Xc16
High-efficiency, two-stage cooling
Compatible with the exclusive Humiditrol®
whole-home dehumidification system—
indoor air quality you can feel
Home Comfort Systems
LEnnoX’ ELItE®SErIES
XC16 Air Conditioner ◆Up to 17.20 SEER

2
Want to feel more comfortable at home? With the XC16 air conditioner, you
can feel more comfortable, without feeling the pinch of high utility bills. That’s
because it has two levels of cooling for a higher level of comfort and efficiency.
A HIGHER LEVEL OF COOL, EFFICIENT COMFORT
With its two-stage design, the XC16 makes the distinction between mild
and extremely hot days, using only the energy necessary to keep you
comfortable. It runs mostly at low stage, so you can avoid temperature
swings and high utility bills.
And, when you combine the XC16 with a ComfortSense™7000 Series
touchscreen thermostat*** and Humiditrol®dehumidification system, you
can also find relief from high humidity.
Elite®Series XC16 Air Conditioner
Innovation never felt so good.
™
EFFICIENCY RATING
Up to 17.20 SEER (Seasonal
Energy Efficiency Ratio).
WARRANTY**
10-year limited warranty
on compressor.
5-year limited warranty
on all remaining covered
components.
*Must be accompanied by either a
variable speed air handler or furnace
and the ComfortSense™7000 Series
touchscreen thermostat.
**Applies to residential applications only.
See actual warranty certificate for details.
Responsible Conserves energy,
while preserving the environment
The two-stage scroll compressor uses the new R410A refrigerant, which
meets the EPA’s standards for environmental safety. Because R410A
contains no chlorine, it’s ozone-responsible.
seer
17.00 vs. 8.0 17.00 vs. 10.0
$1500
$1200
$900
$600
$300
0
17.00 SEER XC16 air conditioner,
compared to older, less-efficient units
5-YEAR COOLING SAVINGS
Efficient Can save you
hundreds of dollars each year
on utility bills
The XC16 has a SEER of up to
17.20, so it can significantly lower
your utility bills, even during the
hottest summer months. It keeps
you comfortable, while keeping
your energy costs down.
$1305
$575
Choosing an ENERGY STAR®product can
help you improve comfort and save money.
Get details at www.itpaystolivesmart.com.
***ComfortSense thermostat is required for proper operation of the Humiditrol system air
conditioners and heat pumps. ComfortSense thermostat will not control the packaged
rooftop unit version of the Humiditrol system.
This chart compares the 5-year savings you can expect from
an XC16 air conditioner vs. units with lower efficiency ratings.
The regions used to calculate household fuel and utility
costs reflect a cross-section of cities in the U.S. using
2006 Department of Energy national average energy rates.
In addition to geography, cooling costs are based on 3-ton
capacity specification, with 1,600 cooling hours per year.
Your actual costs will vary depending on the weather, local
fuel rates, systems settings and your personal lifestyle.
Two-stage operation optimizes
cooling performance, resulting
in more even temperatures
and lower utility bills
Efficient design can result in
significant energy savings
Ozone-responsible
R410A meets the EPA’s
(Environmental Protection
Agency) most stringent
environmental guidelines
Compatible with the exclusive
Humiditrol®whole-home
dehumidification system*
SmartHinge™louvered access
panels provide improved coil
protection and fast, efficient
servicing
ENERGY STAR® qualified

Precision-Balanced Direct-Drive Fan –
Delivers quiet operation.
High-Efficiency Outdoor Coil –
Provides exceptional heat transfer and low
air resistance for high-efficiency operation.
Two-Stage Scroll Compressor –
Operates at low stage most of the time for quieter,
more efficient performance. Plus, it cools your home
using the ozone-responsible R410A refrigerant.
Durable Steel Cabinet –
Made to last with superior high-quality, pre-painted
steel and textured finish. Tested to withstand the
harshest environments.
Drainage Holes –
Prevent damaging moisture from
collecting inside the basepan.
SmartHinge™Louvered Coil Protection –
Allows quick, easy access to interior components
from all sides, so the unit can be serviced in minimal time.
3
Elite®Series XC16 Specifications
XC16 024 036 048 060
SEER Up to 17.20 Up to 16.20 Up to 16.50 Up to 15.70
Sound Rating-dB 74 76 76 78
Dimensions HxWxD (in.) 39 x 30-1/2 x 35 45 x 30-1/2 x 35 39 x 30-1/2 x 35 39 x 35-1/2 x 39-1/2
HxWxD (mm) 991 x 775 x 889 1143 x 775 x 889 991 x 775 x 889 991 x 902 x 1003
Note: Due to Lennox’ ongoing commitment to quality, all specifications, ratings and dimensions are subject to change without notice.
13.70-17.20
22.00
THIS MODEL
10.00
INNOVATIVE FEATURES FOR ENHANCED COMFORT AND EFFICIENCY
Customizable Compatible with the new Humiditrol®whole-home dehumidification system
The XC16 gives you the flexibility to choose a Humiditrol®system for improved comfort and indoor air quality.
Patented Humiditrol technology helps reduce humid conditions in the home, reducing the opportunity for mold
and mildew growth.
Proper sizing and installation of equipment
is critical to achieve optimal performance.
Split system air conditioners and heat
pumps must be matched with appropriate
coil components to meet ENERGY STAR®
criteria. Ask your Lennox dealer for details,
or visit www.energystar.gov.
XC16
Up to 17.20 SEER
ENERGY STAR®
qualified
Lennox is proud of
the fact that these
products have
earned the Good
Housekeeping Seal.

PC55449(22W46) XC16 09/08
© Lennox Industries Inc. 2006
Visit us at www.lennox.com, or contact us at 1-800-9-LENNOX.
1Air conditioner or heat pump
2Thermostat
3Furnace or air handler
4Filtration device
5Germicidal light
6Indoor coil
7Humidifier
8HEPA bypass filtration system
9Energy recovery ventilator
 Supply duct
 Return duct
 Dehumidifier system
 Residential generator
CUSTOMIZE YOUR COMFORT
Lennox®heating, cooling and indoor air quality products are designed to
provide efficient, economical comfort—not only as individual units, but also
together as an integrated system. This combined network of products delivers
on every comfort count, from consistent temperatures and balanced humidity to improved indoor air quality. Lennox
also offers a line of residential generators, which provide safe, reliable standby power in the event of outages.
DEALERS YOU CAN COUNT ON
Choosing the right dealer for your home’s heating, cooling and air quality needs is every bit as important as choosing the
right brand. We think you’ll agree our independent dealers are a big reason you can count on quality customer service
whenever you call. Your Lennox dealer’s dedication to quality shows in his knowledge, training and expertise in designing
the right system for your home, installing it properly and keeping it running perfectly for many years to come.
