Leica Geosystems DISTO D1 User manual

Leica DISTOTM D1
The original laser distance meter
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

Overview 2
Technical data 3
Instrument Set-up 5
Operations 11
Message Codes 14
Care 15
Warranty 16
Safety instructions 17
Leica DISTO™ D1 1
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

Overview
Ove rview
The Leica DISTO™ is a laser distance meter oper-
ating with a class 2 laser. See chapter Technical
data for scope of use.
1Display
2ON/ Measure
3Clear/ OFF
Leica DISTO™ D1 2
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

Technical data
Te c h n ica lda ta
Leica DISTO™ D1 3
General
Accuracy with favourable conditions * 2 mm / 0.08 in ***
Accuracy with unfavourable conditions ** 3 mm / 1/8" ***
Range with favourable conditions * 0.2 - 40 m / 0.6 - 120 ft ***
Range with unfavourable conditions ** 0.2 - 30 m / 0.6 - 100 ft ***
Smallest unit displayed 0.1 mm / 1/32 in
Laser class 2
Laser type 635 nm, <1 mW
ø laser point | at distances 6 /30 /60 mm | 10/ 50/ 100 m
Protection class IP54 (dust- and splash water protected)
Auto. laser switch off after 90 s
Auto. power switch off after 180 s
Bluetooth® Smart Bluetooth® v4.0
Range of Bluetooth® Smart <10m
Battery durability (2 x AAA) up to 10000 measurements
Dimension (H x D x W) 115 x 43.5 x 23.5 mm | 4.53 x 1.71 x 0.93 in
Weight (with batteries) 87 g/ 3.07 oz
Temperature range Storage | Operation -25 to 70°C/ -13 to 158°F | -0 to 40°C/ 32 to 104°F
* favourable conditions are: white and diffuse reflecting target (white painted wall), low background illumination and moderate temperatures.
** unfavourable conditions are: targets with lower or higher reflectivity or high background illumination or temperatures at the upper or lower end of the specified temperature range.
*** Tolerances apply from 0.05 m to 5 m with a confidence level of 95%.
With favourable conditions the tolerance may deteriorate by 0.10 mm/m for distances above 5 m.
With unfavourable conditions the tolerance may deteriorate by 0.15 mm/m for distances above 5 m.
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

Technical data
Functions
Distance measuring yes
Permanent measuring yes
Beep yes
Illuminated display yes
Bluetooth® Smart yes
Leica DISTO™ D1 4
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

Instrument Set-up
Ins tru me n tSet-u p
Introduction
The safety instructions (see Safety
Instructions) and the user manual
should be read through carefully
before the product is used for the first
time.
The person responsible for the
product must ensure that all users
understand these directions and
adhere to them.
The symbols used have the following
meanings:
WARNING
Indicates a potentially hazardous situ-
ation or an unintended use which, if
not avoided, will result in death or ser-
ious injury.
CAUTION
Indicates a potentially hazardous situ-
ation or an unintended use which, if
not avoided, may result in minor injury
and/or appreciable material, financial
and environmental damage.
Important paragraphs which
must be adhered to in practice
as they enable the product to be
used in a technically correct and
efficient manner.
5
Leica DISTO™ D1
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

Instrument Set-up
Insert batteries
To ensure a reliable use, we recom-
mend using high quality Alkaline bat-
teries. Change batteries when
battery symbol is flashing.
Leica DISTO™ D1 6
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

Instrument Set-up
Switching ON/OFF
Device is turned OFF.
Leica DISTO™ D1 7
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

Instrument Set-up
Clear
Undo last action. Leave actual function, go to default
operation mode.
Leica DISTO™ D1 8
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

Instrument Set-up
Message Codes
If the message "i" appears with
a number, observe the instruc-
tions in Message Codes section.
Example:
Leica DISTO™ D1 9
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

