Leica TS01 User manual

Leica TS01
User Manual
Version 1.1.9
English

Introduction
Congratulations on the purchase of the Leica TS01.
This manual contains important safety directions as well as instructions for
setting up the product and operating it. Refer to 1 Safety Directions for fur-
ther information.
Read carefully through the User Manual before you switch on the product.
The content of this document is subject to change without prior notice. Ensure
that the product is used in accordance with the latest version of this docu-
ment.
The content of this document is subject to change without prior notice. Ensure
that the product is used in accordance with the latest version of this docu-
ment.
Updated versions are available for download at the following Internet address:
myWorld@Leica Geosystems > myProducts.
The model and serial number of your product are indicated on the type plate.
Always refer to this information when you need to contact your agency or
Leica Geosystems authorised service centre.
This manual applies to the TS01 manual total station.
On the last page of this manual, you can nd the address of Leica Geosystems
headquarters. For a list of regional contacts, please visit
http://leica-geosystems.com/contact-us/sales_support.
myWorld@Leica Geosystems offers a wide range of services, information and
training material.
With direct access to myWorld, you are able to access all relevant services
whenever it is convenient for you.
The availability of services depends on the instrument model.
Service Description
myProducts Add all products that you and your company own
and explore your world of Leica Geosystems: View
detailed information on your products and update
your products with the latest software and keep up-
to-date with the latest documentation.
myService View the current service status and full service his-
tory of your products in Leica Geosystems service
centres. Access detailed information on the services
performed and download your latest calibration cer-
ticates and service reports.
Purchase
☞
Product identication
Validity of this
manual
Leica Geosystems
address book
2

Service Description
mySupport Create new support requests for your products that
will be answered by your local Leica Geosystems
Support Team. View the complete history of your
support requests and view detailed information on
each request in case you want to refer to previous
support requests.
myLearning Welcome to the home of Leica Geosystems online
learning! There are numerous online courses – avail-
able to all customers with products that have valid
CCPs (Customer Care Packages).
myTrustedServices Add your subscriptions and manage users for Leica
Geosystems Trusted Services, the secure software
services, that assist you to optimise your workow
and increase your efciency.
mySmartNet HxGN SmartNet is the GNSS correction service built
on the world’s largest reference station network,
enabling GNSS-capable devices to quickly determine
precise positions in the range of one to two centi-
metre accuracy. The service is provided 24/7 by a
highly-available infrastructure and professional sup-
port team with more than 10 years of experience
reliably delivering the service.
myDownloads Downloads of software, manuals, tools, training
material and news for Leica Geosystems products.
3

Table of Contents
1 Safety Directions 7
1.1 General 7
1.2 Denition of Use 8
1.3 Limits of Use 8
1.4 Responsibilities 8
1.5 Hazards of Use 9
1.6 Laser Classication 12
1.6.1 General 12
1.6.2 Distancer, Measurements with Reectors 13
1.6.3 Distancer, Measurements without Reectors 13
1.6.4 Red Laser Pointer 15
1.6.5 Laser Plummet 17
1.7 Electromagnetic Compatibility (EMC) 18
2 Description of the System 21
2.1 System Components 21
2.2 Container Contents 21
2.3 Instrument Components 22
3 User Interface 23
3.1 Keyboard 23
3.2 Screen 24
3.3 Status Icons 24
3.4 Softkeys 25
3.5 Operating Principles 26
3.6 Point Search 26
4 Operation 27
4.1 Instrument Setup 27
4.2 Batteries 29
4.2.1 Operating Principles 29
4.2.2 Battery for the TS Instrument 30
4.3 Data Storage 30
4.4 Main Menu 30
4.5 Standard Measurements 31
4.5.1 Overview 31
4.5.2 Angle Measurement 32
4.5.3 Distance Measurement 33
4.5.4 Coordinate Measurement 34
4.6 Distance Measurements - Guidelines for Correct Results 34
5 Settings 36
5.1 Unit Settings 36
5.2 Parameters Settings 37
5.3 Display Settings 38
5.4 Other Settings 39
5.5 Shortcut Keys Settings 39
5.6 EDM Settings 40
5.7 Date/Time Settings 42
5.8 Key Function Settings 42
5.9 WiFi Settings 44
6 Apps - Getting Started 45
6.1 Overview 45
6.2 Starting an App 45
6.3 Station Setup 45
4 Table of Contents

