LevelOne HVE-9000 User manual

HDSpider™ HDMI over Single Cat.5 Distribution Series
HVE-9000
HVE-9001
HVE-9002
HVE-9003
HVE-9900
User Manual
Ver.:1.0-0808

1
TABL OF CONT NT
p.2 Package Content
p.3 Product Introduction
p.4 Panel escription
p.7 Installation
p.12 Systematic Application iagrams
p.13 Frequently Asked Questions
p.14 Specifications
p.15 Notice

2
Package Content
HV -9000 HDSpider™ HDMI Cat.5 Receiver (Long)
1. H Spider™ H MI Cat.5 Receiver (Long) (HVE-9000)
2. 5V 2A C Adapter
3. User Manual
HV -9001 HDSpider™ HDMI Cat.5 Sender
1. H Spider™ H MI Cat.5 Sender (HVE-9001)
2. 5V 2A C Adapter
3. User Manual
HV -9002 HDSpider™ HDMI Cat.5 Sender + 1 HDMI Out
1. H Spider™ H MI Cat.5 Sender + 1 H MI Out (HVE-9002)
2. 5V 4A C Adapter
3. User Manual
HV -9003 HDSpider™ HDMI Cat.5 Sender (Cascadable)
1. H Spider™ H MI Cat.5 Sender (Cascadable) (HVE-9003)
2. 5V 4A C Adapter
3. User Manual
HV -9900 HDSpider™ HDMI Cat.5 Receiver (Short)
1. H Spider™ H MI Cat.5 Receiver (Short) (HVE-9900)
2. User Manual
Introduction

3
Product Introduction
Introduction
The H Spider™ H MI over Single Cat.5 istribution Series provides the most
flexible solution by which the uncompressed, unmodified, and pure digital H MI
signals with 7.1-channel audio can be transmitted to different locations over a
long distance. The cascadability of H Spider™ series is virtually unlimited,
allowing you to extend H MI/ VI displays almost anywhere.
The whole H Spider™ series products can be easily inter-connected to suit almost every
application through Cat.5/5e/6 cables. By taking the advantage of Cat.5/5e/6 cables,
installation work becomes so easy and particularly cost effective wherever the distribution of
H MI signals is required.
Features
The H Spider™ H MI over Single Cat.5 istribution Series offers the users:
 H MI signal transmission through Cat.5/5e/6 cables
 Cat.5/5e/6 cable implementation to minimize use of high-cost H MI cable
 Minimum 40m extension for 1080p resolution*
 Maximum extension up to 80m**
 Uncompressed, unmodified H MI with 7.1-channel audio/video pure digital
transmission
 Cascading virtually unlimited for HVE-9003
 Compliant with H MI 1.2
 Build in 8-level equalizer to fine tune video quality
 E I learning ability to read and store the E I information of the display to
avoid any incompatibility among displays
 Software not required, purely hardware installation. Virus risk free
Note: The length depends on the characteristics and quality of the cables. Higher resolutions
and longer transmission distances require low skew cables (<2 ns/100m) for best
performance.
*single link of HVE-9000. For connection with HVE-9900, 1080p distance at minimum 15m.
**single link at 480p resolution, with high quality, minimal delay skew Cat-6 cable
Introduction

4
Panel Description
HV -9000 HDSpider™ HDMI Cat.5 Receiver (Long)
Front View
HDMI OUT: Connect to a H MI display with a H MI M-M cable here.
EQ: Adjust the 8-level equalization control knob to the received H MI signals. 0 - 7
= strongest – weakest. It is recommended to adjust from 7 to 0 to find the
optimal visual experience.
Rear View
RJ45-IN: Plug in a Cat. 5e/6 cable that needs to be linked to the RJ-45 connector
of the HVE-9000.
+5V DC: Connect to 5V 2A C power supply.
HDMI-OUT
EQ
RJ45-IN
+5V DC

