................................................28
Barcode Management..................................................................................................................28
PIN Management........................................................................................................................29
Configuring a PIN and Timeout ...................................................................................................29
Contents

Aperio GT 450 IT Manager and Lab Administrator Guide, Revision E © Leica Biosystems Imaging, Inc. 20224
Contents
4 Viewing System Information......................................................................................... 31
Displaying Scanner Information and Settings........................................................................................31
Displaying Scanner Statistics............................................................................................................32
Working With the Event Log .............................................................................................................32
Back Up Log Files........................................................................................................................32
Login Alerts...............................................................................................................................32
5 User Management .......................................................................................................... 33
Understanding Roles.......................................................................................................................33
Adding, Editing, and Deleting Users....................................................................................................34
Add a User................................................................................................................................34
Edit a User ................................................................................................................................35
Delete a User.............................................................................................................................35
Unlock a User Account.................................................................................................................35
6 Cybersecurity and Network Recommendations ......................................................... 37
Aperio GT 450 and SAM Cybersecurity Features....................................................................................37
Password, Login, and User Configuration Safeguards..............................................................................38
Physical Safeguards for Servers and Workstations.................................................................................38
Physical Safeguards for Aperio GT 450 Scanners ...................................................................................38
Administrative Safeguards ...............................................................................................................38
Protecting the DSR or Image Storage Server.........................................................................................39
Use of Off the Shelf Software ...........................................................................................................39
A Troubleshooting ............................................................................................................. 40
Scanner Administration Manager (SAM) Server Troubleshooting ...............................................................40
Restart the DataServer.................................................................................................................41
Verify Mirth is Running.................................................................................................................41
IIS Configuration Error..................................................................................................................41
B Summary of Scanner Setting and Conguration Options ......................................... 42
Basic Scanner Information................................................................................................................42
Scanner Configuration .....................................................................................................................42
Index ..................................................................................................................................... 45

Aperio GT 450 IT Manager and Lab Administrator Guide, Revision E © Leica Biosystems Imaging, Inc. 2022 5
Notices
Revision Record
Rev. Issued Sections Affected Detail
E March 2022 Front matter, Chapter 5,
“User Management”
Added revision history, cautions and notes.
Chapter 5: Added steps to unlock a user account.
D January 2021 Chapter 3, “Configuring the
Aperio GT 450”
Updated for patch 1.0.1.8000. Added information on specifying characters to
replace non-printable barcode characters.
C April 2020 Page 7 Changed references to two monitors to “monitor(s)” to accommodate
change in product configuration.
B October 2019 Chapter 3, “Configuring the
Aperio GT 450”
Added Time Zone setting information.
Added new Image page section on setting image file name format and
barcode identifier.
A June 2019 All New document.
Intended Use
For research use only. Not for use in diagnostic procedures.
Cautions and Notes
`Serious Incidents Reporting - Any serious incident that has occurred in relation to the Aperio GT 450 shall be
reported to the manufacturer and the competent authority of the member state in which the user is established.
`Specifications and Performance - For device specifications and performance characteristics, refer to the
document Aperio GT 450 Specifications.
`Installation - Aperio GT 450 must be installed by a trained Leica Biosystems Technical Services representative.
`Repair - Repairs may be done only by a trained Leica Biosystems Technical Services representative. After repairs
are done, ask the Leica Biosystems technician to perform operation checks to determine the product is in good
operating condition.
`Accessories - For information on using Aperio GT 450 with third-party accessories such as a Laboratory
Information System (LIS) not provided by Leica Biosystems, contact your Leica Biosystems Technical Services
representative.
`Quality Control - For information on image quality checks, see the Aperio GT 450 User’s Guide.
`Maintenance and Troubleshooting -For information on maintenance and troubleshooting problems, see the
Aperio GT 450 User’s Guide.
`Cybersecurity - Be aware that workstations are susceptible to malware, viruses, data corruption, and privacy
breaches. Work with your IT administrators to protect workstations by following your institution’s password and
security policies. For Aperio recommendations on protecting your workstations and servers, see “Chapter 6:
Cybersecurity and Network Recommendations” on page 37.
To protect workstations from malware intrusion, use caution when inserting USB drives and other removable
devices. Consider disabling USB ports that are not in use. If you plug in a USB drive or other removable device, you

