LevelOne HVE-0201 User manual

HVE-0201
HDMI Extender via Fiber Channel
User Manual
V1.0

1
Introduction
LevelOne HVE-0201 HDMI extender uses 2 cores
fiber without ny copper wire inside, where r dio
frequency interference phenomenon is liter lly ruled
out, which shows the dv nt ge of high perform nce
nd good sign l qu lity s well s low cost. Optic l
fiber is of low dispersion, which in turn h s the
strength of longer sign l tr nsmission dist nce nd
better sign l tr nsmission qu lity in comp rison to the
tr dition l copper wire c ble.
Feature
 Long dist nce video nd udio tr nsmission
 High resolution nd im ge qu lity
 Supports resolution 1920 x 1080, up to 200m
 HDCP fully compli nt without copper wire
 No RF Interference by optic l fiber
 HDMI Type A connection

2
Pac age Content
– HVE-0201 (RX+TX)
– Power Ad pter (DC5V, 1.0A)
– HDMI C ble
– User M nu l
Hardware Description
Dimension / Weight
95 x 145.8 x 25.8mm (W x D x H), 400g

3
Front Panel
Note:
Sign l between Source nd Sin lso referred to s
the source(TX) nd receiving(RX) devices
Rear Panel
Power
J ck
HDMI
Connector
SC
Fiber
Optic l
Fiber
Power
LED
HDMI
Source
HDMI
Sink

4
Installation
1. Put ‘TX’ module ne r to HDMI sign l source, such s
DVD pl yers or computers.
2. Put ‘RX’ module is ne r to HDMI sink, such s LCD
TVs or Projectors.
3. Connect two pl ce by using multimode fiber of 2
cores.
4. Scour the ll end f ce of fibers. (See Note 1)
5. Plug in the fibers ccording to the indic ted number.
The ‘1’,’2’.
6. Plug in the 5V d pter to the electricity nd TR/RX
modules.
7. Link TX module to HDMI source by HDMI c ble.
(See Note)
8. Link RX module to HDMI sink by HDMI c ble. (See
Note)
Note
1. Cle n end f ce of fiber before plugging in. The dust
will c use d m ge to the fiber.
2. The length of HDMI c ble should be NOT longer th n
2 meters.
3. These three figures in front of the modules represent
linking st tus. These 3 LEDs bl ze green if ll setup is
complete nd correct. The left one st nds for the
connection of fiber. The middle one st nds for the
connection of HDMI source. The right one st nds for
the connection of HDMI source.

5
Connection Diagram
System Requirement
 HDMI Source (DVD pl yer or PC)
 HDMI Sink (Monitor or Projector)
 100~240VAC 50~60Hz 0.2A electricity
HDMI Cable
Multi-mode
SC Fiber, 200m
DVD Player
TX RX

6
Technical Specification
Model HVE-0201
Max Length 200M, 62.5, 50/125 MMF 2-SC
Max Resolution 1920 × 1080
HDCP Compliant Yes
CEC Compliant Yes
Max Power
Consumption
TX: 5V 3W, 600mA
RX: 5V 3W, 600mA
Power DC 5V, 1.0A
Dimension 95 x 145.8 x 25.8mm (W x D x H)
Weight 400g
Operating Temp. 0℃ to 50℃
Storage Temp. -20℃ to 75℃
EMI CE, FCC
