ThinkSystem SR630
Quick Start
In the box
Server
Rail kit*
Cable management arm*
Material box, including items such as accessory kit, power cords* and
documentation
Note: Items marked with asterisk (*) are available on some models only.
If any item is missing or damaged, contact your place of purchase. Ensure
that you retain your proof of purchase. They might be required to receive
warranty service.
First glance
Front view:
Note: Your server might look different from the following illustrations.
Figure 1. Server models with four 3.5-inch drive bays
Figure 2. Server models with eight 2.5-inch drive bays
Figure 3. Server models with ten 2.5-inch drive bays
VGA connector (available
on some models)
Pull-out information tab
XClarity Controller USB
connector
USB 3.0 connector
Power button with power
status LED
Network activity LED
System ID button with ID
LED
System error LED
Rack latch (right)
Hot-swap drive bays
Drive status LED (yellow)
Drive activity LED (green)
Rack latch (left)
Rear view:
Figure 4. Server models with three PCIe slots
Figure 5. Server models with two PCIe slots
Figure 6. Server models with two hot-swap drive bays and one PCIe slot
PCIe slot 1 on riser 1
assembly PCIe slot 2 on riser 1
assembly
PCIe slot 3 on riser 2
assembly
Rear 2.5-inch drive bays
Power supply 1 Power supply 2 (available on
some models)
NMI button
USB 3.0 connectors
VGA connector XClarity Controller network
connector
Ethernet connectors on the
LOM adapter (available on some
models)
Note: For server models with two hot-swap drive bays in the rear, if the
server is installed in a rack and shipped to you, the server comes with a
shipping bracket installed. Before turning on the server, be sure to remove
the shipping bracket. For server models with two hot-swap drive bays in
the rear, if the server is installed in a rack for shipping, be sure to install
the shipping bracket. For details, refer to the ThinkSystem SR630
Maintenance Manual, which is available at:
http://thinksystem.lenovofiles.com/help/topic/7X01/pdf_files.html

Third Edition (April 2019)
© Copyright Lenovo 2017, 2019.
LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is
delivered pursuant to a General Services Administration (GSA)
contract, use, reproduction, or disclosure is subject to restrictions set
forth in Contract No. GS‐35F‐05925.
Setting up the system
1. Install the required server components.
2. Install the server into the rack.
3. Connect the server to power.
4. Connect the server to the network.
5. Turn on the server.
6. Configure the server.
For detailed information about installing hardware options and configuring
the server, see the following Web site:
http://thinksystem.lenovofiles.com/help/topic/7X01/pdf_files.html
Technical specifications
Dimensions and weight
1U
Height: 43.0 mm (1.7 inches)
Width:
With rack latches: 482.0 mm (19.0 inches)
Without rack latches: 434.4 mm (17.1 inches)
Depth: 778.3 mm (30.7 inches)
Note: The depth is measured with rack latches and power supply
installed, but without security bezel installed.
Weight: up to 19.0 kg (41.9 lb)
Processor
Supports (depending on the model):
Up to two Intel®processors
Designed for Land Grid Array (LGA) 3647 socket
Scalable up to 28 cores
Thermal Design Power (TDP): up to 205 watts
Memory
For Intel Xeon Skylake processors:
Slots: 24 DIMM slots
Minimum: 8GB
Maximum:
768 GB using registered DIMMs (RDIMMs)
1.5 TB using load-reduced DIMMs (LRDIMMs)
3 TB using three-dimensional stack registered DIMMs (3DS
RDIMMs)
Type:
TruDDR4 2666, single-rank/dual-rank, 8 GB/16 GB/32 GB
RDIMM
TruDDR4 2666, quad-rank, 64 GB LRDIMM
TruDDR4 2666, octa-rank, 128 GB 3DS RDIMM
For Intel Xeon Cascade Lake processors:
Slots: 24 DIMM slots
Minimum: 8GB
Maximum:
1.5 TB using RDIMMs
3 TB using 3DS RDIMMs
6 TB using DC Persistent Memory Module (DCPMM) and
RDIMMs/3DS RDIMMs in Memory Mode
Type: (depending on the model)
TruDDR4 2666, single-rank/dual-rank, 16 GB/32 GB RDIMMs
TruDDR4 2933, single-rank/dual-rank, 8 GB/16 GB/32 GB/64
GB RDIMMs
TruDDR4 2666, quad-rank, 64 GB 3DS RDIMMs
TruDDR4 2933, quad-rank, 128 GB 3DS RDIMMs
128 GB/256 GB/512 GB DCPMM
Note: Operating speed and total memory capacity depend on the
processor model and UEFI settings.
For a list of supported memory, see the Lenovo ServerProven Web site:
https://static.lenovo.com/us/en/serverproven/index.shtml
Storage
Supports the following drives:
Up to four 3.5-inch hot-swap SAS/SATA drives
Up to four 3.5-inch hot-swap SAS/SATA/NVMe drives
Up to eight 2.5-inch hot-swap SAS/SATA drives
Up to ten 2.5-inch hot-swap NVMe drives
Up to ten 2.5-inch hot-swap SAS/SATA/NVMe drives (NVMe drives
are supported only in drive bays 6-9)
Up to two 2.5-inch hot-swap SAS/SATA drives in the rear
Up to two internal M.2 drives
Networking
One XClarity Controller network connector
Two or four Ethernet connectors on the LOM adapter (available on
some models)
