LENCO DVP-734 User manual

PORTABLE DVD
Before connecting, operating or adjusting this product,
please read this user's manual carefully and completely.
USER'S MANUAL
DVP-734
www.ices-electronics.com

Warning: To reduce the risk of electric shock, do not remove
the cover or back. There are no user-serviceable parts
inside. Refer servicing to qualified personnel.
Warning: To prevent fire or electric shock hazard, do not
expose the unit to rain or moisture.
Do not expose the Adaptor and portable DVD to water
(dripping or splashing) and no objects filled with liquids,
such as vases, should be placed on the unit.
Keep the portable DVD away from direct sunlight and heat
source such as radiators or stoves.
Do not block the ventilation openings. Slots and openings on
the unit are provided for ventilation. The openings should
never be blocked by placing your portable DVD on a cushion,
sofa or other similar surface.
Do not place the portable DVD on unstable cart, stand,
tripod, bracket or table. The unit may fall, resulting in
possible damage or injury.
Never place heavy or sharp objects on the LCD panel or
frame.
Only use the AC adapter included with portable DVD. Using
any other adapter will void your warranty.
The plug of AC adaptor is used as the disconnect device, the
disconnect device shall remain readily operable.
Unplug the power from the outlet when the unit is not in use.
Attention should be drawn to the environmental aspects of
battery disposal.
This marking indicates that this product should not
be disposed with other household wastes
throughout the EU. To prevent possible harm to the
environment or human health from uncontrolled
waste disposal, recycle it responsibly to promote
the sustainable reuse of material resources. To
return your used device, please use the return and
collection systems or contact the retailer where
the product was purchased. They can take this
product for environmental safe recycling.
Important Safety Instructions
CAUTION: Danger of explosion if battery is incorrectly
replaced. Replace only with the same or equivalent type.
WARNNING: The battery (battery or batteries or battery
pack) shall not be exposed to excessive heat such as
sunshine, fire or the like.
WARNING: Prolonged exposure to loud sounds from personal
music players may lead to temporary or permanent hearing
loss.
WARNNING: Only use attachments/accessories specified
provided by the manufacturer, the portable DVD is supplied
by AC adapter, the AC adapter is used as disconnect device,
the disconnect device shall remain readily operable.
Caution: Danger of explosion if battery is incorrectly
replaced, replaced only with the same or equivalent type
(Lithium battery)
1

NNotes on Copyrights:
It is forbidden by law to copy, broadcast, show,broadcast via
cable, play in public, or rent copyrighted material without
permission.
This product features the copy protection function developed by
Macrovision.Copy protection signals are recorded on some discs.
When recording and playing the pictures of these discs picture
noise will appear.This product incorporates copyright protection
technology that is protected by method claims of certain U.S.
Patents and other intellectual property rights owned by
Macrovision Corporation and other rights owners.Use of this
copyright protection technology must be authorized by
Macrovision Corporation, and is intended for home and other
limited viewing uses only unless otherwise authorized by
macrovision Corporation. Reverse engineering or disassembly is
prohibited.
SERIAL NUMBER:
You can find the serial number on the back of the unit.This number
is unique to this unit and not available to others.You should record
requested information here and retain this guide as a permanent
record of your purchase.
Model No. ______________________________
Serial No. ______________________________
Date of Purchase_________________________
Safety Precautions
Warning: when the unit using by child, parents must make sure
to let the child understand all contents in Instruction book how
battery using to guarantee using battery correctly all the time.
Warning: when find battery overheat, swell or dour, please
stop using battery and contact service centre for getting
replacement.
Warning: do not charging battery on the place of insufficient
ventilation such as: mattress, sofa, cushion , soft mat......
Warning: we will not take any responsibility if user incorrectly
use battery, not following our warning instruction label on the
battery case.
Warning: more than 250mm USB extension cord is prohibited
to use for USB port
Warning: This digital video disc player employs a laser system.
Use of controls,adjustments, or the performance of procedures
other than those specified herein may result in hazardous
radiation Exposure.
Warning: To prevent direct exposure to laser beam,do not open
the enclosure.Visible laser radiation when open.
Warning: Never stare directly into the laser beam.
Caution: Do not install this product in a confined space such
as a book case or similar unit.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING
charge
over
heat
40 C
strong
impact
2

Identification of Controls
Main Unit
3
1
1. / Up / Prev
/ Down / Next
/ VOL- Left / VOL-
/ VOL+ Right / VOL+
2 3 4 5 6 7 8 9
2.PLAY/PAUSE;RETURN
3.SETUP
4. SOURCE
5. USB
6. Earphone Socket
7. AV OUT
8. ON/OFF
9. DC IN 9-12V
Remarks:
Short press / / / is Up/Down/Left/Right;
Long press / is Prev/Next
Long press / is VOL- / VOL+
Short press PLAY/PAUSE;
Long press RETURN

