LevelOne IGP-0521 User manual

1
IGP-0521
5-Port Industrial Gigabit Ethernet PoE Switch, 4 PoE Outputs
+ 1 SFP/TX Combo, 126W, 12/24/48VDC
User Manual

2
FCC MARKING
This Equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at
his own expense.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and
(2) this device must accept any interference received; including interference that
may cause undesired operation.
CE MARKING
This equipment complies with the requirements relating to electromagnetic
compatibility, EN 55022 class A for ITE, the essential protection requirement of
Council Directive 2004/108/EC on the approximation of the laws of the Member
States relating to electromagnetic compatibility.
Company has an on-going policy of upgrading its products and it may be possible
that information in this document is not up-to-date. Please check with your local
distributors for the latest information. No part of this document can be copied or
reproduced in any form without written consent from the company.
Trademarks:
All trade names and trademarks are the properties of their respective companies.
Copyright © 2013, All Rights Reserved.

3
Introduction
This rugged designed Industrial Ethernet switch / Industrial Giga -bit 4 port POE Injectors and
Super Booster Industrial Giga-bit 4 port POE Injectors, which comply with IEEE802.3af and
IEEE802.3at, has pass many rigorous environmental test. It delivers 30watts power (Max 36W) per
POE port. And it can generate total 120 watts power(Max 126W) to PD devices. the uplink 2 SFP
port (varied by models), can extend your environment to a much larger area.
The super voltage booster model uses 12/24/48VDC input to boo st voltage to 55VDC. It guaranty
to meet IEE802.3at and to delivery full POE power up to 36Watts per POE port to a PD. With its
multi-purpose design, it can also be used for Din-Rail or wall-mounted. It is an ideal unit for IP
surveillance, traffic monitoring and Security application in critical environment. It can tolerate -
40°C to 75°C in harsh environment to perform a reliable network.
Housing Dimension
MODELS –Super Booster Industrial Giga-bit 4 port POE Injector, 12/24/48 VDC input
This Super Voltage Booster --- The high power 4 port industrial POE+ Injector is
equipped with our high efficiency ColdDesign technology which allows low input
voltage, such as 12/24/48VDC be boost up to 55VDC to meet IEEE802.3at requirement.
The ColdDesign technology will not only boost up Input Voltage, also reduce the
excessive heat problem to a minimum. It accepts the input voltage as low as 12VDC, to
be boost up to 55VDC. And it is also equipped with 2 port SFP fiber that can be used as
fiber redundancy, cascaded to your other devices to expand your network application. It
is being rigorously tested for your Security, Transportation and Telco application.
.

4
Power connection
This unit provides 6 pin terminal block. The POE port can be operated from 44-56VDC power source. The
VDC power range can be 48VDC only or lower, or wide range from 44-56VDC. Always Make sure your
input voltage is within this supported voltage range for each model.
WARNING –any exceeded input voltage will not make this unit function and may damage this unit.
To make power connection –Follow the printed polarity for V1+, V1-,
V2+, V2-, and ground. Connect positive wire to V+ , connect negative
wire to V-, also connect neutral wire to the ground screw as shown .
Relay -- You may use 24V@1Arelay connection to your external
device for special purpose. When 2 powers are connected, the relay is
in SHORT mode. When any power source fails, the relay change to
OPEN status.
Power connecting procedure:
STEP 1 –Pull out 6 pin terminal block.
STEP 2 –Connect wire to V1+, V1-, or V2+, V2-, and Ground the neutral wire to the ground screw.
STEP 3–Plug back 6 pin terminal block to its place.
WARNING –
Always ground the power source to maintain a clean power input. Due to too many cheap made power
supplies, it creates too much noise, and it will cause the power input fluctuates when connect to this
unit. To avoid this, always ground the power source to gain a clean power input.
Din Rail Bracket x 1
Wall mount bracket x 2
6 pin Terminal Block
x1
Installation package
This unit can be installed by din-rail mounted or wall-mounted. Din-rail brackets and wall-mounted
bracket are included.

