LENCO DVP-937 User manual

PORTABLE DVD
Before connecting, operating or adjusting this product,
please read this user's manual carefully and completely.
PDVD-12309C MTK1389QD方 案 ENGLI SH MANU AL 带E UP(带红外 线耳机)带电池
USER'S MANUAL
DVP-937
For information and support,WWW.lenco.eu

1.Warning: To reduce the risk of electric shock, do not remove
the cover or back. There are no user-serviceable parts inside.
Refer servicing to qualified personnel.
2.Warning: To prevent fire or electric shock hazard, do not
expose the unit to rain or moisture.
3.Do not expose the Adaptor and portable DVD to water
(dripping or splashing) and no objects filled with liquids, such as
vases, should be placed on the unit.
4.Keep the portable DVD away from direct sunlight and heat
source such as radiators or stoves.
5.Do not block the ventilation openings. Slots and openings on
the unit are provided for ventilation. The openings should never
be blocked by placing your portable DVD on a cushion, sofa or
other similar surface.
6.Do not place the portable DVD on unstable cart, stand, tripod,
bracket or table. The unit may fall, resulting in possible damage
or injury.
7.Never place heavy or sharp objects on the LCD panel or frame.
8.Only use the AC adapter included with portable DVD. Using
any other adapter will void your warranty.
9.The plug of AC adaptor is used as the disconnect device, the
disconnect device shall remain readily operable.
10.Unplug the power from the outlet when the unit is not in use.
11.Attention should be drawn to the environmental aspects of
battery disposal.
This marking indicates that this product should not
be disposed with other household wastes
throughout the EU. To prevent possible harm to the
environment or human health from uncontrolled
waste disposal, recycle it responsibly to promote
the sustainable reuse of material resources. To
return your used device, please use the return and
collection systems or contact the retailer where
the product was purchased. They can take this
product for environmental safe recycling.
1
Important Safety Instructions
12.CAUTION: Danger of explosion if battery is incorrectly
replaced. Replace only with the same or equivalent type.
13.WARNNING: The battery (battery or batteries or battery pack)
shall not be exposed to excessive heat such as sunshine, fire or
the like.
14.WARNNING: Excessive sound pressure from earphones or
headphones can cause hearing loss.
15.WARNNING: Only use attachments/accessories specified
provided by the manufacturer, the portable DVD is supplied by
AC adapter, the AC adapter is used as disconnect device, the
disconnect device shall remain readily operable.
16.Caution: Danger of explosion if battery is incorrectly replaced,
replaced only with the same or equivalent type (Lithium battery)
Do not use the IR headphones under direct sunlight for IR
headphones could be interrupted by the infrared from the sun.

NNotes on Copyrights:
10. It is forbidden by law to copy, broadcast, show,broadcast via
cable, play in public, or rent copyrighted material without
permission.
11. This product features the copy protection function developed by
Macrovision.Copy protection signals are recorded on some discs.
When recording and playing the pictures of these discs picture
noise will appear.This product incorporates copyright protection
technology that is protected by method claims of certain U.S.
Patents and other intellectual property rights owned by Macrovision
Corporation and other rights owners.Use of this copyright protection
technology must be authorized by Macrovision Corporation, and is
intended for home and other limited viewing uses only unless
otherwise authorized by macrovision Corporation. Reverse
engineering or disassembly is prohibited.
SERIAL NUMBER:
You can find the serial number on the back of the unit.This number
is unique to this unit and not available to others.You should record
requested information here and retain this guide as a permanent
record of your purchase.
Model No. ______________________________
Serial No. ______________________________
Date of Purchase_________________________
2
Safety Precautions
N
5.Warning: when the unit using by child, parents must make sure
to let the child understand all contents in Instruction book how
battery using to guarantee using battery correctly all the time.
6.Warning: when find battery overheat, swell or dour, please
stop using battery and contact service centre for getting
replacement.
7.Warning: do not charging battery on the place of insufficient
ventilation such as: mattress, sofa, cushion , soft mat......
8.Warning: we will not take any responsibility if user incorrectly
use battery, not following our warning instruction label on the
battery case.
9.Warning: more than 250mm USB extension cord is prohibited
to use for USB port
1.Warning: This digital video disc player employs a laser system.
Use of controls,adjustments, or the performance of procedures
other than those specified herein may result in hazardous
radiation Exposure.
2.Warning: To prevent direct exposure to laser beam,do not open
the enclosure.Visible laser radiation when open.
3.Warning: Never stare directly into the laser beam.
4.Caution: Do not install this product in a confined space such
as a book case or similar unit.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING
charge
over
heat
40 C
strong
impact