1 2 34
5678
9 0 10+
VOL - VOL+
REPEAT
SEARCH
TITLE
ENTER
RETURN
STEP
SUBTI TLE
ANG L E AUDIO M ENU
SETUP
AB
DISPL AY
ZOOM MUTE SOURCE
113
19
8
4
11
23
17
20
21
9
10
27
26
15
16
7
6
25
24
18
12
3
5
22
214
Remote control unit
Identification of Controls
4
1. ZOOM
2. SEARCH
Goto time point , title or chapter you want in DVD Mode.
3. SUBTITLE
Press SUBTITLE repeatedly during playback to hear a different
subtitle languages.
4. ANGLE
Press ANGLE will change the view angle, on DVDs that support this
feature.
Each press of the ZOOM button changes the TV screen in the following
sequence:2X size 3X size 4X size 1/2 1/3 1/4.
5. TITLE
Return to DVD title menu.
6. ENTER
Confirms menu selection.
7. SETUP
Accesses or removes setup menu.
8. VOL -
Adjust VOLUME.
9. REPEAT
Press REPEAT during playback to select a desired repeat mode.
DVD: you can play a chapter/title/all on a disc.
VCD CD: you can play a track/all on a disc.
MP3 WMA: you can select Repeat one/Repeat folder/ALL
play mode on a disc.
10.A B
To repeat a segment: press AB once to set the starting point for
repeat segment, press it again to set an end point, and the player
will repeat the segment from the start to the end point.
11.PROGRAM
DVD VCD CD MP3: The program function enables you to
store your favourite tracks from the disc. Press PROGRAM
button,then PROGRAM MENU will appear on screen, now you
can use the number or direction keys input the titles, chapters or
tracks number and select PLAY option to resume normal
playback, press PROGRAM and select CLEAR option on the
program menu.
JPEG:You can press PROGRAM repeatly to select the slide show
mode, the are 16 types slide show.
12. DISPLAY
To display the playtime and status information.
13. SOURCE
DVD/USB.

Identification of Controls
Remote control unit
5
14. MUTE
Disable Audio output.
15. 0-9 NUMBER BUTTON
Selects numbered items in a menu.
16.10+ BUTTON
In order to select a track 10 or greater, first press 10+, For example;
select track 12, first press 10+, and then press number 2 button.
17.STEP
Press STEP once to pause playback, Form this station, press STEP
to advance one video frame.
18. MENU
Accesses menu on a DVD disc, PBC on/off switch for VCD.
19. AUDIO
DVD: Press AUDIO repeatedly during playback to hear a different
audio language or audio track, if avilable.
CD VCD: Press AUDIO repeatedly during playback to hear a
different audio channel (Stereo, Left, or Right).
20. PLAY/PAUSE
Press PLAY/PAUSE once to pause playback, pressing PLAY/
PAUSE second time will resume the playback.
21. STOP
When this buttom is pressed once, the unit records the stopped
point,from where playback will resume if ENTER is pressed after
wards. But if STOP button is pressd again instead of ENTER
button, there will be no resume function.
22. RETURN
Return to upper page.
23. VOL +
Adjust VOLUME.
24. Reverse Skip
Go to previous chapter/ track to the beginning.
25. Forward Skip
Go to next chapter/ track.
26. BUTTON
Press BUTTON allow skipping ahead at 5-level speed(X2->
X4->X8->X20), press ENTER button return to normal playback.
27. BUTTON
Press BUTTON allow skipping back at 5-level speed(X2->
X4->X8->X20), press ENTER button return to normal playback.