5
HV -9001 HDSpider™ HDMI Cat.5 Sender
Front View
HDMI IN: Connect a H MI source with a H MI M-M cable here
Mode: 0 = H MI mode with 8-channel audio
1 = H MI mode with 2-channel audio
2-5 = Reserved
6 = Use default E I (indicated by the RJ-45 LE )
7 = Learn E I from the display (indicated by the RJ-45 LE )
Note
1. on’t plug in H MI cable to H MI input connector while processing writing default E I or
writing monitor E I .
2. The LE next to the rotary control knob turns off when the writing process is completed.
3. The HVE-9001 reads the E I information from the H MI socket of the connected H TV, so
please connect the display from which you want to read E I to HDMI-OUT of the HVE-9000.
Rear View
RJ45-OUT: Plug in a Cat.5e/6 cable that needs to be linked to the RJ45
connector of the HVE-9000 or HVE-9900.
+5V DC: Connect to 5V 2A C power supply.
RJ45-OUT
+5V DC
HDMI-IN
Mode

6
HV -9002 HDSpider™ HDMI Cat.5 Sender + 1 HDMI Out
1. Power indicator
2. IP switch: 1=OFF: Use default E I ;
1=ON: Learn E I from the display;
2=OFF: H MI with 8-channel audio mode;
2=ON: H MI with 2-channel audio mode
3. HDMI In: Connect a H MI source with a H MI M-M cable here
4. Audio out: Plug in a local speaker here
5. HDMI Out: Connect to a H MI display with a H MI M-M cable here
6. RJ-45 Out: Link to HVE-9003 for cascading; or link to HVE-9000 or HVE-9900 to
another H MI display with a Cat.5e/6 cable
7. +5V DC: Connect to 5V 4A C power supply
Note
1. on’t plug in H MI cable to HDMI In while processing writing default E I or writing display
E I .
2. The LE next to the rotary control knob turns off when the writing process is completed.
3. The HVE-9002 reads the E I information from the H MI socket of the connected H TV, so
please connect the display from which you want to read E I to HDMI Out.
1
2
3
4
5
6
7

7
HV -9003 HDSpider™ HDMI Cat.5 Sender (Cascadable)
1. Power indicator
2. 16-level rotary control knob: Adjust the 16-level equalization control knob
according to the transmission distance of receiving H MI signals. For
5.1/7.1-channel mode audio output, please adjust from 0 to 7
(longest-to-shortest transmission distance). For stereo mode audio output,
please adjust from 8 to F (longest-to-shortest transmission distance). It is
recommended to adjust from 7 to 0 or from F to 8 to find the optimal visual
experience.
3. RJ-45 In: Link to HVE-9001, HVE-9002, or HVE-9003 with a CAT.5e/6 cable
4. Audio out: Plug in a local speaker here
5. HDMI Out: Connect to a H MI display with a H MI M-M cable here
6. RJ-45 Out: Link to another HVE-9003 for cascading; or link to HVE-9000 or
HVE-9900 to another H MI display with a Cat.5e/6 cable
7. +5V DC: Connect to 5V 4A C power supply
HV -9900 HDSpider™ HDMI Cat.5 Receiver (Short)
RJ-45 socket: Link from HVE9001, HVE-9002, HVE-9003, or HVE-9900 with a Cat.5e/6
cable
H MI socket: Connect to a local H MI display, or the H MI output of HVE-9002 or
HVE-9003 for H MI over Cat.5 transmission
1
2
3
4
5
6
7

8
Installation
Extends HDMI signals to one display at longer distance
HV -9000 & HV -9001
1. Connect HVE-9001 to your H MI source (such as a Blu-ray isc player)
through a H MI cable.
2. Connect HVE-9000 to your H MI display (such as a LC TV) through a H MI
cable.
3. Connect your CAT-5/5e/6 cable between HVE-9000 and HVE-9001.
4. Make sure your CAT-5/5e/6 cable is tightly connected and not loose.
5. Plug in 5V C power cord to the power jack of HVE-9000.
6. Plug in 5V C power cord to the power jack of HVE-9001.
7. If a flickering or a blinking image is seen, try to adjust the rotary control knob
to improve the cable skew. 0 stands for the strongest EQ while 7 stands for the
weakest. Try adjusting the EQ from 7 to 0.
HV -9000
HDMI cable
HDMI cable
C
at
.5e
/6
cable
HV -9001
HDTV
HDMI source

