ThinkSystem SR860 V2
Messages and Codes Reference
Machine Types: 7Z59 and 7Z60

Note
efore using this information and the product it supports, be sure to read and understand the safety
information and the safety instructions, which are available at:
http://thinksystem.lenovofiles.com/help/topic/safety_documentation/pdf_files.html
In addition, be sure that you are familiar with the terms and conditions of the Lenovo warranty for your server,
which can be found at:
http://datacentersupport.lenovo.com/warrantylookup
Ninth Edition (September 2022)
© Copyright Lenovo 2020 2022.
LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered pursuant to a General Services
Administration (GSA) contract, use, reproduction, or disclosure is subject to restrictions set forth in Contract No. GS-35F-
05925.

Contents
Contents . . . . . . . . . . . . . . . . . i
Chapter 1. Introduction . . . . . . . . . 1
Chapter 2. XClarity Controller
events . . . . . . . . . . . . . . . . . . 3
XCC events that automatically notify Support . . . . 4
XCC events organized by severity. . . . . . . . . 5
List of XClarity Controller events . . . . . . . . 22
Chapter 3. UEFI events . . . . . . . . 135
UEFI events organized by severity . . . . . . . 135
List of UEFI events. . . . . . . . . . . . . . 142
Chapter 4. XClarity Provisioning
Manager events . . . . . . . . . . . . 175
LXPM events organized by severity . . . . . . . 175
List of XClarity Provisioning Manager events . . . 178
Appendix A. Getting help and
technical assistance . . . . . . . . . . 199
efore you call . . . . . . . . . . . . . . . 199
Collecting service data . . . . . . . . . . . . 200
Contacting Support . . . . . . . . . . . . . 201
Index . . . . . . . . . . . . . . . . . . 203
© Copyright Lenovo 2020, 2022 i

ii ThinkSystem SR860 V2 Messages and Codes Reference

Chapter 1. Introduction
When attempting to resolve issues with your server, the best practice is to begin with the event log of the
application that is managing the server:
• If you are managing the server from the Lenovo XClarity Administrator, begin with the Lenovo XClarity
Administrator event log.
• If you are using some other management application, begin with the Lenovo XClarity Controller event log.
The event log contains server hardware events that are recorded by the Lenovo XClarity Controller or by
UEFI. In addition, events can be generated when you perform diagnostic testing on hard drives or memory
through the Lenovo XClarity Provisioning Manager (although these events are not stored in the event log).
Use this section to view the events that can be generated by Lenovo XClarity Controller, UEFI, or the Lenovo
XClarity Provisioning Manager. For each event, a user action is available to help you understand what must
be done to resolve the issue.
Important:
• Lenovo XClarity Controller (XCC) supported version varies by product. All versions of Lenovo XClarity
Controller are referred to as Lenovo XClarity Controller and XCC in this document, unless specified
otherwise. To see the XCC version supported by your server, go to https://sysmgt.lenovofiles.com/help/
topic/lxcc_frontend/lxcc_overview.html.
• Lenovo XClarity Provisioning Manager (LXPM) supported version varies by product. All versions of Lenovo
XClarity Provisioning Manager are referred to as Lenovo XClarity Provisioning Manager and LXPM in this
document, unless specified otherwise. To see the LXPM version supported by your server, go to https://
sysmgt.lenovofiles.com/help/topic/lxpm_frontend/lxpm_product_page.html.
© Copyright Lenovo 2020, 2022 1

2ThinkSystem SR860 V2 Messages and Codes Reference

Chapter 2. XClarity Controller events
When a hardware event is detected by the Lenovo XClarity Controller on the server, the Lenovo XClarity
Controller writes that event in the system-event log on the server.
Notes: Event identifier (ID) is a unique identifier used to search for XCC events. The event message may
have one or more arguments, which could be replaceable text of FRU name or sensor name to identify the
failed component. So one XCC event ID could represent a generic event or similar faults that happened on
different hardware components. The general way of problem determination is to locate the event by ID,
identify the hardware component by message argument if it contains hardware component name, and then
perform actions defined in User Action.
Example:
FQXSPCA0017M: Sensor [SensorElementName] has transitioned to critical from a less severe state
where:
• FQXSPCA0017M is the event ID.
• [SensorElementName] is a sensor variable, indicating the name of hardware component. It can be CPU,
PCI adapter, OCP card or chipset. You can find the event by the event ID FQXSPCA0017M and perform
actions defined in User Action for the component.
For additional information about the Lenovo XClarity Controller event log, see “Viewing Event Logs” section
in the XCC documentation compatible with your server at https://sysmgt.lenovofiles.com/help/topic/lxcc_
frontend/lxcc_overview.html.
For each event code, the following fields are displayed:
Event identifier
An identifier that uniquely identifies an event.
Event description
The logged message string that appears for an event. When the event string is displayed in the event
log, information such as a specific component is displayed. In this documentation, that additional
information appears as variables, which include but not limited to the following:
• [SensorElementName], [ManagedElementName] , [ProcessorElementName],
[ComputerSystemElementName], [PowerSupplyElementName], ...
• [arg1], [arg2], [arg3], [arg4], [arg5]...
Explanation
Provides additional information to explain why the event occurred.
Severity
An indication of the level of concern for the condition. The following severities can be displayed.
• Informational. The event was recorded for audit purposes, usually a user action or a change of states
that is normal behavior.
• Warning. The event is not as severe as an error, but if possible, the condition should be corrected
before it becomes an error. It might also be a condition that requires additional monitoring or
maintenance.
• Error. The event is a failure or critical condition that impairs service or an expected function.
Alert Category
© Copyright Lenovo 2020, 2022 3

