Lexmark X644e - with modem taa/gov User manual

Lexmark

Card for IPDS and SCS/TNe

IPDS Printer and Host Setup Guide

IPDS Printer and Host Setup Guide Notices

NOTICES

Edition Notice

Second Edition. October 2007, EC 20G429

Disclaimers

The following paragraph does not apply to any country where such provisions are inconsistent with local law:

LEXMARK INTERNATIONAL, INC. AND INTERMATE A/S PROVIDE THIS PUBLICATION "AS IS" WITHOUT

WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE

IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. Some

states do not allow disclaimer of express or implied warranties in certain transactions, therefore, this statement

may not apply to you.

This publication could include technical inaccuracies or typographical errors. Changes are periodically made to

the information herein; these changes will be incorporated in later editions. Improvements or changes in the

products or the programs described may be made at any time.

Trademarks

AFP, AIX, AS/400, IBM, iSeries, MVS, OS/2, OS/390, OS/400, Print Services Facility, PSF, System/390,

zSeries, and z/OS are trademarks of International Business Machines Corporation in the United States, other

countries, or both.

Intelligent Printer Data Stream and IPDS are trademarks or registered trademarks of Ricoh Co., Ltd in the

United States, other countries, or both.

Lexmark and Lexmark with diamond design and MarkNet are trademarks of Lexmark International, Inc. regis-

tered in the United States and/or other countries.

Intermate is a trademark of Intermate A/S.

IPDS Printer and Host Setup Guide - Table of Contents

TABLE OF CONTENTS

Notices ........................................................................................................................................................ 2

Table of Contents.............................................................................................................................................. 3

Equipment Requirements and Specifications................................................................................................ 4

Customer Support............................................................................................................................................. 5

1. AS/400 and iSeries LAN Printing Using the Printer Standard Network Port or MarkNet Internal Print

Server ................................................................................................................................................................ 6

2. AS/400 and iSeries Twinax Printing Using the Adapter for SCS ......................................................... 15

3. PSF/MVS LAN Printing Using the Standard Network Port or Internal Print Server ........................... 22

4. MVS Coax Printing Using the Adapter for SCS ..................................................................................... 30

5. PSF/2 LAN Printing Using an Internal LAN Print Server ...................................................................... 35

6. PSF/AIX LAN Printing Using an Internal LAN Print Server .................................................................. 44

7. Printer and Host Timeout Values ............................................................................................................ 50

8. Port Support for IPDS Printing ............................................................................................................... 52

9. Coax/Twinax Adapter for SCS Support .................................................................................................. 53

10. Printer Messages and Problems ............................................................................................................ 54

IPDS Printer and Host Setup Guide Equipment Requirements And Specifications

EQUIPMENT REQUIREMENTS AND

SPECIFICATIONS

This guide provides information to help you configure the host and printer to print IPDS jobs. The information in

this guide applies to the following printers and Multifunction Products (MFPs).

• Lexmark C770, C772, C780, C782, C920, C935 (IPDS color and monochrome printing, SCS

monochrome printing only)

• Lexmark T640, T642,T644

• Lexmark W840

• Lexmark X644e MFP, X646e MFP

• Lexmark X646ef MFP

• Lexmark X782e MFP

• Lexmark X850e MFP, X852e MFP, X854e MFP

• Lexmark X940e MFP, X945e MFP (IPDS color and monochrome printing, SCS monochrome printing

only)

Unless otherwise specified, in the rest of this guide the term "printer" covers both printers and MFPs.

To print IPDS jobs, the printer must have the optional Card for IPDS and SCS/TNe installed, a minimum of 64

MB of user memory (DRAM), and one of the following:

• Standard Network (Ethernet connection integrated into printer system board on selected printer

models).

• a MarkNet internal LAN print server (optional card providing Ethernet or Fiber network connection).

• Lexmark 802.11g Wireless Print Adapter

• a Coax/Twinax Adapter for SCS option card for connection to a host via coax or twinax cables. Refer to

“Coax/Twinax Adapter for SCS Support” [page 53]

for a list of printers which support this adapter.

To install the printer, determine the host, host software, and type of printer connection you will be using. Find

the appropriate chapter in the Table of Contents and follow the steps to configure the host and printer.

IPDS Printer and Host Setup Guide Equipment Requirements And Specifications

Customer Support

If you cannot find answers in this guide about using the IPDS emulation, or require firmware updates, please

contact your point of purchase, your local Lexmark office, or check the Lexmark support web site at

http://support.lexmark.com

IPDS Printer and Host Setup Guide AS/400 and iSeries LAN Printing Using the Printer Standard Network Port or MarkNet Internal Print Server

1. AS/400 and iSeries LAN Printing Using the Printer

Standard Network Port or MarkNet Internal Print

Server

With the optional Card for IPDS/SCS/TNe and a LAN print server installed, the printer can receive, process,

and print AFP/IPDS print jobs over TCP/IP from the following IBM software:

• PSF/400 V3R1-R3, V3R6-R7, V4R1-R5, V5R1-R4, or greater

The information below will lead you through the steps for setting up the AS/400, or iSeries, and the printer to

print IPDS jobs over a LAN. The printer must be configured with a Standard Network port or MarkNet internal

LAN print server.