6.4 Selecting the Orientation 46
6.4.1 Overview 46
6.4.2 Orientation with Angle 47
6.4.3 Orientation with Coordinates 47
6.5 Setting the Job 48
7 Apps 49
7.1 Common Fields 49
7.2 Survey 49
7.3 Set Out 49
7.4 Target Offset 51
7.4.1 Overview 51
7.4.2 Distance Offset 52
7.4.3 Angle Offset 53
7.4.4 Double Distance Offset 54
7.4.5 Cylindrical Offset 55
7.5 Missing Line Measurement 56
7.6 Remote Elevation 58
7.7 Area 58
7.8 Resection 59
7.9 Reference Line 61
7.9.1 Overview 61
7.9.2 Dening the Reference Line 61
7.9.3 Stakeout 63
7.9.4 Measuring to a Reference Line 64
7.9.5 Projections 65
7.10 Road 67
7.10.1 Overview 67
7.10.2 Basic Terms 68
7.10.3 Creating a New Alignment 70
7.10.4 Stake 73
7.10.5 Data Transfer 75
8 Coding 78
9 Data Management 79
9.1 Overview 79
9.2 Memory Information 79
9.3 Deleting the Memory 80
9.4 Working with a USB Memory Stick 80
10 Data Transfer 82
10.1 Exporting Data 82
10.2 Importing Data 83
11 Tools 84
11.1 Check & Adjust 84
11.1.1 Overview 84
11.1.2 Preparation 84
11.1.3 Adjusting Line-of-Sight and Vertical Index Error 85
11.1.4 Adjusting the Compensator 87
11.1.5 Adjusting the Level of the Instrument and Tribrach 88
11.1.6 Inspecting the Laser Plummet of the Instrument 88
11.1.7 Servicing the Tripod 89
11.2 System Information 90
11.3 Loading Firmware or License 90
12 Care and Transport 92
12.1 Transport 92
Table of Contents 5

12.2 Storage 92
12.3 Cleaning and Drying 93
13 Technical Data 94
13.1 Angle Measurement 94
13.2 Distance Measurement with Reectors 94
13.3 Distance Measurement without Reectors (Non-Prism mode) 95
13.4 General Technical Data of the Product 95
13.5 Conformity to National Regulations 97
13.5.1 TS01 97
13.5.1.1 EU Declaration of Conformity 97
13.5.1.2 FCC Declaration of Conformity 98
13.5.2 Dangerous Goods Regulations 99
13.6 Scale Correction 99
13.7 Reduction Formulas 100
14 Software Licence Agreement/Warranty 103
Appendix A Menu Tree 104
Appendix B Directory Structure 105
6 Table of Contents

1 Safety Directions
1.1 General
The following directions enable the person responsible for the product, and
the person who actually uses the equipment, to anticipate and avoid opera-
tional hazards.
The person responsible for the product must ensure that all users understand
these directions and adhere to them.
Warning messages are an essential part of the safety concept of the instru-
ment. They appear wherever hazards or hazardous situations can occur.
Warning messages...
•make the user alert about direct and indirect hazards concerning the use
of the product.
•contain general rules of behaviour.
For the users‘ safety, all safety instructions and safety messages shall be
strictly observed and followed! Therefore, the manual must always be available
to all persons performing any tasks described here.
DANGER, WARNING, CAUTION and NOTICE are standardised signal words for
identifying levels of hazards and risks related to personal injury and property
damage. For your safety, it is important to read and fully understand the
following table with the different signal words and their denitions! Supple-
mentary safety information symbols may be placed within a warning message
as well as supplementary text.
Type Description
DANGER Indicates an imminently hazardous situation
which, if not avoided, will result in death or
serious injury.
WARNING Indicates a potentially hazardous situation
or an unintended use which, if not avoided,
could result in death or serious injury.
CAUTION Indicates a potentially hazardous situation
or an unintended use which, if not avoided,
may result in minor or moderate injury.
NOTICE
Indicates a potentially hazardous situation
or an unintended use which, if not avoided,
may result in appreciable material, nancial
and environmental damage.
☞Important paragraphs which must be
adhered to in practice as they enable the
product to be used in a technically correct
and efcient manner.
Description
About warning
messages
Safety Directions 7