Similar events are grouped together in categories. The alert category is in the following format: sever ty -
dev ce, where:
• sever ty is one of the following severity levels:
– Critical. A key component in the server is no longer functioning.
– Warning. The event might progress to a critical level.
– System. The event is the result of a system error or a configuration change.
• dev ce is the specific device in the server that caused the event to be generated.
Serviceable
Specifies whether user action is required to correct the problem.
CIM Information
Provides the prefix of the message ID and the sequence number that is used by the CIM message
registry.
SNMP Trap ID
The SNMP trap ID that is found in the SNMP alert management information base (MI ).
Automatically contact Service
You can configure the Lenovo XClarity Administrator to automatically notify Support (also known as call
home) if certain types of errors are encountered. If you have configured this function and this field is set
to Yes, Lenovo Support will be notified automatically if the event is generated. While you wait for Lenovo
Support to call, you can perform the recommended actions for the event.
Note: This documentation includes references to I M web sites, products, and information about
obtaining service. I M is Lenovo's preferred service provider for the Lenovo server products.
For more information about enabling Call Home from Lenovo XClarity Administrator, see http://
sysmgt.lenovofiles.com/help/topic/com.lenovo.lxca.doc/admin_setupcallhome.html. In addition, see “XCC
events that automatically notify Support” on page 4 for a consolidated list of all Lenovo XClarity
Controller events that are called home to Lenovo Support.
User Action
Indicates what actions you should perform to solve the event. Perform the steps listed in this section in
the order shown until the problem is solved. If you cannot solve the problem after performing all steps,
contact Lenovo Support.
XCC events that automatically notify Support
You can configure the XClarity Administrator to automatically notify Support (also known as call home) if
certain types of errors are encountered. If you have configured this function, see the table for a list of events
that automatically notify Support.
Table 1. Events that automat cally not fy Support
Event ID Message String
FQXSPEM4014I The RAID controller has problem with the battery. Please contact technical
support to resolve this issue.([arg1],[arg2],[arg3],[arg4],[arg5])
FQXSPEM4015I The RAID controller detected unrecoverable error. The controller needs
replacement.([arg1],[arg2],[arg3],[arg4],[arg5])
FQXSPEM4025I One or more virtual drive have problem. Please contact technical support to
resolve this issue.([arg1],[arg2],[arg3],[arg4],[arg5])
FQXSPEM4026I Drive error was detected by RAID controller. Please contact technical support
to resolve this issue.([arg1],[arg2],[arg3],[arg4],[arg5])
4ThinkSystem SR860 V2 Messages and Codes Reference

Table 1. Events that automat cally not fy Support (cont nued)
Event ID Message String
FQXSPIO0001L The connector [PhysicalConnectorElementName] has encountered a
configuration error.
FQXSPIO0011N An Uncorrectable Error has occurred on [SensorElementName].
FQXSPIO0015M Fault in slot [PhysicalConnectorSystemElementName] on system
[ComputerSystemElementName].
FQXSPMA0007L Scrub Failure for [PhysicalMemoryElementName] on Subsystem
[MemoryElementName].
FQXSPMA0008N Uncorrectable error detected for [PhysicalMemoryElementName] on
Subsystem [MemoryElementName].
FQXSPMA0011G Memory Logging Limit Reached for [PhysicalMemoryElementName] on
Subsystem [MemoryElementName].
FQXSPPU0004M [ProcessorElementName] has Failed with FR 1/ IST condition.
FQXSPPW0002L [PowerSupplyElementName] has Failed.
FQXSPPW0035M Numeric sensor [NumericSensorElementName] going low (lower critical) has
asserted.
FQXSPPW0047M Numeric sensor [NumericSensorElementName] going high (upper critical) has
asserted.
FQXSPPW0063M Sensor [SensorElementName] has transitioned to critical from a less severe
state.
FQXSPSD0001L The [StorageVolumeElementName] has been disabled due to a detected fault.
FQXSPSD0002G Failure Predicted on [StorageVolumeElementName] for array
[ComputerSystemElementName].
FQXSPSD0002L Drive [arg1] in the enclosure/chassis(MTM-SN: [arg2]) has been disabled due
to a detected fault.
FQXSPSD0003G Failure Predicted on drive [arg1] in the enclosure/chassis (MTM-SN: [arg2]).
FQXSPSD0006L Array [ComputerSystemElementName] has failed.
FQXSPSD0008L Array failed on drive [arg1] in the enclosure/chassis (MTM-S/N: [arg2]).
FQXSPSS4004I Test Call Home Generated by user [arg1].
FQXSPSS4005I Manual Call Home by user [arg1]: [arg2].
XCC events organized by severity
The following table lists all XCC events, organized by severity (Information, Error, and Warning).
Table 2. Events organ zed by sever ty
Event ID Message String Severity
FQXSP R4000I Management Controller [arg1]: Configuration restored from a file by
user [arg2].
Informational
FQXSP R4002I Management Controller [arg1] Reset was caused by restoring default
values.
Informational
Chapter 2.XClarity Controller events 5