Aperio GT 450 IT Manager and Lab Administrator Guide, Revision E © Leica Biosystems Imaging, Inc. 20226
should scan the devices with an anti-malware utility. For recommendations on protecting your workstations and
servers, see “Chapter 6: Cybersecurity and Network Recommendations” on page 37.
If a suspected Aperio GT 450 cybersecurity vulnerability or incident is detected, contact Leica Biosystems Technical
Services for assistance.
`Training - This manual is not a substitute for the detailed operator training provided by Leica Biosystems or for
other advanced instruction.
`Safety - Safety protection may be impaired if this device is used in a manner not specified by the manufacturer.
Symbols
The following symbols appear on your product label or in this user’s guide:
Symbol Standard/
Regulation Description
ISO 15223-1 - 5.1.1 Manufacturer
ISO 15223-1 - 5.1.3 Date of manufacture
ISO 15223-1 - 5.1.7 Serial number
ISO 15223-1 – 5.1.6 Catalog number
ISO 15223-1 - 5.4.4 Caution
SO 7010 – W001 General warning
IEC 61010-1 TÜV Product Services have certified that the listed products comply with both U.S and Canadian
safety requirements.
IEC 60417 - 5031 This device is suitable for direct current only.
IEC 60417 - 5007 On. To indicate connection to the mains, at least for mains switches or their positions, and
those cases where safety is involved.

Aperio GT 450 IT Manager and Lab Administrator Guide, Revision E © Leica Biosystems Imaging, Inc. 2022 7
Symbol Standard/
Regulation Description
IEC 60417 - 5008 Off. To indicate disconnection from the mains, at least for main switches, and all those cases
where safety is involved.
2012/19/EU Device is regulated under 2012/19/EU (WEEE Directive) for Electrical and Electronic Equipment
Waste and must be discarded under special conditions.
People’s Republic
of China Electronic
Industry Standard SJ/
T11364
Device contains certain toxic or hazardous elements and can be used safely during its
environmental protection use period. The number in the middle of the logo indicates the
environmental protection use period (in years) for the product.
Symbol Standard/
Regulation Description
IEC 60825-1 Device is a Class 1 Laser Product that is in compliance with international
standards and US requirements.
CA Proposition 65
This product can expose you to chemicals known to the State of California
to cause Cancer and Reproductive Harm. For more information go to
https://www.P65Warnings.ca.gov.
N/A Device is made in the USA of US and foreign components.

Aperio GT 450 IT Manager and Lab Administrator Guide, Revision E © Leica Biosystems Imaging, Inc. 20228
Customer Service Contacts
Please contact the office for your country for technical assistance.
Australia:
96 Ricketts Road
Mount Waverly, VIC 3149
AUSTRALIA
Tel: [phone] (toll free)
Between 8:30 AM-5 PM, Monday-Friday, AEST
Email: [email protected]
Austria:
Leica Biosystems Nussloch GmbH
Technical Assistance Center
Heidelberger Strasse 17
Nussloch 69226
GERMANY
Tel: [phone] (toll free)
In-country Tel: [phone]
Email: [email protected]
België/Belgique:
Tel: [phone] (toll free)
In-country Tel: [phone]
Email: [email protected]
Canada:
Tel: [phone] (toll free)
Direct International Tel: [phone]
Email: T[email protected]
China:
17F, SML Center No. 610 Xu Jia Hui Road, Huangpu District
Shanghai, PRC PC:200025
CHINA
Tel: [phone]
Fax: [phone]
Email: [email protected]
Remote Care email: [email protected]
Danmark:
Tel: [phone] (toll free)
In-country Tel: [phone]
Email: [email protected]
Deutschland:
Leica Biosystems Nussloch GmbH
Technical Assistance Center
Heidelberger Strasse 17
Nussloch 69226
GERMANY
Tel: [phone] (toll free)
In-country Tel: [phone]
Email: [email protected]
Eire:
Tel: [phone] (toll free)
In-country Tel: [phone]
Email: [email protected]
España:
Tel: [phone] (toll free)
In-country Tel: [phone]
Email: [email protected]
France:
Tel: [phone] (toll free)
In-country Tel: [phone]
Email: [email protected]
Italia:
Tel: [phone] (toll free)
In-country Tel: [phone]
Email: [email protected]
Japan:
1-29-9 Takadanobaba, Shinjuku-ku
Tokyo 169-0075
JAPAN
Nederland:
Tel: [phone] (toll free)
In-country Tel: [phone]
Email: [email protected]

