Leica Lino P5 User manual

Leica LINO P5

Overview
Ove rview
The Leica Lino P5 is a self-levelling multifunctional
point laser. It is a reliable precision laser for any
kind of tasks like levelling, plumbing, transfering
and setting out right angles.
It supports you on job side with vertical and hori-
zontal five points (four points and one point in front
of the device) which are arranged precisely in 90°
to each other.
1Window of plumb up point
2Window of horizontal transfer points
3Window of plumbing
4Status LED (on keypad)
5Laser key (on keypad), ON/OFF
6Keypad
7Levelling lock
8Battery pack
9Tripod thread 1/4"
Leica Lino P5 2

Technical data
Te c h n ica lda ta
Leica Lino P5 3
Description P5
Point direction Up, down, right, left, front (90°/180°)
Range* 30 m (98 ft)
Levelling accuracy ±0.2 mm/m = ±2.0 mm @ 10m (±0.002 in/ft = ±0.08 in @ 33ft)
Point accuracy ±0.2 mm/m (±0.002 in/ft)
Self-levelling range ± 4 °
Self-levelling time < 3 s
Out-of-level warning Yes - blink lines every 5 s
Levelling system Automatic pendulum lockable
Pendulum Lock Yes
Laser type 635 ± 5 nm, Class 2 (acc. IEC 60825-1)
Protection class IP 54 (IEC 60529) dust and splash water
Drop resistant 6 x 0.5 m (1.64 ft)
Battery type 3 alkaline AA (opt. Li-Ion battery pack 5200 mAh)
Operating time with Li-Ion battery 59h (5 point) -
100h (2 point) continuous
Operating time with alkaline batteries 25h (5 point) -
37h (2 point) continuous
Automatic shut-off Available
Dimensions (L x W x H) 110 x 60 x 100 mm (4.33 x 2.36 x 3.93 in)
Weight with Li-Ion/Alkaline battery 530/505 g (1.17/1.11 lbs)
Operating temperature -10…+50 °C (+14…+122 °F)
Storage temperature -25…+70 °C (-13…+158 °F)
Laser point diameter at 5m distance < 5 mm (<0.2 in)
Tripod thread 1/4’’ (+ 5/8’’ with adapter)
Pulse power for receiver Not available
* depending on lighting conditions

Instrument Set-up
Ins trume n tSet-up
Introduction
The safety instructions (see Safety Instruc-
tions) and the user manual should be read
through carefully before the product is used
for the first time.
The person responsible for the product must
ensure that all users understand these dir-
ections and adhere to them.
The symbols used have the following meanings:
WARNING
Indicates a potentially hazardous situation or an
unintended use which, if not avoided, will result in
death or serious injury.
CAUTION
Indicates a potentially hazardous situation or an
unintended use which, if not avoided, may result in
minor injury and/or appreciable material, financial
and environmental damage.
Important paragraphs which must be
adhered to in practice as they enable the
product to be used in a technically correct
and efficient manner.
Levelling lock
Levelling unlocked
In the unlocked position the instrument auto-
matically levels itself within the specified inclin-
ation range. (See Technical data)
Levelling locked
Turn the levelling lock in order to transport or tilt
the instrument beyond the self-levelling range.
When locked, the pendulum is fixed and the self-
levelling function is deactivated. In this case the
laser blinks every 5sec.
Leica Lino P5 4

Instrument Set-up
Li-Ion battery (optional)
Charge Li-Ion battery
Charge the Li-Ion battery before using it for the
first time. While charging, the instrument may heat
up. This is normal and should not affect the instru-
ment´s lifespan or performance. At the recom-
mended storage temperature of -20°C to +30°C
(-4°F to +86°F), batteries containing a 50% to
100% charge can be stored up to 1 year. After this
storage period the batteries must be recharged.
CAUTION
Connecting the charger using the wrong adapter
may cause serious damage to the instrument. Any
damage caused by misuse is not covered by war-
ranty. Use only Leica-approved chargers, bat-
teries and cables. Unapproved chargers or cables
can cause the battery to explode or damage the
instrument.
Insert Li-Ion battery
Insert the battery-pack by pressing it down and
then tilting it towards the housing as shown until it
snaps in.
Li-Ion status LED
lights green: charging battery
OFF: charging finished / no charging
Leica Lino P5 5

