LELY Discovery Collector C2 User manual

www.lely.com Lely Industries N.V.
.
Operator Manual
en-US - English Original
5.4008.8573.0 B
Lely Discovery Collector C2
Mobile Barn Cleaner

INTENTIONALLY BLANK
5.4008.8573.0 B
in n o va to r s in a g ric u lt u re

5.4008.8573.0 B
Trademarks, Copyright and Disclaimer 3
Trademarks, Copyright and Disclaimer
The information given in this publication is provided for information purposes only and does not
constitute an offer for sale. Certain products may not be available in individual countries and products
supplied may differ from those illustrated.
No part of this publication may be copied or published by means of printing, photocopying, microfilm or
any other process whatsoever without prior permission in writing by Lely Holding B.V. Although the
contents of this publication have been compiled with the greatest possible care, Lely cannot accept
liability for any damage that might arise from errors or omissions in this publication.
For more information on the right on exclusive use please refer to our trademark notice on www.lely.com.
Copyright © 2024 Lely Holding B.V.
All rights reserved
Lely Industries N.V.
Cornelis van der Lelylaan 1
3147 PB Maassluis
the Netherlands
Phone: [phone]
Fax: [phone]
Website: www.lely.com
in n o va to r s in a g ric u lt u re

INTENTIONALLY BLANK
5.4008.8573.0 B
4 Trademarks, Copyright and Disclaimer
in n o va to r s in a g ric u lt u re

5.4008.8573.0 B
List of included Amendments 5
List of included Amendments
Issue Date
(yyyy/mm)
Revision Chapter(s) Remarks
2024/01 BAll Initial release
2021/10 -Validation version
in n o va to r s in a g ric u lt u re

INTENTIONALLY BLANK
5.4008.8573.0 B
6 List of included Amendments
in n o va to r s in a g ric u lt u re

5.4008.8573.0 B
Preface 7
Preface
Manual Contents
This manual contains the information necessary to operate the Lely Discovery barn cleaner.
The information in this manual is for operators.
Study and understand this information thoroughly before you operate the machine.
Failure to do so could result in damage to equipment or personal injury. Please
consult your local Lely service provider if you do not understand the information in
this manual, or if you need additional information. Store this manual in a safe place
for future reference.
All information in this manual has been compiled with care. Lely shall not be liable for errors or faults in
this manual. The recommendations are meant to serve as guidelines. All instructions, pictures and
specifications in this manual are based on the latest information that was available at the time of
publication. Your machine may comprise improvements, features or options that are not covered in this
manual.
Applicability
The table below shows the machine type numbers for which this manual is applicable.
Model designation
Model Type number
Lely Discovery Collector C2 5.4008.0030.0
Software version
The description, operation and procedures in this manual are based on software version 1.7.4.
Standard Torque Loading of Parts
All the nuts, bolts and screws used on the machine are torque tightened to standard torque loadings
applicable to the construction materials used.
If a part has a non-standard torque loading, it is specified in the applicable part of the manual.
Registration
The type and serial number plate of the Discovery is attached under the top cover, on the right side of the
machine behind the front plate. Always include the type and serial number of your product, when you
contact your local Lely service provider or when you order spare parts.
We suggest that you complete the table below with the type and serial numbers of your machine. This
makes sure that you can easily find the information.
in n o va to r s in a g ric u lt u re

5.4008.8573.0 B
8 Preface
Figure 1. Type and serial number plate
Type number
Serial number
Figure 2. Type and serial number plate
in n o va to r s in a g ric u lt u re

