Leuze electronic AMS 348i SSI User manual

AMS 348i SSI
Optical Laser Measurement System – PROFINET / SSI
de 03-2017/07 50125898 We reserve the right to make technical changes
Original operating instructions

Leuze electronic AMS 348iSSI
© 2017
Leuze electronic GmbH + Co. KG
In der Braike 1
D-73277 Owen / Germany
Phone: [phone]
Fax: [phone]
http://www.leuze.com
[email protected]m

AMS 348iSSI
Die Hauptmenüs AMS 348i 120 SSI
Leuze electronic
GmbH & Co. KG
SW: V 1.3.0 HW:1
SN: -----------------------
Hauptmenü Geräteinformation
In diesem Menüpunkt erhalten Sie detaillierte Infor-
mationen über
•Gerätetyp,
• Hersteller,
• Softwareversion und Hardwarestand,
• Seriennummer.
Es sind keine Eingaben über das Display möglich.
Netzwerk Information
Address: ---.---.---.---
Netmask: ---.---.---.---
Gateway: ---.---.---.---
MAC ID: --.--.--.--.--.--
DevName: ------------------------
Hauptmenü Netzwerk Information
Unter diesem Menüpunkt finden Sie detaillierte Infor-
mationen zu den Netzwerkadressen.
Es sind keine Eingaben über das Display möglich.
IO1 LSR PLB LNK0
IO2 TMP ATT LNK1
ERR SSI
+ 87,000m
Hauptmenü Status- und Messdaten
• Anzeige von Status-, Warn- und Fehlermel-
dungen.
• Zustandsübersicht der Schaltein-/ausgänge.
• Bargraph für den Empfangspegel.
• Aktivierte Schnittstelle.
• Messwert.
Es sind keine Eingaben über das Display möglich.
Siehe "Anzeigen im Display" auf Seite 41.
Parameter
Parameterverwaltung
PROFINET
SSI
Positionswert
I/O
Hauptmenü Parameter
Die Parametrierung für PROFI NET erfolgt über die
Module der GSDML-Datei.
Werte-Eingabe
100
<-|0123456789 save
Standard ----- Maßeinheit
126 | |
Sprachauswahl
o Deutsch
English
o Español
o Français
o Italiano
Hauptmenü Sprachauswahl
• Auswahl der Display-Sprache.
Siehe "Sprachauswahlmenü" auf Seite 52.
Service
Zustandsmeldungen
Diagnose
Erweiterte Diagnose
Hauptmenü Service
• Anzeige von Statusmeldungen.
• Anzeige von Diagnosedaten.
Es sind keine Eingaben über das Display möglich.
Siehe "Servicemenü" auf Seite 52.
Stelle löschen
Ziffer eingeben
Eingabe speichern
ESC
aufwärts/seitwärts
blättern
abwärts/seitwärts
blättern
ESCAPE
Verlassen
ENTER
Bestätigen
Geräte-Tasten:

Table of contents
AMS 348iSSI 1
1 General information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.1 Explanation of symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.2 Declaration of conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.3 Description of functions AMS 348iSSI. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2 Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.1 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.2 Foreseeable misuse. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2.3 Competent persons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2.4 Disclaimer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.5 Laser safety notices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3 Fast commissioning / operating principle . . . . . . . . . . . . . . . . . . . 12
3.1 Mounting the AMS 348iSSI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
3.1.1 Mounting the device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
3.1.2 Reflector mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
3.2 Connecting the voltage supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
3.3 Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
3.4 AMS 348iSSI on the PROFINET . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
4 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
4.1 Specifications of the laser measurement system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
4.1.1 General specifications AMS 348iSSI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
4.1.2 Dimensioned drawing AMS 348iSSI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
4.1.3 Type overview AMS 348iSSI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
5 Installation and mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
5.1 Storage, transportation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
5.2 Mounting the AMS 348iSSI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
5.2.1 Optional mounting bracket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
5.2.2 Parallel mounting of the AMS 348iSSI. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
5.2.3 Parallel mounting of AMS 348iSSI and DDLS optical data transmission . . . . . . . . . . . . 23
5.3 Mounting the AMS 348iSSI with laser beam deflector unit . . . . . . . . . . . . . . . . . . . . . 24
5.3.1 Mounting the laser beam deflector unit With integrated mounting bracket . . . . . . . . . . . 24
5.3.2 Dimensioned drawing of US AMS 01 deflector unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
5.3.3 Mounting the US 1 OMS deflector unit without mounting bracket . . . . . . . . . . . . . . . . . 26