Identification of Controls
Main Unit
3
Insert the battery
Remove battery during storage or when you are not using the DVD
player for a long time.
2.Insert battery.
NNOTES:
1.Open the battery door.
9.SETUP
10.OPEN
11.SD/MMC/MS
12.USB
13. AV OUT
14. Earphone Socket
15. COAXIAL
16.ON/OFF
17.DC IN 9-12V
1.REMOTE SENSOR
2.VOL- / VOL+
3. PLAY/PAUSE
4.■ STOP
5.SOURCE
6. MENU
7.ENTER
8.▲/▼/◄/►(up/down/right/left)
Select an item in the menu.OK key
confirms menu selection.
when playing,VCD,DVD,if available:
right: fast forward
left: fast reverse
up: previous track
down: next track
11 12 13 14 15 17
16

4
Identification of Controls
1 2 34
5678
9 0 10+
REPEAT
TITLE
ENTER
MENU
SUBTITLE
AUDIO
MUTE
SOURCE
MODE
PBC
VOL+VOL-
AB
DISPLAY
11
26 27
9
12
21
20
24
16
1
2
25
14
4
3
23
22
15
87
6
5
19
13
10
17
18
Remote control unit
1. PLAY/PAUSE ( )
Starts playback or pause playback.
2. STOP ( )
Stops playback.
3. Reverse Skip ( )
Go to previous chapter / track or to the
beginning.
4. Forward Skip( )
Go to the next chapter / track.
5.VOL-
6.REPEAT
Repeat chapter, track, title all.
7.A B
Repeat sequence.
8. PROGRAM
Place a track on the program list.
9.SOURCE
DVD, card,USB
10.TITLE
Return to DVD title menu.
11. MODE
Switch the IR headphone ON/OFF.
12.0-9 NUMBER BUTTON
Selects numbered items in a menu.
13.ENTER
Confirms menu selection.
14. VOL+
15.DISPLAY
Accesses On-Screen display.
16.AUDIO
Selects an audio language (DVD).
17.SUBTITLE
Selects a subtitle language.
18.ANGLE
Selects a DVD camera angle if available
19.SETUP
Accesses or removes setup menu.
20.10+ BUTTON
Add 10+ while your selection is more than10.
21.STEP
Step the motion in DVD mode.
22. BUTTON
Fast backward.
23. BUTTON
Fast forward.
24. PBC
PBC on/off switch.
25.MENU
Accesses menu on a DVD disc.
26.SEARCH
Goto time point , title or chapter you want in
DVD Mode
27. MUTE
Disable Audio output.
STEP