Aperio GT 450 IT Manager and Lab Administrator Guide, Revision E © Leica Biosystems Imaging, Inc. 2022 9
New Zealand:
96 Ricketts Road
Mount Waverly, VIC 3149
AUSTRALIA
Tel: [phone] (toll free)
Between 8:30 AM-5 PM, Monday-Friday, AEST
Email: [email protected]
Portugal:
Tel: [phone] (toll free)
In-country Tel: [phone]
Email: [email protected]
The Russian Federation
BioLine LLC
Pinsky lane 3 letter A
Saint Petersburg 197101
THE RUSSIAN FEDERATION
Tel: [phone] (toll free)
In-country Tel: [phone]
Email: [email protected]
Sweden:
Tel: [phone] (toll free)
In-country Tel: [phone]
Email: [email protected]
Switzerland:
Tel: [phone] (toll free)
In-country Tel: [phone]
Email: [email protected]
United Kingdom:
Tel: [phone] (toll free)
In-country Tel: [phone]
Email: [email protected]
USA:
Tel: [phone] (toll free)
Direct International Tel: [phone]
Email: T[email protected]

Aperio GT 450 IT Manager and Lab Administrator Guide, Revision E © Leica Biosystems Imaging, Inc. 202210
This chapter introduces the Aperio Scanner Administration Manager (SAM) for use with one or more Aperio GT 450
Scanners.
The Aperio GT 450 is a high performance, brightfield whole slide scanner that includes continuous loading with 450 slide-
capacity across 15 racks, priority rack scanning, automated image quality check and a scan speed of ~32 seconds at 40x
scanning magnification for a 15 mm x 15 mm area. The Aperio GT 450 scanner was designed to fit into your network
environment and offer the best in security and performance.
This system is intended for use by trained histotechnicians, IT professionals, and pathologists. Ensure you follow appropriate
good laboratory practices and the policies and procedures required by your institution for slide preparation, processing,
storage, and disposal. Use this equipment only for this purpose and in the manner described in the Aperio GT 450 User’s
Guide.
Component Description
Scanner Administration Manager (SAM) Server The SAM server connects to multiple Aperio GT 450 scanners and runs the
SAM Client Application Software.
SAM Client Application Software The Scanner Administration Manager (SAM) client application software
enables IT implementation, PIN configuration, and service access of multiple
scanners from a single desktop client location for IT professionals.
Aperio Viewing Station The viewing station includes monitor(s) and a workstation with Aperio
ImageScope version 12.4 or higher.
The Aperio GT 450 system includes the Aperio Scanner Administration Manager (SAM) that enables IT implementation
and service access of up to 4 scanners from a single desktop client location. SAM facilitates setup, configuration, and
monitoring of each scanner. SAM is installed on a server that resides on the same network as the scanner(s) as well as
other components for image management.
Features of SAM include:
`Web-based user interface, compatible with most current browsers to allow access throughout your facility
network.
`Role-based user access. An operator role allows users to view configuration settings, while an administrative role
allows the user to change the settings.
`Scanner-specific configuration settings for user-access PINs and timeouts. Access to each scanner on the system
can be configured with separate access PINs.
1 Introduction