Table of contents
2AMS348iSSI
6 Reflectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
6.1 General information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
6.2 Description of the reflective tape. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
6.2.1 Specifications of the self-adhesive foil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
6.2.2 Specifications of the reflective tape on a support plate . . . . . . . . . . . . . . . . . . . . . . . . . . 28
6.2.3 Dimensioned drawing of reflective tape on a metal plate . . . . . . . . . . . . . . . . . . . . . . . . . 29
6.2.4 Specifications of heated reflectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
6.2.5 Dimensioned drawing of heated reflectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
6.3 Selecting reflector sizes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
6.4 Mounting the reflector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
6.4.1 General information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
6.4.2 Mounting the reflector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
6.4.3 Table of reflector pitches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
7 Electrical connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
7.1 Safety notices for the electrical connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
7.2 PWR – voltage supply / switching input/output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
7.3 PROFINET BUS IN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
7.4 PROFINET BUS OUT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
7.5 SSI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
7.6 Service. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
8 Display and control panel AMS 348iSSI . . . . . . . . . . . . . . . . . . . . 41
8.1 Structure of the control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
8.2 Status display and operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
8.2.1 Indicators in the display. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
8.2.2 LED status displays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
8.2.3 Control buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
8.3 Menu description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46
8.3.1 The main menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
8.3.2 Parameter menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
8.3.3 Language selection menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
8.3.4 Service menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
8.4 Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
9 PROFINET interface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
9.1 General information on PROFINET . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Table of contents
AMS 348iSSI 3
9.2 Identification & Maintenance Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
9.3 PROFINET – Star topology . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
9.4 PROFINET – Linear topology. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
9.5 PROFINET – General information on wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
9.6 PROFINET – Cable lengths and shielding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
9.7 PROFINET - Electrical connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
9.8 PROFINET – Commissioning and configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
9.8.1 PROFINET implementation of the AMS 348i. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
9.8.2 Measures to be performed prior to the initial commissioning . . . . . . . . . . . . . . . . . . . . . 60
9.8.3 Starting the device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
9.8.4 Configuration steps for a Siemens Simatic S7 control . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
9.9 PROFINET GSD file . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
9.9.1 General information on the GSD file . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
9.9.2 Overview of the GSD modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
9.9.3 Detail description of the modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
10 SSI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
10.1 Principle functionality of the SSI interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
10.1.1 SSI sequence diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
10.1.2 Cable length as a function of the data rate. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104
10.2 SSI - Electrical connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104
10.3 General Information to the AMS 348iSSI parameters . . . . . . . . . . . . . . . . . . . . . . . . . 105
10.4 Default settings of the SSI interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
10.4.1 Changing the SSI settings via the display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106
11 Diagnostics and troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . 107
11.1 Service and diagnostics in the display of the AMS 348iSSI . . . . . . . . . . . . . . . . . . . . 108
11.1.1 Status messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108
11.1.2 Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109
11.1.3 Expanded diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109
11.2 General causes of errors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110
11.2.1 Power LED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110
11.3 Interface errors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111
11.3.1 BUS LED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111
11.4 Status display in the display of the AMS 348iSSI . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111

Table of contents
4AMS348iSSI
12 Type overview and accessories . . . . . . . . . . . . . . . . . . . . . . . . . . 113
12.1 Type key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113
12.2 Type overview AMS 348iSSI (PROFINET + SSI). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113
12.3 Overview of reflector types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114
12.4 Accessories. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114
12.4.1 Accessory mounting bracket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114
12.4.2 Accessory deflector unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114
12.4.3 Accessory M12 connector. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114
12.4.4 Accessory ready-made cables for voltage supply. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115
12.4.5 Accessory ready-made cables for PROFINET. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116
12.4.6 Accessory ready-made cables for SSI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 118
13 Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120
13.1 General maintenance information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120
13.2 Repairs, servicing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120
13.3 Disassembling, packing, disposing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120