Table 2. Events organ zed by sever ty (cont nued)
Event ID Message String Severity
FQXSP R4004I Server timeouts set by user [arg1]: EnableOSWatchdog=[arg2],
OSWatchdogTimout=[arg3], EnableLoaderWatchdog=[arg4],
LoaderTimeout=[arg5].
Informational
FQXSP R4005I Management Controller [arg1]: Configuration saved to a file by user
[arg2].
Informational
FQXSP R4006I Management Controller [arg1]: Configuration restoration from a file by
user [arg2] completed.
Informational
FQXSP T0007I No bootable media available for system
[ComputerSystemElementName].
Informational
FQXSPCA2002I Numeric sensor [NumericSensorElementName] going low (lower
critical) has deasserted.
Informational
FQXSPCA2007I Numeric sensor [NumericSensorElementName] going high (upper
non-critical) has deasserted.
Informational
FQXSPCA2009I Numeric sensor [NumericSensorElementName] going high (upper
critical) has deasserted.
Informational
FQXSPCA2011I Numeric sensor [NumericSensorElementName] going high (upper
non-recoverable) has deasserted.
Informational
FQXSPCA2015I Sensor [SensorElementName] has deasserted the transition from
normal to non-critical state.
Informational
FQXSPCA2017I Sensor [SensorElementName] has transitioned to a less severe state
from critical.
Informational
FQXSPCA2019I Sensor [SensorElementName] has deasserted the transition to non-
recoverable from a less severe state.
Informational
FQXSPCN4000I Serial Redirection set by user [arg1]: Mode=[arg2], audRate=[arg3],
Stop its=[arg4], Parity=[arg5], SessionTerminateSequence=[arg6].
Informational
FQXSPCN4001I Remote Control session started by user [arg1] in [arg2] mode. Informational
FQXSPCN4002I User [arg1] has terminated an active console session. Informational
FQXSPCN4003I Remote Control session started by user [arg1] in [arg2] mode has
been closed.
Informational
FQXSPCR2001I Sensor [SensorElementName] has deasserted the transition to non-
recoverable from a less severe state.
Informational
FQXSPDA2000I The System [ComputerSystemElementName] has detected a POST
Error deassertion.
Informational
FQXSPDM4000I Inventory data changed for device [arg1], new device data hash=
[arg2], new master data hash=[arg3] .
Informational
FQXSPDM4001I Storage [arg1] has changed. Informational
FQXSPDM4003I TKLM servers set by user [arg1]: TKLMServer1=[arg2] Port=[arg3],
TKLMServer2=[arg4] Port=[arg5], TKLMServer3=[arg6] Port=[arg7],
TKLMServer4=[arg8] Port=[arg9].
Informational
FQXSPDM4004I TKLM servers device group set by user [arg1]:
TKLMServerDeviceGroup=[arg2] .
Informational
FQXSPDM4005I User [arg1] has generated a new encryption key pair and installed a
self-signed certificate for the TKLM client.
Informational
6ThinkSystem SR860 V2 Messages and Codes Reference

Table 2. Events organ zed by sever ty (cont nued)
Event ID Message String Severity
FQXSPDM4006I User [arg1] has generated a new encryption key and certificate
signing request for the TKLM client.
Informational
FQXSPDM4007I User [arg1] has imported a signed certificate for the TKLM client from
[arg2].
Informational
FQXSPDM4008I User [arg1] has imported a server certificate for the TKLM server. Informational
FQXSPDM4009I User [arg1] has [arg2] file [arg3] from [arg4]. Informational
FQXSPDM4010I Inventory data collecting and processing complete for [arg1],
sequence number is [arg2].
Informational
FQXSPEA2001I Sensor [SensorElementName] has deasserted the transition from
normal to non-critical state.
Informational
FQXSPEA2002I Sensor [SensorElementName] has transitioned to a less severe state
from critical.
Informational
FQXSPEM0003I The Log [RecordLogElementName] has been cleared. Informational
FQXSPEM0004I The Log [RecordLogElementName] is full. Informational
FQXSPEM0005I The Log [RecordLogElementName] is almost full. Informational
FQXSPEM0009I The System [ComputerSystemElementName] has generated an
auxiliary Log Entry in Log [RecordLogElement].
Informational
FQXSPEM4000I The [arg1] on system [arg2] cleared by user [arg3]. Informational
FQXSPEM4001I The [arg1] on system [arg2] is 75% full. Informational
FQXSPEM4002I The [arg1] on system [arg2] is 100% full. Informational
FQXSPEM4003I LED [arg1] state changed to [arg2] by [arg3]. Informational
FQXSPEM4004I SNMP [arg1] enabled by user [arg2] . Informational
FQXSPEM4005I SNMP [arg1] disabled by user [arg2] . Informational
FQXSPEM4006I Alert Configuration Global Event Notification set by user [arg1]:
RetryLimit=[arg2], RetryInterval=[arg3], EntryInterval=[arg4].
Informational
FQXSPEM4007I Alert Recipient Number [arg1] updated: Name=[arg2],
DeliveryMethod=[arg3], Address=[arg4], IncludeLog=[arg5], Enabled=
[arg6], EnabledAlerts=[arg7], AllowedFilters=[arg8].
Informational
FQXSPEM4008I SNMP Traps enabled by user [arg1]: EnabledAlerts=[arg2],
AllowedFilters=[arg3] .
Informational
FQXSPEM4009I The UEFI Definitions have been changed. Informational
FQXSPEM4010I UEFI Reported: [arg1]. Informational
FQXSPEM4011I XCC failed to log previous event [arg1]. Informational
FQXSPEM4012I User [arg1] made system [arg2] Encapsulation lite Mode. Informational
FQXSPEM4014I The RAID controller has problem with the battery. Please contact
technical support to resolve this issue.([arg1],[arg2],[arg3],[arg4],
[arg5])
Informational
FQXSPEM4015I The RAID controller detected unrecoverable error. The controller
needs replacement.([arg1],[arg2],[arg3],[arg4],[arg5])
Informational
Chapter 2.XClarity Controller events 7

