LevelOne FSW-0511 Manual

FSW
FSWFSW
FSW-
--
-0511
05110511
0511
Fast Ethernet Switch
Fast Ethernet SwitchFast Ethernet Switch
Fast Ethernet Switch
one world_one brand_one level_
Digital Data Communications GmbH.
Zeche-Norm St. 25, 44319, Dortmund, Germany
All mentioned brand names are registered trademarks and property of their owners.
Technical specifications are subject to change without notice.
© 2008 A Rights Reserved
www.level1.com
H/W Ver.
H/W Ver.H/W Ver.
H/W Ver. 1x
1x 1x
1x
5-Port Fast Ethernet Switch
Product verview
The Leve One FSW-0511 is a compact 5-port Fast Ethernet Switch. It is a high-
performance, cost-effective and easy to use network switch for expanding
home and office networks.
Plug-and-Play Expansion of Home/ ffice Network
The Leve One 5-port Fast Ethernet Switch is an easy to insta “p ug-and-p ay”
switch, a owing users to either create a Loca Area Network (LAN) or connect
additiona network devices, such network cameras, storage devices or print
servers, to an estab ished network.
Fast Ethernet Switching Architecture
The FSW-0511 de ivers 200Mbps bandwidth per port and incorporates a non-
b ocking wire-speed switching architecture for seam ess transferring of data
through the network. A ports support auto-negotiation and auto-MDI/MDIX
sensing, e iminating the need for crossover cab es or Up ink ports. Each port
can be used as genera network ports or as connecting ports into a router,
server, hub or another network switch.
FSW-0511
Key Features
• Comp ies with IEEE Ha f- and Fu -Dup ex
standards
• Features 5 Auto-Negotiation RJ45 ports
supporting Auto-MDI/MDIX
• Supports MAC address auto- earning and
auto-aging
• Fu LED disp ay pane for error detection
and network monitoring
• Compact design for desktop or wa -
mounting
• P ug-and-P ay enab ed for easy setup
and configuration
Technical Specification
Network Interface
Standards
IEEE 802.3 10Base-T Ethernet
IEEE 802.3u 100Base-TX Fast Ethernet
IEEE 802.3x F ow Contro and Back Pressure
Network Interface
5x 10/100 Mbps RJ-45 ports
Network Cables
10Base-T: 2-pair UTP/STP Cat.3/4/5, Up to 100 m
100Base-TX: 2-pair UTP/STP Cat. 5, Up to 100 m
Data Transfer Rate
Ethernet: 10Mbps (Ha f-dup ex)
Ethernet: 20Mbps (Fu -dup ex)
Fast Ethernet: 100Mbps (Ha f-dup ex)
Fast Ethernet: 200Mbps (Fu -dup ex)
Switching Protocol
CSMA/CD
Switch Architecture
Store-and-Forward
MAC Address Table
Auto earning function
Physical Specifications
External Power Supply
AC 12V~0.35A, 50/60Hz
LED
Power, Link/Activity
Temperature
Operating: 0°C ~ 40°C
Storage: -40°C ~ 70°C
Humidity
Operating: 10% ~ 90% (Non-condensing)
Storage: 5% ~ 95% (Non-condensing)
Dimension & Weight
141mm (L) x85mm (W) x 27.5mm (H)
Certifications
FCC C ass A
CE
Package Contents
FSW-0511
Power Adapter
User Manua
Wa -Mounting Kit

FSW
FSWFSW
FSW-
--
-0511
05110511
0511
Fast Ethernet Switch
Fast Ethernet SwitchFast Ethernet Switch
Fast Ethernet Switch
one world_one brand_one level_
Digital Data Communications GmbH.
Zeche-Norm St. 25, 44319, Dortmund, Germany
All mentioned brand names are registered trademarks and property of their owners.
Technical specifications are subject to change without notice.
© 2008 A Rights Reserved
www.level1.com
H/W Ver.
H/W Ver.H/W Ver.
H/W Ver. 1x
1x 1x
1x
Product Diagram
Order nformation
FSW-0511: 5-Port Fast Ethernet Switch
