Lenovo IdeaCentre A720 User manual

Version 1.0
Machine type: 10096/2564
2012.02
Lenovo
IdeaCentre A7 Series
User Guide
31501458

Important Safety Information
Before using this manual, it is important that you read and understand all of the
related safety information for this product. Refer to the Safety and Warranty Guide
that you received with this product for the latest safety information. Reading and
understanding this safety information reduces the risk of personal injury or damage
to your product.
The interface and functions shown in this User Guide are provided for reference
only and may differ from actual product appearance. Product design and
specifications may be changed without notice.
Danger: Be aware of extremely hazardous or potentially lethal situations.
Attention: Be aware of possible damage to programs, devices, or data.
Note: Pay attention to this important information.
© Copyright Lenovo 2012. All rights reserved.
LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered
pursuant a General Services Administration “GSA” contract, use, reproduction, or
disclosure is subject to restrictions set forth in Contract No. GS-35F-05925.
© 2012. Lenovo

1
Contents
Contents
Important Safety Information
Chapter 1 Using the Computer Hardware.............................. 1
1.1 Front view of the computer......................................................2
1.2 Left and right view of the computer .........................................3
1.3 B-CAS card installation (Japan models only)............................4
1.4 Rear view of the computer.......................................................5
1.5 Computer stand ......................................................................6
1.6 Connecting your computer ......................................................7
1.7 Important information about using the computer .....................9
Chapter 2 Touch screen instructions.................................... 11
2.1 Touch Screen Calibration.......................................................12
2.2 User Gesture Instructions for the Touch screen......................12
2.3 Precautions when using the Touch Screen.............................20
Chapter 3 Using the Rescue System .................................... 23
3.1 OneKey Recovery..................................................................24
3.2 Driver and Application Installation ..........................................24
3.3 System Setup........................................................................25
3.4 System Backup .....................................................................26
3.5 System Recovery ..................................................................26
3.6 Create Recovery Disc ............................................................26
Chapter 4 Troubleshooting and Confirming Setup.............. 27
4.1 Troubleshooting Display Problems .........................................28
4.2 Troubleshooting Touch screen ...............................................29
4.3 Troubleshooting Audio Problems ...........................................29
4.4 Troubleshooting Software Problems.......................................29

2Contents
4.5 Troubleshooting Problems with Optical Drives and Hard
Disks .....................................................................................30
4.6 Special considerations for troubleshooting Windows .............31
4.7 Performing Daily Maintenance Tasks......................................32
Energy Star Statement.................................................................33

Chapter
This chapter contains the following
topics:
ØIntroduction to the computer hardware
ØInformation on computer connections
Note: The descriptions in this chapter
might be different from what you see on
your computer, depending on the computer
models and configurations.
User Guide 1
Using the Computer Hardware

2User Guide
1.1 Front view of the computer
Attention: Be careful not to block any air vents on the computer. Blocked
air vents can cause overheating.
1 2
37654 8 9
10 11 12 13 14 15
Built-in microphone Built-in camera
Power indicator Hard disk drive indicator
Bluetooth status indicator WIFI status indicator
HDMI-in indicator Built-in speakers
Monitor On/Off PC mode / HDMI-in / AV-in switch
Novo Vision button Volume down
Volume up Brightness down
Brightness up

3
User Guide
1.2 Left and right view of the computer
2 3 468 5
9
10
7
1
Air vents
USB 3.0 connector
HDMI-in connector (selected models only)
HDMI-out connector
Eject button
Optical drive
B-CAS card slot (Japan models only)
Memory card reader
Power button
Anti-scratch protector
Attention: Do not insert 3-inch discs into the optical drive.

4User Guide
1.3 B-CAS card installation (Japan models only)

5
User Guide
1.4 Rear view of the computer
1 2 38764 5
TV tuner connector (selected models only, 2 connectors for Japan)
Headphone connector
Microphone connector
USB 3.0 connector
USB 2.0 connectors (2)
Power connector
Ethernet connector
Security cable slot

6User Guide
1.5 Computer stand
Use the stand to position the display to your preference. It can be rotated 5°
forward and 90° backward.
Attention: Ensure the anti-scratch protector is always on the hinge bar
when using the computer in a horizontal position.

