Personal Systems Reference
Lenovo®Value Line Desktops
November 2009 - Version 366
Visit www.lenovo.com/psref for the latest version

Lenovo C100
Lenovo C100
Lenovo C100

Intel®Atom™processor 230 with single-core,
Hyper-Threading technology, Intel 64 Technology,
Execute Disable Bit, 533MHz system bus, and 512KB L2 cache or
Intel Atom processor 330 with dual-core,
Hyper-Threading technology, Intel 64 Technology,
Execute Disable Bit, 533MHz system bus, and 1MB L2 cache
1GB or 2GB std / 2GB max7 / PC2-5300 667MHz DDR2, non-parity,
one 200-pin SO-DIMM socket; standard memory in one socket; no sockets available
DVD burner, dual-layer support, fixed, removable, 12.7mm, tray-in
160GB or 320GB, SATA 3.0Gb/s, 2.5" wide, 5400 rpm
18.5" (470.1mm) WXGA (1366x768) TFT color,anti-glare, CCFL backlight, 250 nits,
16:9 aspect ratio, 1000:1 contrast ratio
Camera on top of screen, 1.3-megapixel, fixed focus, with mono microphone
Power button on right
Intel Graphics Media Accelerator 950 (GMA 950),
integrated graphics in 945GC, uses main memory
Intel 945GC Express Chipset, I/O Controller Hub 7 [ICH7] (SATA 3.0Gb/s,
ethernet MAC, USB, LPC bus)
None
Rear: Two USB 2.0, ethernet (RJ-45), keyboard (PS/2),
microphone input jack (3.5 mm), headphone jack (3.5 mm)
Left: Two USB 2.0
One Mini PCI Express slot
Some: 11b/g wireless4, Mini PCIe adapter, Realtek®RTL8191SE
None
None
None
10/100 ethernet on planar, Realtek 8103EL
High Definition (HD) Audio, RealTek®ALC662 codec /
two stereo speakers (2 watt) / microphone, microphone input jack (3.5 mm),
headphone jack (3.5 mm)
Supervisor password
PS/2 full-size keyboard
USB Optical Wheel Mouse
None
(WxHxD): 18.5" x 14.6" x 3.98"; 469mm x 370mm x 101mm
13.22 lb (6.0 kg)
Black color
Basic folding stand (adjustable between 35° and 54°)
Processor
Memory
S ATA DV D ±RW
SATA disk
Widescreen
display
Camera
Controls
Graphics
Chipset
Multicard reader
Ports
Mini PCI Express
11b/g28
TV tuner
Bluetooth™
Modem
Ethernet
Audio support
Security
Keyboard
Mouse
Remote control
Dimensions3
Weight
2
Chassis
Stand
Lenovo®C100 (7869)
65-watt AC adapter
RoHS-compliant
7869-1AU Atom 230 1.60 1GB 18.5" WXGA 1.3 GMA 160GB8DVD±RW Black None PS/2 USB XP Home Sep 09
7869-1EU Atom 230 1.60 1GB 18.5" WXGA 1.3 GMA 160GB DVD±RW 11b/g28 Black None PS/2 USB XP Home Sep 09
7869-1CU Atom 330 1.60 2GB 18.5" WXGA 1.3 GMA 320GB DVD±RW Black None PS/2 USB Home Basic Sep 09
Type-model GHz
Widescreen
displayMemory
SATA
disk
SATA
optical
Mini PCIe
802.11
wireless Preload
Avail
date
Personal Systems Reference (PSREF)
© Lenovo
(PH1-1) October 2009
See footnotes for important warranty information
US models announced September 15, 2009
Preloaded operating system20
- Some: Genuine Windows®XP
Home Edition
- Some: Genuine Windows Vista®
Home Basic 32
Preloaded applications14
•Lenovo OneKey Recovery
•Driver and Application Installation
•Trend Micro™PC-cillin™Internet
Security 2008
•Windows Live™Toolbar
(Vista Models)
•Cyberlink Power2Go (DVD±RW)
•Corel®WinDVD®
•All-In-One design with 18.5" 16:9 widescreen
• Lenovo®Rescue System provides OneKey recovery and OneKey Antivirus without
booting into Windows
Graphics KBDProcessor
Limited Warranty12
➫ 1-year parts and labor
➫ Customer Replaceable Unit (CRU)
parts only (with limited onsite
service for selected parts3,
8 am - 5 pm, Mon - Fri coverage
excluding holidays, next business
day response time)
➫Service upgrade options
(in eligible locations):9
• 3-year Lenovo Onsite Repair
9x5 Next Business Day (43R8882)
➫ 24x714 toll-free support for warranty
issues during the warranty period1
via 877-453-6686
Color
Camera
(mega-
pixel)
Blue-
tooth Mouse

Lenovo C300Lenovo C300
Lenovo C300
Lenovo C300
Lenovo C300
Lenovo C300

Intel®Atom™processor 230 with single-core,
Hyper-Threading technology, Intel 64 Technology,
Execute Disable Bit, 533MHz system bus, and 512KB L2 cache or
Intel Atom processor 330 with dual-core,
Hyper-Threading technology, Intel 64 Technology,
Execute Disable Bit, 533MHz system bus, and 1MB L2 cache
1GB, 3GB, or 4GB std / 4GB max7 / PC2-5300 667MHz DDR2, non-parity,
dual-channel capable, two 200-pin SO-DIMM sockets;
Italics: standard memory in both sockets; no sockets available
Non-italics: standard memory in one socket; one socket available
DVD burner, dual-layer support, fixed, removable, 12.7mm, tray-in
160GB, 320GB, 500GB, or 640GB, SATA 3.0Gb/s, 3.5" wide, 7200 rpm
20" (508mm) WXGA++ (1600x900) TFT color,anti-glare,CCFL backlight, 300 nits,
16:9 aspect ratio, 1000:1 contrast ratio
Camera on top of screen, 1.3-megapixel, fixed focus, with mono microphone
Brightness up/down buttons, display on/off button, and power button
Some: Intel Graphics Media Accelerator 950 (GMA 950),
integrated graphics in 945GC, uses main memory
Some: ATI™ Mobility Radeon™ HD 4530, PCI Express®x16, 512MB memory,
DirectX®10, ATI Avivo™ HD
Intel 945GC Express Chipset, I/O Controller Hub 7 [ICH7] (SATA 3.0Gb/s,
ethernet MAC, USB, LPC bus)
6-in-1 reader (MultiMedia Card, Memory Stick, Memory Stick PRO ™ ,
Secure Digital Card, Secure Digital Elite Pro Card, xD-Picture Card ™ )