Aperio GT 450 IT Manager and Lab Administrator Guide, Revision E © Leica Biosystems Imaging, Inc. 2022 11
Chapter 1: Introduction
`Central display of statistics and event logs. Information for each scanner on the system can be displayed and
reviewed from the SAM interface for comparison.
`Support for multiple scanners, with centralized configuration and monitoring.
`Immediate display of scanner status. The home page displays which scanners are online and which are not.
`Integration with Aperio eSlide Manager for image management, if desired. The interface can be configured to use
SSL or another communication method.
`Services to process log data and events via Mirth Connect to a database on the file system.
About This Guide
This guide is intended for laboratory administrators, IT managers, and anyone else responsible for managing the Aperio GT
450 scanner on their facility network. For general information on how to use the scanner, refer to the Aperio GT 450 User’s
Guide.
The next chapter of this guide explains the Aperio GT 450 network architecture and shows how data flows from one
component of the system to another.
Chapters that follow discuss using the Aperio GT 450 Scanner Administration Manager (SAM) application to configure the
Aperio GT 450 scanner(s), including how to add user accounts to SAM, and configure access PINs for each scanner. Tasks
that are only available to Leica Support personnel are beyond the scope of this manual.
For information on specific tasks, use the following table.
Task See…
Learn how the GT 450 scanners and the Scanner
Administration Manager (SAM) server fit into your
network
“Aperio GT 450 Network Architecture” on page 16
Learn how data flows between the Aperio GT 450 scanner,
the SAM server, and image storage and optional Aperio
eSlide Manager servers
“Data Communication Pathways” on page 18
Log in to the Scanner Administration Manager (SAM)
client application software
“Log Into SAM” on page 13
Adjust configuration settings for DICOM (ImageServer) or
DSR communication with the SAM server and scanner
“Scanner Configuration Settings” on page 25
Display information about a scanner on the system “Configuring the Aperio GT 450 Scanner” on page 21
Check to see if a scanner is online “The SAM User Interface” on page 14
Display the serial number, software version, or firmware
version for a scanner on the system
“Scanner System Information: Info Page” on page 23
Review scanner statistics and history “Displaying Scanner Statistics” on page 32
Review advanced configuration options such as camera
settings
“Displaying Scanner Information and Settings” on page 31
Add a new user for Scanner Administration Manager
(SAM) access or as a scanner operator
“Adding, Editing, and Deleting Users” on page 34

Aperio GT 450 IT Manager and Lab Administrator Guide, Revision E © Leica Biosystems Imaging, Inc. 202212
Chapter 1: Introduction
Task See…
Delete a user account from SAM “Adding, Editing, and Deleting Users” on page 34
Change the password for a user “Edit a User” on page 35
Diagnose a problem by reviewing the event and error logs “Working With the Event Log” on page 32
Check for updates to the software “Displaying Scanner Information and Settings” on page 31
Review cybersecurity and network recommendations for
the Aperio GT 450 system
“Cybersecurity and Network Recommendations” on page
37
Related Documents
Videos available through the Aperio GT 450 touchscreen provide instructions for basic scanning tasks such as loading and
unloading racks.
For additional information on operating the Aperio GT 450 scanner, refer to the following documents:
`Aperio GT 450 Quick Reference Guide - Get started with the Aperio GT 450.
`Aperio GT 450 User’s Guide - Learn more about the Aperio GT 450.
`Aperio GT 450 Specifications - Detailed specifications on the Aperio GT 450.
Aperio GT 450 System Components
The diagram below illustrates the components of a typical Aperio GT 450 scanner system, using a DSR server and Aperio
eSlide Manager for image file management. Other configurations may be possible. Consult with your Leica Biosystems
technical representative for more information.
Deploying the Aperio GT 450 System
The following diagram shows how the Aperio GT 450 system fits into the different departments of your organization.

Aperio GT 450 IT Manager and Lab Administrator Guide, Revision E © Leica Biosystems Imaging, Inc. 2022 13
Chapter 1: Introduction
Aperio GT 450 Scanner
DSR Server
SAM Server
ÌMicrosoft Windows Server software
ÌSAM software
ÌDICOM converter software
ÌMirth Connect server software
ÌStorage for logs and events
ÌMicrosoft Windows Server software
ÌAperio eSlide Manager software
ÌStorage for image data
Pathology Lab IT Room IT Manager’s Office Pathologist’s Office
SAM server
DSR server SAM Application Software Aperio Viewing StationAperio GT 450s
Log Into SAM
After the Aperio GT 450 system is installed and configured, the next step is to use the Scanner Administration Manager
(SAM) to manage the Aperio GT 450 scanners and users.
1. Open an Internet browser and enter the address of the SAM server. (The Leica installation representative provides
this address to the IT representative at the facility when the system is installed. Contact your IT staff for this
address if you don’t have it.)
2. Enter your login (user) name and password. If this is the first time you are logging in, use the login information
provided by your system administrator or the Leica Biosystems installer.
3. Click Log In.