General information
Leuze electronic AMS 348iSSI 5
TNT 35/7-24V
1 General information
1.1 Explanation of symbols
The symbols used in this operating manual are explained below.
Attention!
This symbol precedes text messages which must strictly be observed. Failure to comply with
this information results in injuries to personnel or damage to the equipment.
Attention Laser!
This symbol warns of possible danger caused by hazardous laser radiation.
Notice!
This symbol indicates text passages containing important information.
1.2 Declaration of conformity
The AMS 348iSSI absolute measuring optical laser measurement system was designed and
manufactured in accordance with applicable European directives and standards.
The AMS series is "UL LISTED" according to American and Canadian safety standards and
fulfills the requirements of Underwriter Laboratories Inc. (UL).
Notice!
The Declaration of Conformity for these devices can be requested from the manufacturer.
The manufacturer of the product, Leuze electronic GmbH + Co. KG in D-73277 Owen,
possesses a certified quality assurance system in accordance with ISO 9001.

General information
6 AMS 348iSSI Leuze electronic
1.3 Description of functions AMS 348iSSI
The AMS 348iSSI optical laser measurement system calculates distances to fixed as well
as moving system parts. The distance to be measured is calculated according to the prin-
ciple of the propagation time of radiated light. Here, the light emitted by the laser diode is
reflected by a reflector onto the receiving element of the laser measurement system. The
AMS 348iSSI uses the "propagation time" of the light to calculate the distance to the
reflector. The high absolute measurement accuracy of the laser measurement system and
the fast response time are designed for position control applications.
With the AMS 3xxiproduct series, Leuze electronic makes available a range of internation-
ally relevant interfaces. Note that each interface version listed below corresponds to a
different AMS 3xximodel.
AMS 304i
AMS 348i
AMS 348iwith SSI
AMS 355i
AMS 358i
AMS 335i
AMS 338i
AMS 308i
AMS 384i
AMS 301i
AMS 300i

Safety
Leuze electronic AMS 348iSSI 7
TNT 35/7-24V
2 Safety
This sensor was developed, manufactured and tested in line with the applicable safety stan-
dards. It corresponds to the state of the art.
2.1 Intended use
The AMS is an absolute measuring optical laser measurement system which allows
distance measurement of up to 300m against a reflector.
Areas of application
The AMS is designed for the following areas of application:
• Positioning of automated, moving plant components
• Travel and lifting axes of high-bay storage devices
• Repositioning units
• Gantry crane bridges and their trolleys
•Lifts
• Electroplating plants
Attention
For UL applications, use is permitted exclusively in Class 2 circuits according to NEC
(National Electric Code).
CAUTION
Observe intended use!
Only operate the device in accordance with its intended use. The protection of per-
sonnel and the device cannot be guaranteed if the device is operated in a manner not
complying with its intended use.
Leuze electronic GmbH + Co. KG is not liable for damages caused by improper use.
Read the technical description before commissioning the device. Knowledge of this
technical description is an element of proper use.
NOTICE
Comply with conditions and regulations!
Observe the locally applicable legal regulations and the rules of the employer's liability
insurance association.

Safety
8 AMS 348iSSI Leuze electronic
2.2 Foreseeable misuse
Any use other than that defined under "Intended use" or which goes beyond that use is
considered improper use.
In particular, use of the device is not permitted in the following cases:
• Rooms with explosive atmospheres
• As stand-alone safety component in accordance with the machinery directive 1)
• For medicinal purposes
2.3 Competent persons
Connection, mounting, commissioning and adjustment of the device must only be carried
out by competent persons.
Prerequisites for competent persons:
• They have a suitable technical education.
• They are familiar with the rules and regulations for occupational safety and safety at
work.
• They are familiar with the technical description of the device.
• They have been instructed by the responsible person on the mounting and operation
of the device.
Certified electricians
Electrical work must be carried out by a certified electrician.
Due to their technical training, knowledge and experience as well as their familiarity with
relevant standards and regulations, certified electricians are able to perform work on elec-
trical systems and independently detect possible dangers.
In Germany, certified electricians must fulfill the requirements of accident-prevention regu-
lations BGV A3 (e.g. electrician foreman). In other countries, there are respective regula-
tions that must be observed.
1) Use as safety-related component within the safety function is possible, if the component combi-
nation is designed correspondingly by the machine manufacturer.
NOTICE
Do not modify or otherwise interfere with the device.
Do not carry out modifications or otherwise interfere with the device.
The device must not be tampered with and must not be changed in any way.
The device must not be opened. There are no user-serviceable parts inside.
Repairs must only be performed by Leuze electronic GmbH + Co. KG.