Table 2. Events organ zed by sever ty (cont nued)
Event ID Message String Severity
FQXSPEM4016I The RAID controller detected one or more problems. Please contact
technical support for additional assistance.([arg1],[arg2],[arg3],[arg4],
[arg5])
Informational
FQXSPEM4017I The RAID controller detected one or more possible configuration
changes within the subsystem. Please check the drive LED status. If
necessary, contact technical support for additional assistance.([arg1],
[arg2],[arg3],[arg4],[arg5])
Informational
FQXSPEM4018I Enclosure/Chassis issue detected with one or more units. Please
check the enclosure/chassis units to repair the problem.([arg1],[arg2],
[arg3],[arg4],[arg5])
Informational
FQXSPEM4019I Connectivity issue detected with the enclosure/chassis. Please check
your cable configurations to repair the problem.([arg1],[arg2],[arg3],
[arg4],[arg5])
Informational
FQXSPEM4020I Fan problem detected with the enclosure/chassis. Please check the
enclosure/chassis unit fan for correct operation.([arg1],[arg2],[arg3],
[arg4],[arg5])
Informational
FQXSPEM4022I Enclosure/Chassis power supply has problem. Please check the
enclosure/chassis unit power supply for correct operation.([arg1],
[arg2],[arg3],[arg4],[arg5])
Informational
FQXSPEM4023I One or more virtual drive are in abnormal status that may cause
unavailable virtual drive. Please check the event logs and if events are
targeted to the same disk then replace the drive. If necessary, contact
technical support for additional assistance.([arg1],[arg2],[arg3],[arg4],
[arg5])
Informational
FQXSPEM4024I The RAID controller detected one or more possible configuration
problem within the subsystem. Please check the event logs and if
events are targeted to the same disk then replace the drive. If
necessary, contact technical support for additional assistance.([arg1],
[arg2],[arg3],[arg4],[arg5])
Informational
FQXSPEM4025I One or more virtual drive have problem. Please contact technical
support to resolve this issue.([arg1],[arg2],[arg3],[arg4],[arg5])
Informational
FQXSPEM4026I Drive error was detected by RAID controller. Please contact technical
support to resolve this issue.([arg1],[arg2],[arg3],[arg4],[arg5])
Informational
FQXSPEM4027I Drive error was detected by RAID controller. Please check the event
logs and if events are targeted to the same disk then replace the drive.
If necessary, contact technical support for additional assistance.
([arg1],[arg2],[arg3],[arg4],[arg5])
Informational
FQXSPEM4028I The port [arg1] of PCIe device [arg2] at [arg3] has link [arg4]. Informational
FQXSPEM4029I All PCIe slots on [arg1] may not be functional based upon your current
CPU population.
Informational
FQXSPEM4030I A scheduled operation on the RAID controller has encountered an
issue. Refer to RAID Logs under Server Management, Local Storage,
for details.([arg1],[arg2],[arg3],[arg4],[arg5])
Informational
FQXSPFC4000I The bare metal connection process has been started. Informational
FQXSPFC4001I The bare metal update application reports a status of [arg1]. Informational
FQXSPFC4002I System running in setup. Informational
8ThinkSystem SR860 V2 Messages and Codes Reference

Table 2. Events organ zed by sever ty (cont nued)
Event ID Message String Severity
FQXSPFC4003I UEFI deployment boot mode is enabled for Next oot. Informational
FQXSPFC4004I UEFI deployment boot mode is enabled for NextAc. Informational
FQXSPFC4005I UEFI deployment boot mode has been disabled. Informational
FQXSPFW0003I The System [ComputerSystemElementName] encountered firmware
progress.
Informational
FQXSPFW0004I UEFI advanced memory test is running. Informational
FQXSPFW0005I UEFI advanced memory test is completed. Informational
FQXSPFW2001I The System [ComputerSystemElementName] has detected a POST
Error deassertion.
Informational
FQXSPIO0000I The connector [PhysicalConnectorElementName] has been
connected.
Informational
FQXSPIO0010I A Correctable us Error has occurred on bus [SensorElementName]. Informational
FQXSPIO2001I The connector [PhysicalConnectorElementName] configuration error
has been repaired.
Informational
FQXSPIO2002I The System [ComputerSystemElementName] has detected a POST
Error deassertion.
Informational
FQXSPIO2003I System [ComputerSystemElementName] has recovered from a
diagnostic interrupt.
Informational
FQXSPIO2004I us [SensorElementName] has recovered from a bus timeout. Informational
FQXSPIO2006I System [ComputerSystemElementName] has recovered from an NMI. Informational
FQXSPIO2007I A PCI PERR recovery has occurred on system
[ComputerSystemElementName].
Informational
FQXSPIO2008I A PCI SERR on system [ComputerSystemElementName] has
deasserted.
Informational
FQXSPIO2010I us [SensorElementName] has recovered from a Correctable us
Error.
Informational
FQXSPIO2014I us [SensorElementName] is no longer operating in a degraded state. Informational
FQXSPMA2005I The System [ComputerSystemElementName] has detected a POST
Error deassertion.
Informational
FQXSPMA2007I Scrub Failure for [PhysicalMemoryElementName] on Subsystem
[MemoryElementName] has recovered.
Informational
FQXSPMA2010I [PhysicalMemoryElementName] on Subsystem
[MemoryElementName] is no longer Throttled.
Informational
FQXSPMA2012I An Over-Temperature Condition has been removed on the
[PhysicalMemoryElementName] on Subsystem
[MemoryElementName].
Informational
FQXSPMA2013I The System [ComputerSystemElementName] has detected a POST
Error deassertion.
Informational
FQXSPMA2024I Sensor [SensorElementName] has deasserted. Informational
FQXSPNM4000I Management Controller [arg1] Network Initialization Complete. Informational
Chapter 2.XClarity Controller events 9