9
Extends HDMI signals to one display at shorter distance
HV -9900 & HV -9001
1. Connect HVE-9001 to your H MI source (such as a Blu-ray isc player) through
a H MI cable.
2. Connect HVE-9900 directly to your H MI display (such as a LC TV).
3. Connect your CAT-5/5e/6 cable between HVE-9001 and HVE-9900.
4. Make sure your CAT-5/5e/6 cable is tightly connected and not loose.
5. Plug in 5V C power cord to the power jack of HVE-9001.
HDTV
HDMI cable
C
at
.5e
/6
cable
HV -9001
HV -9900
HDMI source

10
Extends HDMI signals to next cascading device with one local display
HV -9002
1. Switch off all devices, including monitors.
2. Connect a local H MI display to the H MI out of the HVE-9002 and then
connect a speaker to the 3.5mm audio socket.
3. Connect to a H MI source (such as a Blu-Ray isc player)
4. Connect HVE-9002 to HVE-9003 (for cascading), to HVE-9000 (to H TV at long
range), or HVE-9900 (to H TV at mid range) via RJ-45 Out by a Cat.5e cable.
5. Plug in 5V4A C power supply.
6. Power on the H TV.
7. Power on the H MI source.
HDMI source
HV
-
9002
HV -9900
HV -9003
HDMI c
abl
e
H
V
-
9000
Speaker
HDMI cable
C
at
.5e cable
Audio cable
HDTV

11
Relays HDMI signals to next cascading device with one local display
HV -9003
1. Switch off all devices, including monitors.
2. Connect a local H MI display to the H MI Out of the HVE-9003 and then
connect a speaker to the 3.5mm audio socket.
3. Connect to HVE-9003 via RJ-45 in by a Cat.5e cable.
4. Connect to next HVE-9003 (for cascading), to HVE-9000 (to H TV at long
range), or HVE-9900 (to H TV at mid range) via RJ-45 out by a Cat.5e cable.
5. Plug in 5V4A C power supply.
6. Power on the H TV.
HV
-
9002
HV
-
900
3
HV -9900
HV -9003
H
V
-
90
00
Speaker
HDMI cable
C
at
.5e cable
Audio cable
HDTV
C
at
.5e cable

12
Systematic Application Diagrams
HV -9002 & HV -9003 with HV -9000 & HV -9900
HDMI cable
HDMI cable
C
at
.5e
cable
HV -9002
HV -9003
HV -9900
HV -9003
H
V
-
9000
Audio
cable
Speaker
HDTV
HDMI source
HDTV Speaker
Audio
cable
HDMI cable
C
at
.5e cable
HDTV
Speaker
Audio
cable
HDMI cable
C
at
.5e cable
Cat.5e cable
HDTV

13
Frequently Asked Questions
How does equalizer
(EQ) work?
Equalizer is a built in electronic device used to fine
tune picture quality. Please turn knob anticlockwise
from 7 to 0 to get the optimal vision. If you find the
display is not showing properly, please check your
cable connection or it is out transmission limit.
What is the minimum
requirement of Cat-X
cable
Minimum cable requirement is Category 5 cable for
H Spider™ series products. Please ensure all cables
are terminated with RJ-45 plug according to
EIA/TIA568B definition.
What kind of Cat-X
cable is
recommended?
We recommend using Category 6 or 7 STP cable for
best picture quality at maximum extension. For better
result please use cable with minimum delay skew.
I want extension
above specification, is
that possible?
Yes. To extend H MI signal above specification
published please use high quality H MI cable (24
gauges) and recommended Cat-X cable. On field
test, it is possible using CAT.6 cable for 50m
transmission under 1080p. If further extension is
required, please set H MI source at 480p resolution.
I am using HVE-9900 to
receive H MI signal,
but there is no image
on monitor.
HVE-9900 is only intended to use for shorter
transmission length. The maximum transmission length
is at 15m under 1080p or 25m under 720p/1080i
resolution. If your application exceeds this transmission
limit, please use H Spider™ H MI Cat.5 Receiver
(Long) (HVE-9000) instead.
There is no image on
display, what could
be the problem?
First please check all cable is properly installed.
Secondly check display source is functioning correctly.
It is still not working. If problem persist, please try the E I learning function
on HVE-9001 and HVE-9002 (stated on p.4-5).