Refer to the IPDS User’s Guide for detailed instructions on using the control panel to select and change option

settings.

Steps

The following steps must be completed to begin printing IPDS jobs.

Choose a Printer Port for Use in the Device Description

Create a PSFCFG

Create a Printer Device Description

Configure the Printer’s Print Server TCP/IP Settings

Configure the Printer’s Network Job Timeout

Select the IPDS Emulation, Bar Code Size, Host Resolution, and Fax Interrupt Settings

Verify IPDS Printing

Troubleshooting

Step 1 Choose a Printer Port for Use in the Device Description

Several printer ports are available for receiving IPDS jobs when using the printer Standard Network port or the

MarkNet internal LAN print server. The printer port will be used in one of the following steps.

Port descriptions:

•Port 5001 - This is the recommended port selection for receiving IPDS jobs. This port should only be

used for receiving IPDS jobs. The printer’s Network Job Timeout and Job Buffering settings are

automatically set to the correct settings for receiving IPDS jobs on this port. This port is recommended

when a significant performance impact is seen when downloading IPDS resources for each job. With

the proper configuration settings on the host and printer, the IPDS resources can be saved in the printer

memory while the printer is printing non-IPDS jobs.

•Port 9100 - This port can receive PCL, Postscript, or IPDS jobs. In order to print IPDS jobs, the printer’s

Network Job Timeout must be manually set to "0" (or to "Disable") and Job Buffering must be

manually set to "OFF".These settings also affect printing of non-IPDS jobs.

How to find the Network Job Timeout Option (which is also known as End-of-Job Timeout) on the control

panel: On printers, press MENU and then select Settings > Setup Menu > Timeouts > Network Job

Timeout. On MFPs, touch Menus and then select Settings > General Settings > Timeouts > Network Job

Timeout.

IPDS Printer and Host Setup Guide AS/400 and iSeries LAN Printing Using the Printer Standard Network Port or MarkNet Internal Print Server

How to find Job Buffering on the control panel: Job Buffering is only visible as a menu setting if there is a

hard disk installed in the printer. Press MENU or touch Menus and then select Network/Ports > Standard

Network > Job Buffering.

•Port 9600 - This port should only be used for receiving IPDS jobs. The printer’s Network Job Timeout

setting is automatically set to the correct setting for receiving IPDS jobs on this port. This port is only

provided for compatibility with some older printers. Port 5001 is the recommended port for printing IPDS

jobs.

Step 2 Create a PSFCFG

Note: Examples showing parameters displayed on an AS/400 may be different than the parameters

displayed on your system. Examples are shown with V5R2 parameters.

Define a PSF configuration object for your printer using CRTPSFCFG. The PSFCFG object defined in this step

is referenced in the printer device description (CRTDEVPRT). More than one printer can use this object.

Below is an example of a PSF configuration. The parameters in bold are the parameters which must be

changed for printing IPDS jobs.

Example PSFCFG with parameters to change shown in bold.

PSF configuration PSFCFG > IPDSPRT

(Note: IPDSPRT is a user defined name.)

Library............................... > QGPL

User resource library list.. USRRSCLIBL *JOBLIBL

Device resource library list DEVRSCLIBL *DFT

+ for more values

IPDS pass through..................... IPDSPASTHR > *NO <note1>

Activate release timer................ ACTRLSTMR *NORDYF

Release timer......................... RLSTMR > *SEC15 <note2>

Restart timer......................... RESTRTMR *IMMED

APPC and TCP/IP retry count........... RETRY 15

Delay time between APPC retries....... RETRYDLY 90

Acknowledgement frequency............. ACKFRQ 100

Printer response timer................ PRTRSPTMR *NOMAX

Generate PDF output................... PDFGEN *NONE

Text 'description'.................... TEXT > 'IPDS Printer'

(Note: ‘IPDS Printer’ is user defined text.)

Additional Parameters

Automatic session recovery: AUTOSSNRCY

Enabled........................... *NO

Message option....................

Blank page............................ BLANKPAGE *YES

Page size control..................... PAGSIZCTL *NO

Resident fonts........................ RESFONT *YES

Resource retention.................... RSCRET *YES

Edge orient........................... EDGEORIENT *NO

Use outline fonts..................... USEOUTLFNT *NO <note3>

PSF defined option.................... PSFDFNOPT *NONE

Font substitution messages............ FNTSUBMSG *YES

Capture host fonts at printer......... FNTCAPTURE *NO <note4>

Font resolution for formatting........ FNTRSL *SEARCH

Font mapping table.................... FNTTBL *NONE

Library.............................

