LENCO CR-430DAB+ User manual




Model:CR‐430DAB+




Usermanual DAB+/FMClockRadiowithLCDDisplay
Gebruiksaanwijzing DAB+/FM‐klokradiometLCD‐scherm
Benutzerhandbuch DAB+/UKW‐UhrenradiomitLCD‐Anzeige
Moded’emploi Radio‐réveilDAB+/FMavecécranLCD
Manualdelusuario RadiorelojDAB+/FMconpantallaLCD

2

Index
English..................................................................................................................... 3
Nederlands ........................................................................................................... 13
Deutsch................................................................................................................. 23
Français................................................................................................................. 35
Español ................................................................................................................. 46













Version1.0

3

EnglishDAB+/FMClockRadiowithLCDDisplay
1. Safety

Forhouseholdandindooruseonly
Placetheapplianceonaflat,stablesurfacewithadequateventilationandawayfromother
sourcesofheat.Minimumdistancesaroundtheapplianceforadequateventilationis10cm.Do
notcoverorrestrictventilationopenings.
Keeptheapplianceanditscordoutofreachofchildrenlessthan8years.
Donotallowchildrentousetheappliancewithoutsupervision.
Thisappliancecanbeusedbychildrenagedfrom8yearsandaboveandpersonswithreduced
physical,sensoryormentalcapabilitiesorlackofexperienceandknowledgeiftheyhavebeen
givensupervisionorinstructionconcerninguseoftheapplianceinasafewayandunderstand
thehazardsinvolved.Childrenshallnotplaywiththeappliance.Cleaningandusermaintenance
shallnotbemadebychildrenunlesstheyareagedfrom8yearsandaboveandsupervised.
Fullyunwindthecablebeforeplugginginandensurethecableispositionedawayfromareas
whereitislikelytogetdamagedorcauseatriphazard.
Theoutputcordofthismainsadaptorcannotbereplaced.Intheeventofdamagetothecable,
jackplugoradaptor,theentireadaptorunitshouldbereplaced.
Connectionsmustonlybemadeviathemainsadaptorsupplied,neverconnecttheappliance
directlytothe240vmainssupply.
Neverusetheadaptorsuppliedwithanyotherappliance.
Themainsadaptorwillbecomewarminuse;donotcoverorplaceonornearsurfacesthatcould
beaffectedbyheatsuchastabletopsandcarpets.
Removemainsadaptorfromsupplyifapplianceisunusedforalongperiodoftimeandduring
thunderstorms.
Donotpullonthecabletodisconnectfrommainssupply.
Keepappliance,cable,mainsadaptorplugdryandawayfromareaswhereitislikelytoget
splashed.Avoidusinginhot,humidenvironments.
Donotplaceitemswithnakedflamesorcontainerswithliquidsonthisappliance.
Switchoffandunplugwhennotinuseandbeforecleaningorservicingtheappliance.Servicing
ofthisappliancemustonlybecarriedoutbyaqualifiedelectrician.
Alwaysensurethemainsadaptorplugisreadilyunpluggable–donotusewith‘lockable’sockets
orpermanentlywiretomains.

Thelightningflashwitharrow‐headsymbol,
withinanequilateraltriangle,isintendedto
alerttheusertothepresenceofun‐
insulated“dangerousvoltage”withinthe
product’senclosurethatmaybeof
sufficientmagnitudetoconstituteariskof
electricshock.
Theexclamationpointwithinanequilateral
triangleisintendedtoalerttheuserto
presenceofimportantoperatingand
maintenance(servicing)instructionsinthe
literatureaccompanyingtheappliance.