Safety
Leuze electronic AMS 348iSSI 9
TNT 35/7-24V
2.4 Disclaimer
Leuze electronic GmbH + Co. KG is not liable in the following cases:
• The device is not being used properly.
• Reasonably foreseeable misuse is not taken into account.
• Mounting and electrical connection are not properly performed.
• Changes (e.g., constructional) are made to the device.
2.5 Laser safety notices
ATTENTION LASER RADIATION – LASER CLASS 2
Never look directly into the beam!
The device satisfies the requirements of IEC 60825-1:2007 (EN 60825-1:2007) safety
regulations for a product in laser class 2 as well as the U.S. 21 CFR 1040.10 regulations
with deviations corresponding to "Laser Notice No. 50" from June 24th, 2007.
Never look directly into the laser beam or in the direction of reflecting laser beams.
If you look into the beam path over a longer time period, there is a risk of injury to the
retina.
Do not point the laser beam of the device at persons!
Interrupt the laser beam using a non-transparent, non-reflective object if the laser
beam is accidentally directed towards a person.
When mounting and aligning the device, avoid reflections of the laser beam off reflec-
tive surfaces!
CAUTION! The use of operating or adjusting devices other than those specified here
or carrying out of differing procedures may lead to dangerous exposure to radiation.
Adhere to the applicable legal and local regulations regarding protection from laser
beams.
The device must not be tampered with and must not be changed in any way.
There are no user-serviceable parts inside the device.
Repairs must only be performed by Leuze electronic GmbH + Co. KG.

Safety
10 AMS 348iSSI Leuze electronic
Figure 2.1: Laser apertures, laser warning signs
NOTICE
Affix laser information and warning signs!
Laser information and warning signs are attached to the device (see figure 2.1):
In addition, self-adhesive laser warning and information signs (stick-on labels) are supplied
in several languages (see figure 2.2).
Affix the laser information sheet to the device in the language appropriate for the place
of use.
When using the device in the US, use the stick-on label with the "Complies with
21 CFR 1040.10" notice.
Affix the laser information and warning signs near the device if no signs are attached
to the device (e.g., because the device is too small) or if the attached laser information
and warning signs are concealed due to the installation position.
Affix the laser information and warning signs so that they are legible without exposing
the reader to the laser radiation of the device or other optical radiation.
ALaser aperture
BLaser warning sign
CLaser information sign with laser parameters
A B C

Safety
Leuze electronic AMS 348iSSI 11
TNT 35/7-24V
Figure 2.2: Laser warning and information signs – supplied stick-on labels
AVOID EXPOSURE – LASER RADIATION
IS EMITTED FROM THIS APERTURE
EXPOSITION DANGEREUSE – UN RAYONNEMENT
LASER EST ÉMIS PAR CETTE OUVERTURE
LASERSTRAHLUNG
NICHT IN DEN STRAHL BLICKEN
LASER KLASSE 2
DIN EN 60825-1:2008-05
Max. Leistung (peak):
Impulsdauer:
Wellenlänge:
RADIAZIONE LASER
NON FISSARE IL FASCIO
APARRECCHIO LASER DI CLASSE 2
EN 60825-1:2007
Potenza max. (peak):
Durata dell'impulso:
Lunghezza d'onda:
LASER RADIATION
DO NOT STARE INTO BEAM
CLASS 2 LASER PRODUCT
EN 60825-1:2007
Maximum Output (peak):
Pulse duration:
Wavelength:
RAYONNEMENT LASER
NE PAS REGARDER DANS LE FAISCEAU
APPAREIL À LASER DE CLASSE 2
EN 60825-1:2007
Puissance max. (crête):
Durée d`impulsion:
Longueur d`onde:
RADIACIÓN LÁSER
NO MIRAR FIJAMENTE AL HAZ
PRODUCTO LÁSER DE CLASE 2
EN 60825-1:2007
Potencia máx. (peak):
Duración del impulso:
Longitud de onda:
RADIAÇÃO LASER
NÃO OLHAR FIXAMENTE O FEIXE
EQUIPAMENTO LASER CLASSE 2
EN 60825-1:2007
Potência máx. (peak):
Período de pulso:
Comprimento de onda:
LASER RADIATION
DO NOT STARE INTO BEAM
CLASS 2 LASER PRODUCT
IEC 60825-1:2007
Complies with 21 CFR 1040.10
Maximum Output (peak):
Pulse duration:
Wavelength:
䉏⏘戟⺓
▎䦃展⏘㧮
伊䉏⏘ℶ❐
GB7247.1-2012
㦏⮶戢⒉᧤⽿⋋᧥
厘⑁㖐兼㢅梃
㽱栎
4 mW
18 μs
655 nm
4 mW
18 μs
655 nm
4 mW
18 μs
655 nm
4 mW
18
μ s
655 nm
4 mW
18 μs
655 nm
4 mW
18 μs
655 nm
4 mW
18 μs
655 nm
4 mW
18 μs
655 nm
50125612-01