Aperio GT 450 IT Manager and Lab Administrator Guide, Revision E © Leica Biosystems Imaging, Inc. 202214
Chapter 1: Introduction
The SAM User Interface
The SAM home page with the scanner list is shown below. Note that users with the Operator role will not see the
Configuration icons.
The four general areas of the page are described below.
Scanner List
This list displays each scanner in the system, including the custom or “friendly” name,
and the scanner model. Lab Admin users can click a scanner name in this area to
display the Edit Scanner options.

Aperio GT 450 IT Manager and Lab Administrator Guide, Revision E © Leica Biosystems Imaging, Inc. 2022 15
Chapter 1: Introduction
Scanner Status Area
This area displays the status of each scanner.
User Login
This displays the user name for the current SAM user.
Select your login name to display links for changing the password and logging out.
Commands Area
The icons used to display System Information, Event Log, and Configuration pages are
included in this area.
Note that the Configuration icons are only available to users with the Lab Admin role.

Aperio GT 450 IT Manager and Lab Administrator Guide, Revision E © Leica Biosystems Imaging, Inc. 202216
This chapter presents a basic architectural overview of how the Aperio GT 450 scanner and the SAM server fit in your
network.
Aperio GT 450 Architecture
The Aperio GT 450 was designed with IT ease of use and security in mind. It is integration-ready for Aperio eSlide Manager,
an LIS, and other networked systems.
The Aperio GT 450 system includes an Aperio GT 450 scanner, Aperio Scanner Administration Manager (SAM) server,
cables, and plugs. Each instance of the SAM server can accommodate four Aperio GT 450 scanners and multiple SAM
servers can exist on your network.
The SAM client application software resides on the SAM server, and includes the following:
`SAM software for configuration of the scanner
`Web-based user interface for scanner administration and configuration
`Logging and messaging services for events and errors
`DICOM server to convert the DICOM image files to SVS and transfer them to the image storage system
General Information
The following guidelines apply:
`The network share where images are stored (DSR) can exist on the same server as the Aperio eSlide Manager, or it
may reside elsewhere on the local network.
`Messaging includes an instance of Mirth Connect and the deployment of various channels used to transform and
route scanner messages (scan events and logs).
Before the installation of the Aperio GT 450 scanners, SAM client application software, SAM server, and Aperio Viewing
Station, the Leica Biosystems technical representative determines the best architecture for the installation based on
projected usage, current network configuration, and other factors. This includes deciding which components (SAM, DICOM
converter, etc.) are installed on each physical server in the network. The various components and services can be installed
on different servers, or co-located on a single server.
2
Aperio GT 450 Network
Architecture

Aperio GT 450 IT Manager and Lab Administrator Guide, Revision E © Leica Biosystems Imaging, Inc. 2022 17
Chapter 2: Aperio GT 450 Network Architecture
Network Bandwidth Requirements
For the connection between the Aperio GT 450 and the SAM server, the required minimum bandwidth is a gigabit ethernet
with a speed equal to or greater than 1 gigabits per second (Gbps) For the connection between the SAM server and the
image repository (DSR), the required minimum bandwidth is 10 gigabits per second.
How the Aperio GT 450 Fits into Your Network
These are the major components of the Aperio GT 450 scanner and SAM system:
`Aperio GT 450 scanner - One or more Aperio GT 450 scanners can be connected to a SAM server through the
network. Each SAM server can support multiple scanners.
`Aperio Scanner Administration Manager (SAM) Server - The SAM server contains the Scanner
Administration Manager client application software, the subject of this guide. The SAM server provides the DICOM
Image converter to convert DICOM images to SVS image file format. (Aperio GT 450 scanners stream encrypted
DICOM images to the SAM server). SAM also manages scanner configuration settings, and manages messaging
using Mirth connections.
`Digital Slide Repository (DSR) Server - This server (also known as an Image Storage System server) contains
the whole slide images from the scanner and the infrastructure to manage them. The repository may be a network
share available through a server on your network, or may reside on an optional Aperio eSlide Manager Server.
`SAM Workstation/Console - Accessed through a web browser (Firefox, Chrome, or Edge) on PC or laptop on your
network, administrators and operators use the console to view event data and statistics. Administrators can also
add user accounts, configure PINs, and make configuration changes.
`Database - The MS SQL Server Database that contains user data, settings data, the data and events reported via
the statistical reports, and the errors reported in the logs.
`Network File Share - The location on your network where event logs are stored.
Secure Access
Access via the SAM user interface is secured using SSL. Self-signed SSL certificates are provided at installation. To avoid
security messages from the browser, customers may provide their own security certificates.
iTo protect your network from cybersecurity attacks, we recommend that you disable unused ports and services on
your network.