4

Parts
Topview

Rearview


1. Modebutton
2. Standby()button
3. Menu/Infobutton
4. Alarm1button
5. Enterbutton
6. Alarm2button
7. Snooze/Sleepbutton
8. Presetbutton
9. Scanbutton
10. Backward( )button
11. Volume‐button
12. Forward()button
13. Volume+button
14. Speaker
15. Antenna
16. On/offswitch
17. DCinjack
18. Headphonejack
19. LCDdisplay

5


1. BATTERYINSTALLATIONANDUSE
Tousetheappliancewithbatteriesensurethatthepowercordisnotconnectedtothemains
andinstallthebatteriesintothebatterycompartment.
1.1 Liftoffthebatterycompartmentcoverfromtheundersideofthe
radio.
1.2 Insert4xAA1.5Valkalinebatteries(notincluded)inaccordance
withthediagraminthebatterycompartment.Takecaretoobserve
thecorrectpolarity(+/‐).
1.3 Refitthebatterycompartmentcover. 
1.4 Donotexposethebatteriesortheinstalledbatteriestoexcessiveheat(e.g.fire,sunshine
orpositionclosetoradiatorsetc.).
Notes:
AllDABradio’susemorepowerduringusethan‘traditional’radiosandsowillrunbatteries
downwithinafewhours.Thereforeuseofmainspower(orrechargeablebatteries)is
recommendedforextendedlistening.
Alwaysswitchoffusingtheon/offatrearwhennotinuse.Standbymodecontinuestouse
powerand(ifinbatterymode)willflattenthebatterieswithinacoupleofdays.
BATTERYSAFETYANDDISPOSAL
CAUTION‐Dangerofexplosionifbatteriesareincorrectlyfitted/replaced.
Onlyuse‘AA’1.5Vbatteriesinthisappliance.
Besuretoinsertbatteriescorrectlytakingcaretoobservethecorrectpolarity(+and‐).
Useonlybatteriesofthesameorequivalenttypeasrecommended.
Batteriesshouldbereplacedbyanadult.
Donotrechargenon‐rechargeablebatteries.
Removerechargeablebatteriesfromappliancebeforerecharging.
Nevermixoldandnewbatteries(replaceallbatteriesatthesametime).
Nevertrytodismantlebatteries.
Alwaysremoveexhaustedordeadbatteriesfromtheproduct.
Removebatteriesfromtheproductbeforeextendedstorage.
Disposeofbatteriesresponsiblyatlocalauthorityhouseholdwasterecyclingfacility.
DONOTdisposeofbatteriesinafireasthebatteriesmayexplode.
2. GETTINGSTARTED
2.1 Ifusingmainspower,inserttheadaptorcordintothepowersocketattherearoftheradio.
Plugtheadaptorintothemainssupplysocket.
2.2 Ifusingtheradiowithbatteriesensurethatthepowercordisnotinsertedintothebackof
theapplianceandinstallthebatteriesintothebatterycompartment.
2.3 Fullyextendthetelescopicantenna.
2.4 Movetheon/offswitchattherearoftheradiotothe‘on’positionandthedisplaywill
illuminate,awelcomemessagewillbedisplayedbriefly(Fig.1)andthentheclock(00:00:00)
willbeshown.
Fig.1
2.5 PresstheStandby()buttontoturntheradioonandstarttotunein.
2.6 DABmodewillautomaticallybeselectedandtheradiowillperformanautotunefullscan
(Fig.2).Thedisplaywillthenshow‘searching’,togetherwithaslidebar(Fig.3)that
indicatestheprogressofthescanandthenumberofstationsfoundsofar.