IPDS Printer and Host Setup Guide AS/400 and iSeries LAN Printing Using the Printer Standard Network Port or MarkNet Internal Print Server

Note 1: IPDS pass through may be set to *YES. This may increase job performance. Selecting *YES may

change the fonts downloaded from the host and change paper jam recovery action between the host

and printer.

Note 2: Refer to

“Printer and Host Timeout Values” [page 50]

for information on selecting the Release

Timer value.

Note 3: Use outline fonts controls the type of fonts downloaded to the printer. When set to *YES,

outline fonts are downloaded to the printer. When set to *NO, raster fonts are downloaded to the

printer. When the outline or raster fonts are marked eligible for capture on the host, the host will send

fonts which can be captured at the printer.

Note 4: Capture host fonts at printer must be set to *YES and fonts must be marked eligible

to be captured before the host will send fonts which can be captured to the printer. Refer to the IPDS

Emulation User's Guide for additional information on capturing fonts.

Step 3 Create a Printer Device Description

Note: Examples showing parameters displayed on an AS/400 may be different than the parameters

displayed on your system. Examples are shown with V5R2 parameters.

Create a printer device description for your printer using CRTDEVPRT.

Below is an example of a device description. The parameters in bold are the parameters which must be

changed for printing IPDS jobs.

Cut sheet emulation mode.............. CSEMODE *NONE

Use DBCS simulation fonts............. MAPIGCFNT *NO

Replace............................... REPLACE *YES

Authority............................. AUT *LIBCRTAUT

Example CRTDEVPRT with parameters to change shown in bold.

Device description.................... DEVD > IPDSPRT

(Note: IPDSPRT is a user defined name.)

Device class.......................... DEVCLS > *LAN

Device type........................... TYPE > *IPDS

Device model.......................... MODEL > 0

LAN attachment........................ LANATTACH > *IP

Switched line list.................... SWTLINLST

LAN remote adapter address............ ADPTADR

Adapter type.......................... ADPTTYPE *INTERNAL

Adapter connection type............... ADPTCNNTYP *PARALLEL

Emulated twinaxial device............. EMLDEV

Advanced Function Printing............ AFP > *YES

AFP attachment........................ AFPATTACH *WSC

Port number........................... PORT > 5001

(Note: Port number selected in step

above.)

Switch setting........................ SWTSET

Local location address................ LOCADR

Auxiliary printer..................... AUXPRT

Emulating ASCII device................ EMLASCII *NO

Physical attachment................... ATTACH

Example PSFCFG with parameters to change shown in bold.

IPDS Printer and Host Setup Guide AS/400 and iSeries LAN Printing Using the Printer Standard Network Port or MarkNet Internal Print Server

Online at IPL......................... ONLINE *YES

Attached controller................... CTL

Language type......................... LNGTYPE *SYSVAL

Print quality......................... PRTQLTY *STD

Font: FONT

Identifier.......................... > 11

Point size.......................... *NONE

Form feed............................. FORMFEED > *AUTOCUT

Separator drawer...................... SEPDRAWER *FILE

Separator program.....................

Library.............................

SEPPGM *NONE

Number of drawers..................... NBRDRAWER

Printer error message................. PRTERRMSG *INQ

Message queue......................... MSGQ *CTLD

Library.............................

Maximum length of request unit........ MAXLENRU *CALC

Application type...................... APPTYPE *NONE

Activation timer...................... ACTTMR > *NOMAX <note1>

Inactivity timer...................... INACTTMR *ATTACH

SNA pass-through device desc.......... SNPTDEV *NONE

SNA pass-through group name........... SNPTGRP *NONE

Host signon/logon command............. LOGON *NONE

Pacing ............................... PACING 7

Line speed............................ LINESPEED *TYPE

Word length........................... WORDLEN *TYPE

Type of parity........................ PARITY *TYPE

Stop bits............................. STOPBITS *TYPE

Host Print Transform.................. TRANSFORM *NO

Manufacturer type and model........... MFRTYPMDL

Paper source 1........................ PPRSRC1 *MFRTYPMDL

Paper source 2........................ PPRSRC2 *MFRTYPMDL

Envelope source....................... ENVELOPE *MFRTYPMDL

ASCII code page 899 support........... ASCII899 *NO

Maximum pending requests ............. MAXPNDRQS 6

Print while converting................ PRTCVT *YES

Print request timer................... PRTRQSTMR *NOMAX

Form definition....................... FORMDF F1C10110

Library............................. *LIBL

Character identifier: CHRID

Graphic character set............. *SYSVAL

Code page.......................

Remote location: RMTLOCNAME

Name or address..................... > 157.184.67.102

(See your Network Administrator for address.)

Local location........................ LCLLOCNAME *NETATR

Mode.................................. MODE QSPWTR

User-defined options ................. USRDFNOPT *NONE

User-defined object: USRDFNOBJ

Object.............................. > IPDSPRT

Library........................... > QGPL

Object type......................... > *PSFCFG

(Note: PSFCFG object and library created in prior step.)