14
Specifications
Model Name HV -9000 HV -9001 HV -9900
Package Contents
1x HVE-9000
1x 5V transformer
1x User Manual
1x HVE-9001
1x 5V transformer
1x User Manual
1x HVE-9900
1x User Manual
Video Bandwidth 1.65Gbps
Resolution 480i – 1080p
Transmission Length 60m under H (720p/1080i) or 40m under Full H (1080p)
Audio channel 7.1-channel or stereo
Supported signal H MI 1.2 & VI 1.1
Input 1x RJ-45 1x H MI 1x RJ-45
Output 1x H MI 1x RJ-45 1x H MI
Power 5V 2A C 5V 2A C None
H MI Connector 19-pin female 19-pin female 19-pin female
RJ-45 Connector 2 indication LE s 2 indication LE s 2 indication LE s
Housing Metal Metal Plastic
imensions (L x W x H)
87 x 60 x 25 (mm) 87 x 60 x 25 (mm) 45 x 25 x 20 (mm)
Weight 160g 160g 25g
Model Name HV -9002 HV -9003
Package Contents
1x HVE-9002
1x 5V transformer
1 x User Manual
1x HVE-9003
1x 5V transformer
1 x User Manual
Video Bandwidth 1.65Gbps
Resolution 480i – 1080p
Transmission Length 60m under H (720p/1080i) or 40m under Full H (1080p)
Audio channel 7.1-channel or stereo
Supported signal H MI 1.2 & VI 1.1
Input 1x H MI 1x RJ-45
Output
1x H MI (display or cascading)
1x RJ-45
1x 3.5mm audio socket
1x H MI (display or cascading)
1x RJ-45 (cascadable)
1x 3.5mm audio socket
Power 5V 4A C 5V 4A C
H MI Connector 19-pin female 19-pin female
RJ-45 Connector 2 indication LE s 2 indication LE s
Housing Metal Metal
imensions (L x W x H)
180 x 108 x 27 (mm) 180 x 108 x 27 (mm)
Net Weight 430g 430g
*Specification subject to change without notice

15
Notice
1. Please read user manual carefully before operating the device.
2. Please use the power adaptor accompanied with this product. Warranty
does not cover for damages caused by pairing other power adaptor.
3. Please check all connecting devices are properly grounded to avoid
electric failure.
4. This product has limited warranty for one year from defects in material and
workmanship. Items that are physically damaged, misused, tempered with
or altered are void of warranty. For further details please contact your
distributor. In case warranty sticker is damaged or missing, warranty is void.
For further details please contact your distributor.
5. If your H MI ( VI) device requires an E I present, you can use an E I
Reader/Writer to provide H MI ( VI) E I information.
6. All of the transmission distances are measured by using Belden Cat.5e
125MHz cables and PlayStation3 as the H MI source.
7. To reduce the interference among the unshielded twisted pairs of wires in
Cat.5/5e/6 cable, you can use shielded Cat.5/5e/6 cables to improve EMI
problems, which is worsen in the long transmission.
8. Because the quality of the Cat.5/5e/6 cables has the major effects in how
long transmission distance and how good the picture quality may be, the
actual transmission length is subject to your Cat.5/5e/6 cables. For
resolution greater than 1080i or 1280x1024, a Cat.6 cable is recommended.
V1