1.2 Denition of Use
•Measuring horizontal and vertical angles
•Measuring distances
•Recording measurements
•Visualising the aiming direction and vertical axis
•Data communication with external appliances
•Computing with software
•Use of the product without instruction
•Use outside of the intended use and limits
•Disabling of safety systems
•Removal of hazard notices
•Opening the product using tools, for example a screwdriver, unless this is
permitted for certain functions
•Modication or conversion of the product
•Use after misappropriation
•Use of products with recognisable damage or defects
•Use with accessories from other manufacturers without the prior explicit
approval of Leica Geosystems
•Deliberate dazzling of third parties
•Controlling of machines, moving objects or similar monitoring applications
without additional control and safety installations
•Aiming directly into the sun
•Inadequate safeguards at the working site
1.3 Limits of Use
Suitable for use in an atmosphere appropriate for permanent human habita-
tion. Not suitable for use in aggressive or explosive environments.
WARNING
Working in hazardous areas, or close to electrical installations or sim-
ilar situations
Life Risk.
Precautions:
▶Local safety authorities and safety experts must be contacted by the
person responsible for the product before working in such conditions.
1.4 Responsibilities
Leica Geosystems AG, CH-9435 Heerbrugg, hereinafter referred to as Leica
Geosystems, is responsible for supplying the product, including the User
Manual and original accessories, in a safe condition.
Intended use
Reasonably
forseeable misuse
Environment
Manufacturer of the
product
8 Safety Directions

The person responsible for the product has the following duties:
•To understand the safety instructions on the product and the instructions
in the User Manual
•To ensure that it is used in accordance with the instructions
•To be familiar with local regulations relating to safety and accident pre-
vention
•To stop operating the system and inform Leica Geosystems immediately if
the product and the application become unsafe
•To ensure that the national laws, regulations and conditions for the oper-
ation of the product are respected
1.5 Hazards of Use
NOTICE
Dropping, misusing, modifying, storing the product for long periods or
transporting the product
Watch out for erroneous measurement results.
Precautions:
▶Periodically carry out test measurements and perform the eld adjust-
ments indicated in the User Manual, particularly after the product has
been subjected to abnormal use as well as before and after important
measurements.
DANGER
Risk of electrocution
Because of the risk of electrocution, it is dangerous to use poles, levelling
staffs and extensions in the vicinity of electrical installations such as power
cables or electrical railways.
Precautions:
▶Keep at a safe distance from electrical installations. If it is essential to
work in this environment, rst contact the safety authorities responsible
for the electrical installations and follow their instructions.
WARNING
Lightning strike
If the product is used with accessories, for example masts, staffs, poles, you
may increase the risk of being struck by lightning.
Precautions:
▶Do not use the product in a thunderstorm.
Person responsible
for the product
Safety Directions 9

WARNING
Distraction/loss of attention
During dynamic applications, for example stakeout procedures, there is a
danger of accidents occurring if the user does not pay attention to the envir-
onmental conditions around, for example obstacles, excavations or trafc.
Precautions:
▶The person responsible for the product must make all users fully aware of
the existing dangers.
WARNING
Inadequate securing of the working site
This can lead to dangerous situations, for example in trafc, on building sites
and at industrial installations.
Precautions:
▶Always ensure that the working site is adequately secured.
▶Adhere to the regulations governing safety, accident prevention and road
trafc.
CAUTION
Pointing product toward the sun
Be careful when pointing the product toward the sun, because the telescope
functions as a magnifying glass and can injure your eyes and/or cause damage
inside the product.
Precautions:
▶Do not point the product directly at the sun.
CAUTION
Not properly secured accessories
If the accessories used with the product are not properly secured and the
product is subjected to mechanical shock, for example blows or falling, the
product may be damaged or people can sustain injury.
Precautions:
▶When setting up the product, make sure that the accessories are correctly
adapted, tted, secured, and locked in position.
▶Avoid subjecting the product to mechanical stress.
10 Safety Directions

