Lexmark ImageQuick User manual

Technical Reference
November 2001
ImageQuick Option

Edition: November 2001
The following paragraph does not apply to any country where such provisions are inconsistent
with local law: LEXMARK INTERNATIONAL, INC., PROVIDES THIS PUBLICATION “AS IS” WITHOUT
WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE
IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. Some
states do not allow disclaimer of express or implied warranties in certain transactions; therefore, this
statement may not apply to you.
This publication could include technical inaccuracies or typographical errors. Changes are periodically
made to the information herein; these changes will be incorporated in later editions. Improvements or
changes in the products or the programs described may be made at any time.
References in this publication to products, programs, or services do not imply that the manufacturer
intends to make these available in all countries in which it operates. Any reference to a product, program,
or service is not intended to state or imply that only that product, program, or service may be used. Any
functionally equivalent product, program, or service that does not infringe any existing intellectual property
right may be used instead. Evaluation and verification of operation in conjunction with other products,
programs, or services, except those expressly designated by the manufacturer, are the user’s
responsibility.
Lexmark, Lexmark with diamond design, and Optra are trademarks of Lexmark International, Inc.,
registered in the United States and/or other countries.
Drag’N’Print and ImageQuick are trademarks of Lexmark International, Inc.
PCL®is a registered trademark of the Hewlett-Packard Company. PCL is Hewlett-Packard Company’s
designation of a set of printer commands (language) and functions included in its printer products. This
printer is intended to be compatible with the PCL language. This means the printer recognizes PCL
commands used in various application programs, and that the printer emulates the functions
corresponding to the commands.
PostScript®is a registered trademark of Adobe Systems Incorporated. PostScript X is Adobe Systems’
designation of a set of printer commands (language) and functions included in its software products. This
printer is intended to be compatible with the PostScript X language. This means the printer recognizes
PostScript X commands used in various application programs, and that the printer emulates the functions
corresponding to the commands.
© Copyright 2001 Lexmark International, Inc.
All rights reserved.
UNITED STATES GOVERNMENT RESTRICTED RIGHTS
This software and documentation are provided with RESTRICTED RIGHTS. Use, duplication or disclosure
by the Government is subject to restrictions as set forth in subparagraph (c)(1)(ii) of the Rights in Technical
Data and Computer Software clause at DFARS 252.227-7013 and in applicable FAR provisions: Lexmark
International, Inc., Lexington, KY 40550.

iii
Table of
contents
Step 1: Introducing the ImageQuick Option . . . . . . . . . . . . 5
Step 2: Supported image formats . . . . . . . . . . . . . . . . . . . . 6
TIFF support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Other supported formats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
PostScript extensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Step 3: Image printing system performance . . . . . . . . . . 16
Step 4: PBM tag descriptions . . . . . . . . . . . . . . . . . . . . . . 17
About PBM language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
PBM file transfer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
PBM tag descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
PBM file and folder access attributes . . . . . . . . . . . . . . . . . . .24
Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Printer Bookmarks Manager . . . . . . . . . . . . . . . . . . . . . . . . . .25
Step 5: Printer Bookmarks parameters . . . . . . . . . . . . . . 26
Folder capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Flash space . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26

iv
Step 6: PJL tag descriptions . . . . . . . . . . . . . . . . . . . . . . . 28
LPULLPRINT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
LEXECNPA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Step 7: Operator panel function . . . . . . . . . . . . . . . . . . . . 29
Image Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
Scaling settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
AutoFit Algorithm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Color image details . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33

5
Introducing the ImageQuick Option
Introducing the
ImageQuick Option
The ImageQuick™option provides seamless integration of image
printing capabilities into the Lexmark RIP architecture. With the option
installed, your printer automatically prints files in addition to any
standard Printer Control Language (PCL) emulation or PostScript
emulation jobs.
Unlike some image file processing options, the ImageQuick option is
not a translator; therefore, there is no impact to throughput of
standard PCL or PostScript emulation jobs. It adds image format
processing capabilities as fully integrated extensions to your printer.
With the option installed, the printer automatically detects image
formats in the incoming data stream and processes them.
The printer automatically detects and identifies images on a job
boundary when a PJL UEL is received or when the printer is idle. For
network ports, it also occurs when a connection is opened or closed.
It is possible to send several identical format images without an
intervening job boundary. The images print correctly and are treated
as a single job for job cancel and tracking purposes. Mixing image
types in the same manner is not supported and causes an error after
the first image prints.
Disabling PostScript datastream sensing for a port also disables
image detection. Setting the PostScript systemparam /Filtering to
/None has the same effect.