7
User Guide
1.6 Connecting your computer
Note: Your computer may not have all of the connectors described in this
section.
1.6.1 Basic connector instructions
Connector Description
Microphone Use this connector to attach a microphone to your
computer when you want to record sound or if you use
speech-recognition software.
Headphone Use this connector to attach headphones to your
computer when you want to listen to music or other
sounds without disturbing anyone.
USB connector Use this connector to attach a device that requires a
USB connection.
Ethernet connector Use this connector to attach the computer to an
Ethernet-type local area network.
HDMI connector
(optional)
Connects to the HDMI connector on your display or TV.
TV-Tuner connector
(optional)
Connects to an external antenna to view programs
using the optional TV tuner card.
Note: If your computer is equipped with a wireless keyboard or mouse,
follow the installation instructions for those devices.

8User Guide
1.6.2 Connecting the power cord

9
User Guide
1.7 Important information about using the computer
Press the power button on the side of the computer to turn on the computer.
Note: The buttons at the bottom of the screen are touch buttons. Touching
them turns on the indicator lights.

10 User Guide
Hold the computer tightly when you carry it.
Attention: Do not place your computer face-down as shown below.

Chapter
Touch screen instructions
User Guide 11
This chapter contains the following
topics:
ØTouch Screen Calibration
ØUser Gesture Instructions for the Touch screen
ØAttentions when using the Touch Screen

12 User Guide
The monitor is touch-sensitive thanks to its touch-sensitive screen. A touch screen
is an input device just like a mouse or a keyboard, and the user’s fingers transmit
position information via the touch screen to the computer. With this technology,
you only need to touch the pictures or words on the computer display lightly with
your finger, and the computer will react.
2.1 Touch Screen Calibration
Prior to first use or whenever the touch screen reacts in a different place where you
are touching it, start the calibration program. The procedure is as follows:
1. In Windows 7, Select “Start” – “Control Panel”.
2. In Control Panel, select “Hardware and Sound”.
3. In “Hardware and Sound” window, select “Tablet PC Settings”.
4. In “Tablet PC Settings” dialogue, click “Calibrate” button.
2.2 User Gesture Instructions for the Touch screen
The Touch screen supports single touch and rotational movements, enlargement
and reduction multi-touch operations, and the user can transmit position
information to the computer via touch. The touch screen uses a very low pressure
movement recognition method, which only needs the finger to move lightly on the
computer display screen or make a simple hand gesture to be detected by the
main computer processor.
2.2.1 Basic Hand Gestures
1. Single Click / Double Click
For the item selected on the touch screen, with one finger touch it one or two
times, to perform a single click or double click operation. This is similar to the
action performed by clicking the mouse left button.

13
User Guide
2. Single Finger Right Click
For the item selected on the touch screen, press and hold your finger on the
screen until a circle appears. After lifting your finger from the touch screen, a menu
bar will pop up, completing the single finger right click operation. This is similar to
the action performed by clicking the mouse right button.

14 User Guide
3. Double Finger Right Click
First touch a finger to the screen to select the desired item and hold it there, then
touch another finger anywhere nearby on the screen and quickly lift it up again,
to complete a double finger right click operation. The area where the first finger is
placed can be used to show the right-click menu or perform related operations.
12
4. Dragging Movement
First touch your finger on the desired item on the screen and hold it there, then
make a dragging movement. This is similar to the click and drag movement you
can make with a mouse.

15
User Guide
5. High Speed Slide
If you touch the screen with a single finger and slide it a short distance horizontally
(about 5 cm), then quickly lift it up again, this is called a High Speed Slide, and the
screen will show the “Forward” or “Back” icon.
In the default situation, a high speed horizontal sliding movement will execute a
forward or back operation. For example: Forward and Back operations for the
IE browser; or Previous and Next slide operations in Windows Photo Viewer
slideshow mode.
about 5 FP
6. Rolling Movement
When you move your finger one time vertically (or horizontally) on the touch screen,
this is called a Rolling Operation. For example: This operation is similar to moving
the scroll wheel on the top of a mouse, and produces the same results as the scroll
wheel interface does.