Fast commissioning / operating principle
12 AMS 348iSSI Leuze electronic
3 Fast commissioning / operating principle
Notice!
Below, you will find a short description for the initial commissioning of the AMS 348iSSI.
Detailed explanations for the listed points can be found throughout the handbook.
3.1 Mounting the AMS 348iSSI
The AMS 348iand the corresponding reflector are mounted on two mutually opposing,
plane-parallel, flat walls.
Figure 3.1: Schematic illustration of mounting
Attention!
For error-free position measurement, there must be an unobstructed line-of-sight between
the AMS 348iand the reflector.
3.1.1 Mounting the device
The laser is mounted using 4 screws (M5).
Alignment is performed using 2 adjustment screws. Adjust so that the laser light spot is posi-
tioned at the center of the reflector. The alignment is to be secured with the knurled nut and
locked with the M5 nut.
Further information can be found in chapter 5.2 and chapter 5.3.
3.1.2 Reflector mounting
The reflector is mounted using 4 screws (M5). The reflector is angled using the spacer
sleeves included. Incline the reflector by approx. 1°.
Detailed information can be found in chapter 6.4.

Fast commissioning / operating principle
Leuze electronic AMS 348iSSI 13
TNT 35/7-24V
3.2 Connecting the voltage supply
The laser measurement system is connected using M12 connectors. The voltage supply is
connected via the PWR M12 connection (18 … 30VDC). 2 freely programmable switching
inputs/outputs for individual adaptation to the respective application are also available here.
Detailed information can be found in chapter 7.
3.3 Display
Once the laser measurement system is supplied with voltage, the device status as well as
the measured position values can be read on the display. The display automatically switches
to the display of the measurement values.
Use the up/down buttons to the left of the display to read and change a wide range
of data and parameters.
Detailed information can be found in chapter 8.
3.4 AMS 348iSSI on the PROFINET
Install the GSDML file associated with the AMS 348iSSI in the PROFINET Manager of your
control. Activate the desired modules (at least one module).
The network address for PROFINET is assigned via the PROFINET Manager.
Standalone operation in PROFINET
During standalone operation of the AMS 348iSSI, the PROFINET network is connected to
BUS IN. BUS OUT requires no terminating resistor.
Network operation in PROFINET
In network mode the AMS 348iSSI is connected to PROFINET via BUS IN. Further
PROFINET participants can be connected to the integrated switch of the AMS 348iSSI via
the BUS OUT connection.
Commissioning of the AMS 348iSSI
The procedures described below are for the configuration of an AMS 348iSSI with a
Siemens Simatic S7 PLC.
• Switching on the supply voltage.
The AMS 348iSSI displays the "Status and measurement data" main menu.
• Installation of the corresponding GSD file in the Simatic Hardware Manager.
• Projection of the PROFINET network including the AMS 348iSSI GSD file. Definition
of the IP addresses, sub-network mask and definition of a device name assigned to
the IP address.
• Download of the project to the connected Siemens control.
Further information regarding the individual commissioning steps is provided in see chapter
9.8.4 "Configuration steps for a Siemens Simatic S7 control".
Detailed information can be found in chapter 9.