6Supported image formats
Supported image formats
This section focuses on details not covered in the Overview section of
the ImageQuick option User’s Guide.
TIFF support The ImageQuick option supports the baseline TIFF file format as
described in the TIFF Revision 6.0 specification, published by the
Adobe Developers Association. The TIFF format allows for image
compression by numerous methods.
The option supports the following compression formats:
•TIFF RGB full color images
•TIFF palette full color images
•TIFF tiled images
•TIFF grayscale images (monochrome)
•TIFF CCITT Group 4
•TIFF CCITT Group 3 2D
•TIFF CCITT Group 3 1D
•TIFF Type 2
•TIFF PackBits
•TIFF Uncompressed
•TIFF LZW
Note: The ImageQuick option
does not support JBIG
compression or IPCL TIFF
segments.
CCITT Group 3 and 4 formats are often referred to as “fax
compression” methods. They were designed to be used by fax
machines for electronic data transmission. However, they are also
popular methods for storing documents electronically, particularly
Group 4. TIFF Type 2 is also called “Modified Huffman run-length
encoding,” and is a variant of CCITT Group 3. TIFF PackBits is a
simple form of run-length encoding, which stores data as sequences
of uncompressed bytes or as repeat-counts.

7
Supported image formats
The printer recognizes a file as a TIFF image if the file begins with
0x4d 0x4d 0x00 0x2a or 0x49 0x49 0x2a 0x00.
The following TIFF fields are accepted by the ImageQuick option. All
other tags are ignored.
Tag name Required in Image File directory? Value restrictions
ImageWidth Yes None
ImageLength Yes None
Compression Yes 1 (Uncompressed)
2 (CCITT 1D)
3 (Group 3 Fax)
4 (Group 4 Fax)
5 (LZW)
32773 (PackBits)
PhotometricInterpretation Yes 0 (WhiteIsZero)
1 (BlackIsZero)
2 (RGB)
3 (RGB Palette)
5 (CMYK)
Xresolution Yes 0 is mapped to 96 dpi.
Yresolution Yes 0 is mapped to 96 dpi.
StripOffsets* Yes None
StripByteCounts* Yes None
RowsPerStrip* Yes None
TileWidth No None
TileLength No None
TileOffsets* No None
TileByteCounts* No None
BitsPerSample No Defaults to 1.
FillOrder No Defaults to 1.
SamplesPerPixel No Defaults to 1.
T4Options No Only bit 0 and bit 2 honored.
ResolutionUnit No Defaults to 2 (inches).
Predictor No Defaults to 1.

8Supported image formats
*If TileWidth and TileLength are present, then TileOffsets/
TileByteCounts must be present. Otherwise, StripOffsets/
StripByteCounts/RowsPerStrip must be present. The Orientation
field is ignored.
If ExtraSamples is nonzero, the extra samples are discarded for each
pixel. Associated alpha handling is not supported and is ignored.
Other supported
formats In addition to TIFF, the ImageQuick option supports these document
and image formats:
•JPEG baseline
•JPEG progressive
•GIF87a
•GIF89a
•PNG
•BMP
•Monochrome PCX Compression
•DCX, which is based on monochrome PCX
•HTML 4.0 (except animated GIF files, DHTML, and Java
Script)
•PDF 1.3 for Adobe Acrobat 4
•PDF 1.2 for Adobe Acrobat 3
Colormap Required for Palette image. None
ExtraSamples No None
PlanarConfiguration No Must be 1 (chunky) if
SamplesPerPixel > 1.
Tag name Required in Image File directory? Value restrictions

9
Supported image formats
The following rules are used to recognize file types.
JPEG The ImageQuick option supports direct printing of both color and
monochrome JPEG format images including both baseline and
progressive encodings. It does not support lossless JPEG images.
The printer recognizes a file as a JPEG image if it has an HTTP
Content-type of image/jpeg, or if the file begins with 0xff 0xd8.
GIF The ImageQuick option supports direct printing of both color and
monochrome GIF format images, including both GIF87a and GIF89a.
The printer recognizes a file as a GIF image if it has an HTTP
Content-type of image/gif, or if the file begins with either GIF87a or
GIF89a.
PNG The ImageQuick option supports direct printing of both color and
monochrome PNG format images.
The printer recognizes a file as a PNG image if it has an HTTP
Content-type of image/png, or if the file begins with
0x89 0x50 0x4e 0x47 0x0d 0x0a 0x1a 0x0a.
BMP The ImageQuick option supports direct printing of both color and
monochrome Windows BMP format images including versions 2
(Win2x), 3 (Win3x and WinNT), and 4 (Win95). Version 1 is not
supported.
The printer recognizes a file as a BMP image if it has an HTTP
Content-type of image/bmp, or if the file begins with BM.
PCX The ImageQuick option supports direct printing of bitonal
monochrome PCX format images.
The printer recognizes a file as a PCX image if the file begins with
0x0a, followed by a value less than 0x06, but not equal to 0x01,
followed by 0x01.

