ThinkSystem SR630
Quick Start
In the box
Server
Rail kit*
Cable management arm*
Material box, including items such as accessory kit, power cords*
and documentation
Note: Items marked with asterisk (*) are available on some models
only.
If any item is missing or damaged, contact your place of purchase.
Ensure that you retain your proof of purchase. They might be required
to receive warranty service.
First glance
Front view:
Note: Your server might look different from the following illustrations.
Figure 1. Server models with four 3.5-inch drive bays
Figure 2. Server models with eight 2.5-inch drive bays
Figure 3. Server models with ten 2.5-inch drive bays
VGA connector (available
on some models)
Pull-out information tab
XClarity Controller USB
connector
USB 3.0 connector
Power button with power
status LED
Network activity LED
System ID button with ID
LED
System error LED
Rack latch (right)
Hot-swap drive bays
Drive status LED (yellow)
Drive activity LED (green)
Rack latch (left)
Rear view:
Figure 4. Server models with three PCIe slots
Figure 5. Server models with two PCIe slots
Figure 6. Server models with two hot-swap drive bays and one PCIe
slot
PCIe slot 1 on riser 1
assembly PCIe slot 2 on riser 1
assembly
PCIe slot 3 on riser 2
assembly
Rear 2.5-inch drive bays
Power supply 1 Power supply 2 (available on
some models)
NMI button
USB 3.0 connectors
VGA connector XClarity Controller network
connector
Ethernet connectors on the
LOM adapter (available on some
models)
Note: For server models with two hot-swap drive bays in the rear, if the
server is installed in a rack and shipped to you, the server comes with
a shipping bracket installed. Before turning on the server, be sure to
remove the shipping bracket. For server models with two hot-swap
drive bays in the rear, if the server is installed in a rack for shipping, be
sure to install the shipping bracket. For details, refer to the
ThinkSystem SR630 Maintenance Manual, which is available at:
http://thinksystem.lenovofiles.com/help/topic/7X01/pdf_files.html

Second Edition (November 2017)
© Copyright Lenovo 2017.
LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software
is delivered pursuant to a General Services Administration “GSA”
contract, use, reproduction, or disclosure is subject to restrictions set
forth in Contract No. GS‐35F‐05925.
Setting up the system
1. Install the required server components.
2. Install the server into the rack.
3. Connect the server to power.
4. Connect the server to the network.
5. Turn on the server.
6. Configure the server.
For detailed information about installing hardware options and
configuring the server, see the following Web site:
http://thinksystem.lenovofiles.com/help/topic/7X01/pdf_files.html
Technical specifications
Dimensions and weight
1U
Height: 43.0 mm (1.7 inches)
Width:
With rack latches: 482.0 mm (19.0 inches)
Without rack latches: 434.4 mm (17.1 inches)
Depth: 778.3 mm (30.7 inches)
Note: The depth is measured with rack latches and power
supply installed, but without security bezel installed.
Weight: up to 19.0 kg (41.9 lb)
Processor
Supports (depending on the model):
Up to two Intel®processors
Designed for Land Grid Array (LGA) 3647 socket
Scalable up to 28 cores
Thermal Design Power (TDP): up to 205 watts
DIMM
Minimum: 8GB
Maximum:
768 GB using registered DIMMs (RDIMMs)
1.5 TB using load-reduced DIMMs (LRDIMMs)
3 TB using three-dimensional stack registered DIMMs (3DS
RDIMMs)
Type:
RDIMM, LRDIMM, or 3DS RDIMM
Single-rank, dual-rank, quad-rank, or octa-rank
PC4-21300 (DDR4-2666), operating speed depends on the
processor model and UEFI Operating Mode selection
Slots: 24 DIMM slots
Supports (depending on the model):
8 GB, 16 GB, and 32 GB RDIMMs
64 GB LRDIMMs
128 GB 3DS RDIMMs
Storage
Supports the following drives:
Up to four 3.5-inch hot-swap SAS/SATA drives
Up to four 3.5-inch hot-swap SAS/SATA/NVMe drives
Up to eight 2.5-inch hot-swap SAS/SATA drives
Up to ten 2.5-inch hot-swap NVMe drives
Up to ten 2.5-inch hot-swap SAS/SATA/NVMe drives (NVMe
drives are supported only in drive bays 6-9)
Up to two 2.5-inch hot-swap SAS/SATA drives in the rear
Up to two internal M.2 drives
Networking
One XClarity Controller network connector
Two or four Ethernet connectors on the LOM adapter (available
on some models)