Aperio GT 450 IT Manager and Lab Administrator Guide, Revision E © Leica Biosystems Imaging, Inc. 202218
Chapter 2: Aperio GT 450 Network Architecture
Data Communication Pathways
The various components reside on servers on the network. In general, multiple components may be installed on the same
physical server, depending on your specific laboratory configuration.
The following diagram shows a standard, secure configuration for the Aperio GT 450 system connected to a SAM server and
a DSR server that is running Aperio eSlide Manager. Other configurations may apply to your specific network and use case.
This diagram is intended to be used to help you visualize the movement of images and the associated data.

Aperio GT 450 IT Manager and Lab Administrator Guide, Revision E © Leica Biosystems Imaging, Inc. 2022 19
Chapter 2: Aperio GT 450 Network Architecture
Config Data
Port 44386
Image Data
TCP 2762
Metadata Port
44386
Aperio GT 450 Scanner
Event Data Ports
6662, 6663
SAM DataServer Mirth
DICOM Converter
SQL Server
Database
SAM Server File System
Log Data
Events
Events
Config Data
Secured Port 443 SAM Web Page
Image Metadata
Port 44386
Image Data UDP 137, 138
TCP 139, 445
Aperio eSlide Manager DataServer
Image Server File System
DSR Server
SAM Server
Time
Synchronization Port 123

Aperio GT 450 IT Manager and Lab Administrator Guide, Revision E © Leica Biosystems Imaging, Inc. 202220
Chapter 2: Aperio GT 450 Network Architecture
Data Type Description Port
Image Data The Scanner sends DICOM image data to the DICOM Converter. The data is sent using
TLS encryption.
Configure the communication between the scanner and the DICOM converter using the
Hostname and Port settings on the Images configuration page.
TCP 2762
The DICOM Converter sends the image data (either as a converted SVS file, or as raw
DICOM data) to the Image File System on the DSR Server. The data is sent using SMB3
Encryption.
Configure the communication between the DICOM converter and the DSR using the File
Location setting on the Images page.
UDP 137,
138
TCP 139,
445
Scanner
Configuration
Data
The scanner sends a call to the SAM DataServer to request configuration data. The
SAM DataServer returns the configuration data to the scanner. The data is sent using
TLS Encryption. Communication between the scanner and the SAM DataServer is
configured on the scanner.
44386
The SAM DataServer stores the configuration data on the SQL Server Database on the
SAM Server.
The SAM DataServer displays the configuration data through the SAM web page.
Time
Synchronization
Timeclock synchronization between SAM and Multiple Scanners is maintained using
network time protocol.
UDP 123
Image Metadata The Scanner sends Image Metadata to the SAM DataServer. The data is sent using TLS
encryption. Communication between the scanner and the SAM DataServer is configured
on the scanner.
44386
The SAM DataServer sends image metadata to the Aperio eSlide Manager DataServer
located on the DSR. The data is sent using TLS encryption.
Configure the communication between the SAM DataServer and the scanner using the
Hostname and Port settings on the DSR page.
Messaging and
Event Data
The scanner sends logs and event data to the Mirth Connect Server. No sensitive data
is transferred.
Configure the communication between the scanner and the Mirth Connect Server on the
Event Handling configuration page.
6662,
6663
The Mirth Connect Server copies critical event and error data to the SAM DataServer
then the SAM DataServer sends this data to the SQL database. This is the data
reported out via the SAM Event Logs.
The SAM DataServer displays the event data through the SAM web page.
Mirth Connect Server processes the Log data and appends the Event Log, which resides
on the file system. The communication between Mirth and the Event Log is configured
within the Mirth Application setup. It is not accessible through SAM.
“Scanner Configuration Settings” on page 25 provides information on how to configure the various connections between
the components and services through the SAM interface.
