Lenovo ThinkSystem SR250 User manual

ThinkSystem SR250
Type 7Y51 and 7Y52
Quick Start
PN: SP47A37086
Printed in China
Your shipping box contains the following items:
SR250
Material box, including printed documentation
If any item is missing or damaged, contact your place of purchase.
Ensure that you retain your proof of purchase and packing material.
They might be required to receive warranty service.
First glance
Server front view:
Four drives model
VGA connector (optional)
Front operator panel
USB 2.0 connector
Four drive bays (0-3)
USB 3.1 Gen 1 connector
Rack release latches
Ten 2.5-inch hot-swap drives model
USB 2.0 connector
VGA connector (optional)
USB 3.1 Gen 1 connector
Ten 2.5-inch hot-swap drive
bays (0-9)
Front operator panel
Rack release latches
Server rear view:
Fixed power supply model
PCIe slot 1
Ethernet connector 1
(shared with XCC network
port)
PCIe slot 2
Dedicated XClarity
Controller (XCC) network
connector
Power connector
VGA connector
USB 3.1 Gen 2 connectors
Serial connector
Ethernet connector 2
Note 1: For the rear view of the redundant power supply model, there
are two power connectors on your server.
Note 2: Depending on the configuration, the illustrations above might
differ slightly from your server.
Setting up the System
1. Install the required solution components.
2. Install the enclosure into the rack.
See the Rack Installation Guide that was provided with the rail kit.
3. Connect the cables.
4. Connect the management controller to the network.
5. Power on the nodes.
6. Configure the system.
For detailed information about installing hardware options and
configuring the system, see the following website:
http://thinksystem.lenovofiles.com/help/topic/7Y51/introduc
tion.html

Technical specifications
Dimensions and weight
Height: 43.0 mm (1.7 inches)
Width: 434.4 mm (17.1 inches)
- With rack handles: 481.7 mm (18.9 inches)
- Without rack handles: 434.4 mm (17.1 inches)
Depth: 497.8 mm (19.6 inches)
Note: The depth is measured from the front mounting
flange of the rack to the rear of the server.
Weight (depending upon configuration):
- Maximum: 12.3 kg (27.1 lbs)
Processor
Your server comes with one Intel® multi-core processor from
Core™, Pentium®, Celeron® or Xeon® E processor family.
Memory
Minimum: 8GB
Maximum: 64 GB
DIMM types:
- PC4-21300, 2666 MT/s, error correcting code (ECC),
double-data-rate 4 (DDR4) unbuffered DIMM
(UDIMM)
Slots: Four DIMM slots
Node expansion bays (depending on the
model)
Four 2.5/3.5-inch simple-swap SAS/SATA HDD bays
Eight 2.5-inch hot-swap SAS/SATA HDD bays + Two 2.5-
inch hot-swap NVMe drive bays
Eight 2.5-inch hot-swap SAS/SATA HDD bays
Ten 2.5-inch hot-swap SAS/SATA HDD bays
Four 3.5-inch hot-swap SAS/SATA HDD bays
Where to go for support
Link
QR Code
Lenovo Press
(Product guides and white
papers)
https://lenovopress.com/
Lenovo Datacenter Systems
Forums
https://forums.lenovo.com/t5/
Datacenter-Systems/ct-
p/sv_eg
Lenovo Support –SR250
(including drivers and
software)
https://datacentersupport.leno
vo.com/products/servers/think
system/sr250?linkTrack=QR
Lenovo Product Security
Advisories
http://support.lenovo.com/us/
en/product_security/home
Lenovo Server Proven
(Compatibility information)
http://www.lenovo.com/serve
rproven
First Edition (November 2018)
© Copyright Lenovo 2018.
LIMITED AND RESTRICTED RIGHTS NOTICE: If
data or software is delivered pursuant to a General
Services Administration (GSA) contract, use,
reproduction, or disclosure is subject to restrictions
set forth in Contract No. GS
‐
35F
‐
05925.