Rear: Four USB 2.0, ethernet (RJ-45), keyboard (PS/2),
IEEE 1394 FireWire 400 (4-pin connector; 1394a-2000 standard)
Left: Two USB 2.0
One Mini PCI Express slot
11b/g wireless4, Mini PCIe adapter, Broadcom®BCM4312
None
None
None
10/100 ethernet on planar, Intel 82562G
High Definition (HD) Audio, RealTek®ALC662 codec /
two stereo speakers (2 watt) / microphone, microphone input jack (3.5 mm),
headphone jack (3.5 mm)
Power-on password, supervisor password, security lockhole
PS/2 full-size keyboard
USB Optical Wheel Mouse
None
(WxHxD): 19.05" x 14.12" x 3.28"; 484mm x 359mm x 83mm
13.8 lb (6.26 kg)
Black color
Fold-away stand (adjustable between 12° and 40°)
Processor
Memory
S ATA DV D ±RW
SATA disk
Widescreen
display
Camera
Controls
Graphics
Chipset
Multicard reader
Ports
Mini PCI Express
11b/g28
TV tuner
Bluetooth™
Modem
Ethernet
Audio support
Security
Keyboard
Mouse
Remote control
Dimensions3
Weight
2
Chassis
Stand
Lenovo®C300 (3012)
120-watt AC adapter
RoHS-compliant
3012-1AU Atom 230 1.60 1GB 20" WXGA++ 1.3 GMA 160GB8DVD±RW 11b/g28 Black None PS/2 USB XP Home Jun 09
3012-1JU Atom 230 1.60 1GB 20" WXGA++ 1.3 GMA 160GB DVD±RW 11b/g Black None PS/2 USB XP
Home Sep09
3012-1OU Atom 230 1.60 2GB 20" WXGA++ 1.3 GMA 320GB DVD±RW 11b/g Black None PS/2 USB Home Basic Sep09
3012-1EU Atom 230 1.60 3GB 20" WXGA++ 1.3 GMA 320GB DVD±RW 11b/g Black None PS/2 USB Home Basic Jun 09
3012-1RU Atom 230 1.60 3GB 20" WXGA++ 1.3 GMA 500GB DVD±RW 11b/g Black None PS/2 USB Prem 32 Sep09
3012-2DU Atom 330 1.60 4GB 20" WXGA++ 1.3 HD 4530 640GB DVD±RW 11b/g Black None PS/2 USB Prem 32 Jun 09
Type-model GHz
Widescreen
displayMemory
SATA
disk
SATA
optical
Mini PCIe
802.11
wireless Preload
Avail
date
Personal Systems Reference (PSREF)
© Lenovo
(CRB1-1) September 2009
See footnotes for important warranty information
☞US models announced September 10, 2009; previous models on June 24, 2009
Preloaded operating system20
- Some: Genuine Windows®XP
Home Edition
- Some: Genuine Windows Vista®
Home Basic 32
- Some: Genuine Windows Vista
Home Premium 32
Preloaded applications14
•Lenovo OneKey Recovery
•Driver and Application Installation
•Trend Micro™PC-cillin™Internet
Security 2008
•Windows Live™Toolbar
(Vista Models)
•Cyberlink Power2Go (DVD±RW)
•Corel®WinDVD®
•All-In-One design with 20" 16:9 widescreen
• Lenovo®Rescue System provides OneKey recovery and OneKey Antivirus without
booting into Windows
• Advanced hinge design allows changing the screen angle with only one hand, and
resting the screen angle at any intermediate position between 12° and 40°
Graphics KBDProcessor
Limited Warranty12
➫ 1-year parts and labor
➫ Customer Replaceable Unit (CRU)
parts only (with limited onsite
service for selected parts3,
8 am - 5 pm, Mon - Fri coverage
excluding holidays, next business
day response time)
➫Service upgrade options
(in eligible locations):9
• 3-year Lenovo Onsite Repair
9x5 Next Business Day (43R8882)
➫ 24x714 toll-free support for warranty
issues during the warranty period1
via 877-453-6686
Available at these retailers
•lenovo.com
Color
Camera
(mega-
pixel)
Blue-
tooth
☞
☞
☞
Mouse

Intel®Atom™processor 330 with dual-core,
Hyper-Threading technology, Intel 64 Technology,
Execute Disable Bit, 533MHz system bus, and 1MB L2 cache
3GB std / 4GB max7 / PC2-5300 667MHz DDR2, non-parity,
dual-channel capable, two 200-pin SO-DIMM sockets;
Italics: standard memory in both sockets; no sockets available
DVD burner, dual-layer support, fixed, removable, 12.7mm, tray-in
500GB, SATA 3.0Gb/s, 3.5" wide, 7200 rpm
20" (508mm) WXGA++ (1600x900) TFT color,anti-glare,CCFL backlight, 300 nits,
16:9 aspect ratio, 1000:1 contrast ratio
Camera on top of screen, 1.3-megapixel, fixed focus, with mono microphone
Brightness up/down buttons, display on/off button, and power button
ATI™ Mobility Radeon™ HD 4530, PCI Express®x16, 512MB memory,
DirectX®10, ATI Avivo™ HD
Intel 945GC Express Chipset, I/O Controller Hub 7 [ICH7] (SATA 3.0Gb/s,
ethernet MAC, USB, LPC bus)
6-in-1 reader (MultiMedia Card, Memory Stick, Memory Stick PRO ™ ,
Secure Digital Card, Secure Digital Elite Pro Card, xD-Picture Card ™ )
Rear: Four USB 2.0, ethernet (RJ-45), keyboard (PS/2),
IEEE 1394 FireWire 400 (4-pin connector; 1394a-2000 standard)
Left: Two USB 2.0
One Mini PCI Express slot
11b/g wireless4, Mini PCIe adapter, Broadcom®BCM4312
None
None
None
10/100 ethernet on planar, Intel 82562G
High Definition (HD) Audio, RealTek®ALC662 codec /
two stereo speakers (2 watt) / microphone, microphone input jack (3.5 mm),
headphone jack (3.5 mm)
Power-on password, supervisor password, security lockhole
PS/2 full-size keyboard
USB Optical Wheel Mouse
None
(WxHxD): 19.05" x 14.12" x 3.28"; 484mm x 359mm x 83mm
13.8 lb (6.26 kg)
Black color
Fold-away stand (adjustable between 12° and 40°)
Processor
Memory
S ATA DV D ±RW
SATA disk
Widescreen
display
Camera
Controls
Discrete Graphics
Chipset
Multicard reader
Ports
Mini PCI Express
11b/g28
TV tuner
Bluetooth™
Modem
Ethernet
Audio support
Security
Keyboard
Mouse
Remote control
Dimensions3