10 Supported image formats
DCX The ImageQuick option supports direct printing of bitonal
monochrome DCX format images.
The printer recognizes a file as a DCX image if the file begins with
0xb1 0x68 0xde 0x3a.
HTML The ImageQuick option supports numerous character set encodings
within the HTML emulator. These encodings are utilized by either of
two methods.
1The HTTP Response Header Field
The printer recognizes a file as an HTML image if it has an
HTTP-Content type of text/html; charset=xxx.
Note: The HTTP Response
Field is not usually accessible
for setting by the user.
2The HTML Meta tag
The printer recognizes a file as an HTML image if it has the
following tag:
<META HTTP-EQUIV=”Content-type” CONTENT=”text/
html; charset=xxx”>
In the given methods, xxx indicates the desired character set
encoding:
•ISO 8859-1
•ISO 8859-2
•ISO 8859-5
•ISO 8859-7
•ISO 8859-9
•ISO 8859-10
•ISO 8859-15
•Windows 1250
•Windows 1251
•Windows 1252 (default)
•Windows 1253
•Windows 1254
•Windows 1257

11
Supported image formats
PostScript
extensions
Userparams and
systemparams The following keys have been added to the userparams and
systemparams dictionaries to let the user modify the Image Menu
options from a PostScript job. The new keys, their possible values,
and the corresponding Image Menu values are shown below.
The Values in the table are integers.
When set using the setsystemparams operator, the values persist
from job to job, like when they are set using the Image Menu.
When set using the setuserparams operator, the values only persist
until reset or the end of the job. Changes to userparams are subject
to Save and Restore. The default userparams at the beginning of a
job are equal to the current systemparams values.
Key Value Image Menu value
ImageAutoFit 0 Off
1On
ImageInvert 0 Off
1On
ImageScaling 0 Anchor Center
1 Fit Height/Width
2 Fit Height
3FitWidth
4 Not used
5 Anchor TopLeft
6BestFit
ImageOrientation 0 Portrait
1 Landscape
2ReversePortrait
3 Reverse Landscape

12 Supported image formats
Userparams only persist for a single job:
%!PS
<</ImageInvert 1>> setuserparams
Systemparams are written into NV and persist across power cycles:
%!PS
true 0 startjob
<</ImageScaling 2>> setsystemparams
Network files The file operator has been extended to pull files from a Web server
using HTTP. It will read any type of file:
(%net%http://www.foo.com/myfile)(r) file
Imagetiff and
directimage operators The imagetiff operator lets the user process TIFF, PCX, and DCX
images within a PostScript job. Similarly, the directimage operator
processes GIF, JPEG, PNG, and BMP images. The format of the
operators is:
file imagetiff -
file directimage -
Where file is a file object that contains the image data.
After processing, the file is popped off of the operand stack.
Do not change the PostScript current transformation matrix prior to
calling imagetiff or directimage. Doing so may have unpredictable
results. Path operators like moveto have no effect.
Binary data requirement Processing images within PostScript using the %stdin file requires
that the data be received over a binary communications port.
Note: Turning on binary mode
for a port deactivates emulation
sniffing.
The following PostScript turns on binary mode for the port it is sent
over:
%!PS
true 0 startjob
currentsystemparams /CurInputDevice get
<< /Filtering /None >> setdevparams