6

fig.2
fig.3
2.7 Whenthescanisfinishedtheradiowillplaythefirstalphanumericallyfoundstation.The
displaywillshowthestationbeinglistenedto.
2.8 Iftheradiodoesnotfindanystation,‘NosignalDAB’willbedisplayed.Ensuretheantenna
isfullyextendedortrymovingtheradiotoanotherlocation(nearawindowmaybebetter)
andrepeattheabovesteps.
2.9 AdjustthevolumetothedesiredlevelusingVol+orVol‐buttons.
2.10 Tosearchthestationsthathavebeenfound,presstheForward()buttonorbackward
()buttontoscrollthroughtheavailablestations.
2.11 ToswitchtoFMradio,presstheModebutton.Thedisplaywillshow‘switchingtoFM’.
PressthebuttonagaintoreturntheradiotoDABmode.
2.12 PresstheStandby( )buttontoplacetheunitinstandbymode.
2.13 Toturntheclockradiocompletelyoff,movetheon/offswitchattherearoftheradioto
the‘off’position.(Note:Clockdisplayandalarmwillnotfunctioninoffmode.)
Note:TheclockinthisradioisequippedtoreceiveaDABradiofrequencytimesignalorFMtime
signalwithRDSandafterturnedon,itwillautomaticallytuneintoaDABradiostationand
updatetheclock.Itmaybenecessarytowaitfor1‐2minutestoallowtheunittoreceivethe
timesignal.
3. USINGTHERADIO‐DABMODE
DABdiffersfromanalogueradio;theseparatesignalsfromanumberofstationsaregrouped
togetherandtransmittedasasinglefrequency.Thesegroupsarereferredtoasmultiplexesand
ensembles.Eachtimeagrouphasbeenfoundthenameofthegroupwillbeshownonthelower
halfofthedisplay.
3.1 DABmode‐autoscan
ThisfunctionallowstheradiotosearchautomaticallyforDABBandIIIchannels.
3.1.1 TosearchallDABbandIIIchannels,presstheScanbuttonand‘Autotunefullscan’is
displayed.Thescanwillbeinitiatedandaslidebarwillbeshowninthedisplaytoshowthe
processofthescan.
3.1.2 Whenthescanisfinishedtheradiowillplaythefirstalphanumericallyfoundstation.
3.1.3 Iftheradiodoesnotfindanystations,‘NosignalDAB’willbedisplayed.Trymovingthe
radiotoanotherlocation(nearawindowmaybebetter)andrepeatingtheabovesteps.
Ensuretheantennaisfullyextended.
3.1.4 Toscrollthroughthestationsthathavebeenfound,presstheForward()buttonor
Backward()button.ThenpresstheEnterbuttonlistentothestationofchoiceorwaita
fewsecondsandtheradiowillautomaticallyretune.
3.2 DABmode‐Manualscan
Thisfunctionallowsaspecificornewensembletobemanuallyaddedtothestationsalready
availableontheradio.
3.2.1 PressandholdtheEnterbuttonuntilthedisplayshows‘manualtune’.
3.2.2 PresstheForward( )buttonorBackward()buttontomovethroughtheDAB
channelsandtheassociatedfrequencies.Whenthedesiredensemble/frequencyappears
inthedisplay,presstheenterbuttontoaddtheensembleanddisplaythename.

7

3.2.3 PresstheForward( )buttonorBackward()buttontomovethroughthestations
includedintheensembleandpresstheEnterbuttontolistentothestationofchoiceand
exitthemanualtunemode.
3.3 DABMODE‐SECONDARYSERVICES
Somestationsincludesecondaryservicesandwhentheseareavailablea‘>’symbolappears
afterthestationname.ToaccessthisservicepresstheEnterbutton.
4. USINGTHERADIO‐FMMODE
4.1 Turntheradioon,presstheModebuttonandselecttheFMmode.Thedisplaywillshow
‘switchingtoFM’andtheradiowilltuneto87.50MHz.
4.2 Toactivateautosearch,brieflypresstheScanbuttonandtheradiowillstartscanningup
thefrequencyandstopautomaticallyoncethenextstationuphasbeenfound.Toscan
downwards,pressandholdtheScanbuttonforatleast1second.
4.3 Tosearchmanually,presstheForward()buttonorBackward()buttontoincrement
thefrequencyby0.05MHz.
4.4 Tochangetheaudiomode(autoormono)presstheEnterbuttonontheunit,thiswill
switchfromautotomono,pressandagaintoswitchback.Ifautoisselectedtheradiowill
automaticallyswitchbetweenstereoandmonomode.(Note:Asthisunitonlyhasasingle
speaker,thesemodeswillnotaffectthespeakeroutput.)
4.5 IfanFMRDS(RadioDataSignal)ispresent,thedisplaywillautomaticallyshowthestation
nameandradiotext(whereavailable).
5. RADIODISPLAYMODES
IftheMenubuttonispressedrepeatedlywhenaradiostationisplaying,thesecondlineofthe
stationdisplaywillscrollthroughthefollowmodeswitheachpressofthebutton.
InDABmode