Instrument Set-up
Settings
Press both keys simultaneousley. Switch between the following units:
0.000 m
0'00" 1/16
0.0000 m
0.000 in
0.00 ft
0 in 1/16
Leica DISTO™ D1 10
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

Operations
Ope ratio n s
Measuring single distance
Aim active laser at target.
Target surfaces: Measuring
errors can occur when meas-
uring to colourless liquids, glass,
styrofoam or permeable sur-
faces or when aiming at high
gloss surfaces. Against dark
surfaces the measuring time
increases.
11
Leica DISTO™ D1
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

Operations
Permanent measuring
The last value measured is displayed
in the main line.
Stops permanent measuring.
Leica DISTO™ D1 12
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

Operations
Bluetooth® Smart
DISTO™ sketch. Use App for
Bluetooth® data transfer.
Bluetooth® Smart is always act-
ive when the device is switched
on. Connect the device with
your smart-phone, tablet,
laptop.. Measurement values
will be transferred automatically
right after a measurement. The
efficient and innovative
Bluetooth® Smart module (with
the new Bluetooth® standard
V4.0) works together with all
Bluetooth® Smart Ready
devices. All other Bluetooth®
devices do not support the
energy saving Bluetooth®
Smart Module, which is integ-
rated in the device.
We provide no warranty for free
DISTO™ software and offer no
support for it. We accept no liab-
ility whatsoever arising from the
use of the free software and we
are not obliged to provide cor-
rections nor to develop
upgrades. A wide range of com-
mercial software can be found
on our homepage. Apps for
Android® or iOS can be found in
special internet shops. For more
details, see our homepage.
Leica DISTO™ D1 13
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

Message Codes
Mes s a g e C o d e s
Leica DISTO™ D1 14
No. Cause Correction
204 Calculation error Perform measurement again.
220 Hardware error Contact your dealer
240 Data transfer error Connect device and repeat procedure
252 Temperature too high Let device cool down.
253 Temperature too low Warm device up.
255 Received signal too weak, measuring time too long Change target surface (e.g. white paper).
256 Received signal too high Change target surface (e.g. white paper) .
257 Too much background light Shadow target area.
* If other message codes are displayed frequently even the instrument has been switched off and on, please contact your dealer.
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

Care
Care
lClean the device with a damp, soft cloth.
lNever immerse the device in water.
lNever use aggressive cleaning agents or
solvents.
Leica DISTO™ D1 15
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

Warranty
Warran ty
Warranty under PROTECT by Leica
Geosystems
Lifetime Manufacturer´s Warranty
Warranty coverage for the entire usage time of
the product under PROTECT according to Leica
Geosystems International Limited Warranty and
PROTECT General Terms & Conditions set out
charge repair or replacement of all products or
any parts under PROTECT that suffer defects as
a result of faults in materials or workmanship.
3 Years No Cost
Additional services should the product under
PROTECT become defective and require ser-
vicing under normal conditions of use, as
described in the user manual, at no additional
charge.
To receive the "3 Years No Cost" period, the
product under PROTECT must be registered at
the purchase date. If the product under
PROTECT is not registered, a "2 years No Cost"
period applies.
Leica DISTO™ D1 16
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

Safety instructions
Sa fety ins tru c tio n s
The person responsible for the instrument
must ensure that all users understand these
directions and adhere to them.
Leica DISTO™ D1 17
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

Safety instructions
Symbols used
The symbols used have the following meanings:
WARNING
Indicates a potentially hazardous situation or an
unintended use which, if not avoided, will result in
death or serious injury.
CAUTION
Indicates a potentially hazardous situation or an
unintended use which, if not avoided, may result in
minor injury and/or appreciable material, financial
and environmental damage.
Important paragraphs which must be
adhered to in practice as they enable the
product to be used in a technically correct
and efficient manner.
Leica DISTO™ D1 18
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

Safety instructions
Permitted use
lMeasuring distances
lData transfer with Bluetooth®
Leica DISTO™ D1 19