13
Supported image formats
The following PostScript restores the non-binary mode for a port it is
sent over:
%!PS
true 0 startjob
currentsystemparams /CurInputDevice get
<< /Filtering /InterpreterBased >> setdevparams
Imageshowpage and
Imagesetclip
procedures
Two user-definable PostScript procedures let you customize direct
image printing. They let you include time stamps and watermarks,
and perform other operations. Imagesetclip reserves space for these
marks by reducing the printable area on the page. Images do not
exceed these bounds. Imageshowpage applies the actual marks
after the image is rendered.
imagesetclip
At the start of processing of each image, the paper selection,
orientation, and scaling settings are resolved. These settings are
dependent upon the printable area, which is modified by the
imagesetclip PostScript procedure. This is a user-definable procedure
that is executed once for each installed paper source (when AutoFit is
on) and once after the paper source is selected. It is always run prior
to scaling and orientation resolution. Imagesetclip changes the
clippath and makes marks on the page, but it should not be used to
keep track of the image count. Scaling should not be done here since
it adversely affects normal scaling and orientation.
Note: Do not enlarge the
clipping path beyond the page or
the image may be incorrectly
scaled.
imageshowpage
After an image is rendered the imageshowpage procedure is
executed. If the procedure is not defined, a showpage is done.
Watermarks and page counting are two anticipated uses.
Both procedures are optional, but if present, they cannot do
exitservers or unmatched save/restores. The stacks must also be left
unchanged.

14 Supported image formats
The following example demonstrates how to add an annotation to all
pages within a job. It requires that PostScript setup code be
prepended to the job, and cleanup code be appended to the job. In
the following example, imagesetclip increases the upper and lower
margins by 50 units. Imageshowpage prints a message with a border
at the bottom and top of the page. Since the clippath was reduced, an
initgraphics is done to allow drawing into the previously protected
area.
Setup code to prepend to the job:
%!
true 0 startjob
/imagesetclip {10 dict begin clippath pathbbox /ury
exch def /urx exch def /lly exch def /llx exch def /lly
lly 50 add def /ury ury 50 sub def
llx lly urx llx sub ury lly sub rectclip end}def
/imageshowpage {
10 dict begin
% Print lower message
initgraphics clippath pathbbox pop pop 10 add exch 10
add exch translate
/Helvetica 20 selectfont newpath 0 0 moveto (Business
use only bottom message)
dup false charpath pathbbox
/ury exch def /urx exch def /lly exch def /llx exch def
% draw a box around the message
llx 5 sub lly 5 sub urx llx sub 10 add ury lly sub 10
add 2 setlinewidth rectstroke
newpath 0 0 moveto show
% Print upper message
initgraphics clippath pathbbox 32 sub 3 index 10 add
exch translate pop pop pop
/Helvetica 20 selectfont newpath 0 0 moveto (Business
use only upper message)
dup false charpath pathbbox
/ury exch def /urx exch def /lly exch def /llx exch def
% draw a box around the message
llx 5 sub lly 5 sub urx llx sub 10 add ury lly sub 10
add 2 setlinewidth rectstroke
newpath 0 0 moveto show
showpage end}def

15
Supported image formats
Cleanup code to append to the job:
<esc>%-12345X%!
% Undefine the imagesetclip and imageshowpage
procedures if they exist.
true 0 startjob % make procedures persist across job
boundaries
/imagesetclip where { /imagesetclip undef} if
/imageshowpage where { /imageshowpage undef} if
Note: For an example of the
imagesetclip and
imageshowpage procedures,
see the imageshowpage_ex.ps
file on your CD.
%net% files The file operator has been extended to open and read HTTP URLs.
Prepending %net% to a URL lets it open as a read-only, seekable file.
The HTTP header is included in the file data, but the initial file position
is set to discard it. This means that no special action needs to be
performed.
Example:
(%net%http://www.lexmark.com/)(r)file

16 Image printing system performance
Image printing system
performance
Image formats are commonly used to store electronic copies of
documents. The standard procedure for printing these stored files
requires that a host computer read the files into an application, format
the images in PCL emulation or PostScript emulation languages, and
then send them to the printer.
With the ImageQuick option installed, you can print image format files
in their stored format. It is no longer necessary to convert image files
to PCL or PostScript emulations. This reduces the host computer's
load substantially.

17
PBM tag descriptions
PBM tag descriptions
About PBM
language The ImageQuick option provides support for an XML tag language
called Printer Bookmarks Manager (PBM), through which the Printer
Bookmarks are specified to the printer. This section defines each of
the tags and their attributes that comprise this language.
The PBM emulator supports the following tags:
•DOCTYPE
•BOOKMARKS
•FOLDER
•ITEM
•DEFAULT
•PASSWORD
•SETPASSWORD
•SERVER
•RELOAD
A PBM file that contains no known tags causes nothing to happen
within the printer.
PBM tags and their attributes are case insensitive.
The general structure of a PBM file is:
<!DOCTYPE LEXMARK_PBM>
…
…SERVER, RELOAD, SETPASSWORD, PASSWORD tags…
…
<BOOKMARKS>
…
…ITEM, FOLDER, DEFAULT tags…
…
</BOOKMARKS>