5.4008.8573.0 B
Preface 9
Personnel Requirements
Risk of accident from insufficiently qualified personnel.
Unqualified personnel working on the machine can be the cause of serious injuries and
considerable damage to material.
•All activities must only be carried out by qualified personnel.
•Keep unqualified personnel away from the machine.
•Only persons who can be expected to carry out their job reliably are authorized as
personnel. Persons whose reactions are impaired, e.g. by drugs, alcohol, medications
are not authorized to work with the machine.
Maintenance Authorization
Risk of accident from uncertified technicians.
Uncertified technicians doing maintenance on the machine can be the cause of serious
injuries and considerable damage to material.
Only technicians certified by Lely Industries are authorized to do maintenance on the
machine, except for the maintenance done by the operator as indicated in the operator
manual. If people who are not certified by Lely Industries do maintenance on the
machine, the warranty on the machine becomes invalid.
Technician Training
All the technicians certified by Lely Industries have completed an approved training program, and passed
written and practical examinations during and at the end of the training program. The training is given by
Lely International or a specialist from the LSO and includes troubleshooting and corrective maintenance
of the machine
During training, a trainee is permitted to work for up to a maximum of six months under close supervision
of a certified technician. A trainee can do work on the machine only in the presence of a certified
technician.
Contact Number Local Service Provider
We suggest you write the telephone number and email address of your local service provider contact in
the table below. This makes sure you can easily find the information.
Telephone number
email address
in n o va to r s in a g ric u lt u re

5.4008.8573.0 B
10 Preface
Left, Right, Rear and Front
The positions left, right, rear and front in this manual refer to either:
•The machine, as seen in the driving direction.
•The particular component, as seen when standing in front of it.
in n o va to r s in a g ric u lt u re

5.4008.8573.0 B
Table of Contents 11
Table of Contents
1 The Lely Discovery Mobile Barn Cleaner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-1
1.1 Intended Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
1.2 Foreseeable Misuse . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
2 Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-1
2.1 Signal Icons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
2.2 Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
2.2.1 Stop the machine in case of an emergency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
2.2.2 How to act in case of an acute problem with the battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
2.2.3 GeneralSafety ........................................................................ 2-4
2.2.4 Electrical Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5
2.2.5 OperatingSafety ....................................................................... 2-5
2.2.6 Installation Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6
2.2.7 Maintenance Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6
2.3 Safety Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7
2.3.1 Safety Devices on the Machine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7
2.3.2 Safety Devices on the Charger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8
2.3.3 Safeguard on the Open Dump Pit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9
2.3.4 Safeguard on the Syphon . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-10
2.4 Safety Decals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-12
2.4.1 Safety decals on the machine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-12
2.4.2 Safety decals on the charger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-13
2.4.3 Safety signs in the barn . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-14
2.4.4 Installation of Safety Decals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-14
2.4.5 Maintenance of Safety Decals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-14
3 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
3.1 Barn Cleaner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
3.2 Charging Station . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
3.3 Water Filling Station . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
3.4 Dump Station . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3
3.5 Smartphone Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4
4 Description and Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
4.1 Main Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
4.2 Component Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
4.2.1 BarnCleaner ........................................................................... 4-2
4.2.2 Water Filling Station . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-6
4.2.3 ChargingStation ....................................................................... 4-8
4.2.4 DumpStation .......................................................................... 4-9
4.3 User Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-11
in n o va to r s in a g ric u lt u re

5.4008.8573.0 B
12 Table of Contents
4.3.1 MenuStructure .......................................................................4-11
4.3.2 HomePage ...........................................................................4-12
4.3.3 ManualControl .......................................................................4-14
4.3.4 Dayplanning ..........................................................................4-16
4.3.5 Routes ................................................................................4-17
4.3.6 Alarms ................................................................................4-18
4.3.7 Testing ...............................................................................4-19
4.3.8 Settings ...............................................................................4-20
4.3.8.1 Wheels .....................................................................4-20
4.3.8.2 Cloud ......................................................................4-21
4.3.8.3 WiFi Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-22
4.3.8.4 Gyroscope ..................................................................4-23
4.4 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-23
5 Operating Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
5.1 Pair your Smartphone with the Discovery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
5.2 Open or Close the Top Cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
5.3 Switch the Machine On and Off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-3
5.4 Put the Machine into Operation and take it out of Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-5
5.4.1 Put the Machine into Operation and take it Out of Operation with the Pause Button . . . 5-6
5.4.2 Put the Machine into Operation and Take it Out of Operation with the Lely Control Plus
Application ............................................................................... 5-7
5.5 Control the Machine with your Smartphone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-8
5.5.1 Connect the Lely Control Plus app to the Machine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-8
5.5.2 Synchronize the Clock of the Discovery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-9
5.5.3 Manually Control the Machine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-10
5.5.3.1 Manually drive the Machine to a Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-10
5.5.3.2 Drive the Machine back to the Charging Station . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-12
5.5.3.3 Use a Return Route to Drive the Machine back to the Charging Station . . . . . 5-13
5.5.3.4 Drive the Machine to the Water Filling Station . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-14
5.5.3.5 Manually start a Route . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-15
5.5.3.6 Manually empty the Manure Tank of the Machine . . . . . . . . . . . . . . . . . . . . . . . . . . 5-16
5.5.4 View and acknowledge Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-17
5.5.5 Modify the Day Planning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-18
5.5.6 Enable or disable Water Spraying on all Routes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-20
5.6 Prepare the Machine for Wintertime . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-21
5.7 Charge a Completely Depleted Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-21
6 Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1
6.1 Maintenance Schedule . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1
6.2 Shave the Tails . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-2
6.3 Clean the Machine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-2
6.4 Clean the Pad and the black Plate on the Machine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3
6.5 Clean the Pad and Alignment Mechanism and Plate on the Charger . . . . . . . . . . . . . . . . . . . . . . . 6-4
6.6 Clean the Top Air Filter and the Level Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-6
6.7 Clean the Ultrasonic Sensors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-8
in n o va to r s in a g ric u lt u re