WARNING
Inappropriate mechanical inuences to batteries
During the transport, shipping or disposal of batteries it is possible for inap-
propriate mechanical inuences to constitute a re hazard.
Precautions:
▶Before shipping the product or disposing it, discharge the batteries by the
product until they are at.
▶When transporting or shipping batteries, the person in charge of the
product must ensure that the applicable national and international rules
and regulations are observed.
▶Before transportation or shipping, contact your local passenger or freight
transport company.
WARNING
Exposure of batteries to high mechanical stress, high ambient temper-
atures or immersion into uids
This can cause leakage, re or explosion of the batteries.
Precautions:
▶Protect the batteries from mechanical inuences and high ambient tem-
peratures. Do not drop or immerse batteries into uids.
WARNING
Short circuit of battery terminals
If battery terminals are short circuited e.g. by coming in contact with jewellery,
keys, metallised paper or other metals, the battery can overheat and cause
injury or re, for example by storing or transporting in pockets.
Precautions:
▶Make sure that the battery terminals do not come into contact with
metallic objects.
Safety Directions 11

WARNING
Improper disposal
If the product is improperly disposed of, the following can happen:
•If polymer parts are burnt, poisonous gases are produced which may
impair health.
•If batteries are damaged or are heated strongly, they can explode and
cause poisoning, burning, corrosion or environmental contamination.
•By disposing of the product irresponsibly you may enable unauthorised
persons to use it in contravention of the regulations, exposing themselves
and third parties to the risk of severe injury and rendering the environ-
ment liable to contamination.
•Improper disposal of silicone oil may cause environmental contamination.
•The product does include parts of Beryllium inside. Any modication of
some internal parts can release Beryllium dust or fragments, creating a
health hazard.
Precautions:
▶The product must not be disposed with household waste.
Dispose of the product appropriately in accordance with
the national regulations in force in your country.
Always prevent access to the product by unauthorised
personnel.
Product-specic treatment and waste management information can be
received from your Leica Geosystems distributor.
WARNING
Improperly repaired equipment
Risk of injuries to users and equipment destruction due to lack of repair
knowledge.
Precautions:
▶Only authorised Leica Geosystems Service Centres are entitled to repair
these products.
1.6 Laser Classication
1.6.1 General
The following chapters provide instructions and training information about
laser safety according to international standard IEC 60825-1 (2014-05) and
technical report IEC TR 60825-14 (2004-02). The information enables the
person responsible for the product and the person who actually uses the
equipment, to anticipate and avoid operational hazards.
☞According to IEC TR 60825-14 (2004-02), products classied as laser
class 1, class 2 and class 3R do not require:
•laser safety ofcer involvement,
•protective clothes and eyewear,
•special warning signs in the laser working area
if used and operated as dened in this User Manual due to the low
eye hazard level.
General
12 Safety Directions

☞National laws and local regulations could impose more stringent
instructions for the safe use of lasers than IEC 60825-1 (2014-05)
and IEC TR 60825-14 (2004-02).
1.6.2 Distancer, Measurements with Reectors
The EDM module built into the product produces a visible laser beam which
emerges from the telescope objective.
The laser product described in this section is classied as laser class 1 in
accordance with:
•IEC 60825-1 (2014-05): “Safety of laser products”
These products are safe under reasonably foreseeable conditions of operation
and are not harmful to the eyes provided that the products are used and
maintained in accordance with this User Manual.
Description Value
Wavelength 685 nm
Pulse duration 6673 ps
Pulse repetition frequency 75 MHz
Maximum average radiant power 0.34 mW
Beam divergance 1.5 mrad x 3 mrad
0022396_001
a
a Laser beam
1.6.3 Distancer, Measurements without Reectors
The EDM module built into the product produces a visible laser beam which
emerges from the telescope objective.
The laser product described in this section is classied as laser class 3R in
accordance with:
•IEC 60825-1 (2014-05): “Safety of laser products”
Direct intrabeam viewing may be hazardous (low eye hazard level), in particu-
lar for deliberate ocular exposure. The beam may cause dazzle, ash-blindness
and after-images, particularly under low ambient light conditions. The risk of
injury for laser class 3R products is limited because of:
General
Labelling
General
Safety Directions 13