18 PBM tag descriptions
PBM file transfer The ImageQuick Printer Bookmarks Manager software uses the
HTTP GET method to load a printer’s bookmarks configuration into
the application. The URL is as follows:
http://www.printername/printer/pbm/bookmarks.pbm
where printername is the name or IP address of the printer on the
network.
Printer Bookmarks Manager uses the HTTP PUT method, with the
same URL, to save bookmarks to the printer. The printer also accepts
a PBM file sent as a job over any print channel. Because of this,
Printer Bookmarks Manager lets you manually create a PBM file or
save a PBM file to disk within Printer Bookmarks Manager, then
transfer the file to the printer.
PBM tag
descriptions The following sections describe the format and function of the PBM
tags supported by the ImageQuick option.
DOCTYPE The DOCTYPE tag is required at the beginning of a PBM file. Do not
put information preceding this tag except for white space. The tag
form is:
<!DOCTYPE LEXMARK_PBM>
If the tag is not exactly like the preceding example the PBM emulator
does not recognize the file as a PBM file and the tag is flushed.
BOOKMARKS The required BOOKMARKS tag and the closing
/BOOKMARKS tag surround the section of the file which defines the
bookmarks tree. Only ITEM, FOLDER, and DEFAULT tags are
allowed within the BOOKMARKS element.
For backward compatibility, the <BOOKMARKS>...
</BOOKMARKS> tags may be omitted if the file contains only
FOLDER, ITEM, and DEFAULT tags.

19
PBM tag descriptions
The tag form is:
<BOOKMARKS>
The close tag:
</BOOKMARKS>
indicates that no more bookmarks are found in the file. If ITEM,
FOLDER, or DEFAULT tags are found outside of the BOOKMARKS
tags, then the file is flushed.
To erase the bookmarks in a printer, send the following:
<!DOCTYPE LEXMARK_PBM>
<BOOKMARKS>
</BOOKMARKS>
For examples, see the \examples\EraseBookmarks.pbm file on
your CD.
FOLDER The FOLDER tag is optional and defines a folder (or directory-like)
structure in the BOOKMARKS menu on the printer's operator panel.
The tag form is:
<FOLDER name = “….”access = “…” >
The 'name' attribute is a string (up to 15 characters) that defines the
name that appears on the printer's operator panel to identify this
particular folder.
The 'access' attribute is a string that defines whether the FOLDER is
served, public, or private. A description of this attribute follows the tag
definitions.
FOLDERs without an access attribute are public.
All ITEMs and FOLDERs defined after this tag and before the
corresponding </FOLDER> tag are said to reside in this folder.
FOLDERs nest up to a depth of 255 and hold a maximum of 176
ITEMs and/or FOLDERs in a FOLDER. If these numbers are
exceeded, the extra ITEMs or FOLDERs are ignored.
The required /FOLDER tag closes the FOLDER tag. A FOLDER tag
without a corresponding /FOLDER tag causes the file to be flushed.

20 PBM tag descriptions
ITEM The optional ITEM tag defines items that are pulled from the network
and printed when selected from the BOOKMARKS menu on the
operator panel.
The tag form is:
<ITEM name = “….”url = “….”npa = “….”access = “…” >
where ‘name' is the string (up to 16 characters) that defines the name
that appears on the printer's operator panel to identify this particular
ITEM. The 'url' attribute is a string of up to 4096 characters that
identifies the URL that this bookmarked item is to be pulled from. The
'npa' attribute is a hex-encoded NPA Variable Write (Current NV Only)
command that defines the job attributes that this item is to be printed
with.
The 'access' attribute is a string that defines whether the ITEM is
served, public, or private. A description of this attribute follows the tag
definitions.
ITEMs without an access attribute are public.
The PBM firmware does not check the validity of the NPA attribute.
If the name attribute exceeds 16 characters it is truncated.
The following characters are not allowed within the URL attribute and
are converted by the Printer Bookmarks Manager Application:
•Space - Converted to %20 prior to the query character and to
'+' afterward.
•Backslash - Converted to Forward Slash (/) prior to the query
and left alone afterward.
•Double quote - Converted to %22.
The PBM firmware does not check the validity of the URL. If it is
invalid, then when it is passed to the INA, it will most likely result in an
error.
The /ITEM tag is optional and closes the ITEM tag. No tags are
expected between the two, and an unclosed ITEM tag does not
generate an error.
The tag form is:
</ITEM>