Weight
2
Chassis
Stand
Lenovo®C300 (3012) - Windows 7
120-watt AC adapter
RoHS-compliant
3012-2KU Atom 330 1.60 3GB 20" WXGA++ 1.3 HD 4530 500GB8DVD±RW None None 11b/g28 Black None Prem 32 Nov 09
Type-model GHz
Widescreen
displayMemory
SATA
disk
SATA
optical
Mini PCIe
802.11
wireless Win7
preload
Avail
date
Personal Systems Reference (PSREF)
© Lenovo
(CRB1-2) November 2009
See footnotes for important warranty information
US model announced November 3, 2009
Preloaded operating system20
- Genuine Windows®7
Home Premium 32
Preloaded applications14
•Lenovo OneKey Recovery
•Driver and Application Installation
•McAfee VirusScan®Plus 2009
(30 days of virus defi nitions)
•Cyberlink Power2Go (DVD±RW)
•Corel®WinDVD®
•All-In-One design with 20" 16:9 widescreen
• Lenovo®Rescue System provides OneKey recovery without booting into Windows
• Advanced hinge design allows changing the screen angle with only one hand, and
resting the screen angle at any intermediate position between 12° and 40°
Discrete
graphics
TV
tunerProcessor
Limited Warranty12
➫ 1-year parts and labor
➫ Customer Replaceable Unit (CRU)
parts only (with limited onsite
service for selected parts3,
8 am - 5 pm, Mon - Fri coverage
excluding holidays, next business
day response time)
➫Service upgrade options
(in eligible locations):9
• 3-year Lenovo Onsite Repair
9x5 Next Business Day (43R8882)
➫ 24x714 toll-free support for warranty
issues during the warranty period1
via 877-453-6686
Color
Camera
(mega-
pixel)
Blue-
tooth
Remote
control

57091128 1x4 Atom 230 1.60 512KB 1 1GB 16-in-1 160GB2DVD±RW GMA 950 None L195 HD None Home Basic Jan 09
57099437 1x4 Atom 230 1.60 512KB 1 1GB 160GB DVD±RW GMA 950 None D185 HD None XP Home Mar 09
57098978 1x4 Atom 230 1.60 512KB 1 1GB 160GB DVD±RW GMA 950 None None XP Home Apr 09
Processor
Implementation
Memory
Graphics
SATA disk
SATA controller
S ATA DV D ±RW
SATA cables
EIDE controller
EIDE cables
Diskette drive
Media reader
Chipset
Front ports
Rear ports
Rear audio ports
Audio
External speakers
Internal speaker
Ethernet
Modem
Security chip
TV tuner
Camera
Keyboard
Mouse
Power supply
Intel®Atom™Processor 230 with single-core,
Hyper-Threading technology, Intel 64 Technology,
Execute Disable Bit, 533MHz system bus, and 512KB L2 cache
Processor in Micro-FCBGA package in BGA437 socket
1GB std, 2GB max8, one 240-pin DIMM socket
57091128: PC2-5300 667MHz DDR2, non-parity;
others: PC2-6400 800MHz DDR2, non-parity
Intel Graphics Media Accelerator 950 (GMA 950),
integrated graphics in 945GC, uses main memory,
one 15-pin analog VGA DB-15 connector
160GB, SATA 3.0Gb/s, 7200 rpm
Serial ATA, SATA 3.0Gb/s, integrated in ICH7
Multi-Burner DL DVD±RW SATA 3.0Gb/s Drive
Two SATA cables (each 1-drop to device), two SATA connectors
None
None
None
Some: 16-in-1 media reader
Intel 945GC Express Chipset, I/O Controller Hub 7 [ICH7] (SATA 3.0Gb/s,
ethernet MAC, PCI 2.3, USB, LPC bus), ITE Tech®IT8718 Super I/O
Two USB 2.0, microphone (stereo, 3.5mm), headphone (stereo, 3.5mm)
Four USB 2.0, one serial (9-pin), keyboard (PS/2),
mouse (PS/2), ethernet (RJ-45), monitor (VGA DB-15)
Line-in (stereo, 3.5mm), line-out (stereo, 3.5mm), microphone-in (stereo, 3.5mm)
High Definition (HD) audio, ALC662 codec
None
None
10/100 ethernet on planar, Realtek® RTL8102E
None
None
None
None
104-key standard keyboard (PS/2 connector)
Optical Wheel Mouse (USB connector), 400 dpi
280 watts, universal, manual switch
Lenovo®H200
GHz
Part number Processor Memory8SATA
disk
SATA
optical Graphics
Avail
date
Slot x
bay
Personal Systems Reference (PSREF)
Tower
L2
cache
See footnotes for important warranty information
☞US model announced April 22, 2009; previous model on Jan 13 or March 17, 2009
© Lenovo
(SCL2-1) April 2009
Modem
Media
reader
Limited Warranty1
➫ 1-year parts and labor
➫ Customer Replaceable Unit (CRU)
parts only (with limited onsite service
for selected parts3, 8 am - 5 pm,
Mon - Fri coverage excluding holidays,
next business day response time)
➫Service upgrade options
(in eligible locations):9
• 3-year Lenovo Onsite Repair
9x5 Next Business Day (43R8882)
➫ 24x714 toll-free support for warranty
issues during the warranty period1
via 877-453-6686
☞
Cores
•Black bezel with glossy finish
• 6.9" W X 16.1" D X 14.2" H
• 175mm W X 409mm D X 360mm H
•20.1 lb (9.1 kg) in max configuration
Bay ①5.25", 1.6" high, access, standard optical
Bay ②3.0", 1" high, access, media reader*
Bay ③3.5", 1" high, no access, standard disk
Bay ④ 3.5", 1" high, no access, optional disk
* 16-in-1 media reader in some models
Slot 1: half-length,full-height, 32-bit PCI Ver 2.3
Camera
• Lenovo Rescue System provides OneKey recovery and OneKey Antivirus without booting into Windows
Preload
Available at these retailers
•Newegg®
•TigerDirect
Preloaded operating system20
- Some: Genuine Windows®XP
Home Edition
- Some: Genuine Windows Vista®
Home Basic 32
✧Vista model: Vista Basic logo
Preloaded applications5
• Lenovo®Rescue System
• Driver and Application Installation
•Trend Micro™PC-cillin™Internet Security 2008
•Windows Live™Toolbar