a)unintentional exposure would rarely reect worst case conditions of (e.g.)
beam alignment with the pupil, worst case accommodation,
b)inherent safety margin in the maximum permissible exposure to laser radi-
ation (MPE)
c)natural aversion behaviour for exposure to bright light for the case of
visible radiation.
Description Value
Wavelength 685 nm
Maximum average radiant power 4.8 mW
Pulse duration 6673 ps
Pulse repetition frequency 75 MHz
Beam divergence 0.2 mrad x 0.3 mrad
NOHD (Nominal Ocular Hazard Distance) @ 0.25s 44 m
CAUTION
Class 3R laser products
From a safety perspective, class 3R laser products should be treated as poten-
tially hazardous.
Precautions:
▶Prevent direct eye exposure to the beam.
▶Do not direct the beam at other people.
CAUTION
Reected beams aimed at reecting surfaces
Potential hazards are not only related to direct beams but also to reected
beams aimed at reecting surfaces such as prisms, windows, mirrors, metallic
surfaces, etc.
Precautions:
▶Do not aim at areas that are essentially reective, such as a mirror, or
which could emit unwanted reections.
▶Do not look through or beside the optical sight at prisms or reecting
objects when the laser is switched on, in laser pointer or distance meas-
urement mode. Aiming at prisms is only permitted when looking through
the telescope.
14 Safety Directions

0022409_002
0
9
_
002
Art No.: 945232
S. No.: 1234567
Power: 7.4V ,1.4A max.
Leica Geosystems AG
CH-9435 Heerbrugg
Made in China
Manufactured: MM.YYYY
Complies with 21 CFR 1040.10 and 1040.11 except for
conformance with IEC 60825-1 Ed.3, as described in Laser
Notice No. 56, dated May 8, 2019
Pav λ= 685nm= 4.8mW
IEC 60825-1:2014
tp =6667ps
TS01 5” R500
Model:
0022417_001
1.6.4 Red Laser Pointer
The laser pointer built into the product produces a visible red laser beam
which emerges from the telescope objective.
The laser product described in this section is classied as laser class 3R in
accordance with:
•IEC 60825-1 (2014-05): “Safety of laser products”
Direct intrabeam viewing may be hazardous (low eye hazard level), in particu-
lar for deliberate ocular exposure. The beam may cause dazzle, ash-blindness
and after-images, particularly under low ambient light conditions. The risk of
injury for laser class 3R products is limited because of:
a)unintentional exposure would rarely reect worst case conditions of (e.g.)
beam alignment with the pupil, worst case accommodation,
b)inherent safety margin in the maximum permissible exposure to laser radi-
ation (MPE)
c)natural aversion behaviour for exposure to bright light for the case of
visible radiation.
Description Value
Wavelength
Measurements to prisms and reectorless
685 nm
Maximum average radiant power 4.8 mW
Labelling
General
Safety Directions 15

Description Value
Pulse duration 6673 ps
Pulse repetition frequency (PRF) 75 MHz
Beam divergence 0.2 mrad x 0.3 mrad
NOHD (Nominal Ocular Hazard Distance) @ 0.25 s 44 m / 144 ft
CAUTION
Class 3R laser products
From a safety perspective, class 3R laser products should be treated as poten-
tially hazardous.
Precautions:
▶Prevent direct eye exposure to the beam.
▶Do not direct the beam at other people.
CAUTION
Reected beams aimed at reecting surfaces
Potential hazards are not only related to direct beams but also to reected
beams aimed at reecting surfaces such as prisms, windows, mirrors, metallic
surfaces, etc.
Precautions:
▶Do not aim at areas that are essentially reective, such as a mirror, or
which could emit unwanted reections.
▶Do not look through or beside the optical sight at prisms or reecting
objects when the laser is switched on, in laser pointer or distance meas-
urement mode. Aiming at prisms is only permitted when looking through
the telescope.
0022409_002
0
9
_
002
Labelling
16 Safety Directions