InFMmode

Ensemble/Multiplex(Groupname)‐Theensemble/multiplexisagroupofstationthatare
bundledandtransmittedtogetherinasinglefrequency.Therearenationalandlocalmultiplexes,
localonescontainstationsthatarespecifictothelocalarea.
Signalstrength‐thedisplaywillshowaslidebartoindicatethestrengthofthesignal.The
strongerthesignal,thelongerthebar.
DLS(dynamiclabelsegment)/Radiotext‐Thebroadcastermayincludeascrollingmessageabout
thecurrentprogramme.
Programmetype‐thisdescribesthestyleoftheprogramme.Iftheinformationisnotavailable
thedisplaywillshow‘<Programmetype>’.
Timeanddate‐thetimeanddatewillbeautomaticallyupdatedbytheradiotimesignal.
Audiomode‐thedisplaywillshowifthestationbeingreceivedisstereoormono.
Frequency‐displaywillshowthefrequencyofthestationbeingbroadcast.
Audiobitrate‐thedisplaywillshowthedigitalaudiobitratebeingreceived.
6. PROGRAMMEDSTATIONFUNCTION
Thisfunctionallowsupto10stationstobeprogrammedintothememoryandstoredintheDAB
andFMmodes.
6.1 Followthedirectionsabovetoselectaradiostation.
6.2 PressandholdthePresetbuttonuntilthedisplayshowstheflashingPresetnumber.(Fig.8)
Ensemble/Multiplex(Groupmame)FrequencyAudiobitrate
Signalstrength
Time/Date
DLS (Scrollingtext)
ProgrammeType
ProgrammeType
Audiomode Frequency
Time/Date
Signalstrength
RadioText

8

Fig.8
6.3 PresstheForward( )buttonorBackward()buttontoselectthepresetstorage
locationofchoiceandthenpresstheEnterbuttontoconfirm.Thestationnow
broadcastinghasnowbeenstoredintheselectedlocation(Fig.9)
Fig.9
6.4 Tostorefurtherstations,pressandholdthePresetbuttonandthenpresstheForward
( )buttonorBackward()buttonrepeatedlyuntilanemptystoragelocationisfound.
PresstheEnterbuttontosavethestation.
6.5 Tolistentoapresetstation,pressthepresetbuttononceandthenpresstheForward( )
buttonorBackward()buttontoselectthedesiredpresetlocation.Whenthestorage
locationofchoiceisdisplayed,presstheEnterbuttontolistentothestoredstation.Ifthe
presethasnotbeenallocated‘Presetempty’willbeshowninthedisplay(Fig.10).
Fig.10
7. ALARMFUNCTION
Thisradiohasdualalarmfunctionanditispossibletosettwoindividualalarmtimes.Thisalarm
andmaybesettowakeasabuzzertoneortoafavoriteradio(DAB/FM)station.Thealarmcan
besetinstandbyorduringoperation.
7.1 Tosetthefirstalarm,presstheAlarm1buttontodisplaythealarm1status,usethe
Forward( )buttonorBackward()buttonuntil‘AlarmstatusON’isdisplayedand
presstheEnterbuttontoenterthesetupmode.
7.2 Thedisplaywillnowshowthecurrenttime,thewakeuptimeandthehourdigitsforthe
wakeuptimewillflash.PresstheForward( )buttonorBackward()buttonuntilthe
correctalarmhourisdisplayed.
7.3 PresstheEnterbuttontoacceptandtheminutedigitswillnowflashinthedisplay.Usethe
Forward( )buttonorBackward()buttonuntilthecorrectalarmminuteisdisplayed.
7.4 PresstheEnterbuttontoacceptandthealarmfrequency(e.g.daily,weekdays,weekends,
once)willnowbedisplayed.UsetheForward( )buttonorBackward()buttontoset
thealarmfrequency.
7.5 PresstheEnterbuttontoacceptandthewakeupmode(e.g.BEEPER,DABorFM)willbe
displayed.UsetheForward( )buttonorBackward()buttontoselectthewakeup
modeofchoice.
7.6 PresstheEnterbuttontoacceptandthealarmvolumewillnowbedisplayed.Usethe
Forward()buttonorBackward()buttontosetthewakeupvolumeofchoice.
7.7 PresstheEnterbuttononcemoretoacceptandexitthesetupmode.Thealarmindicator
(1)willnowbeshowninthedisplayunderstandbymode.
7.8 Thealarmisnowsetandwillremaininmemorywhentheunitisswitchedtostandbymode.
7.9 Whenthetimeontheclockisthesameasthealarmtimethathasbeenset,thealarmwill
soundandthedisplaywillflash.
7.10 Thealarmwillcontinuetosoundandstopautomaticallyafteronehour.Tosilencethe
alarm,pressStandbybutton.Ifadailyalarmhasbeenset,thealarmindicatorwillremain
illuminatedandthealarmwillsoundagainatthetimethefollowingdayuntilthealarmis
switchedoff.