Table 2. Events organ zed by sever ty (cont nued)
Event ID Message String Severity
FQXSPNM4001I Ethernet Data Rate modified from [arg1] to [arg2] by user [arg3]. Informational
FQXSPNM4002I Ethernet Duplex setting modified from [arg1] to [arg2] by user [arg3]. Informational
FQXSPNM4003I Ethernet MTU setting modified from [arg1] to [arg2] by user [arg3]. Informational
FQXSPNM4004I Ethernet locally administered MAC address modified from [arg1] to
[arg2] by user [arg3].
Informational
FQXSPNM4005I Ethernet interface [arg1] by user [arg2]. Informational
FQXSPNM4006I Hostname set to [arg1] by user [arg2]. Informational
FQXSPNM4007I IP address of network interface modified from [arg1] to [arg2] by user
[arg3].
Informational
FQXSPNM4008I IP subnet mask of network interface modified from [arg1] to [arg2] by
user [arg3].
Informational
FQXSPNM4009I IP address of default gateway modified from [arg1] to [arg2] by user
[arg3].
Informational
FQXSPNM4011I ENET[[arg1]] DHCP-HSTN=[arg2], DN=[arg3], IP@=[arg4], SN=[arg5],
GW@=[arg6], DNS1@=[arg7] .
Informational
FQXSPNM4012I ENET[[arg1]] IP-Cfg:HstName=[arg2], IP@=[arg3] ,NetMsk=[arg4],
GW@=[arg5] .
Informational
FQXSPNM4013I LAN: Ethernet[[arg1]] interface is no longer active. Informational
FQXSPNM4014I LAN: Ethernet[[arg1]] interface is now active. Informational
FQXSPNM4015I DHCP setting changed to [arg1] by user [arg2]. Informational
FQXSPNM4016I Domain name set to [arg1] by user [arg2]. Informational
FQXSPNM4017I Domain Source changed to [arg1] by user [arg2]. Informational
FQXSPNM4018I DDNS setting changed to [arg1] by user [arg2]. Informational
FQXSPNM4019I DDNS registration successful. The domain name is [arg1]. Informational
FQXSPNM4020I IPv6 enabled by user [arg1] . Informational
FQXSPNM4021I IPv6 disabled by user [arg1] . Informational
FQXSPNM4022I IPv6 static IP configuration enabled by user [arg1]. Informational
FQXSPNM4023I IPv6 DHCP enabled by user [arg1]. Informational
FQXSPNM4024I IPv6 stateless auto-configuration enabled by user [arg1]. Informational
FQXSPNM4025I IPv6 static IP configuration disabled by user [arg1]. Informational
FQXSPNM4026I IPv6 DHCP disabled by user [arg1]. Informational
FQXSPNM4027I IPv6 stateless auto-configuration disabled by user [arg1]. Informational
FQXSPNM4028I ENET[[arg1]] IPv6-LinkLocal:HstName=[arg2], IP@=[arg3] ,Pref=[arg4]
.
Informational
FQXSPNM4029I ENET[[arg1]] IPv6-Static:HstName=[arg2], IP@=[arg3] ,Pref=[arg4],
GW@=[arg5] .
Informational
FQXSPNM4030I ENET[[arg1]] DHCPv6-HSTN=[arg2], DN=[arg3], IP@=[arg4], Pref=
[arg5], DNS1@=[arg5].
Informational
10 ThinkSystem SR860 V2 Messages and Codes Reference