Data transform program................ USRDTATFM *NONE

Example CRTDEVPRT with parameters to change shown in bold.

IPDS Printer and Host Setup Guide AS/400 and iSeries LAN Printing Using the Printer Standard Network Port or MarkNet Internal Print Server

Note 1: Setting the Activation Timer to *NOMAX allows multiple writers or multiple hosts to use

the same printer. The writer does not time out while waiting on the printer to start a new job.

Step 4 Configure the Printer’s Print Server TCP/IP Settings

To enable IPDS printing with a Standard Network port or a MarkNet internal LAN print server, several settings

must be verified. You can verify these settings from the printer control panel as shown below.

1From a Ready state press the MENU button (printers) or touch (Menus on MFPs).

2Use the navigation buttons or icons to scroll to Network/Ports.

3Select Network/Ports.

TIp: To do this on printers, press the Select button ; on MFPs just touch Network/Ports.

4Now you will see a list of menus. Select the TCP/IP menu.

5Use the navigation buttons or icons to scroll through the options. Check each of the following settings and

change them as needed to configure TCP/IP communication.

Library.............................

User defined driver program........... USRDRVPGM *NONE

Library.............................

System driver program................. SYSDRVPGM

Secure connection..................... SECURECNN *NO

Validation list....................... VLDL *NONE

Library............................

Publishing information: .............. PUBLISHINF

Support duplex..................... *UNKNOWN

Support color...................... *UNKNOWN

Pages per minute black............. *UNKNOWN

Pages per minute color............. *UNKNOWN

Location........................... *BLANK

Data streams supported ............ *UNKNOWN

+ for more values

Text 'Description'.................... TEXT > 'IPDS PRINTER'

(Note: 'IPDS PRINTER' is user defined text.)

Dependent location name............... DEPLOCNAME *NONE

Additional Parameters

Remote network identifier............. RMTNETID *NETATR

Workstation customizing object........ WSCST *NONE

Library............................

Authority............................. AUT *LIBCRTAUT

Example CRTDEVPRT with parameters to change shown in bold.

IPDS Printer and Host Setup Guide AS/400 and iSeries LAN Printing Using the Printer Standard Network Port or MarkNet Internal Print Server

6Save/submit any changes and return to the Ready screen.

7To verify the new print server settings, print a Network Setup Page. Using the control panel MENU/Menus,

select Reports > Network Setup Page. This can be Network Setup Page, Network 1 Setup Page, or

Network 2 Setup Page. Note that the Network Job Timeout is identified as End-of-job Timeout on this

report.

Step 5 Configure the Printer’s Network Job Timeout

Note: If you specified Port 5001 or 9600 in the AS/400 device description, you do not need to configure the

printer’s Network Job Timeout. Go directly to Step

6 [page 12]

Important! If you specified Port 9100 in the AS/400 device description, the printer’s Network Job Timeout

must be manually disabled by setting it to "0" (or to "Disable"). This is necessary to allow the host’s Release

Timer value or the printer’s IPDS Timeout value to control when print jobs from another protocol, interface,

TCP/IP Settings

Parameter Value

Activate On

(Printers: Must be "On" to enable TCP/IP communi-

cations. MFPs: not displayed.)

Address 157.184.67.102

(Address available from your network administrator)

Netmask 255.255.255.0

(Appropriate netmask for your network)

Gateway 157.184.67.1

(IP address of your IP gateway)

Enable DHCP On or Off

(On, if you use a DHCP server.)

(Off, if you set the IP address another way.)

Enable RARP On or Off

(On, if you use a RARP server.)

(Off, if you set the IP address another way.)

Enable BOOTP On or Off

(On, if you use a BOOTP server.)

(Off, if you set the IP address another way.)

AutoIP On or Off

(Default is On. This is the recommended setting.)

WINS Server Address 157.184.100.20

(Address of your WINS Server)

DNS Server Address 157.184.115.7

(Address of your DNS Server)

IPDS Printer and Host Setup Guide AS/400 and iSeries LAN Printing Using the Printer Standard Network Port or MarkNet Internal Print Server

server, or host can be started. It also prevents the printer from ending the IPDS session if communication is

delayed between the host and printer.

Additional information on the printer IPDS Timeout value may be found in the IPDS Emulation User’s Guide.

Follow these steps to disable the printer’s Network Job Timeout from the control panel:

1 Navigate to Network Job Timeout.

To find the Network Job Timeout Option on the control panel: On printers, press MENU and then select

Settings > Setup Menu > Timeouts > Network Job Timeout. On MFPs, touch Menus and then select

Settings > General Settings > Timeouts > Network Job Timeout.

2Select 0. This disables the network job timeout.

3Save/Submit any changes and return to the Ready screen.