5.4008.8573.0 B
Table of Contents 13
6.8 Clean the Manure Tank . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-10
6.9 Hoist the Machine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-12
7 Test and Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-1
7.1 Test the Ultrasonic Sensors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-1
7.2 Calibrate the Wheels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-1
7.3 Set the Gyroscope Target Temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-2
8 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8-1
8.1 Troubleshooting Tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-1
9 Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-1
9.1 Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-1
9.2 Disposal of the battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-1
10 Declaration of Conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-1
10.1 EC Declaration of Conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10-1
10.2 UKCA Declaration of Conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10-2
in n o va to r s in a g ric u lt u re

INTENTIONALLY BLANK
5.4008.8573.0 B
14 Table of Contents
in n o va to r s in a g ric u lt u re

5.4008.8573.0 B
The Lely Discovery Mobile Barn Cleaner 1-1
1 The Lely Discovery Mobile Barn Cleaner
1.1 Intended Use
The Lely Discovery Collector C2 is intended solely for use in an agricultural barn with closed concrete or
emission reducing floors that have only small openings. The machine is used to take in manure from cows
and to release this manure in a dump pit that is specially designed for this purpose.
The machine is intended to operate autonomous on preprogrammed routes efficient and safely between
cows within an enclosed space on the barn floor, the manure alley. The machine moisturizes the floor with
water and sucks up cow manure into a container by means of a vacuum. The manure is released in a
designated area by removing the vacuum from the container. The implemented safety measures are
designed for this application only.
Leaving this designated, enclosed space (e.g. crossing the feed alley to get from one manure alley to
another) is not an intended use and therefore not allowed.
Application of the Lely Discovery Collector C2 in any way other than the intended use is dangerous and
can cause serious injuries or death.
Usage going beyond the intended use as described above does not constitute proper use. The
manufacturer is not liable for damage resulting from improper use; the operator only bears the risk.
Intended use also implies that the instructions and rules prescribed by the manufacturer are obeyed.
1.2 Foreseeable Misuse
The Lely Discovery must not be used for taking in other materials than manure of cows.
It is not allowed to autonomously cross the feeding alley or any other area outside the
manure alley.
It is not allowed for people (children) to climb or sit on the machine and/or ride along.
It is not allowed to use a high pressure cleaner to clean the machine.
The Lely Discovery must not be operated outside an agricultural barn.
in n o va to r s in a g ric u lt u re

INTENTIONALLY BLANK
5.4008.8573.0 B
1-2 The Lely Discovery Mobile Barn Cleaner
in n o va to r s in a g ric u lt u re

5.4008.8573.0 B
Safety 2-1
2 Safety
The Lely Discovery is an autonomous driving machine. Therefore it is of the utmost importance to obey all
safety instructions.
2.1 Signal Icons
Note the use of the signal words DANGER, WARNING and CAUTION with the safety messages. The signal
word for each message uses the following guidelines:
Danger
Indicates a hazardous situation which, if not avoided, will result in
death or serious injury.
Warning
Indicates a hazardous situation which, if not avoided, could result in death or serious
injury.
Caution
Indicates a hazardous situation which, if not avoided, could result in minor or moderate
injury.
Notice
Is used to address practices not related to physical injury e.g. property damage.
Tip
Indicates information that may help the reader, but not hazard related.
in n o va to r s in a g ric u lt u re

