Lennox XC14 User manual

XC14
Quiet and efficient cooling comfort
Compatible with the exclusive Humiditrol®
whole-home dehumidification system—
indoor air quality you can feel
Home Comfort Systems
LENNOX’ ELITE®SERIES
XC14 Air Conditioner ◆Up to 16.20 SEER

2
Designed for comfort inside and quiet performance outside, the XC14 air
conditioner makes it easy to relax and feel good at home. At the heart of
the system is a precision-engineered scroll compressor, which provides
quiet, efficient and reliable operation—no matter how hot the weather.
THE IDEAL CHOICE FOR YOUR HOME ENVIRONMENT
AND THE GLOBAL ENVIRONMENT.
With efficiency ratings of up to 16.20 SEER, the XC14 delivers more
comfort for your energy dollar, compared to standard air conditioners.
It also uses the chlorine-free R410A refrigerant, which meets the
U.S. Environmental Protection Agency’s newest, most stringent
environmental guidelines.
Elite®Series XC14 Air Conditioner
Innovation never felt so good.
™
EFFICIENCY RATING
Up to 16.20 SEER (Seasonal
Energy Efficiency Ratio).
WARRANTY**
10-year limited warranty
on the compressor.
5-year limited warranty
on all remaining covered
components.
This chart compares the 5-year savings you can expect from
a 16 SEER air conditioner vs. units with lower efficiency
ratings. The regions used to calculate household fuel and
utility costs reflect a cross-section of cities in the U.S. using
2006 Department of Energy national average energy rates.
In addition to geography, cooling costs are based on 3-ton
capacity specifications, with 1,600 cooling hours per year.
Your actual costs will vary depending on the weather, local
fuel rates, systems settings and your personal lifestyle.
Efficient Can save you
hundreds of dollars each year
on utility bills
The XC14 has a SEER of up to
16.20, so it can significantly lower
your utility bills, even during the
hottest summer months. It keeps
you comfortable, while keeping
your energy costs down.
Choosing an ENERGY STAR®product
can help you improve comfort and
save money. Get details at
www.itpaystolivesmart.com.
seer
16.00 vs. 10.0 16.00 vs. 13.00
$1200
$1000
$800
$600
$400
0
16.00 SEER XC14 air conditioner,
compared to older, less-efficient units
5-YEAR COOLING SAVINGS
$1190
$455
Precision-engineered
scroll compressor with
special compressor sound
dampening system assures
smooth, quiet operation
Efficient design can result in
significant energy savings
High-efficiency cooling
performance can help you
save hundreds of dollars a
year in energy costs
Ozone-responsible
R410A meets the EPA’s
(Environmental Protection
Agency) most stringent
environmental guidelines
Compatible with the exclusive
Humiditrol®whole-home
dehumidification system*
SmartHinge™louvered access
panels provide improved coil
protection and fast, efficient
servicing
ENERGY STAR®qualified
**Applies to residential applications only.
See actual warranty certificate for details.
*Must be accompanied by either a variable speed air handler or furnace and the
ComfortSense™7000 Series Touchscreen Thermostat.

Precision-Balanced Direct-Drive Fan –
Provides a quieter environment outside your home.
High-Efficiency Outdoor Coil –
Provides exceptional heat transfer and low air resistance for
high-efficiency operation that can lower your cooling bills.
Precision-Engineered Scroll Compressor
with Special Compressor Sound
Dampening System –
Provides quiet, efficient and reliable operation
even in the most demanding applications.
Durable Steel Cabinet –
Made to last with an attractive,
high-quality textured paint finish.
Drainage Holes –
Prevent damaging moisture from collecting
inside the basepan, ensuring longer product life.
SmartHinge™Louvered Coil Protection –
Allows quick, easy access to interior components
from all sides, so the unit can be serviced in
minimal time, saving you money.
3
Elite®Series XC14 Specifications
XC14 018 024 030 036 042 048 060
SEER Up to 16.20 Up to 16.20 Up to 16.20 Up to 16.00 Up to 15.70 Up to 15.50 Up to 15.00
Sound Rating – dB 71 71 71 70 73 73 73
Dimensions HxWxD (in.) 31 x 27 x 28 35 x 30-1/2 x 35 39 x 30-1/2 x 35 39 x 30-1/2 x 35 31 x 30-1/2 x 35 39 x 30-1/2 x 35 35 x 35-1/2 x 39-1/2
HxWxD (mm) 787 x 686 x 711 889 x 775 x 889 991 x 775 x 889 991 x 775 x 889 787 x 775 x 889 991 x 775 x 889 889 x 902 x 1103
Note: Due to Lennox’ ongoing commitment to quality, all specifications, ratings and dimensions are subject to change without notice.
INNOVATIVE FEATURES FOR ENHANCED COMFORT AND EFFICIENCY
Proper sizing and installation
of equipment is critical to achieve
optimal performance. Split system
air conditioners and heat pumps
must be matched with appropriate
coil components to meet ENERGY STAR®
criteria. Ask your Lennox dealer for
details, or visit www.energystar.gov.
XC14
Up to 16.20 SEER
ENERGY STAR®
qualified
Quality you can trust.
Constructed of heavy-gauge, pre-painted
steel and tested in the most extreme
environments to ensure maximum durability.
Lennox is proud of
the fact that these
products have
earned the Good
Housekeeping Seal.
13.00-16.20
22.00
THIS MODEL

PC54844(29W10) XC14 7/08
© Lennox Industries Inc. 2007
Visit us at www.lennox.com, or contact us at 1-800-9-LENNOX.
1Air conditioner or heat pump
2Thermostat
3Furnace or air handler
4Filtration device
5Germicidal light
6Indoor coil
7Humidifier
8HEPA bypass filtration system
9Energy recovery ventilator
 Supply duct
 Return duct
 Dehumidifier system
 Residential generator
CUSTOMIzE YOUR COMFORT
Lennox®heating, cooling and indoor air quality products are designed to
provide efficient, economical comfort—not only as individual units, but also
together as an integrated system. This combined network of products delivers
on every comfort count, from consistent temperatures and balanced humidity to improved indoor air quality. Lennox
also offers a line of residential generators, which provide safe, reliable standby power in the event of outages.
DEALERS YOU CAN COUNT ON
Choosing the right dealer for your home’s heating, cooling and air quality needs is every bit as important as choosing the
right brand. We think you’ll agree our independent dealers are a big reason you can count on quality customer service
whenever you call. Your Lennox dealer’s dedication to quality shows in his knowledge, training and expertise in designing
the right system for your home, installing it properly and keeping it running perfectly for many years to come.