Table 2. Events organ zed by sever ty (cont nued)
Event ID Message String Severity
FQXSPNM4031I IPv6 static address of network interface modified from [arg1] to [arg2]
by user [arg3].
Informational
FQXSPNM4033I Telnet port number changed from [arg1] to [arg2] by user [arg3]. Informational
FQXSPNM4034I SSH port number changed from [arg1] to [arg2] by user [arg3]. Informational
FQXSPNM4035I Web-HTTP port number changed from [arg1] to [arg2] by user [arg3]. Informational
FQXSPNM4036I Web-HTTPS port number changed from [arg1] to [arg2] by user [arg3]. Informational
FQXSPNM4037I CIM/XML HTTP port number changed from [arg1] to [arg2] by user
[arg3].
Informational
FQXSPNM4038I CIM/XML HTTPS port number changed from [arg1] to [arg2] by user
[arg3].
Informational
FQXSPNM4039I SNMP Agent port number changed from [arg1] to [arg2] by user
[arg3].
Informational
FQXSPNM4040I SNMP Traps port number changed from [arg1] to [arg2] by user [arg3]. Informational
FQXSPNM4041I Syslog port number changed from [arg1] to [arg2] by user [arg3]. Informational
FQXSPNM4042I Remote Presence port number changed from [arg1] to [arg2] by user
[arg3].
Informational
FQXSPNM4043I SMTP Server set by user [arg1] to [arg2]:[arg3]. Informational
FQXSPNM4044I Telnet [arg1] by user [arg2]. Informational
FQXSPNM4045I DNS servers set by user [arg1]: UseAdditionalServers=[arg2],
PreferredDNStype=[arg3], IPv4Server1=[arg4], IPv4Server2=[arg5],
IPv4Server3=[arg6], IPv6Server1=[arg7], IPv6Server2=[arg8],
IPv6Server3=[arg9].
Informational
FQXSPNM4046I LAN over US [arg1] by user [arg2]. Informational
FQXSPNM4047I LAN over US Port Forwarding set by user [arg1]: ExternalPort=
[arg2], US -LAN port=[arg3].
Informational
FQXSPNM4048I PXE boot requested by user [arg1]. Informational
FQXSPNM4049I User [arg1] has initiated a TKLM Server Connection Test to check
connectivity to server [arg2].
Informational
FQXSPNM4050I User [arg1] has initiated an SMTP Server Connection Test. Informational
FQXSPNM4051I User [arg1] has set the SMTP Server reverse-path to [arg2]. Informational
FQXSPNM4052I DHCP specified hostname is set to [arg1] by user [arg2]. Informational
FQXSPNM4053I DNS discovery of Lenovo XClarity Administrator has been [arg1] by
user [arg2].
Informational
FQXSPNM4054I The hostname from DHCP is [arg1] by user [arg2]. Informational
FQXSPNM4055I The hostname from DHCP is invalid. Informational
FQXSPNM4056I The NTP server address [arg1] is invalid. Informational
FQXSPNM4057I Security: IP address: [arg1] had [arg2] login failures, it will be blocked
to access for [arg3] minutes.
Informational
Chapter 2.XClarity Controller events 11

Table 2. Events organ zed by sever ty (cont nued)
Event ID Message String Severity
FQXSPOS4000I OS Watchdog response [arg1] by [arg2] . Informational
FQXSPOS4001I Watchdog [arg1] Screen Capture Occurred . Informational
FQXSPOS4004I Operating System status has changed to [arg1]. Informational
FQXSPOS4005I Host Power-On password changed. Informational
FQXSPOS4006I Host Power-On password cleared. Informational
FQXSPOS4007I Host Admin password changed. Informational
FQXSPOS4008I Host Admin password cleared. Informational
FQXSPOS4009I OS Crash Video Captured. Informational
FQXSPPP4000I Attempting to [arg1] server [arg2] by user [arg3]. Informational
FQXSPPP4001I Server Power Off Delay set to [arg1] by user [arg2]. Informational
FQXSPPP4002I Server [arg1] scheduled for [arg2] at [arg3] by user [arg4]. Informational
FQXSPPP4003I Server [arg1] scheduled for every [arg2] at [arg3] by user [arg4]. Informational
FQXSPPP4004I Server [arg1] [arg2] cleared by user [arg3]. Informational
FQXSPPP4005I The power cap value changed from [arg1] watts to [arg2] watts by
user [arg3].
Informational
FQXSPPP4006I The minimum power cap value changed from [arg1] watts to [arg2]
watts.
Informational
FQXSPPP4007I The maximum power cap value changed from [arg1] watts to [arg2]
watts.
Informational
FQXSPPP4008I The soft minimum power cap value changed from [arg1] watts to
[arg2] watts.
Informational
FQXSPPP4011I Power capping was activated by user [arg1]. Informational
FQXSPPP4012I Power capping was deactivated by user [arg1]. Informational
FQXSPPP4013I Static Power Savings mode has been turned on by user [arg1]. Informational
FQXSPPP4014I Static Power Savings mode has been turned off by user [arg1]. Informational
FQXSPPP4015I Dynamic Power Savings mode has been turned on by user [arg1]. Informational
FQXSPPP4016I Dynamic Power Savings mode has been turned off by user [arg1]. Informational
FQXSPPP4017I Power cap and external throttling occurred. Informational
FQXSPPP4018I External throttling occurred . Informational
FQXSPPP4019I Power cap throttling occurred. Informational
FQXSPPP4020I The measured power value has returned below the power cap value. Informational
FQXSPPP4021I The new minimum power cap value has returned below the power cap
value.
Informational
FQXSPPP4022I The server was restarted for an unknown reason. Informational
FQXSPPP4023I The server is restarted by chassis control command. Informational
FQXSPPP4024I The server was reset via push button. Informational
12 ThinkSystem SR860 V2 Messages and Codes Reference