5.4008.8573.0 B
2-2 Safety
2.2 Safety Instructions
Contact your nearest Lely service provider if you have any questions concerning the
safety instructions.
2.2.1 Stop the machine in case of an emergency
Stop the machine with the pause button
1. Push the pause button (1).
Figure 3. Location of the pause button
•The machine stops immediately. It also stops taking in manure and sprinkling water.
Stop the machine with the smartphone
1. Open the Lely Control Plus app and connect to the appropriate machine.
in n o va to r s in a g ric u lt u re

5.4008.8573.0 B
Safety 2-3
2. Draw the slider to the left position.
•When the machine was moving, it stops immediately. It also stops taking in manure and sprinkling
water.
•The color of the slider turns to white .
•The pause button light switches ON.
•The operational sound of the machine is switched OFF.
2.2.2 How to act in case of an acute problem with the battery
When malfunctioning or wrong use causes a blowout of gasses, smoke, deformation or
fire, you must take the machine outside the building and away from public roads. Call the
emergency number for the fire department.
1. First take care of your own safety and the safety of people around you.
2. Push or tow the machine outside the building and leave it at a safe distance from buildings and public
roads.
Be aware that pushing or towing will also cause damage to the electronics, so only tow or push in case
of an emergency.
KEY: 1. Attachment points for towing
in n o va to r s in a g ric u lt u re

5.4008.8573.0 B
2-4 Safety
3. Call the emergency number for the fire department and inform them about the situation. The machine
has a 24V Li-ion rechargable battery.
4. Call your Lely service provider to let a service technician remove the battery and have it collected by a
specialized waste disposal company. See also Disposal of the battery (see page 9-1).
2.2.3 General Safety
•When locking up cows in the feed fence (e.g. for clawcare) on a location where the machine can drive
during a route or by accident, the machine must be switched off or taken out of operation to prevent
serious injury of cows! Locked up cows can not get away when the machine approaches.
•No calfs are allowed in the area where the machine is active.
•Separate pregnant cows timely to prevent cows from calving in the regular barn. The machine can be
dangerous for newborn calves (injuries and/or pushed into the manure pit).
•Cut off the tail plume and shave the tail to prevent as much as possible that the tail is being entangled
when the cow lies on the bed and the machine drives behind the cow.
•Do not modify the installation or the building and make sure the fencing and walls that prevents the
machine from leaving the manure alley stay in place and not damaged.
•Read and understand the manual and all safety signs before you connect power supplies to operate,
maintain or adjust the machine.
•Do not work near the magnets in the charger if you have a cardiac pacemaker or other implant that can
be impaired by magnetic fields.
•Only trained persons are permitted to operate the machine.
•Review safety related requirements with all machine operators frequently (annually).
•Keep unauthorized persons, especially small children away from the manure alley at all times because
of hazards from the unpredictability of cows.
•Make sure that the danger and caution signs are clearly visible. Clean them when they are dirty and
replace them when they are damaged. The signs are:
•A danger sign near the open hole when it is next to a public area
•Caution signs for moving vehicles at the entrance of each corridor in the barn
•A first-aid kit must be available in or near the barn where the machine operates. Store in a highly visible
place.
•Know the emergency medical center number for your area.
•The area around the dump pit must be well ventilated especially when there is a combined dump pit
and charger. The manure gasses can be explosive.
•Always ventilate the area before and during work on the machine. The manure gasses can be toxic.
•Always ventilate the barn during manure mixing. The manure gasses can be toxic.
•Make sure no manure mixing is active when you work on the machine near the dump pit. The manure
gasses can be toxic and explosive.
•A carbon dioxide gas extinguisher or powder fire extinguisher must be available in or near the barn
where the machine operates. Store in a highly visible place.
Dry sand can also be used to cover the machine when the battery is burning.
•When the buzzer is defect, make sure it is being repaired before putting the machine into operation
again.
in n o va to r s in a g ric u lt u re