4To verify the new print server settings, print a Network Setup Page. Using the control panel MENU/Menus,

select Reports > Network Setup Page. This can be Network Setup Page, Network 1 Setup Page, or

Network 2 Setup Page. Note that the Network Job Timeout is identified as End-of-job Timeout on this

report.

Step 6 Select the IPDS Emulation, Bar Code Size, Host Resolution, and Fax Interrupt

Settings

It is important to select the correct emulation in the printer IPDS MENU before sending IPDS jobs.

Guidelines for Choosing the IPDS Emulation Setting

The IPDS Emulation, the BAR CODE and Host Resolution options are found in the printer control panel

under MENU/Menus > Option Card Menu > IPDS MENU > EMULATION.

1"Resident" is the default setting. If you are replacing a printer that used a Native Emulation setting,

"Resident" is the recommended emulation.

2If you are replacing a printer that used a 4028 Emulation setting, choose the "Resident" Emulation and

change the following settings:

a) Set Bar Code Size to "4028" under BARCODE > Bar Code Size.

b) The recommended Host Resolution setting is "Auto". If you experience printing problems, set Host

Resolution to "300".

3If you are replacing a printer that used a 43xx Emulation setting, choose the "Resident" Emulation and

change the following settings:

a) Set Bar Code Size to "43xx" under BAR CODE > Bar Code Size.

b) The recommended Host Resolution setting is "Auto". If you experience printing problems, set Host

Resolution to "300".

4If you are replacing a printer that used a 3812/3816 Emulation, select the "3812/3816" Emulation. This

emulation only accepts 240 dpi resources (fonts, overlays, etc.) from the host and does not support DBCS

printing.

On MFPs, you can set the print priority of received faxes. Refer to the IPDS Emulation User’s Guide for addi-

tional information about Fax Interrupt. This option is found under MENU/Menus > Option Card Menu > IPDS

MENU > EMULATION.

Refer to the IPDS Emulation User’s Guide for information on these options and other IPDS MENU settings to

format IPDS jobs.

IPDS Printer and Host Setup Guide AS/400 and iSeries LAN Printing Using the Printer Standard Network Port or MarkNet Internal Print Server

Note 1: If the IPDS code release on an MFP is 3.00-01090 or higher, "Copy Interrupt" is supported: an IPDS

job can be interrupted by copy jobs and will resume printing automatically. At lower release levels,

intervening copy jobs will be spooled to disk (when available) and be processed after the IPDS job is

finished.

Note 2: The supported printers and MFPs do not contain an Advanced Function Common Control Unit

(AFCCU).

Step 7 Verify IPDS Printing

If you have completed the steps above to configure the host and printer, you are ready to print your first IPDS

job.

It is assumed that TCP/IP communications is installed and started on the host.

1Vary ON the device.

VRYCFG CFGOBJ(IPDSPRT) CFGTYPE(*DEV) STATUS(*ON)

2Start the writer.

STRPRTWTR IPDSPRT

3Send an IPDS job from your host system.

4Observe the printer control panel. When the first job data is received, BUSY should be displayed in the

printer control panel. If the job does not print, go to Step

Troubleshooting

5After the last page of the IPDS job prints, BUSY will remain displayed until the host or printer ends the

session. This is controlled by the Release Timer on the host or by the IPDS Timeout on the printer.

6You may want to refer to the IPDS Emulation User's Guide to determine if other IPDS MENU settings need

to be changed.

Step 8 Troubleshooting

If the IPDS job does not print, try the following.

1If BUSY is not displayed in the printer control panel or if the printer remains in Ready mode, check to be

sure the printer is connected to the network. Try to PING the printer.

2If BUSY is not displayed in the printer control panel or if the printer remains in Ready mode, check all host

and printer settings to be sure they are correct.

3If you receive an IPDS Negative Acknowledgement (NACK) beginning with ’08C1’ indicating that the job is

printing outside the printer valid printable area, choose one of the following solutions:

a) Change the Printable Area setting to Physical Page. Using the control panel MENU/Menus, select

Option Card Menu > IPDS MENU > EMULATION > Printable Area.

b) Change your application to position the text within the printable area. Refer to Printable Area in the

IPDS Emulation User’s Guide for more information.

c) Change the Exception Ctrl setting to Sup Beyond VPA. Using the control panel MENU/Menus,

select Option Card Menu > IPDS MENU > EMULATION > Exception Ctrl. The printer will not send

a NACK to the host when printing outside the valid printable area.

4If you receive an IPDS Negative Acknowledgement (NACK) beginning with ’0821’ indicating there are

undefined characters in the job, choose one of the following solutions:

a) Change your application to send only valid characters and control codes.

IPDS Printer and Host Setup Guide AS/400 and iSeries LAN Printing Using the Printer Standard Network Port or MarkNet Internal Print Server

b) Change the Exception Ctrl setting to Sup Undef Char. Using the control panel MENU/Menus,

select Option Card Menu > IPDS MENU > EMULATION > Exception Ctrl. The printer will not send

undefined character NACKs to the host.