9

7.11 Toactivatethesnoozefunction,presstheSnooze/Sleepbuttonwhenthealarmsounds.
Thesnoozeindicator(Zz)willbeshowninthedisplay:thealarmwillsilenceandthensound
againafterapproximatelynineminutes.
7.12 Toturnoffthealarmpermanently,presstheAlarm1buttontodisplaythealarmstatus.
UsetheForward( )buttonorBackward()buttonuntil‘Alarmstatusoff’isdisplayed,
thenpresstheEnterbuttontoacceptandexitthemode.Thealarmhasbeendeactivated
andthealarmindicatorwillnolongerbeshowninthedisplay.
Notes:
Ifthepowerisinterrupted(ortheunitisswitchedoffusingtherearswitch)andbatteriesare
notfittedinthebatterycompartment,thealarmsettingwillbelost.
Tosetthesecondalarm,usetheAlarm2buttonandthenfollowthestepsabovetosetthis
alarm.
IftheDABorFMradiowakeupoptionisselectedthealarmwillplaythelaststationlistenedto
inDABorFM.
Theclockdisplaysize/brightnessisfixedandcannotbeadjusted.
8. SETTINGANDUSINGTHESLEEPFUNCTION
Thisfunctionwillswitchofftheradioautomaticallyafterapresettimeinterval.
8.1 Withtheradioofchoiceplaying,presstheSnooze/Sleepbuttonandthesleepstatusis
showninthedisplay.
8.2 PresstheForward()buttonorBackward()buttonrepeatedlyuntilthedesiredsleep
interval(seesequencebelow)isshowninthedisplay.