Table 2. Events organ zed by sever ty (cont nued)
Event ID Message String Severity
FQXSPPP4025I The server was powered-up via power push button. Informational
FQXSPPP4026I The server was restarted when the watchdog expired.. Informational
FQXSPPP4027I The server was restarted for OEM reason. Informational
FQXSPPP4028I The server was automatically powered on because the power restore
policy is set to always restore..
Informational
FQXSPPP4029I The server was automatically powered on because the power restore
policy is set to restore previous power state..
Informational
FQXSPPP4030I The server was reset via Platform Event Filter. Informational
FQXSPPP4031I The server was power-cycled via Platform Event Filter. Informational
FQXSPPP4032I The server was soft reset. Informational
FQXSPPP4033I The server was powered up via Real Time Clock (scheduled power
on).
Informational
FQXSPPP4034I The server was powered off for an unknown reason. Informational
FQXSPPP4035I The server was powered off by chassis control command. Informational
FQXSPPP4036I The server was powered off via push button. Informational
FQXSPPP4037I The server was powered off when the watchdog expired. Informational
FQXSPPP4038I The server stayed powered off because the power restore policy is set
to always restore..
Informational
FQXSPPP4039I The server stayed powered off because the power restore policy is set
to restore previous power state..
Informational
FQXSPPP4040I The server was powered off via Platform Event Filter. Informational
FQXSPPP4041I The server was powered off via Real Time Clock (scheduled power
off).
Informational
FQXSPPP4042I Management Controller [arg1] reset was initiated due to Power-On-
Reset.
Informational
FQXSPPP4043I Management Controller [arg1] reset was initiated by PRESET. Informational
FQXSPPP4044I Management Controller [arg1] reset was initiated by CMM. Informational
FQXSPPP4045I Management Controller [arg1] reset was initiated by XCC firmware. Informational
FQXSPPP4046I Remote power permission is [arg1]. Informational
FQXSPPP4047I Management Controller [arg1] reset was initiated by user [arg2]. Informational
FQXSPPP4048I Attempting to AC power cycle server [arg1] by user [arg2]. Informational
FQXSPPP4049I Management Controller [arg1] reset was initiated by Front Panel. Informational
FQXSPPP4050I Management Controller [arg1] reset was initiated to activate PFR
Firmware.
Informational
FQXSPPR0001I [ManagedElementName] detected as absent. Informational
FQXSPPR2000I [ManagedElementName] detected as present. Informational
FQXSPPU0000I [ProcessorElementName] in slot [SlotElementName] has been added. Informational
Chapter 2.XClarity Controller events 13

Table 2. Events organ zed by sever ty (cont nued)
Event ID Message String Severity
FQXSPPU2000I [ProcessorElementName] in slot [SlotElementName] has been
removed.
Informational
FQXSPPU2001I An Over-Temperature Condition has been removed on
[ProcessorElementName].
Informational
FQXSPPU2002I The Processor [ProcessorElementName] is no longer operating in a
Degraded State.
Informational
FQXSPPU2007I The System [ComputerSystemElementName] has detected a POST
Error deassertion.
Informational
FQXSPPW0001I [PowerSupplyElementName] has been added to container
[PhysicalPackageElementName].
Informational
FQXSPPW0005I [PowerSupplyElementName] is operating in an Input State that is out
of range.
Informational
FQXSPPW0008I [SensorElementName] has been turned off. Informational
FQXSPPW0009I [PowerSupplyElementName] has been Power Cycled. Informational
FQXSPPW2001I [PowerSupplyElementName] has been removed from container
[PhysicalPackageElementName].
Informational
FQXSPPW2002I [PowerSupplyElementName] has returned to OK status. Informational
FQXSPPW2003I Failure no longer predicted on [PowerSupplyElementName]. Informational
FQXSPPW2005I [PowerSupplyElementName] has returned to a Normal Input State. Informational
FQXSPPW2006I [PowerSupplyElementName] has returned to a Normal Input State. Informational
FQXSPPW2007I [PowerSupplyElementName] Configuration is OK. Informational
FQXSPPW2008I [PowerSupplyElementName] has been turned on. Informational
FQXSPPW2031I Numeric sensor [NumericSensorElementName] going low (lower non-
critical) has deasserted.
Informational
FQXSPPW2035I Numeric sensor [NumericSensorElementName] going low (lower
critical) has deasserted.
Informational
FQXSPPW2047I Numeric sensor [NumericSensorElementName] going high (upper
critical) has deasserted.
Informational
FQXSPPW2057I Sensor [SensorElementName] has deasserted the transition from
normal to non-critical state.
Informational
FQXSPPW2061I Sensor [SensorElementName] has transitioned to a less severe state
from critical.
Informational
FQXSPPW2063I Sensor [SensorElementName] has transitioned to a less severe state
from critical.
Informational
FQXSPPW2101I Redundancy Degraded for [RedundancySetElementName] has
deasserted.
Informational
FQXSPPW2104I Non-redundant:Sufficient Resources from Redundancy Degraded or
Fully Redundant for [RedundancySetElementName] has deasserted.
Informational
FQXSPPW2110I Non-redundant:Insufficient Resources for
[RedundancySetElementName] has deasserted.
Informational
FQXSPPW4001I PCIe Power rake for [arg1] has been [arg2]. Informational
14 ThinkSystem SR860 V2 Messages and Codes Reference