5If the job prints, but some characters are printed incorrectly, you should check the default code page setting.

Using the control panel MENU/Menus, select Option Card Menu > IPDS MENU > EMULATION > Default

Codepage. On printers, the next step is to select Codepages A-E or Codepages F-K or Codepages L-Z,

then select the proper code page from these groups. On MFPs, the complete list of code pages appear

beside Default Codepage.

6If the job prints, but some bar codes print in the wrong size, refer to the Bar Code Size option in the IPDS

User’s Guide for more information. Using the control panel MENU/Menus, select Option Card Menu >

IPDS MENU > EMULATION > BARCODE > Bar Code Size.

7Refer to

Chapter 10. Printer Messages and Problems

on page

for additional problem solutions.

8Once the job prints, refer to the IPDS Emulation User’s Guide for information on changing other IPDS MENU

settings.

IPDS Printer and Host Setup Guide AS/400 and iSeries Twinax Printing Using the Adapter for SCS

2. AS/400 and iSeries Twinax Printing Using the

Adapter for SCS

With the optional Card for IPDS/SCS/TNe and the optional Coax/Twinax Adapter for SCS installed, the printer

can receive, process, and print AFP/IPDS print jobs over TCP/IP from the following IBM software:

• PSF/400 V3R1-R3, V3R6-R7, V4R1-R5, V5R1-R4, or greater

Some printers do not support the Coax/Twinax Adapter for SCS. Refer to

“Coax/Twinax Adapter for SCS Sup-

port” [page 53]

to determine if your printer supports the adapter. Note that no MFPs support Twinax printing.

The information below will lead you through the steps for setting up the AS/400, or iSeries, and the printer to

print IPDS jobs over a direct Twinax connection using the optional Coax/Twinax Adapter for SCS. Refer to the

IPDS User’s Guide for detailed instructions on using the control panel to select and change option settings.

Steps

The following steps must be completed to begin printing IPDS jobs.

Configure the Adapter IPDS and SCS Twinax Addresses

Set the Adapter for SCS Twinax Timeout

Select the IPDS Emulation, Bar Code Size, Host Resolution, and Fax Interrupt Settings

Modify the Auto-created Twinax Device Description or Use CRTDEVPRT to Create a Printer Device Description

Verify IPDS Printing

Troubleshooting

Step 1 Configure the Adapter IPDS and SCS Twinax Addresses

When the printer has both the "Card for IPDS and SCS/TNe" and the "Coax/Twinax Adapter for SCS" installed,

it is possible to print IPDS jobs using the IPDS emulation in the Card for IPDS and SCS/TNe and SCS jobs

using the SCS emulation of the Adapter for SCS.

To use both emulations, when you install and configure the option cards, assign a twinax address for the IPDS

device address and a different twinax address for the SCS device address in the Adapter for SCS. This is done

using the SCS DEV.ADDR. and IPDS DEV. ADDR. options as shown below. In our examples, we will give

address 0 to SCS and address 2 to IPDS.

Important:

If the IPDS device address and the adapter SCS device address are the same, the Adapter SCS

device address will be used and the IPDS device address will be ignored. The word DUPLICATE will

display in the control panel.

Be certain to set the correct twinax addresses in the Adapter for SCS for both the SCS device address

and the IPDS device address before physically connecting your printer to the twinax wiring system. If

you were to incorrectly enter the same address used by another device, you would disable that device.

If you do not know your printer's correct address, contact your network administrator.

Step 1A: Configure the Printer Adapter IPDS Device Address - or Disable IPDS Printing

The following options for the Adapter for SCS only appear when the IPDS emulation is detected in the printer.

The IPDS Device Address is used to select the twinax address for the IPDS emulation or to disable the IPDS

emulation.

IPDS Printer and Host Setup Guide AS/400 and iSeries Twinax Printing Using the Adapter for SCS

1From a Ready state, on printers press the MENU button.

2Use the navigation buttons or icons to scroll to Option Card Menu.

3On printers, press the Select button .

4Navigate to SCS MENU 1 (or SCS MENU 2) > IPDS Options > IPDS Dev. Addr.

5Use the navigation buttons or icons to scroll through the values, which include 0-6 and "Disable". Select the

desired value.

Note: If you see the string SCS displayed after one of the numbers, for example "5 SCS", this means

that the number - in this example number 5 - has already been set as the SCS Dev. Addr.

number.

6Save/Submit the value and exit to the Ready page.

Step 1B: If you are using the IPDS emulation, set IPDS Buffer Size

IPDS Buffer Size is used to select the size of the data/command buffer used by the Adapter for SCS when

receiving data/commands from the twinax host. IPDS Buf. Size appears as an option in the printer panel only if

the IPDS Dev. Addr. is enabled (address = 0 - 6).