Instrument Set-up
Alkaline batteries
To ensure a reliable use, we recommend
using high quality Alkaline batteries.
Insert Alkaline batteries
Insert Alkaline batteries in the battery-pack.
Insert the battery-pack
Insert the battery-pack by pressing it down and
then tilting it towards the housing as shown until it
snaps in.
Leica Lino P5 6

Operations
Ope rations
Switching ON/OFF Auto power-off
Place the lock switch to the unlocked position
(see Levelling lock). To activate auto power-
off after 30 min operation press and hold the
On button at start for 5 sec. The status LED
blinks 3 times in green colour. To deactivate
it again repeat the described steps until the
status LED blinks 3 times in red colour.
Leica Lino P5 7

How to use the smart adapters
How tous e the s ma rtada p ters
Setup device to adapter
Snap the device on the Twist 360 adapter.
Alignment of vertical laser lines
Turn the device 360° around the plumb point to
adjust the vertical line.
Alignment of horizontal laser lines
Turn the adjustment knob of UAL130 to fine adjust
the horizonal line to the desired reference level.
Leica Lino P5 9

How to use the smart adapters
Different fixing applications
Leica Lino P5 10

Message Codes
Mes s a g e C o d e s
Leica Lino P5 11
Laser LED Cause Correction
ON/OFF lights red Instrument has low power Charge Li-Ion battery or change
Alkaline batteries
OFF blinks red Temperature alert Cool down or heat up instrument
blinks blinks red Instrument is out of self-levelling
range
Place the instrument almost hori-
zontal and self-levelling will start
automatically
blinks lights red Instrument is out of self-levelling
range and has low power
Charge Li-Ion battery or change
Alkaline batteries
blinks every 5 sec lights red Levelling lock is activated but
instrument has low power
Charge Li-Ion battery or change
Alkaline batteries
blinks every 5 sec blinks green Levelling lock is activated for work-
ing without self-levelling

Accuracy Check
Ac c u rac y Ch e c k
Check the accuracy of your Leica Lino reg-
ularly and particularly before important meas-
uring tasks. Check Levelling lock before
checking the accuracy.
Levelling
Checking the accuracy of the levelling
Set the instrument on a tripod half-way between
two walls (A+B) that are approx. 5 m apart. Place
the lock switch in the "Unlocked" position (see Lev-
elling lock). Direct the instrument at wall A and
switch on the instrument. Activate the horizontal
laser line or laser point and mark the position of
the line or the point on wall (A1). Rotate the instru-
ment by 180° and mark the horizontal laser line or
the laser point in exactly the same way on wall
(B1).
Then place the instrument at the same elevation
as close as possible to wall A and again mark the
horizontal laser line or the laser point on wall A
(A2). Rotate the instrument by 180° again and
mark the laser on wall B (B2). Measure the dis-
tances of the marked points A1-A2 and B1-B2.
Calculate the difference of the two meas-
urements.
|(A1 - A2) - (B1 - B2)| <=2 mm
If the difference does not exceed 2 mm, then the
Leica Lino is within tolerance.
Should your Leica Lino be outside of the spe-
cified tolerance, please contact a local dealer
or an authorised Leica Geosystems dis-
tributor.
Leica Lino P5 12

Accuracy Check
Vertical plumb points
Checking the accuracy of the upper plumb
point:
Place the lock switch in the "Unlocked" position
(see Levelling lock). Set up the laser on its tripod to
wall mount bracket near point A1 at a minimum dis-
tance of 1.5 m from point B1. The horizontal laser
is aligned in direction 1. Mark the laser points A1
and B1 with a pin.
Checking the accuracy of the lower plumb
point:
Rotate the instrument by 180° so that it points in
the opposite direction 2 to direction 1. Adjust the
instrument so that the laser beam hits point A1
exactly. If point B2 is no further than 2 mm away
from point B1, then the Leica Lino is within tol-
erance.
Should your Leica Lino be outside of the spe-
cified tolerance, please contact a local dealer
or an authorised Leica Geosystems dis-
tributor.
Leica Lino P5 13