SETUP Menu Setting
System Setup Page
Language Setup Page
Language setup
Press SETUP button to get the setup menu. Use direction buttons
to select the preferred item. After finishing settings, press
SETUP again to normal display.
System Setup
TV System
Selecting the color system that corresponds to your TV when AV
output. This DVD Player is compatible with both NTSC and PAL.
PAL - Select this if the connected TV is PAL system. It will change
the video signal of a NTSC disc and output in PAL format.
NTSC - Select this if the connected TV is NTSC system. It will
change the video signal of a PAL disc and output in NTSC format.
Power Resume
This function is used to turn the last memory on or off.
TV Type
Selects the aspect ratio of the playback picture.
4:3 PS: if you have a normal TV and want both sides of the
picture to be trimmed or formatted to fit your TV screen.
4:3 LB: if you have a normal TV. In this case, a wide picture with
black bands on the upper and lower portions of the TV screen will
be displayed.
16:9: wide screen display.
Default
Restore the factory setting of setup menu.
You can select OSD language, and select audio/subtitle/menu
language of DVD discs if available. Also you can select font type
for mpeg4 subtitle.
6
Password
Input user password. Default password is 0000.
Rating
After input correct password, you can change parental level.
TV SYSTEM
POWER RESUME ON
OFF
NTSC
PAL
TV TYPE 4:3 PS
4:3 LB
16:9
PASSWORD
RATING
DEFAULT 1 KID SAFE
2 G
3 PG
4 PG13
5 PG-R
6 R
7 NC-17
8 ADULT
RESTORE
1111
OSD LANGUAGE ENGLISH
GERMAN
SPANISH
FRENCH
PORTUGUESE
ITALIAN
AUDIO LANG
SUBTITLE LANG
MENU LANGUAGE
ENGLISH
GERMAN
SPANISH
FRENCH
PORTUGUESE
ITALIAN
ENGLISH
GERMAN
SPANISH
FRENCH
PORTUGUESE
ITALIAN
OFF
ENGLISH
GERMAN
SPANISH
FRENCH
PORTUGUESE
ITALIAN
1111
SYSTEM SETUP
LANGUAGE SETUP

SETUP Menu Setting
Video Setup Page
You can change the video setting: brightness, contrast, hue,
saturation.
Audio Setup Page
7
The function is use to select standby setting: OFF, 3 HOURS,
4 HOURS
OFF: No standby
3 HOURS: No remote control and panelkey operation within three
hours into standby
4 HOURS: No remote control and panelkey operation within four
hours into standby
AUTO STANDBY
OFF
3 HOURS
4 HOURS
BRIGHTNESS
CONTRAST
HUE
SATURATION
SHARPNESS
12
10
8
6
4
2
0
8
6
4
2
0
12
10
8
6
4
2
0
+6
+4
+2
0
-2
-4
-6
12
10
8
6
4
2
0
1111
STANDBY SETTING VIDEO SETUP
1111

Parameters and specifications
Item Standard requirement
Electronical parameters
Power requirements : AC 100-240 V , 50/60 Hz
Output
VIDEO OUT
AUDIO OUT :1.2 Vrms (1 KHz, 0 dB)
Power consumption
Operating humidity
: <10W
: 5 % to 90 %
System
Laser :Semiconductor laser, wavelength 650 nm
Signal system : NTSC / PAL
Frequency
response
Signal-to-noise ratio :More than 80 dB (ANALOG OUT connectors only)
Dynamic range :More than 85 dB (DVD/CD)
Note: Design and specifications are subject to change prior notice.
: 20Hz to 20 kHz(1dB)
Battery Parameters
Battery Specifications：
Output：7.4V
Charge / Discharge Time：
Standard charge time：3h ~ 4h
Storage and work circumstances：
1. Storage circumstances Temperature Humidity
2.Work circumstances Temperature Humidity
6 months -20 C +45 C~
-20 C +65 C~
65+20%
65+20%
Standard charge
Standard discharge
0 C +45 C~
-20 C +65 C~
65+20%
65+20%
1 week
8

This symbol indicates that the relevant electrical product or battery
should not be disposed of as general household waste in Europe.
To ensure the correct waste treatment of the product and battery,
please dispose them in accordance to any applicable local laws of
requirement for disposal of electrical equipment or batteries. In so
doing, you will help to conserve natural resources and improve
standards of environmental protection in treatment and disposal of
electrical waste (Waste Electrical and Electronic Equipment
Directive).
Products with the CE marking comply with the EMC Directive
(2004/108/EC) and the Low Voltage Directive (2006/95/EC)
issued by the Commission of the European Community.
®All rights reserved
Service and support
For information: www.lenco.com
For support: http://lencosupport.zendesk.com
Lenco helpdesk:
Germany 0900-1520530 (Local charges)
The Netherlands 0900-23553626 (Local charges + 1ct p/min)
Belgium 02-6200115 (Local charges)
France 03-81484280 (Local charges)
The helpdesk is accessible from Monday till Friday from 9 AM till 6 PM.
When contacting Lenco, you will always be asked for the model and serial
number of your product. The serial number can be found on the back of the
device. Please write down the serial number below:
Model: DVP-734
Serial number:_________________________________
Lenco offers service and warranty in accordance to European law, which means
that in case of repairs (both during and after the warranty period) you should
contact your local dealer.
Important note: It is not possible to send products that need repairs to Lenco
directly.
Important note: If this unit is opened or accessed by a non-official service center
in any way, the warranty expires.
This device is not suitable for professional use. In case of professional use, all
warranty obligations of the manufacturer will be voided.