1Use the control panel MENU as described above to select Option Card Menu > SCS MENU 1 (or SCS

MENU 2) > IPDS Options > IPDS Buf. Size. Select 256 or 1024.

Note: 256 is the recommended value. The 1024 byte buffer has the fastest transfer rate, but it is not

compatible with some older IBM equipment.

2Save the value and exit to the Ready page.

Step 1C: Configure the Printer Adapter SCS Device Address - or Disable SCS Printing

The SCS Device Address is used to select the twinax device address for the adapter SCS emulation or to dis-

able the adapter SCS emulation.

1Use the control panel MENU as described above to select Option Card Menu > SCS MENU 1 (or SCS

MENU 2) > SCS Options > SCS Dev. Addr.

2Use the navigation buttons to scroll through the values, which include 0-6 and "Disable". Select the desired

value.

Note: If the IPDS emulation and the adapter SCS emulation are given the same address, the SCS

emulation in the Adapter for SCS is used and the IPDS emulation is ignored. The word

DUPLICATE will display in the control panel.

3Save the value and exit to the Ready page.

Step 2 Set the Adapter for SCS Twinax Timeout

The Twinax Timeout value specifies the amount of time the printer Adapter for SCS will wait before closing the

connection to the host and allowing non-IPDS jobs to print. The default is 10 (= 30 seconds). Values equal to or

less than 10 give a 30 second timeout; values equal to or more than 11 give a timeout in seconds as specified

in the value used.

To change the Twinax Timeout value:

1Use the control panel MENU as described in Step 1A (page

) to select Option Card Menu > SCS MENU

1 (or SCS MENU 2) > SCS OPTIONS > Twinax Timeout.

IPDS Printer and Host Setup Guide AS/400 and iSeries Twinax Printing Using the Adapter for SCS

2Use the navigation buttons to scroll the display to the desired value - or use the numeric buttons to enter a

value.

3Save the value and return to the Ready screen.

Note: The Option Card Menu > IPDS MENU > EMULATION > IPDS Timeout value is not active when the

printer is connected to a host through an Adapter for SCS card. The IPDS timeout is controlled by the

Twinax Timeout value on the Adapter for SCS card.

Additional Information

Please refer to the Adapter for SCS, Coax/Twinax Connection, Installation and User's Guide which came with

the adapter for a detailed description of other menu settings which affect job formatting.

Step 3 Select the IPDS Emulation, Bar Code Size, Host Resolution, and Fax Interrupt

Settings

It is important to select the correct emulation in the printer IPDS MENU before sending IPDS jobs.

Guidelines for Choosing the IPDS Emulation Setting

The IPDS Emulation, the BAR CODE and Host Resolution options are found in the printer control panel

under MENU > Option Card Menu > IPDS MENU > EMULATION.

1"Resident" is the default setting. If you are replacing a printer that used a Native Emulation setting,

"Resident" is the recommended emulation.

2If you are replacing a printer that used a 4028 Emulation setting, choose the "Resident" Emulation and

change the following settings:

a) Set Bar Code Size to "4028" under BARCODE > Bar Code Size.

b) The recommended Host Resolution setting is "Auto". If you experience printing problems, set Host

Resolution to "300".

3If you are replacing a printer that used a 43xx Emulation setting, choose the "Resident" Emulation and

change the following settings:

a) Set Bar Code Size to "43xx" under BAR CODE > Bar Code Size.

b) The recommended Host Resolution setting is "Auto". If you experience printing problems, set Host

Resolution to "300".

4If you are replacing a printer that used a 3812/3816 Emulation, select the "3812/3816" Emulation. This

emulation only accepts 240 dpi resources (fonts, overlays, etc.) from the host and does not support DBCS

printing.

Refer to the IPDS Emulation User’s Guide for information on these options and other IPDS MENU settings to

format IPDS jobs.

Note: The supported printers do not contain an Advanced Function Common Control Unit (AFCCU).

IPDS Printer and Host Setup Guide AS/400 and iSeries Twinax Printing Using the Adapter for SCS

Step 4 Modify the Auto-created Twinax Device Description or Use CRTDEVPRT to Create

a Printer Device Description

When you let the host auto-create your IPDS device, you will need to alter the following device description

parameters to enable full IPDS printing:

An example of a device description for Twinax printing is shown below. The italicized lines show the parame-

ters which must be changed for sending IPDS jobs. Use CRTDEVPRT to create the device description if you

did not use auto-config on the AS/400.

Note: Examples showing parameters displayed on an AS/400 may be different than the parameters

displayed on your system. Examples are shown with V5R2 parameters.

Example CRTDEVPRT for OS/400 (locally attached printers)

"default values":

Advanced Function Printing AFP *NO

Form Feed FORMFEED *CONT

"altered values":

Advanced Function Printing AFP *YES

Form Feed FORMFEED *AUTOCUT

Example CRTDEVPRT with parameters to change shown in bold.