• Microsoft®Office 2007 Trial (60-day)
(Vista model only)
•Corel®WinDVD®(DVD±RW)
•CyberLink Power2Go (DVD±RW)
Monitor

5357-1FU 1x4 Atom 230 1.60 512KB 1GB PC2-5300 16-in-1 160GB DVD GMA 950 None Home Basic Jan 09
5357-1VU 1x4 Atom 230 1.60 512KB 1GB PC2-6400 160GB2DVD±RW GMA 950 None XP Home Mar 09
5357-1WU 1x4 Atom 230 1.60 512KB 1GB PC2-6400 160GB DVD±RW GMA 950 None XP Home Mar 09
5357-1XU 1x4 Atom 230 1.60 512KB 1GB PC2-6400 160GB DVD±RW GMA 950 None D185 XP Home Sep 09
5357-1KU 1x4 Atom 230 1.60 512KB 2GB PC2-5300 1TB DVD±RW GMA 950 None Home Basic Mar 09
5357-1CU 1x4 Atom 230 1.60 512KB 2GB PC2-5300 320GB DVD±RW GMA 950 None Home Basic Sep 09
5357-1GU 1x4 Atom 230 1.60 512KB 2GB PC2-5300 16-in-1 320GB DVD±RW GMA 950 None Home Basic Jan 09
5357-ACU 1x4 Atom 230 1.60 512KB 2GB PC2-6400 320GB DVD±RW GMA 950 None D185 Home Basic Sep 09
Processor
Implementation
Memory
Graphics
SATA disk
SATA controller
S ATA DV D
S ATA DV D ±RW
SATA cables
EIDE controller
EIDE cables
Diskette drive
Media reader
Chipset
Front ports
Rear ports
Rear audio ports
Audio
External speakers
Internal speaker
Ethernet
Modem
Security chip
TV tuner
Camera
Keyboard
Mouse
Power supply
Intel®Atom™Processor 230 with single-core,
Hyper-Threading technology, Intel 64 Technology,
Execute Disable Bit, 533MHz system bus, and 512KB L2 cache
Processor in Micro-FCBGA package in BGA437 socket
1GB or 2GB std, 2GB max8, one 240-pin DIMM socket;
Some: PC2-6400 800MHz DDR2, non-parity;
Some: PC2-5300 667MHz DDR2, non-parity
Intel Graphics Media Accelerator 950 (GMA 950),
integrated graphics in 945GC, uses main memory,
one 15-pin analog VGA DB-15 connector
160GB, 320GB, or 1TB, SATA 3.0Gb/s, 7200 rpm
Serial ATA, SATA 3.0Gb/s, integrated in ICH7
Some: DVD-ROM DL SATA 1.5Gb/s 16X-48X Max
Some: Multi-Burner DL DVD±RW SATA 1.5Gb/s Drive
Two SATA cables (each 1-drop to device), two SATA connectors
None
None
None
Some: 16-in-1 media reader
Intel 945GC Express Chipset, I/O Controller Hub 7 [ICH7] (SATA 3.0Gb/s,
ethernet MAC, PCI 2.3, USB, LPC bus), ITE Tech®IT8718 Super I/O
Two USB 2.0, microphone (stereo, 3.5mm), headphone (stereo, 3.5mm)
Four USB 2.0, one serial (9-pin), keyboard (PS/2),
mouse (PS/2), ethernet (RJ-45), monitor (VGA DB-15)
Line-in (stereo, 3.5mm), line-out (stereo, 3.5mm), microphone-in (stereo, 3.5mm)
High Definition (HD) audio, ALC662 codec
None
None
10/100 ethernet on planar, Realtek® RTL8102E
None
None
None
None
104-key standard keyboard (PS/2 connector)
Optical Wheel Mouse (USB connector), 400 dpi
280 watts, universal, manual switch
Lenovo®H200 (5357)
GHz
Type-model Processor Memory8SATA
disk
SATA
optical Graphics
Avail
date
Slot x
bay
Personal Systems Reference (PSREF)
Tower
L2
cache
See footnotes for important warranty information
☞US models announced September 10, 2009; previous models on Jan 13 or March 17, 2009
✂US models withdrawn effective November 2009
© Lenovo
(SCL2-2) September 2009
Modem
Media
reader
Limited Warranty1
➫ 1-year parts and labor
➫ Customer Replaceable Unit (CRU)
parts only (with limited onsite service
for selected parts3, 8 am - 5 pm,
Mon - Fri coverage excluding holidays,
next business day response time)
➫Service upgrade options
(in eligible locations):9
• 3-year Lenovo Onsite Repair
9x5 Next Business Day (43R8882)
➫ 24x714 toll-free support for warranty
issues during the warranty period1
via 877-453-6686
✂
✂
☞
✂
☞
✂
☞
•Black bezel with glossy finish
• 6.9" W X 16.1" D X 14.2" H
• 175mm W X 409mm D X 360mm H
•20.1 lb (9.1 kg) in max configuration
Bay ①5.25", 1.6" high, access, standard optical
Bay ②3.0", 1" high, access, 16-in-1 media reader
Bay ③3.5", 1" high, no access, standard disk
Bay ④ 3.5", 1" high, no access, optional disk
Slot 1: half-length,full-height, 32-bit PCI Ver 2.3
Monitor
• Lenovo Rescue System provides OneKey recovery and OneKey Antivirus without booting into Windows
Preload
Available at these retailers
•Lenovo.com
•Fry's
Preloaded operating system20
- Some: Genuine Windows®XP
Home Edition
- Some: Genuine Windows Vista®
Home Basic 32
✧Vista models: Vista Basic logo
Preloaded applications5
• Lenovo®Rescue System
• Driver and Application Installation
•Trend Micro™PC-cillin™Internet Security 2008
•Windows Live™Toolbar
• Microsoft®Office 2007 Trial (60-day)
(Vista models only)
•Corel®WinDVD®(Combo, DVD±RW)
•CyberLink Power2Go (DVD±RW)

57088764 4x4 Pentium E2200 2.20 1MB 2 2GB 500GB2DVD±RW GMA 3100 None None Prem 32 Oct 08
57088788 4x4 Pentium E2200 2.20 1MB 2 4GB 16-in-1 640GB DVD±RW GMA 3100 None None Prem 32 Oct 08
57094408 4x4 Pentium E2220 2.40 1MB 2 3GB 320GB DVD±RW GMA 3100 None None Prem 32 Jan 09
57098997 4x4 Pentium E5200 2.50 2MB 2 4GB 640GB DVD±RW GMA 3100 None None Prem 64 Mar 09
57088774 4x4 Core 2 Duo E7200 2.53 3MB 2 4GB 16-in-1 640GB DVD±RW GMA 3100 None None Prem 32 Oct 08
57098966 4x4 Core 2 Duo E7400 2.80 3MB 2 4GB 16-in-1 640GB DVD±RW GMA 3100 None None Prem 64 Mar 09
Processor
Implementation
Memory
Graphics
SATA disk
SATA controller
S ATA DV D ±RW
SATA cables
EIDE controller
EIDE cables
Diskette drive
Media reader
Chipset