SETUP Menu Setting
General Setup Page
OSD Language
You can select your own preferred language seetings.
Angle Mark
Displays current angle setting information on the right hand corner
of the TFT screen if available on the disc.
Closed Captions
Closed captions are data that are hidden in the video signal of some
discs.Before you select this function,please ensure that the disc
contains closed captions information and your TV set also has this
function.
Screen Saver
This function is used to turn the screen saver On or Off.
Audio Setup Page
Audio Setup Page
-- --
DOWNMINX STR
DOLBY DIGITAL
LT/RT
SPDIF/OFF
SPDIF/RAW
SPDIF/PCM
DUAL MONO
DYNAMIC
STR STR
L-MONO
R-MONO
MIX-MONO
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
FULL
OFF
-
Press SETUP button to get the setup menu. Use direction buttons
to select the preferred item. After finishing settings, press
SETUP again to normal display.
The following menu items can be changed:
GENERAL: selects the GENERAL PAGE menu.
AUDIO: selects the AUDIO PAGE menu.
VIDEO: selects the VIDEO PAGE menu.
PREFERENCE : selects the PREFERENCE PAGE menu.
PASSWORD: selects the PASSWORD PAGE menu.
General Setup Page
TV DISPLAY: selects the aspect ratio of the playback picture.
4:3 PANSCAN: if you have a normal TV and want both sides of the
picture to be trimmed or formatted to fit your TV screen.
4:3 LETTERBOX: if you have a normal TV. In this case, a wide picture
with black bands on the upper and lower portions of the TV screen will
be displayed.
16:9:wide screen display.
- - - -AUDIO SETUP PAGE
GO TO AUDIO SETUP PAGE
DIGITAL OUTPUT RAW STEREO
IR HEADPHONE
This function is used to select the IR headphone ON or OFF
5
- - GENERALSETUP PAGE - -
GOTO GENERAL SETUP PAGE
TV DISPLAY WIDE
TFT DISPLAY 16:9
ANGLE MARK ON
OSD LANGUAGE ENG
CLOSED CAPTIONS ON
SCREEN SAVER ON
4:3 PANSCAN
4:3 LETTERBOX
16:9
ON
OFF
ENGLISH
FRENCH
GERMAN
SPANISH
DUTCH
POLISH
HUNGARIAN
ON
OFF
ON
OFF
16:9
4:3
ON
OFF
IR HEADPHONE OFF
TFT DISPLAY: selects the aspect ratio of the panel.

SETUP Menu Setting
Video Setup Page
Video Setup Page
- - VIDEO SETUP PAGE - -
GOTO VIDEO SETUP PAGE
BRIGHTNESS 00
CONTRAST 00
HUE 00
SATURATION 00
Brightness,Contrast,Hue,Saturation:setting the video
quality.
Preference Page
Preference Page
TV Type
Selecting the colour system that corresponds to your TV when AV
outputs.This DVD Player is compatible with both NTSC and PAL.
Downmix
This options allows you to set the stereo analog output of your
DVD Player.
Audio Setup Page
LT/RT :Select this option if your DVD Player is connected to a
Dolby Pro Logic decoder.
Stereo :Select this option when output delivers sound from only
the two front speakers.
Dolby digital
The options included in Dolby Digital Setup are: and
'Dynamic '.
'Dual Mono '
Dual Mono
Stereo:Left mono sound will send output signals to Left speaker
and Right mono sound will send output signals to Right speaker.
L-Mono:Left mono sound will send output signals to Left speaker
and Right speaker.
R-Mono:Right mono sound will send output signals to Left speaker
and Right speaker.
Mix-Mono:Left and Right mixed mono sound will send output
signals to Left and Right speakers.
Dynamic
Dynamic range compression.
Digital Output
The function is used to select the SPDIF Output:SPDIF Off,SPDIF
/RAW,SPDIF/PCM.
SPDIF Off: Turns off the SPDIF output.
SPDIF/RAW: If you have connected your DIGITAL AUDIO OUT
to a multi-channel decoder/receiver.
SPDIF/PCM: Only if your receiver is not capable of decoding
multi-channel audio.
6
- - PREFERENCE SETUP PAGE - -
GOTO PREFERENCE PAGE
TV TYPE PAL
AUDIO ENG
SUBTITLE OFF
DISC MENU ENG
PARENTAL
DEFAULT
PAL
AUTO
NTSC
ENGLISH
FRENCH
GERMAN
SPANISH
DUTCH
POLISH
HUNGARIAN
OTHERS
1 KID SAF
2 G
3 PG
4 PG13
5 PGR
6 R
7 NC17
8 ADULT
RESET
ENGLISH
FRENCH
GERMAN
SPANISH
DUTCH
POLISH
HUNGARIAN
OTHERS
ENGLISH
FRENCH
GERMAN
SPANISH
DUTCH
POLISH
HUNGARIAN
OFF
OTHERS

