Lenovo HORIZON 2s User manual

Machine type: F0AT
Lenovo
HORIZON 2s
User Guide
www.lenovo.com
Version 1.0 2014.07
SP40G09257

Important Safety Information
Before using this manual, it is important that you read and understand all of the
related safety information for this product. Refer to the Safety and Warranty Guide
that you received with this product for the latest safety information. Reading and
understanding this safety information reduces the risk of personal injury or product
damage.
The interface and functions shown in this User Guide are provided for reference
only and may differ from actual product appearance. Product design and
specifications may be changed without notice.
Danger: Be aware of extremely hazardous or potentially lethal situations.
Attention: Be aware of possible damage to programs, devices, or data.
Note: Pay attention to this important information.
© Copyright Lenovo 2014. All rights reserved.
LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered
pursuant a General Services Administration “GSA” contract, use, reproduction,
or disclosure is subject to restrictions set forth in Contract No. GS-35F-05925.

i
Contents
Contents
Important Safety Information
Using the Computer Hardware ................................................. 1
Front view of the computer.........................................................................2
Left and right view of the computer ............................................................3
Rear view of the computer .........................................................................4
Computer stand .........................................................................................5
Basic connector instructions ......................................................................6
Connecting your computer.........................................................................6
Important information about using the computer ........................................7
Charger stand (purchased separately) ........................................................8
Connecting to the Internet..........................................................................9
Using the E-Dice....................................................................... 11
E-Dice Components and Connectors.......................................................12
Charging the E-Dice.................................................................................12
Playing with the E-Dice.............................................................................13
Use and Maintenance ..............................................................................14
Using Windows 8.1 ................................................................... 15
Switching between the main Windows 8.1 interfaces ...............................16
The Charms Bar.......................................................................................16
Shutting down the computer....................................................................16
Switching between apps ..........................................................................17
Closing an app.........................................................................................17
Opening other system programs ..............................................................17
Windows Help and Support .....................................................................17

ii Contents
Touch screen instructions ....................................................... 19
Touch Screen Calibration..........................................................................20
User Gesture Instructions for the Touch screen ........................................20
Precautions when using the Touch Screen ...............................................25
Using the Rescue System........................................................ 27
OneKey Recovery ....................................................................................28
Driver and Application Installation .............................................................29
Using the Software................................................................... 31
Lenovo Support .......................................................................................32
Troubleshooting and Confirming Setup ................................. 33
Troubleshooting Display Problems............................................................34
Troubleshooting Touch screen..................................................................35
Troubleshooting Audio Problems ..............................................................35
Troubleshooting Software Problems .........................................................36
Troubleshooting Problems Hard Disks ......................................................37
Special considerations for troubleshooting Windows ................................37
Windows Help and Support .....................................................................38
BIOS setup utility......................................................................................38
Performing Daily Maintenance Tasks ........................................................39
Appendix. .................................................................................. 41
Declaration...............................................................................................41
Trademarks ..............................................................................................42
Energy Star Statement .............................................................................42
Enabling ErP compliance mode................................................................43
Electronic emissions notices .................................................. 44
Mexico regulatory notice......................................................... 45

User Guide 1
This chapter contains the following
topics:
ØIntroduction to the computer hardware
ØInformation on computer connections
Note: The descriptions in this chapter
might be different from what you see on
your computer, depending on the computer
model and configuration.
Using the Computer Hardware

2User Guide
Front view of the computer
1 2 3 4
5
1
6
Built-in microphone
Camera LED indicator
Built-in camera
Ambient light sensor*
Windows button**
Near Field Communication (NFC)
* Ambient light sensor
The ambient light sensor detects the amount of light in your surroundings.
The screen brightness automatically adjusts depending on the ambient light
conditions detected by the built-in ambient light sensor.
** Windows button
Press this button to toggle between the current view and the Start screen.
Note: Battery status is displayed in several places in the Windows OS. You
will be alerted when the battery starts to run low. Make sure you connect
the power supply when you receive an alert.
Note: Connect the power supply to your computer when using it for the
first time.

3
User Guide
Left and right view of the computer
1
3
4
5
6
8
7
2
Combo audio jack*
USB 3.0 connectors (2)
Power connector
Memory card reader
Volume down/up
Battery status indicator
Power button
Power status indicator
* Combo audio jack: Used to connect headsets.
Notes:
•The combo audio jack does not support conventional microphones.
•Different industry standards may lead to the recording function not
being supported if third-party headphones or headsets are connected.