Front ports
Rear ports
Rear audio ports
Audio
External speakers
Internal speaker
Ethernet
Modem
Security chip
TV tuner
Camera
Keyboard
Mouse
Power supply
Intel®Pentium®Processor E2200, E2220, or E5200 with
dual-core, Intel 64 Technology, Execute Disable Bit, EIST,
800MHz system bus,
E2200/E2220: 1MB L2 cache; E5200: 2MB L2 cache or
Intel Core™2 Duo Processor E7200 or E7400 with dual-core,
Intel 64 Technology, Execute Disable Bit, EIST, and
1066MHz system bus with 3MB L2 cache
Processor in FC-LGA6 or FC-LGA8 package in LGA775 socket
2GB, 3GB, or 4GB std, 4GB max8, two 240-pin DIMM sockets;
Italics: standard memory in both sockets; no sockets available;
57098966/57098997: PC2-6400 800MHz DDR2, non-parity,
dual-channel capable;
Others: PC2-5300 667MHz DDR2, non-parity,
dual-channel capable
Intel Graphics Media Accelerator 3100 (GMA 3100),
integrated graphics in G31, uses main memory,
one 15-pin analog D-sub connector
320GB, 500GB, or 640GB, SATA 3.0Gb/s, 7200 rpm
Serial ATA, SATA 3.0Gb/s, integrated in ICH7
Multi-Burner DL DVD±RW SATA 1.5Gb/s Drive
Two SATA cables (each 1-drop to device), four SATA connectors
None
None
None
Some: 16-in-1 media reader
Intel G31 Express Chipset (PCI Express®x16), I/O Controller Hub 7 [ICH7]
(SATA 3.0Gb/s, PCI Express x1, ethernet MAC, PCI 2.3, USB, LPC bus),
Winbond®W83627DHG or ITE Tech®IT8718F Super I/O
Two USB 2.0, microphone (stereo, 3.5mm), headphone (stereo, 3.5mm)
Four USB 2.0, one serial (9-pin), keyboard (PS/2),
mouse (PS/2), ethernet (RJ-45), monitor (DB-15)
Line-in (stereo, 3.5mm), line-out (stereo, 3.5mm), microphone-in (stereo, 3.5mm)
High Definition (HD) audio, ALC662 codec
None
None
10/100 ethernet on planar, Intel 82562GZ (PHY/MAC)
None
None
None
None
104-key standard keyboard (PS/2 connector)
Optical Wheel Mouse (USB connector), 400 dpi
280 watts, universal, manual switch
Lenovo®H210
GHz
Part number Processor Memory8SATA
disk
SATA
optical Graphics
Avail
date
Slot x
bay
Personal Systems Reference (PSREF)
Tower
L2
cache
See footnotes for important warranty information
☞US models announced March 17, 2009; previous models on October 22, 2008 or Jan 13, 2009
© Lenovo
(SCL1-1) May 2009
Modem
Media
reader
Limited Warranty1
➫ 1-year parts and labor
➫ Customer Replaceable Unit (CRU)
parts only (with limited onsite service
for selected parts3, 8 am - 5 pm,
Mon - Fri coverage excluding holidays,
next business day response time)
➫Service upgrade options
(in eligible locations):9
• 3-year Lenovo Onsite Repair
9x5 Next Business Day (43R8882)
➫ 24x714 toll-free support for warranty
issues during the warranty period1
via 877-453-6686
Cores
☞
☞
•Black bezel with glossy finish
• 6.9" W X 16.1" D X 14.2" H
• 175mm W X 409mm D X 360mm H
•20.1 lb (9.1 kg) in max configuration
Bay ①5.25", 1.6" high, access, standard optical
Bay ②3.0", 1" high, access, media reader *
Bay ③3.5", 1" high, no access, standard disk
Bay ④ 3.5", 1" high, no access, optional disk
* 16-in-1 media reader in some models
Slot 1: half-length,full-height, PCI Express x16 Ver 1.1
Slot 2: half-length,full-height, PCI Express x1 Ver 1.1
Slot 3: half-length,full-height, PCI Express x1 Ver 1.1
Slot 4: half-length,full-height, 32-bit PCI Ver 2.3
Cam-
era
• Lenovo Rescue System provides OneKey recovery and OneKey Antivirus without booting into Windows
Vista
preload
Available at these retailers
•Newegg®
•TigerDirect
Preloaded operating system20
- Some: Genuine Windows®Vista®
Home Premium 32
- Some: Genuine Windows Vista
Home Premium 64
✧Vista Basic logo
Preloaded applications5
• Lenovo®Rescue System
•Lenovo Healthcare Software
(Premium 32-bit models only)
• Driver and Application Installation
•Trend Micro™PC-cillin™Internet Security
•Windows Live™Toolbar
• Microsoft®Office 2007 Trial (60-day)
•VeriFace™
(Premium 32-bit models only)
•Corel®WinDVD®(DVD±RW)
•CyberLink Power2Go (DVD±RW)

5355-1EU 4x4 Pentium E2200 2.20 1MB 2GB PC2-5300 500GB2DVD±RW GMA 3100 None Prem 32 Oct 08
5355-1FU 4x4 Pentium E2200 2.20 1MB 3GB PC2-5300 16-in-1 320GB DVD±RW GMA 3100 None Prem 32 Nov 08
5355-ADU 4x4 Pentium E2220 2.40 1MB 2GB PC2-5300 16-in-1 250GB DVD±RW GMA 3100 None Prem 32 Jan 09
5355-1VU 4x4 Pentium E2220 2.40 1MB 3GB PC2-5300 320GB DVD±RW GMA 3100 None Prem 32 Jan 09
5355-AEU 4x4 Pentium E2220 2.40 1MB 3GB PC2-5300 16-in-1 320GB DVD±RW GMA 3100 None Prem 32 Jan 09
5355-AFU 4x4 Pentium E2220 2.40 1MB 3GB PC2-5300 320GB DVD±RW GMA 3100 None Prem 32 Jan 09
5355-2JU 4x4 Pentium E5200 2.50 2MB 3GB PC2-5300 16-in-1 500GB DVD±RW GMA 3100 None Prem 32 Jan 09
5355-2NU 4x4 Pentium E5200 2.50 2MB 4GB PC2-6400 320GB DVD±RW GMA 3100 None Prem 64 Sep 09
5355-2OU 4x4 Pentium E5200 2.50 2MB 4GB PC2-6400 500GB DVD±RW GMA 3100 None Prem 64 Sep 09
5355-BCU 4x4 Pentium E5200 2.50 2MB 4GB PC2-6400 500GB DVD±RW GMA 3100 None D185 Prem 64 Sep 09
5355-2DU 4x4 Pentium E5200 2.50 2MB 4GB PC2-5300 16-in-1 500GB DVD±RW GMA 3100 None Prem 32 Nov 08
5355-2MU 4x4 Pentium E5300 2.60 2MB 4GB PC2-6400 16-in-1 640GB DVD±RW GMA 3100 None Prem 64 Mar 09
5355-3HU 4x4 Core 2 Duo E7400 2.80 3MB 4GB PC2-5300 16-in-1 640GB DVD±RW GMA 3100 None Prem 32 Feb 09