Specifications
14 AMS 348iSSI Leuze electronic
4 Specifications
4.1 Specifications of the laser measurement system
4.1.1 General specifications AMS 348iSSI
Measurement data AMS 348i40 (H)
SSI
AMS 348i120 (H)
SSI
AMS 348i200 (H)
SSI
AMS 348i300 (H)
SSI
Measurement range 0.2 … 40m 0.2 … 120m 0.2 … 200m 0.2 … 300m
Accuracy ±2mm ±2mm ±3mm ±5mm
Consistency 1) 0.3mm 0.5mm 0.7mm 1.0mm
Light spot diameter ≤40mm ≤100mm ≤150mm ≤225mm
Output time 1.7ms
Response time 14ms
Basis for contouring error calculation 7ms
Resolution adjustable, see chapter of the individual interfaces
Temperature drift ≤0.1mm/K
Ambient temperature sensitivity 1ppm/K
Air pressure sensitivity 0.3ppm/hPa
Traverse rate ≤10m/s
Electrical data
Supply voltage Vin 2) 18 … 30VDC
Current consumption without device heating: ≤250mA / 24VDC
with device heating: ≤500mA / 24VDC
Optical data
Transmitter laser diode, red light
Laser class 2 in accordance with IEC 60825-1:2007, CDRH
Wavelength 655nm
Impulse duration ≤18μs
Max. output power (peak) ≤4mW
PROFINET interface
Interface type PROFINET-RT with integrated switch
for BUS IN and BUS OUT
Protocol PROFINET-RT communication
Conformance Class B
SSI interface
Interface type SSI interface
SSI clock rate 50kHz … 800kHz
Data format see chapter 10.4
Operating and display elements
Keyboard 4 buttons
Display monochromatic graphical display, 128 x 64 pixels
LED 4 LEDs, 2 of which are used to display the PROFINET connection

Specifications
Leuze electronic AMS 348iSSI 15
TNT 35/7-24V
The AMS 348iSSI is designed in accordance with safety class III for supply
with PELV (protective extra-low voltage).
Inputs/outputs
Quantity
Input
Output
2, programmable
protected against polarity reversal
max. 60mA, short-circuit proof
Mechanical data
Housing cast zinc and aluminum
Optics glass
Weight approx. 2.45kg
Degree of protection IP 65 acc. to EN 60529 3)
Environmental conditions
Operating temperature
without device heating
with device heating
-5°C … +50°C
-30°C … +50°C 4)
Storage temperature -30°C … +70°C
Air humidity max. 90% rel. humidity, non-condensing
Mechanical/electrical loading capacity
Vibrations acc. to EN 60068-2-6
Noise acc. to EN 60060-2-64
Shock acc. to EN 60068-2-27
EMC acc. to EN 61000-6-2 and EN 61000-6-4 5)
1) Statistical error: 1 sigma; minimum switch-on time: 2min.
2) For UL applications: only for use in "Class 2" circuits acc. to NEC.
3) With screwed-on M12 plugs or mounted caps.
4) With devices with heating, the switch on/off area of the internal heating can be extended to prevent
condensation from forming. A 100% prevention of the formation of condensation cannot be guaran-
teed due to the limited heating capacity of the AMS 348iSSI.
5) This is a Class A product. In a domestic environment this product may cause radio interference, in
which case the operator may be required to take adequate measures.

Specifications
16 AMS 348iSSI Leuze electronic
4.1.2 Dimensioned drawing AMS 348iSSI
Figure 4.1: Dimensioned drawing AMS 348iSSI
AM5 screw for alignment
BKnurled nut with WAF4
hexagon socket and M5 nut for securing
COptical axis
DZero point of the distance to be measured
A
B
D
A
C

Specifications
Leuze electronic AMS 348iSSI 17
TNT 35/7-24V
4.1.3 Type overview AMS 348iSSI
AMS 348iSSI (PROFINET + SSI)
Type designation Description Part no.
AMS 348i40 SSI 40m operating range, PROFINET/SSI interface 50127219
AMS 348i120 SSI 120m operating range, PROFINET/SSI interface 50127220
AMS 348i200 SSI 200m operating range, PROFINET/SSI interface 50127221
AMS 348i300 SSI 300m operating range, PROFINET/SSI interface 50127222
AMS 348i40 H SSI 40m operating range, PROFINET/SSI interface, integrated heating 50127223
AMS 348i120 H SSI 120m operating range, PROFINET/SSI interface, integrated heating 50127224
AMS 348i200 H SSI 200m operating range, PROFINET/SSI interface, integrated heating 50127225
AMS 348i300 H SSI 300m operating range, PROFINET/SSI interface, integrated heating 50127226
Table 4.1: Type overview AMS 348iSSI