SETUP Menu Setting
Password: select the menu password change page.
Password Setup Page
OLD PASSWORD
NEW PASSWORD
CONFIRM PWD
OK
OLD PASSWORD: Enter the OLD password, (Factory setting is
1369), and the cursor will jump automatically to
NEW PASSWORD
.
NEW PASSWORD: Enter the NEW password. Enter 4 digits from
the remote control unit numeric buttons, and the
cursor will automatically jump to CONFIRM PASSWORD.
CONFIRM PASSWORD: Confirm the NEW password by entering
it again. If the confirmation is incorrect, the cursor
will stay in this column. After entering, the correct new password
again, the cursor will jump automatically to OK.
OK: When cursor is on this button, press ENTER key to confirm
setting.
PAL - Select this if the connected TV is PAL system.It will change the
video signal of a NTSC disc and output in PAL format.
NTSC-Select this if the connected TV is NTSC system.It will change
the video signal of a PAL disc and output in NTSC format.
Auto:Chang the video signal output automatic according to the
playing disk format.
Preference Page
Audio:Selects a language for audio (if available).
Subtitle:Selects a language for subtitle (if available).
Disc Menu:Selects a language for disc menu (if available).
Parental
Some DVDs may have a parental level assigned to the complete disc
or to certain scenes on the disc.This feature lets you set a playback
limitation level.The rating levels are from 1 to 8 and are country
dependent. You can prohibit the playing of certain discs that are not
suitable for your children or have certain discs played with alternative
scenes.
Default:Back to the factory setting.
Password Setup Page
Password Setup Page
- - PASSWORD SETUP PAGE - -
GOTO PASSWORD SETUP PAGE
PASSWORD MODE ON
PASSWORD
ON
OFF
Password mode: Set password mode on/off. If set to off, change
parental level will not check password.
Note: If the password has been changed, the parentaland disc
lock code will also be changed.
The default password(1369)is always active even the password
has been changed.
N
7

Parameters and specifications
Battery Parameters
Battery Specifications:
Output:7.4V
Storage and work circumstances:
1. Storage circumstances Temperature Humidity
6 months -20°C +45 C~ °
-20 C +65 C° ~ °
65+20%
65+20%
2.Work circumstances Temperature Humidity
Standard charge
Standard discharge
0 C +45 C° ~ °
-20 C +65 C° ~ °
65+20%
65+20%
1 week
8
Item Standard requirement
Output
Electronical parameters
VIDEO OUT
AUDIO OUT :1.2 Vrms (1 KHz, 0 dB)
Power requirements
Operating humidity
: AC 100-240 V , 50/60 Hz
: 5 % to 90 %
System
Laser :Semiconductor laser, wavelength 650 nm
Signal system : NTSC / PAL
Frequency
response
Signal-to-noise ratio :More than 80 dB (ANALOG OUT connectors only)
Dynamic range :More than 80 dB (DVD/CD)
Accessories
Note: Design and specifications are subject to change prior notice.
N
:Video/Audio cable,Remote control,
Stereo headphone,Rechargeable battery,
: 20Hz to 20 kHz(1dB)
Power consumption : <10W
: 0.948kg
Dimensions (Approx.)
Weight (Approx.)
: 240(L)X186(W)X44(H)MM
If at any time in the future you should need to dispose of this
product please note that: Waste electrical products should
not be disposed of with household waste.
Please recycle where facilities exist. Check with your Local
Authority or retailer for recycling advice. (Waste Electrical
and Electronic Equipment Directive)
Other manuals for DVP-937
2
Table of contents
Other LENCO Portable DVD Player manuals

LENCO
LENCO DVP-747 User manual

LENCO
LENCO DVP-1273 User manual

LENCO
LENCO DVP-945 User manual

LENCO
LENCO DVP-937 User manual

LENCO
LENCO DVP-1210 User manual

LENCO
LENCO MES-415 User manual

LENCO
LENCO DVP-935 User manual

LENCO
LENCO MES-219 MPEG4 - User manual

LENCO
LENCO DVP-706 User manual

LENCO
LENCO MES-404 User manual

LENCO
LENCO DVP-1047 User manual

LENCO
LENCO DVP-1034 User manual

LENCO
LENCO DVP-938 User manual

LENCO
LENCO DVP-1064BK User manual

LENCO
LENCO DVP-753 User manual

LENCO
LENCO DVP-947 BK User manual

LENCO
LENCO DVP-1022 User manual

LENCO
LENCO DVP-1027 User manual

LENCO
LENCO MES-249 User manual

LENCO
LENCO DVP-1045 User manual