Accuracy Check
Perpendicularity horizontal points
Place lock switch in "Unlocked" position (see Lev-
elling lock). Mark a reference point (P1) approx.
5m from the walls and position the lower plumb
point exactly on it. Align the cross hair to the left
wall and mark the intersection point (a1) approx.
on the same hight like P1 to the wall. Shortly after
mark the right-hand perpendicular beam (b1) on
the front wall.
Then rotate the device exactly 90° clockwise
around the plumb point P1 and position the left-
hand perpendicular beam to the existing ref-
erence point a1. Make sure that the upper plumb
point is still exactly on the reference P1. Check
afterwards the new reference point b2 with the old
reference b1 on the front wall. The deviation
between the two points may be max. 3mm. Mark
the new position of the right-hand perpendicular
beam to the right wall with c1.
Afterwards turn the device exactly 180° around
the plumb point P1 and position the right-hand per-
pendicular beam to the existing reference point
a1. Make sure that the upper plumb point is still
exactly on the reference P1. Then mark the left-
hand beam to the right wall and mark it with c2. Fin-
ally measure the difference between the former
reference point c1 and the new point c2. The devi-
ation may be max. 3mm between these two
points.
Should your Leica Lino be outside of the spe-
cified tolerance, please contact a local dealer
or an authorised Leica Geosystems dis-
tributor.
Leica Lino P5 14

Care
Care
Never immerse the device in water. Wipe off dirt
with a damp soft cloth. Never use aggressive
cleaning agents or solvents. Treat the instrument
with the same care that you would apply to bin-
oculars or a camera. Dropping or violent shaking
of the instrument may damage it. Check the instru-
ment for any damage before using it. Check the
levelling accuracy of the instrument regularly.
To warranty the best precision and visibility please
clean the optics of your device regularly. There-
fore blow off the dust from the glasses without
touching the optics with your fingers. If necessary
use a damp soft cloth and a little bit of pure alcohol.
To avoid wrong measurements also clean your
adapters regularly. This could be done also by the
proposed recommendation. Especially the inter-
face between the adapter and device should
always be clean to enable easy rotation. To clean
the magnetic surface you could use compressed
air or modelling clay.
If the equipment get wet always dry it (max.
70°C/158°F) before repacking it into the case.
Leica Lino P5 15

Warranty
Warran ty
International Limited Warranty
The Leica Lino comes with a two year warranty
from Leica Geosystems AG. To receive an addi-
tional year warranty, the product must be
registered on our website at http://myworld.leica-
geosystems.com within eight weeks of the pur-
chase date. If the product is not registered, our
two year warranty applies.
More detailed information about the International
Limited Warranty can be found on the internet at:
www.leica-geo-
systems.com/internationalwarranty.
Calibration and repair service
Leica Geosystems recommend to check the
device within regular intervals to prove the func-
tion and reliability in accordance with standards
and requirements. At least one time per year.
In case of damaging your product please never
attemp to repair the device yourself.
For calibration or repair service please visit your
local dealer or any certified Leica Geosystems dis-
tributor.
Leica Lino P5 16

Safety instructions
Sa fety ins tru c tion s
The person responsible for the instrument
must ensure that all users understand these
directions and adhere to them.
Areas of responsibility
Responsibilities of the manufacturer of the ori-
ginal equipment:
Leica Geosystems AG
Heinrich-Wild-Strasse
CH-9435 Heerbrugg
Internet: www.leica-geosystems.com
The company above is responsible for supplying
the product, including the User Manual in a com-
pletely safe condition.
The company above is not responsible for third
party accessories.
Responsibilities of the person in charge of the
instrument:
1. To understand the safety instructions on
the product and the instructions in the
User Manual.
2. To be familiar with local safety regulations
relating to accident prevention.
3. Always prevent access to the product by
unauthorised personnel.
Permitted use
1. Projection of horizontal and vertical laser
lines and laser points
Leica Lino P5 17