Art No.: 945232
S. No.: 1234567
Power: 7.4V ,1.4A max.
Leica Geosystems AG
CH-9435 Heerbrugg
Made in China
Manufactured: MM.YYYY
Complies with 21 CFR 1040.10 and 1040.11 except for
conformance with IEC 60825-1 Ed.3, as described in Laser
Notice No. 56, dated May 8, 2019
Pav λ= 685nm= 4.8mW
IEC 60825-1:2014
tp =6667ps
TS01 5” R500
Model:
0022417_001
1.6.5 Laser Plummet
The laser plummet built into the product produces a visible red laser beam
which emerges from the bottom of the product.
The laser product described in this section is classied as laser class 2 in
accordance with:
•IEC 60825-1 (2014-05): “Safety of laser products”
These products are safe for momentary exposures but can be hazardous for
deliberate staring into the beam. The beam may cause dazzle, ash-blindness
and after-images, particularly under low ambient light conditions.
Description Value
Wavelength 640 nm
Maximum average radiant power 0.95 mW
Pulse duration 0.1 ms - cw
Pulse repetition frequency (PRF) 1 kHz
Beam divergance <1.5 mrad
CAUTION
Class 2 laser product
From a safety perspective, class 2 laser products are not inherently safe for
the eyes.
Precautions:
▶Avoid staring into the beam or viewing it through optical instruments.
▶Avoid pointing the beam at other people or at animals.
General
Safety Directions 17

0022412_001
a
b
a Laser beam
b Exit for laser beam
1.7 Electromagnetic Compatibility (EMC)
The term Electromagnetic Compatibility is taken to mean the capability of
the product to function smoothly in an environment where electromagnetic
radiation and electrostatic discharges are present, and without causing elec-
tromagnetic disturbances to other equipment.
WARNING
Electromagnetic radiation
Electromagnetic radiation can cause disturbances in other equipment.
Precautions:
▶Although the product meets the strict regulations and standards which
are in force in this respect, Leica Geosystems cannot completely
exclude the possibility that other equipment may be disturbed.
CAUTION
Use of the product with accessories from other manufacturers. For
example, eld computers, personal computers or other electronic
equipment, non-standard cables or external batteries
This may cause disturbances in other equipment.
Precautions:
▶Use only the equipment and accessories recommended by Leica Geosys-
tems.
▶When combined with the product, other accessories must meet the strict
requirements stipulated by the guidelines and standards.
▶When using computers, two-way radios or other electronic equipment,
pay attention to the information about electromagnetic compatibility
provided by the manufacturer.
Labelling
Description
18 Safety Directions

CAUTION
Intense electromagnetic radiation. For example, near radio transmit-
ters, transponders, two-way radios or diesel generators
Although the product meets the strict regulations and standards which are in
force in this respect, Leica Geosystems cannot completely exclude the possib-
ility that the function of the product may be disturbed in such an electromag-
netic environment.
Precautions:
▶Check the plausibility of results obtained under these conditions.
CAUTION
Electromagnetic radiation due to improper connection of cables
If the product is operated with connecting cables, attached at only one
of their two ends, the permitted level of electromagnetic radiation may be
exceeded and the correct functioning of other products may be impaired. For
example, external supply cables or interface cables.
Precautions:
▶While the product is in use, connecting cables, for example product to
external battery or product to computer, must be connected at both ends.
WARNING
Use of product with radio or digital cellular phone devices
Electromagnetic elds can cause disturbances in other equipment, installa-
tions, medical devices, for example pacemakers or hearing aids, and aircrafts.
Electromagnetic elds can also affect humans and animals.
Precautions:
▶Although the product meets the strict regulations and standards which
are in force in this respect, Leica Geosystems cannot completely exclude
the possibility that other equipment can be disturbed or that humans or
animals can be affected.
▶Do not operate the product with radio or digital cellular phone devices in
the vicinity of lling stations or chemical installations, or in other areas
where an explosion hazard exists.
▶Do not operate the product with radio or digital cellular phone devices
near medical equipment.
▶Do not operate the product with radio or digital cellular phone devices in
aircrafts.
▶Do not operate the product with radio or digital cellular phone devices for
long periods with the product immediately next to your body.
Radios or digital cel-
lular phones
Safety Directions 19

CAUTION
Exceeding the RF radiation exposure limits for general population
Health risk
Precautions:
▶The antennas used for this transmitter must be installed such that a min-
imum separation distance of at least 23 cm is always maintained between
the radiator (antenna) and all persons.
▶The antennas used for this transmitter must not be co-located or oper-
ated with any other antenna or transmitter.
20 Safety Directions
