Jogger 20/24/28/32, Introduction
en
Introduction
Purchase Congratulations on the purchase of a Leica Jogger 20/24/28/32.
This manual contains important safety directions as well as instructions for setting
up the product and operating it. Refer to "1 Safety Directions" for further informa-
tion.
Read carefully through the User Manual before you switch on the product.
Product identifica-
tion
The type and serial number of your product are indicated on the type plate.
Enter the type and serial number in your manual and always refer to this information
when you need to contact your agency or Leica Geosystems authorised service work-
shop.
Type: _______________
Serial No.: _______________

Jogger 20/24/28/32, Introduction 3
en
Symbols The symbols used in this manual have the following meanings:
Validity of this
manual
This manual applies to the Jogger 20/24/28/32 instruments. Differences between the
various models are marked and described.
Type Description
DANGER Indicates an imminently hazardous situation which, if not
avoided, will result in death or serious injury.
WARNING Indicates a potentially hazardous situation or an unintended
use which, if not avoided, could result in death or serious
injury.
CAUTION Indicates a potentially hazardous situation or an unintended
use which, if not avoided, may result in minor or moderate
injury.
NOTICE Indicates a potentially hazardous situation or an unintended
use which, if not avoided, may result in appreciable material,
financial and environmental damage.
Important paragraphs which must be adhered to in practice as
they enable the product to be used in a technically correct and
efficient manner.

4
Jogger 20/24/28/32, Introduction
en
Available docu-
mentation Name Description/Format
Jogger
20/24/28/32
User Manual
All instructions required in order to operate the product
to a basic level are contained in the User Manual.
Provides an overview of the product together with tech-
nical data and safety directions.


Jogger 20/24/28/32, Table of Contents 5
en
Table of Contents
In this manual Chapter Page
1 Safety Directions 6
1.1 General Introduction 6
1.2 Definition of Use 7
1.3 Limits of Use 8
1.4 Responsibilities 8
1.5 Hazards of Use 9
2 Description of the System 13
2.1 Container Contents 14
2.2 Instrument Components 15
3Operation 16
3.1 Distance and Angle measurement 16
3.2 Check & Adjust the line of sight 18
4 Care and Transport 21
4.1 Transport 21
4.2 Storage 22
4.3 Cleaning and Drying 22
5 Technical Data 24

6
Jogger 20/24/28/32, Safety Directions
en
1 Safety Directions
1.1 General Introduction
Description The following directions enable the person responsible for the product, and the
person who actually uses the equipment, to anticipate and avoid operational
hazards.
The person responsible for the product must ensure that all users understand these
directions and adhere to them.

Jogger 20/24/28/32, Safety Directions 7
en
1.2 Definition of Use
Intended Use • Optical height readings.
• Optical distance measuring with stadia readings.
Reasonably fore-
seeable misuse
• Use of the product without instruction.
• Use outside of the intended use and limits.
• Disabling safety systems.
• Removal of hazard notices.
• Opening the product using tools, for example screwdriver, unless this is
permitted for certain functions.
• Modification or conversion of the product.
• Use after misappropriation.
• Use of products with recognisable damages or defects.
• Use with accessories from other manufacturers without the prior explicit
approval of Leica Geosystems.
• Aiming directly into the sun.
• Inadequate safeguards at the working site.