Safety instructions
Prohibited use
1. Using the product without instruction
2. Using outside the stated limits
3. Deactivation of safety systems and
removal of explanatory and hazard labels
4. Opening of the equipment by using tools
(screwdrivers, etc.)
5. Carrying out modification or conversion
of the product
6. Deliberate dazzling of third parties; also in
the dark
7. Inadequate safeguards at the surveying
site (e.g. when measuring on roads, con-
struction sites, etc.)
Hazards in use
WARNING
Watch out for erroneous measurements if the
instrument is defective or if it has been dropped or
has been misused or modified. Carry out periodic
test measurements. Particularly after the instru-
ment has been subject to abnormal use, and
before, during and after important meas-
urements.
CAUTION
Never attempt to repair the product yourself. In
case of damage, contact a local dealer.
WARNING
Changes or modifications not expressively
approved by Leica Geosystems/manufacturer for
compliance could void the user´s authority to oper-
ate the equipment.
WARNING
Laser/adapters should not be used in the vicinity of
pacemaker because of integrated magnets which
can affect the function of the pacemaker.
Limits of use
Refer to section Technical data. The instru-
ment is designed for use in areas per-
manently habitable for humans. Do not use
the product in explosion hazardous areas or
in aggressive environments.
Leica Lino P5 18

Safety instructions
Disposal
CAUTION
Flat batteries must not be disposed of with house-
hold waste. Care for the environment and take
them to the collection points provided in accord-
ance with national or local regulations.
The product must not be disposed with
household waste. Dispose of the product
appropriately in accordance with the national
regulations in force in your country. Adhere
to the national and country specific reg-
ulations.
Product specific treatment and waste man-
agement can be downloaded from our
homepage.
Transport
Transport of instrument
Always set the device in "Locked" position by turn-
ing the lock switch when transporting the device
(see Levelling lock). Please use the original case
or an equivalent packaging for transporting and
shipping your measuring device.
Transport of Li-Ion battery
WARNING
During transport, shipping or disposal of batteries
it is possible for inappropriate mechanical influ-
ences to constitute a fire hazard.
Precautions:
Before shipping the product or disposing it, dis-
charge the batteries by running the product until
they are flat. When transporting or shipping bat-
teries, the person in charge of the product must
ensure that the applicable national and inter-
national rules are observed. Before transportation
or shipping, contact your local passenger or
freight transport company.
WARNING
High mechanical stress, high ambient tem-
peratures or immersion into fluids can cause leak-
age, fire or explosion of the batteries.
Precautions:
Protect the batteries from mechanical influences
and high ambient temperatures. Do not drop or
immerse batteries into fluids.
For further information about charging
please refer to Li-Ion battery.
Leica Lino P5 19
Other manuals for Lino P5
1
Table of contents
Other Leica Laser Level manuals

Leica
Leica LMR 360R User manual

Leica
Leica Rugby 640 User manual

Leica
Leica Rugby 880 User manual

Leica
Leica LINO L2G User manual

Leica
Leica Rugby 880 User manual

Leica
Leica BLK ARC User manual

Leica
Leica Rugby 200 User manual

Leica
Leica Sprinter 150 User manual

Leica
Leica Sprinter 50 User manual

Leica
Leica DISTO D3a BT User manual

Leica
Leica Lino L360 User manual

Leica
Leica Rugby 820 User manual

Leica
Leica Lino ML90 User manual

Leica
Leica Lino L2 User manual

Leica
Leica Rugby 620 User manual

Leica
Leica NA720 User manual

Leica
Leica Lino L4P1 User manual

Leica
Leica Rugby 670 User manual

Leica
Leica DNA 10 User manual

Leica
Leica Rugby 400 DG User manual