4User Guide
Rear view of the computer
Attention: Be careful not to block any air vents on the computer. Blocked
air vents can cause overheating.
1
2
1 13
Air vents
Stand
Charging connector

5
User Guide
Computer stand
14º
90º
Attention: Do not place your computer as shown below.

6User Guide
Basic connector instructions
Note: Your computer may not have all of the connectors described in this
section.
Connector Description
Microphone Use this connector to attach a microphone to your
computer when you want to record sound or if you use
speech-recognition software.
Headphone Use this connector to attach headphones to your computer
when you want to listen to music or other sounds without
disturbing anyone.
USB connector Use this connector to attach a device that requires a USB
connection.
Note: If your computer is equipped with a wireless keyboard or mouse,
follow the installation instructions for those devices.
Connecting your computer
Connecting the power cord
Connect the power cord to an electrical outlet. We recommend using a grounded
connection or a surge protector.

7
User Guide
Important information about using the
computer
Press the power button on the side of the computer to turn on the computer.
Hold the computer tightly when you carry it.

8User Guide
Charger stand (purchased separately)
Note: Connect the power cord to an electrical outlet. We recommend using
a grounded connection or a surge protector.

9
User Guide
Connecting to the Internet
To connect to the Internet, you’ll need a contract with an Internet Service Provider
(ISP) and some hardware.
IPSs and ISP offerings vary by country. Contact your ISP for offerings available in
your country.
Your computer is designed to support a wireless network that connects your
computer to other devices.
Wireless network connection
For wireless networks, you can use the built-in wireless LAN antenna to access
your wireless home network.
To connect your computer to the wireless network:
1. Move the cursor to the top right or bottom right corner of the screen, then click
Settings. (If your computer is equipped with touch screen, swipe in from the
right edge of the screen, then tap Settings.)
2. Click or tap the network icon , then select the name of your router. Click or
tap Connect, then follow the steps on the screen.
Test the wireless network by opening your Web browser and accessing any
Web site.

10 User Guide

Using the E-Dice
This chapter contains the following
topics:
ØE-Dice instructons
Note: Only some models are equipped with
E-Dice.
Note: The interface and functionality of these
features will depend on which software
was shipped with the computer model you
purchased.
User Guide 11

12 User Guide
E-Dice Components and Connectors
Battery indicator Charging connector
Charging the E-Dice
The E-Dice has an internal rechargeable battery. If the indicator light blinks while
you are rolling the dice, this indicates the battery is low on power.
To charge the battery, do the following:
Put the E-Dice into the included USB power adapter and connect the adapter to
the USB connector on your computer.
Note: The indicator will blink while the E-Dice is charging. When the light
stays on constantly, the E-Dice is fully charged.

13
User Guide
Playing with the E-Dice
The E-Dice is paired in the factory for your convenience. It should work immediately
after plugging the dongle into your computer.
To play with the E-Dice, do the following:
1. Plug the dongle into USB connector of your computer.
2. Lay the computer face-up on a flat surface to switch the desktop interface to
the Aura program. Open the Lenovo Tycoon game and play the game with
the E-Dice as per the directions.
You may need to manually pair the E-Dice if it does not work.
To pair the E-Dice, do the following:
1. Open the Lenovo Tycoon game and go to the Dice Inspection interface. Click
the Inspection Start button in the pop-up dialog box, then roll the E-Dice. The
dice on the screen will roll and stop with the E-Dice.
2. Click Inspection Completed →OK to finish the pairing process.
Note: You need to pair all the E-Dice before playing a game. Only
successfully paired E-Dice can be used for the game.
If the E-Dice does not pair successfully, please do the following:
1. Check that the E-Dice battery has not run out or run low.
2. Check that the dongle is securely connected to your computer.
After checking the above, wait a few minutes and repeat the pairing process.

14 User Guide
Use and Maintenance
• TheminimumagerecommendedforusingtheE-Diceis14yearsold.
• KeeptheE-Diceawayfromwaterordampenvironments.Cleanthedicewitha
soft dry cloth.
• TheeffectiverangebetweentheE-Diceandthecomputeris2meters.Finda
comfortable posture when rolling the dice.
• MakesuretherearenophysicalobstaclesbetweentheE-Diceandthe
computer.
• Makesuretherearenoelectronicdevicescloseby,whichmightcreatestrong
electromagnetic fields that could interrupt the wireless connection, such as
speakers, remote controls for electronic toys or cell phones.
• AlwayskeeptheE-Diceanditspoweradaptercleantopreventdustbuildup.
• TheE-DiceanditsaccessoriesareonlycompatiblewiththeLenovo
HORIZON 2s model. Do not use them with other equipment.

Using Windows 8.1
This chapter contains the following
topics:
ØSwitching between the main Windows 8.1
interfaces
ØThe Charms Bar
ØShutting down the computer
ØSwitching between apps
ØClosing an app
ØOpening other system programs
ØWindows Help and Support
Attention: The Windows 8.1 operating system
is provided by Microsoft Corporation. Please
use it in accordance with the END USER
LICENSE AGREEMENT (EULA) between you
and Microsoft. For any question related to the
operating system, please contact Microsoft
directly.
User Guide 15