8.3 PresstheEnterbuttontoaccept.Thesleeptimerisnowactivatedandthedisplaywillshow
thesleepindicator(s)andthetimeintervalremainingbeforetheradioswitchesoff.
8.4 Thesleepfunctionwillcountdownandtheunitwillswitchoffautomaticallyafterthetime
intervalselectedhasbeenlapsed.
8.5 Tocancelthesleeptimer,presstheSnooze/SleepbuttonandthenpresstheForward( )
buttonorBackward()buttonrepeatedlyuntil‘OFF’isshowninthedisplay.Pressthe
Enterbuttontoaccept.
9. USINGHEADPHONES(notincluded)
Astereoheadphonejackhasbeenprovidedsothattheunitcanbeusedwithoutdisturbing
others.Plugintheheadphonesatthepointmarked‘ ’attherearoftheradioandadjustthe
listeningvolumetoyourchosenlevel.Excessivesoundpressurefromearphonesand
headphonescancausehearingloss.Thespeakerwillnotoperatewhenearphonesarefitted.
10. RESET
Movingtheradiotoanotherlocationinthecountrythepre‐tunedandstoredstationsmayno
longerbeavailableanditwillbenecessarytoresettheradiobacktothefactorysettings.
10.1 Withtheunitswitchedon,pressandholdtheMenu/Infobuttonuntilthedisplayshows
<SetTime/Date>,thenpress buttontoselectthe‘systemreset’.
10.2 PresstheEnterbuttontoconfirmresetand‘pressenterkeytoreset’willbedisplayed.
10.3 PresstheEnterbuttononceagaintoconfirm.Theradiowilldisplay‘systemreset’andthe
resetwillbegin.
10.4 A‘fullscan’willthenstartandthedisplaywillshowprogressingslidebar.
10.5 Whenthescanisfinishedtheradiowillplaythefirstalphanumericallyfoundstation.All
storedprogrammedstationswillbelostduringreset.
Note:Ifpress buttonagaininstep10.1the‘softwarenumber’willbedisplayed.
OFF

10

11. CAREANDMAINTENCE
Wipeexternalsurfaceswithasoftcloth.Ifthecabinetisverydirty,unplugfromthemains
supplyanduseadampclothsoakedinaweaksolutionofwashingupliquidandwater.Allowto
drythoroughlybeforereusing.

12. TROUBLESHOOTINGGUIDE
ObservationPotentialcause/solution
Theunitdoesnot
work.
Hastheadaptorleadbeencorrectlypluggedintothemainsandthe
DCinputjackattherearoftheunit?
Doesthesocketthatisbeingusedhavepower?
Hasthepowerleadbeenremovedfromthebackoftheunitwithout
thebatteriesbeinginstalled?
HastheON/OFFbuttonattherearoftheunitbeenmovedtothe
‘on’position?
Theunitdoesnot
workonbatteries
Hastheadaptorleadbeenremovedfromthebackoftheunit?
Arethebatteriesinsertedcorrectly?
Arethebatteriesexhausted?
HastheON/OFFbuttonattherearoftheunitbeenmovedtothe
‘on’position?
NosoundIsthevolumecontrolsetatminimum?
Areheadphonesfittedinthephonesjack?
Radioreception
noisy(FM)
Extendtheantennaoradjustthepositionoftheradio.
FMstereo‐ifweakswitchtoMonoasthisrequireslesssignal
strength.
Radioreception
stutters/bubbing
sounds(DAB)
Signalisweak.Extendtheantennaoradjustthelocationofthe
radio.Positionshigherupornearerwindowsmayimprove
reception.Notesometimesretractingtheaerialslightly(lessthan
fulllength)mayimprovereception.
DAB‘NosignalDAB’Thisnormallymeansthesignalisveryweak,notthatthereisno
signal.Trymovingtheradiotoadifferentlocationandre‐scanning.
CheckthatyourlocalareahasDABcoverage.
Alarmfunction
doesnotwork
Hasthealarmbeenactivates‐seesection9.1?
Hasthecorrectalarmbeenactivated?
Sleepfunctiondoes
notwork
Hasthesleepfunctionbeenactivated‐seesection10?
13. TECHNICALSPECIFICATION
Input100‐240V~50/60Hz,0.15A
Output5V/0.5A
BatteryDC6V(1.5Vx4AA)(Notincluded)
Powerconsumption3W
Powerconsumption(standby) 0.3W
Audiooutput 1WRMS
Radio DAB174‐240MHz
FM87.5‐108MHz
Operatingconditions Temperature:5°C~35°C
Humidity5%to90%
Operatingposition Horizontal
Powersupplyadaptor:(ForEUonly)