5355-3OU 4x4 Core 2 Duo E7400 2.80 3MB 4GB PC2-6400 16-in-1 1TB DVD±RW GMA 3100 None Prem 64 Mar 09
5355-3UU 4x4 Core 2 Duo E7500 2.93 3MB 4GB PC2-6400 320GB DVD±RW GMA 3100 None Prem 64 Sep 09
5355-3WU 4x4 Core 2 Duo E7500 2.93 3MB 4GB PC2-6400 16-in-1 640GB DVD±RW GMA 3100 None Prem 64 Sep 09
Processor
Implementation
Memory
Graphics
SATA disk
SATA controller
S ATA DV D ±RW
SATA cables
EIDE controller
EIDE cables
Diskette drive
Media reader
Chipset
Front ports
Rear ports
Rear audio ports
Audio
External speakers
Internal speaker
Ethernet
Modem
Security chip
TV tuner
Camera
Keyboard
Mouse
Power supply
Intel®Pentium®Processor E2200, E2220, E5200, or E5300
with dual-core, Intel 64 Technology, Execute Disable Bit, EIST,
800MHz system bus,
E2200/E2220: 1MB L2 cache; E5200/E5300: 2MB L2 cache or
Intel Core™2 Duo Processor E7400 or E7500 with dual-core,
Intel 64 Technology, Execute Disable Bit, EIST,
1066MHz system bus, and 3MB L2 cache
Processor in FC-LGA6 or FC-LGA8 package in LGA775 socket
2GB, 3GB, or 4GB std, 4GB max8, two 240-pin DIMM sockets;
Italics: standard memory in both sockets; no sockets available;
Non-italics: standard memory in one socket; one socket available;
Some: PC2-6400 800MHz DDR2, non-parity,
dual-channel capable;
Some: PC2-5300 667MHz DDR2, non-parity,
dual-channel capable
Intel Graphics Media Accelerator 3100 (GMA 3100),
integrated graphics in G31, uses main memory,
one 15-pin analog D-sub connector
250GB, 320GB, 500GB, 640GB, or 1TB, SATA 3.0Gb/s, 7200 rpm
Serial ATA, SATA 3.0Gb/s, integrated in ICH7
Multi-Burner DL DVD±RW SATA 1.5Gb/s Drive
Two SATA cables (each 1-drop to device), four SATA connectors
None
None
None
Some: 16-in-1 media reader
Intel G31 Express Chipset (PCI Express®x16), I/O Controller Hub 7 [ICH7]
(SATA 3.0Gb/s, PCI Express x1, ethernet MAC, PCI 2.3, USB, LPC bus),
Winbond®W83627DHG or ITE Tech®IT8718F Super I/O
Two USB 2.0, microphone (stereo, 3.5mm), headphone (stereo, 3.5mm)
Four USB 2.0, one serial (9-pin), keyboard (PS/2),
mouse (PS/2), ethernet (RJ-45), monitor (DB-15)
Line-in (stereo, 3.5mm), line-out (stereo, 3.5mm), microphone-in (stereo, 3.5mm)
High Definition (HD) audio, ALC662 codec
None
None
10/100 ethernet on planar, Intel 82562GZ (PHY/MAC)
None
None
None
None
104-key standard keyboard (PS/2 connector)
Optical Wheel Mouse (USB connector), 400 dpi
280 watts, universal, manual switch
Lenovo®H210 (5355)
GHz
Type-model Processor Memory8SATA
disk
SATA
optical Graphics
Avail
date
Slot x
bay
Personal Systems Reference (PSREF)
Tower
L2
cache
See footnotes for important warranty information
☞US models announced September 10, 2009;
previous models on October 22, 2008 or Jan 13, February 24, or March 17, 2009
✂US models withdrawn effective November 2009
© Lenovo
(SCL1-2) September 2009
Modem
Media
reader
Limited Warranty1
➫ 1-year parts and labor
➫ Customer Replaceable Unit (CRU)
parts only (with limited onsite service
for selected parts3, 8 am - 5 pm,
Mon - Fri coverage excluding holidays,
next business day response time)
➫Service upgrade options
(in eligible locations):9
• 3-year Lenovo Onsite Repair
9x5 Next Business Day (43R8882)
➫ 24x714 toll-free support for warranty
issues during the warranty period1
via 877-453-6686
✂
✂
✂
☞
☞
☞
✂
✂
✂
☞
☞
•Black bezel with glossy finish
• 6.9" W X 16.1" D X 14.2" H
• 175mm W X 409mm D X 360mm H
•20.1 lb (9.1 kg) in max configuration
Bay ①5.25", 1.6" high, access, standard optical
Bay ②3.0", 1" high, access, media reader *
Bay ③3.5", 1" high, no access, standard disk
Bay ④ 3.5", 1" high, no access, optional disk
* 16-in-1 media reader in some models
Slot 1: half-length,full-height, PCI Express x16 Ver 1.1
Slot 2: half-length,full-height, PCI Express x1 Ver 1.1
Slot 3: half-length,full-height, PCI Express x1 Ver 1.1
Slot 4: half-length,full-height, 32-bit PCI Ver 2.3
Monitor
• Lenovo Rescue System provides OneKey recovery and OneKey Antivirus without booting into Windows
Vista
preload
Available at these retailers
•lenovo.com
•Fry's
Preloaded operating system20
- Some: Genuine Windows®Vista®
Home Premium 32
- Some: Genuine Windows Vista
Home Premium 64
✧Vista Basic logo
Preloaded applications5
• Lenovo®Rescue System
•Lenovo Healthcare Software
(Premium 32-bit models only)
• Driver and Application Installation
•Trend Micro™PC-cillin™Internet Security
•Windows Live™Toolbar
• Microsoft®Office 2007 Trial (60-day)
•VeriFace™
(Premium 32-bit models only)
•Corel®WinDVD®(DVD±RW)
•CyberLink Power2Go (DVD±RW)

3022-1AU 4x4 E5300 2.60 2MB 4GB (2, 2) 16-in-1 320GB2DVD±RW GMA X4500 None 180w Prem 64 Oct 09
3022-1BU 4x4 E5300 2.60 2MB 4GB (2, 2) 16-in-1 1TB DVD±RW GMA X4500 None 180w Prem 64 Oct 09
3022-1CU 4x4 E7500 2.93 3MB 4GB (2, 2) 16-in-1 500GB DVD±RW GMA X4500 None 180w Prem 64 Oct 09
3022-1KU 4x4 E7500 2.93 3MB 6GB (2, 2, 2) 16-in-1 640GB DVD±RW GMA X4500 None 180w Prem 64 Oct 09
3022-1DU 4x4 E7500 2.93 3MB 6GB (2, 2, 2) 16-in-1 640GB DVD±RW GMA X4500 11b/g11 None 180w Prem 64 Oct 09
3022-1EU 4x4 Q8300 2.50 4MB 4GB (2, 2) 16-in-1 500GB DVD±RW GMA X4500 None 280w Prem 64 Oct 09