Table 2. Events organ zed by sever ty (cont nued)
Event ID Message String Severity
FQXSPS 2000I The System [ComputerSystemElementName] has detected a POST
Error deassertion.
Informational
FQXSPSD0000I The [StorageVolumeElementName] has been added. Informational
FQXSPSD0001I The [StorageVolumeElementName] Drive [arg1] in the enclosure/
chassis(MTM-SN: [arg2]) has been added.
Informational
FQXSPSD0003I Hot Spare enabled for [ComputerSystemElementName]. Informational
FQXSPSD0005I Hot Spare enabled for drive [arg1] in the enclosure/chassis (MTM-SN:
[arg2]).
Informational
FQXSPSD0007I Rebuild in progress for Array in system
[ComputerSystemElementName].
Informational
FQXSPSD0008I Array rebuild in progress on drive [arg1] in the enclosure/chassis
(MTM-S/N: [arg2]).
Informational
FQXSPSD2000I The [StorageVolumeElementName] has been removed from unit
[PhysicalPackageElementName].
Informational
FQXSPSD2001I The [StorageVolumeElementName] has been enabled. Informational
FQXSPSD2002I Failure no longer Predicted on [StorageVolumeElementName] for
array [ComputerSystemElementName].
Informational
FQXSPSD2003I Hot spare disabled for [ComputerSystemElementName]. Informational
FQXSPSD2005I Critical Array [ComputerSystemElementName] has deasserted. Informational
FQXSPSD2006I Array in system [ComputerSystemElementName] has been restored. Informational
FQXSPSD2007I Rebuild completed for Array in system
[ComputerSystemElementName].
Informational
FQXSPSD2008I Drive [arg1] in the enclosure/chassis(MTM-SN: [arg2]) has been
enabled.
Informational
FQXSPSD2010I Drive [arg1] in the enclosure/chassis(MTM-SN: [arg2]) has been
removed.
Informational
FQXSPSD2011I Failure no longer Predicted on drive [arg1] in the enclosure/chassis
(MTM-S/N: [arg2]).
Informational
FQXSPSD2012I Hot Spare disabled for drive [arg1] in the enclosure/chassis (MTM-SN:
[arg2]).
Informational
FQXSPSD2013I Array critical deasserted on drive [arg1] in the enclosure/chassis
(MTM-S/N: [arg2]).
Informational
FQXSPSD2014I Array restored on drive [arg1] in the enclosure/chassis (MTM-S/N:
[arg2]).
Informational
FQXSPSD2015I Array rebuild completed on drive [arg1] in the enclosure/chassis
(MTM-S/N: [arg2]).
Informational
FQXSPSE2000I The Chassis [PhysicalPackageElementName] was closed. Informational
FQXSPSE4001I Remote Login Successful. Login ID: [arg1] using [arg2] from [arg3] at
IP address [arg4].
Informational
FQXSPSE4002I Security: Userid: [arg1] using [arg2] had [arg3] login failures from WE
client at IP address [arg4].
Informational
Chapter 2.XClarity Controller events 15

Table 2. Events organ zed by sever ty (cont nued)
Event ID Message String Severity
FQXSPSE4003I Security: Login ID: [arg1] had [arg2] login failures from CLI at [arg3]. Informational
FQXSPSE4004I Remote access attempt failed. Invalid userid or password received.
Userid is [arg1] from WE browser at IP address [arg2].
Informational
FQXSPSE4005I Remote access attempt failed. Invalid userid or password received.
Userid is [arg1] from TELNET client at IP address [arg2].
Informational
FQXSPSE4007I Security: Userid: [arg1] using [arg2] had [arg3] login failures from an
SSH client at IP address [arg4].
Informational
FQXSPSE4008I SNMPv1 [arg1] set by user [arg2]: Name=[arg3], AccessType=[arg4],
Address=[arg5], .
Informational
FQXSPSE4009I LDAP Server configuration set by user [arg1]: SelectionMethod=
[arg2], DomainName=[arg3], Server1=[arg4], Server2=[arg5], Server3=
[arg6], Server4=[arg7].
Informational
FQXSPSE4010I LDAP set by user [arg1]: RootDN=[arg2], UIDSearchAttribute=[arg3],
indingMethod=[arg4], EnhancedR S=[arg5], TargetName=[arg6],
GroupFilter=[arg7], GroupAttribute=[arg8], LoginAttribute=[arg9].
Informational
FQXSPSE4011I Secure Web services (HTTPS) [arg1] by user [arg2]. Informational
FQXSPSE4012I Secure CIM/XML(HTTPS) [arg1] by user [arg2]. Informational
FQXSPSE4013I Secure LDAP [arg1] by user [arg2]. Informational
FQXSPSE4014I SSH [arg1] by user [arg2]. Informational
FQXSPSE4015I Global Login General Settings set by user [arg1]:
AuthenticationMethod=[arg2], LockoutPeriod=[arg3],
SessionTimeout=[arg4].
Informational
FQXSPSE4016I Global Login Account Security set by user [arg1]: PasswordRequired=
[arg2], PasswordExpirationPeriod=[arg3],
MinimumPasswordReuseCycle=[arg4], MinimumPasswordLength=
[arg5], MinimumPasswordChangeInterval=[arg6],
MaxmumLoginFailures=[arg7], LockoutAfterMaxFailures=[arg8].
Informational
FQXSPSE4017I User [arg1] created. Informational
FQXSPSE4018I User [arg1] removed. Informational
FQXSPSE4019I User [arg1] password modified. Informational
FQXSPSE4020I User [arg1] role set to [arg2]. Informational
FQXSPSE4021I User [arg1] custom privileges set: [arg2][arg3][arg4][arg5][arg6][arg7]
[arg8].
Informational
FQXSPSE4022I User [arg1] for SNMPv3 set: AuthenticationProtocol=[arg2],
PrivacyProtocol=[arg3], AccessType=[arg4], HostforTraps=[arg5].
Informational
FQXSPSE4023I SSH Client key added for user [arg1]. Informational
FQXSPSE4024I SSH Client key imported for user [arg1] from [arg2]. Informational
FQXSPSE4025I SSH Client key removed from user [arg1]. Informational
FQXSPSE4026I Security: Userid: [arg1] had [arg2] login failures from a CIM client at IP
address [arg3].
Informational
16 ThinkSystem SR860 V2 Messages and Codes Reference