5
Dip switch function
SPD
ON –1000M speed is detected.
OFF –10M or 100M speed is detected
PW1
ON -- when V1+, V1- is connected
LNK
ON—TX link is detected
OFF –TX port is not detected
Flashing –TX port is active
LED indicator
This unit is equipped with dip switches, located on the front panel. Adjusting the dip switches will change
the default function of this unit. This unit has set to manufacturer default as: Port 5 SFP and the speed is
set to 1000M for both port 5 and port 6 SFP ports. you may adjust dip switch setting to select port 5 as TX
( disable port 5 SFP) or set SFP speed to 100M. The detail setting as shown below:
PW2
ON -- when V2+, V2- is connected
ERR
ON –
connect only PW1 or PW2.
OFF-
both PW1 and PW2 are connected
F5
ON –port 5 SFP fiber is detected
OFF –port 5 SFP fiber is not detected.
Flashing –port 5 SFP fiber is active
P1,P2,P3,P4
ON—PD is detected on designated port.
OFF –no PD is detected
Warning:
Dip switch function will not work if it is
changed when power is connected.
Always turn off or disconnect power
supply to change dip switch settings.

6
Specification:
IEEE Standard
IEEE 802.3 10Base-T Ethernet
IEEE 802.3u 100Base-TX Fast Ethernet
IEEE 802.3ab 1000Base-T Gigabit Ethernet
IEEE 802.3z 1000Base-X Gigabit Ethernet
IEEE802.3x Flow Control and Back Pressure,
IEEE802.3af for POE
IEEE802.3at for POE+
Switch Architecture
Back-plane (Switching Fabric): 12Gbps
Data Processing
Store and Forward
Flow Control:
IEEE 802.3x Flow Control and Back Pressure
Jumbo Frame
9KB
MAC address Table Size
1K
Packet Buffer Size
1M
Network Connector :
5xRJ-45 10/100/1000BaseT(X) auto negotiation,
4 Giga POE+ 802.3at/af PSE port
Auto MDI/MDI-X function, Full/Half duplex
1x SFP 100/1000M BaseX
Network Cable
UTP/STP above Cat.5e Cable
EIA/TIA-568 10-ohm (100m)
Fiber Cable (Multi-mode):50/125um,62.5/125um
Fiber Cable (Single-mode): 9/125um
Protocol
CSMA/CD
LED
PW1(Power 1) Green,
PW2(Power 2) Green,
ERR( Fault ) Amber,
TX/RJ-45 port:
LNK (Link/Active) Green,
SPD(Speed) 10/100(OFF ) ,1000 (Green)
SFP Fiber Per port:
Link (Green)
Active Flash
DIPSwitch
DIP 1: OFF: Port 5 SFP (DEFAULT)
ON: Port 5 TX
DIP 2: OFF: SFP 1000M (DEFAULT)
ON: SFP 100M
Reserve polarity protection
Present
Overload current protection
Present
Power Supply
Redundant Dual DC 9V-56V Power Input without
POE
Power Consumption
5.76W@12/24/48 VDC full load, Without POE

7
Alarm Relay Contact
Relay outputs with current carrying capacity of 1 A
@24VDC,
Relay in short circuit mode when 2 powers are
connected. in open circuit mode when only one
power supply is connected
Ethernet Switch power input
Ethernet switch power input 9VDC -56VDC
POE power
POE power per port 30watts. Maximum 36Watts
Maximum total power 126Watts at 24VDC and
48VDC power input.
Maximum total power 65W at 12VDC power input .
Removable Terminal Block
Provide 2 Redundant power , Alarm relay contact ,6
Pin
Wire range: 0.34mm^2 to 2.5mm^2
Solid wire (AWG):12-24/14-22
Stranded wire(AWG): 12-24/14-22
Torque:5lb-In/0.5Nm/0.56Nm
Wire Strip length: 7-8mm
Operating Temperature
-40℃~75℃fully tested.
Operating Humidity
5% to 95% (Non-condensing)
Storage Temperature
-40℃~85℃
MTBF (mean time between failure)
510,304 hrs ( MIL-HDBK-217F) at 25°C
Housing
Rugged Metal ,IP30 Protection
Case Dimension (L x W x D)
142mmx43mmx105mm (LxWxD)
Installation mounting
DIN Rail mounting and Wall Mounting
EMC/EMS
CE, FCC,VCCI
EMI
FCC Part 15 Subpart B Class A,
CE EN 55022 Class A