Device description................DEVD > IPDSPRT

(Note: IPDSPRT is a user defined name.)

Device class......................DEVCLS > *LCL

Device type.......................TYPE > *IPDS

Device model......................MODEL > 0

LAN attachment....................LANATTACH *LEXLINK

Switched line list................SWTLINLST

LAN remote adapter address........ADPTADR

Adapter type......................ADPTTYPE *INTERNAL

Adapter connection type...........ADPTCNNTYP *PARALLEL

Emulated twinaxial device.........EMLDEV

Advanced Function Printing .......AFP > *YES

AFP attachment....................AFPATTACH *WSC

Port number.......................PORT > 2

(Note: Twinax address selected for IPDS printing.)

Switch setting....................SWTSET > 0

Local location address............LOCADR

Auxiliary printer.................AUXPRT

Emulating ASCII device............EMLASCII *NO

Physical attachment...............ATTACH

Online at IPL.....................ONLINE *YES

Attached controller...............CTL > CTL01

Language type.....................LNGTYPE *SYSVAL

Print quality.....................PRTQLTY *STD

Font: FONT

Identifier...................... > 11

Point size...................... *NONE

Form feed.........................FORMFEED > *AUTOCUT

Separator drawer..................SEPDRAWER *FILE

Separator program.................

Library.........................

SEPPGM *NONE

Number of drawers.................NBRDRAWER

Printer error message.............PRTERRMSG *INQ

IPDS Printer and Host Setup Guide AS/400 and iSeries Twinax Printing Using the Adapter for SCS

Message queue.....................MSGQ QSYSOPR

Library......................... *LIBL

Maximum length of request unit....MAXLENRU *CALC

Application type..................APPTYPE *NONE

Activation timer..................ACTTMR > *NOMAX

Inactivity timer..................INACTTMR *ATTACH

SNA pass-through device desc......SNPTDEV *NONE

SNA pass-through group name.......SNPTGRP *NONE

Host signon/logon command.........LOGON *NONE

Pacing ...........................PACING 7

Line speed .......................LINESPEED *TYPE

Word length....................... WORDLEN *TYPE

Type of parity....................PARITY *TYPE

Stop bits.........................STOPBITS *TYPE

Host Print Transform..............TRANSFORM *NO

Manufacturer type and model.......MFRTYPMDL

Paper source 1.................... PPRSRC1 *MFRTYPMDL

Paper source 2....................PPRSRC2 *MFRTYPMDL

Envelope source................... ENVELOPE *MFRTYPMDL

ASCII code page 899 support....... ASCII899 *NO

Maximum pending requests.......... MAXPNDRQS 6

Print while converting............ PRTCVT *YES

Print request timer............... PRTRQSTMR *NOMAX

Form definition................... FORMDF F1C10110

Library......................... *LIBL

Character identifier: CHRID

Graphic character set......... *SYSVAL

Code page...................

Remote location: RMTLOCNAME

Name or address.................

Local location.................... LCLLOCNAME *NETATR

Mode ............................. MODE QSPWTR

User-defined options..............USRDFNOPT *NONE

User-defined object: USRDFNOBJ

Object.......................... > *NONE

Library...................... >

Object type..................... >

Data transform program............USRDTATFM *NONE

Library ........................

User-defined driver program ...... USRDRVPGM *NONE

Library.........................

System driver program............. SYSDRVPGM

Secure connection.................SECURECNN *NO

Validation list...................VLDL *NONE

Library........................

Publishing information: ..........PUBLISHINF

Support duplex................. *UNKNOWN

Support color.................. *UNKNOWN

Pages per minute black......... *UNKNOWN

Pages per minute color......... *UNKNOWN

Location....................... *BLANK

Data streams supported ........ *UNKNOWN

Text 'Description'................ TEXT > 'IPDS PRINTER'

(Note: 'IPDS PRINTER' is user defined text.)

Dependent location name...........DEPLOCNAME *NONE

Example CRTDEVPRT with parameters to change shown in bold.

IPDS Printer and Host Setup Guide AS/400 and iSeries Twinax Printing Using the Adapter for SCS

Step 5 Verify IPDS Printing

If you have completed the steps above to configure the host and printer, you are ready to print your first IPDS

job.

1Send an IPDS job from your host system.

2Observe the printer control panel. When the first job data is received, BUSY should be displayed in the

printer control panel. If the job does not print, go to Step

Troubleshooting

3After the last page of the IPDS job prints, BUSY will remain displayed until the host or printer ends the

session. This is controlled by the Release Timer on the host or by the Twinax Timeout on the Adapter for

SCS.

4You may want to refer to the IPDS Emulation User's Guide to determine if other IPDS MENU settings need

to be changed.

Step 6 Troubleshooting

If the IPDS job does not print, try the following.

1If BUSY is not displayed in the printer control panel or if the printer remains in Ready mode, check to be

sure the printer is connected to the network.