3022-1FU 4x4 Q8300 2.50 4MB 6GB (2, 2, 2) 16-in-1 640GB DVD±RW GMA X4500 11b/g None 280w Prem 64 Oct 09
Processor
Implementation
Memory
Graphics
SATA disk
SATA controller
S ATA DV D ±RW
SATA cables
EIDE controller
EIDE cables
Diskette drive
Media reader
Chipset
Front ports
Rear ports
Rear audio ports
Audio
External speakers
Internal speaker
Wireless
Ethernet
Modem
Security chip
TV tuner
Camera
Keyboard
Mouse
Power supply
Intel®Pentium®Processor E5300 with dual-core,
Intel 64 Technology, Execute Disable Bit, EIST,
800MHz system bus, and 2MB L2 cache or
Intel Core 2 Duo™Processor E7500 with dual-core,
Intel 64 Technology, Execute Disable Bit, EIST,
1066MHz system bus, and 3MB L2 cache or
Intel Core 2 Quad Processor Q8300 with quad-core
(dual-core on dual-die), Intel 64 Technology, Execute Disable Bit,
EIST, 1333MHz system bus, and 4MB L2 cache
Processor in FC-LGA6 package in LGA775 socket
4GB or 6GB std, 8GB max8, PC3-8500 1066MHz DDR3, non-parity,
dual-channel capable, four 240-pin DIMM sockets
Intel Graphics Media Accelerator X4500 (GMA X4500),
integrated graphics in G43, uses main memory, DirectX®10,
one 15-pin analog VGA DB-15 connector
320GB, 500GB, 640GB, or 1TB, SATA 3.0Gb/s, 7200 rpm
Serial ATA, SATA 3.0Gb/s, integrated in ICH10R
Multi-Burner DL DVD±RW SATA 1.5Gb/s Drive
Two SATA cables (each 1-drop to device), five SATA connectors
None
None
None
16-in-1 media reader
Intel G43 Express Chipset (PCI Express®2.0 x16), I/O Controller Hub 10 RAID
[ICH10R] (SATA 3.0Gb/s, PCI Express x1, ethernet MAC, PCI 2.3, USB, LPC
bus), SMSC®SCH5147-NW Super I/O
Two USB 2.0, microphone (stereo, 3.5mm), headphone (stereo, 3.5mm)
Six USB 2.0, one serial (9-pin), keyboard (PS/2), mouse (PS/2), ethernet (RJ-45),
monitor (DB-15)
Line-in (stereo, 3.5mm), line-out (stereo, 3.5mm), microphone-in (stereo, 3.5mm)
High Definition (HD) audio, ALC662 codec
None
None
Some: 11b/g wireless4, Broadcom BCM4312, PCIe x1 adapter
10/100 ethernet on planar, Realtek®RTL8102E
None
None
None
None
Full-size keyboard (PS/2 connector), Fn keys, black
Optical Wheel Mouse (USB connector), 1000 dpi, black
Some: 180 watts, universal, manual switch
Some: 280 watts, universal, manual switch
Lenovo®H230 (3022) - Windows 7
GHz
Type-model
Pro-
cessor
Memory8SATA
disk
SATA
optical Graphics
Avail
date
Slot x
bay
Personal Systems Reference (PSREF)
Tower
L2
cache
See footnotes for important warranty information
US models announced October 23, 2009
© Lenovo
(SCL3-1) October 2009
Modem
Media
reader
Limited Warranty1
➫ 1-year parts and labor
➫ Customer Replaceable Unit (CRU)
parts only (with limited onsite service
for selected parts3, 8 am - 5 pm,
Mon - Fri coverage excluding holidays,
next business day response time)
➫Service upgrade options
(in eligible locations):9
• 3-year Lenovo Onsite Repair
9x5 Next Business Day (43R8882)
➫ 24x714 toll-free support for warranty
issues during the warranty period1
via 877-453-6686
•Black bezel with glossy finish
• 6.9" W X 16.1" D X 14.2" H
• 175mm W X 409mm D X 360mm H
•20.1 lb (9.1 kg) in max configuration
Bay ①5.25", 1.6" high, access, standard optical
Bay ②3.0", 1" high, access, 16-in-1 media reader
Bay ③3.5", 1" high, no access, standard disk
Bay ④ 3.5", 1" high, no access, optional disk
Slot 1: half-length,full-height, PCI Express x16 Ver 2.0
Slot 2: half-length,full-height, PCI Express x1 Ver 2.0*
Slot 3: half-length,full-height, PCI Express x1 Ver 2.0
Slot 4: half-length,full-height, 32-bit PCI Ver 2.3
* Wireless adapter in slot in some models
• Lenovo Rescue System provides OneKey recovery without booting into Windows
Win7
preload
Preloaded operating system20
- Genuine Windows®7
Home Premium 64
Preloaded applications5
• Lenovo®OneKey Recovery
• Driver and Application Installation
• McAfee VirusScan®Plus
(30 days of virus defi nitions)
•CyberLink Power2Go (DVD±RW)
DIMM
capacity
802.11
wireless
Power
supply

Partial list of Lenovo®Care Services22
for Lenovo Value Line desktops
For more information see:
http://www.lenovo.com/services_warranty/us/en/index.html
Lenovo Care service upgrade options
Lenovo Value Line desktops with 1-year Depod warranty
Mail in = Mail In repair, ADP = Accidental Damage Protection
2-year Mail In warranty 9x5 55Y2506
3-year Mail In warranty 9x5 55Y2507
1-year Mail In warranty 9x5 with ADP 55Y2511
2-year Mail In warranty 9x5 with ADP 55Y2512
3-year Mail In warranty 9x5 with ADP 55Y2513
LOR = Lenovo Onsite Repair, ADP = Accidental Damage Protection
1-year LOR warranty 9x5 55Y2508
2-year LOR warranty 9x5 55Y2509
3-year LOR warranty 9x5 55Y2510
1-year LOR warranty 9x5
with ADP 55Y2514
2-year LOR warranty 9x5 with ADP 55Y2515
3-year LOR warranty 9x5 with ADP 55Y2516
© Lenovo
(S-VLD) March 2009
Lenovo®Value Line Desktops - Lenovo CareSM Services Personal Systems Reference (PSREF)

Availability: All offers subject to avail-
ability. Lenovo reserves the right to alter
product offerings and specifications at
any time, without notice. Lenovo is not
responsible for photographic or typo-
graphic errors.
