ThinkSystem SR150
Type 7Y54
Quick Start
PN: SP47A31791
Printed in China
Your shipping box contains the following items:
SR150
Material box, including printed documentation
If any item is missing or damaged, contact your place of purchase.
Ensure that you retain your proof of purchase and packing material.
They might be required to receive warranty service.
First glance
Server front view:
Server front view
VGA connector
Network activity LED
(green)
USB 2.0 with Lenovo
XClarity Controller
management
Identification button/LED
(blue)
USB 3.1 Gen1 connector
System error LED (yellow)
Power button/LED (green)
Simple-swap drive bays
Drive activity LED (green)
Rack release latches
Note 1: Depending on the configuration, the illustrations above might
differ slightly from your server.
Server rear view:
Server rear view
PCIe slot 1
LAN connector 2
PCIe slot 2
LAN connector 1 with
Lenovo XClarity Controller
management
Server power connector
VGA connector
USB 3.1 Gen1 connectors
Serial connector
Setting up the System
1. Install the required solution components.
2. Install the server into the rack.
See the Rack Installation Guide provided with the rail kit.
3. Connect the cables.
4. Connect the management controller to the network.
5. Power on the server.
6. Configure the system.
For detailed information about installing hardware options and
configuring the system, see the following website:
http://thinksystem.lenovofiles.com/help/topic/7Y54/introduction.html

Technical specifications
Dimensions and weight
Height: 43.0 mm (1.7 inches)
Width:
- With rack handles: 481.7mm (18.9 inches)
- Without rack handles: 434.4 mm (17.1 inches)
Depth: 497.8 mm (19.6 inches)
Weight (depending upon configurations)
- Maximum: 12.3 kg (27.1 lbs)
Note 2: The depth is measured from the front
mounting flange of the rack to the rear of the
server.
Processor
Your server comes with one Intel®multi-core processor from
Core™, Pentium®, Celeron®, or Xeon®E processor family
Memory
Minimum: 8GB
Maximum: 128 GB
DIMM types:
- Single-rank (dual-rank), error correcting code (ECC),
double-data-rate 4 (DDR4) unbuffered DIMM (UDIMM)
Slots: Four DIMM slots
Storage bays
Depending on the configuration, server supports up to four
drives or two simple-swap drives:
Four 2.5/3.5-inch SATA/SAS drives installed in drive bay
0-3.
Two 2.5/3.5-inch SATA drives installed in drive bay 0-1.
Networking
Supports up two Ethernet connectors
LAN connector 1 can be set to access Lenovo XClarity
Controller
Where to go for support
Link
QR Code
Lenovo Press
(Product guides and white
papers)
https://lenovopress.com/
Lenovo Datacenter Systems
Forums
https://forums.lenovo.com/t5/
Datacenter-Systems/ct-
p/sv_eg
Lenovo Support –SR150
(including drivers and
software)
http://support.lenovo.com.cn/
EsWeb/
Lenovo Product Security
Advisories
http://support.lenovo.com/us/
en/product_security/home
Lenovo Server Proven
(Compatibility information)
https://static.lenovo.com/us/
en/serverproven/index.shtml