Warranty: For a copy of applicable
product warranties, write to: Warranty In-
formation, P.O. Box 12195, RTP, NC, 27709,
Attn: Dept ZPYA/B676. Lenovo makes no
representation or warranty regarding third
party products or services.
1 Limited warranty: Support unrelated to
a warranty issue may be subject to ad-
ditional charges.
2 Hard disk drive: GB = billion bytes, TB =
trillion bytes. Accessible capacity is less;
up to 4GB is service partition.
3Customer Replacement Units (CRUs)
are designed to be replaced by custom-
ers during the applicable warranty pe-
riod. Lenovo will send a technician onsite
to perform a repair if remote telephone
diagnosis does not isolate the problem,
if customer replaceable parts are unable
to resolve the problem, or at the request
of the customer. For a list of customer
replaceable parts, contact Lenovo. Sup-
port unrelated to a warranty issue may
be subject to additional charges.
5Included software may differ from its
retail version (if available), and may not
include user manuals or all program
functionality. License agreements may
apply.
6Post-warranty annual maintenance
agreement: Service begins at the end
of the base warranty or the end of any
other applied warranty and maintenance
option, whichever occurs last. Service
delivery is not available the same day the
maintenance agreement is purchased.
Maintenance agreements must be
purchased and the registration success-
fully completed prior to the service being
available.
7Lenovo Care Services: Not all machine
types and models are covered. Service
period begins with the equipment date
of purchase. Service must be purchased
during the original limited product war-
ranty period. Service levels are response
time objectives and are not guarantees.
If the machine problem turns out to be
a Customer Replaceable Unit (CRU), a
part at your discretion, will be express
shipped to you for quick replacement.
See Lenovo Care terms and conditions
for complete details and restrictions.
8Memory: For PCs without a separate vid-
eo card, memory supports both system
and video. Accessible system memory is
up to 64MB less than the amount stated,
depending on video mode.
9International Warranty Service is avail-
able for most models in any country in
which this product is sold and serviced.
Service delivery methods and parts avail-
ability vary by country, may be different
from that in the country of purchase, and
are subject to change without notice.
Fees and restrictions may apply in some
countries.
1 0 Modem speeds: Public network
download speeds are limited to 53Kbps.
Upload speeds are limited to 48Kbps for
V.92 modems. Actual speeds depend on
many factors and are often less than the
maximum possible. V.92 functions and
speeds require compatible phone line
and server equipment. Check with your
telephone and ISP service providers for
availability.
14 Response times may vary. May exclude
some holidays. Telephone support may
be subject to additional charges.
20 Operating System: Level of support var-
ies by operating system. Operating sys-
tems not preloaded on the system may
not provide full feature functionality. Refer
to lenovo.com/pc/support and enter your
machine type and model number for
more information.
This publication was developed for prod-
ucts and services offered in the United
States. Lenovo may not offer the products,
services or features discussed in this
document in other countries. Lenovo may
withdraw an offering at any time. Informa-
tion is subject to change without notice.
Consult your local representative for
information on offerings available in your
area.
Lenovo reserves the right to change spec-
ifications and other product information
at any time without prior notice. Lenovo is
not responsible for photographic or typo-
graphical errors. LENOVO PROVIDES THIS
PUBLICATION “AS IS” WITHOUT WAR-
RANTY OF ANY KIND, EITHER EXPRESS
OR IMPLIED, INCLUDING THE IMPLIED
WARRANTIES OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE.
Some jurisdictions do not allow disclaimer
of express or implied warranties in certain
transactions; therefore this disclaimer may
not apply to you.
Trademarks: Lenovo, the Lenovo logo,
New World. New Thinking., Access Con-
nections, Rescue and Recovery, Think-
Vantage, and ThinkVision are trademarks
of Lenovo. Microsoft, Windows, and Vista
are registered trademarks of Microsoft
Corporation. Intel, the Intel logo, Intel
Inside logo, Intel Core and Core Inside
are trademarks of Intel Corporation in the
US and other countries. AMD, the AMD
logo, AMD Athlon, AMD Sempron, and
combinations thereof, are trademarks
of Advanced Micro Devices, Inc. PCI
Express is a trademark of PCI-SIG. Other
company, product, or service names may
be trademarks or service marks of oth-
ers.
Visit www.lenovo.com/safecomputing
periodically for the latest information on
safe and effective computing.
Visit www.lenovo.com/psref
for the latest version of
Personal Systems Reference.
© Lenovo, 2009.
All rights reserved.
Lenovo
1009 Think Place
Morrisville, NC 27560
U. S.A.
November 2009
jbook.pdf
