Networking
General networking
Networking overview
A network is a collection of devices such as computers, printers, Ethernet hubs, wireless access points, and routers
connected together for communication through cables or through a wireless connection. A network can be either
wired, wireless, or designed to have both wired and wireless devices.
Devices on a wired network use cables to communicate with each other.
Devices on a wireless network use radio waves instead of cables to communicate with each other. For a device to
be able to communicate wirelessly, it must have a wireless print server attached or installed that enables it to receive
and transmit radio waves.
Common home network configurations
For desktop computers, laptops, and printers to communicate with each other over a network, they must be
connected by cables and/or have wireless network adapters built in or installed in them.
There are different ways a network can be set up. Five common examples appear below.
Note: The printers in the following diagrams represent Lexmark printers with Lexmark internal print servers built in
or installed in them so that they can communicate over a network. Lexmark internal print servers are devices made
by Lexmark to enable Lexmark printers to be connected to wired or wireless networks.
Wired network example
•A computer, a laptop, and a printer are connected by Ethernet cables to a hub, router, or switch.
•The network is connected to the Internet through a DSL or a cable modem.
Internet
Wireless network examples
Four common wireless networks appear below:
•Scenario 1: Laptop and printer connected wirelessly with Internet
•Scenario 2: Computer, laptop, and printer connected wirelessly with Internet
•Scenario 3: Computer, laptop, and printer connected wirelessly without Internet
•Scenario 4: Laptop connected wirelessly to printer without Internet
31

Scenario 1: Laptop and printer connected wirelessly with Internet
•A computer is connected to a wireless router by an Ethernet cable.
•A laptop and a printer are connected wirelessly to the router.
•The network is connected to the Internet through a DSL or a cable modem.
Internet
Scenario 2: Computer, laptop, and printer connected wirelessly with Internet
•A computer, a laptop, and a printer are connected wirelessly to a wireless router.
•The network is connected to the Internet through a DSL or a cable modem.
Internet
32

Scenario 3: Computer, laptop, and printer connected wirelessly without Internet
•A computer, a laptop, and a printer are connected wirelessly to a wireless access point.
•The network has no connection to the Internet.
Scenario 4: Laptop connected wirelessly to printer without Internet
•A laptop is directly connected wirelessly to a printer without going through a wireless router.
•The network has no connection to the Internet.
What information do I need and where do I find it?
This printer may contain an internal wireless print server, which allows the printer to be used on a wireless network.
You need the following settings from your existing wireless network:
•The network name, also known as the SSID
•The wireless mode (the type of wireless network you are using, either infrastructure or ad hoc)
•The type of security used on the network (WEP, WPA, or WPA2)
•Any applicable security keys or passwords used with the network security encryption type
Note: You must know this information in order to properly set up the printer for use on the wireless network. To
obtain these settings, see the documentation that came with your wireless router or consult the person who set up
your wireless network.
Finding the MAC address
Most network equipment has a unique hardware identification number to distinguish it from other devices on the
network. This is called the Media Access Control (MAC) address.
If your printer has a factory installed internal wireless print server, the MAC address is a series of letters and numbers
located on the back of your printer.
33

If you purchased the internal wireless print server separately, the MAC address appears on an adhesive label that
came with the wireless print server. Attach the adhesive label to your printer so you will be able to find the MAC
address when you need it.
UAA: XX XX XX XX XX XX
Note: A list of MAC addresses can be set on a router so that only devices with matching MAC addresses can be
allowed to operate on the network. This is called MAC filtering. If MAC filtering is enabled in your router and you
want to add a printer to your network, the MAC address of the printer must be included in the MAC filter list.
Printing a network setup page
A network setup page lists your network configuration settings.
Note: You can print a network setup page only when an internal wireless print server is installed in the printer.
To print a network setup page:
1From the control panel of the printer, press or repeatedly until Setup is highlighted.
2Press .
3Press or repeatedly until Network Setup is highlighted.
4Press .
5Press or repeatedly until Print Network Setup Page is highlighted.
6Press
A network setup page prints.
Sharing a printer in a Windows environment
1Prepare the computers to share the printer.
aMake all computers printing to the printer accessible through Network Neighborhood by enabling File and
Print Sharing. See the Windows documentation for detailed instructions.
bInstall the printer software on all computers that will print to the printer.
2Identify the printer.
34

On the computer that is attached to the printer:
aClick Start Settings Printers or Printers and Faxes.
bRight-click the Lexmark 4800 Series icon.
cClick Sharing.
dClick Shared As, and give the printer a distinctive name.
eClick OK.
3Locate the printer from the remote computer.
Note: The remote computer is the one that is not attached to the printer.
Windows 2000 or Windows XP users only:
aClick Start Settings Printers and Faxes.
bRight-click the Lexmark 4800 Series icon.
cClick Properties.
dClick the Ports tab, and then click Add Port....
eSelect Local Port, and then click New Port....
fEnter the Universal Naming Convention (UNC) Port name which consists of the server name and the
distinctive printer name that was specified in step 2 on page 34. The name should be in the form \\server
\printer.
gClick OK.
hClick Close on the Printer Ports dialog box.
iMake sure the new port is selected on the Ports tab, and then click Apply.
The new port is listed with the printer name.
jClick OK.
Finding a printer/print server located on remote subnets
The printer software CD can automatically find the printers that are located on the same network as the computer.
If the printer and print server are located on another network (called a subnet), you must manually enter an IP address
during printer software installation.
Wireless networking
Finding IP addresses
An IP address is a unique number used by devices on an IP network to locate and communicate with each other.
Devices on an IP network can only communicate with each other if they have unique and valid IP addresses. A
unique IP address means no two devices on the same network have the same IP address.
How to locate a printer IP address
You can locate the printer IP address by printing out the printer network setup page. For more information, see
“Printing a network setup page” on page 34.
How to locate a computer IP address
1Do one of the following:
•In Windows Vista, click All Programs Accessories Command Prompt.
•In Windows XP, click Start Programs or All Programs Accessories Command Prompt.
2Type ipconfig.
35

3Press Enter.
The IP address appears as four sets of numbers separated by periods, such as 192.168.0.100.
Assigning an IP address
An IP address may be assigned by the network using DHCP. The print object, created at the end of the installation,
sends all print jobs across the network to the printer using this address.
Many networks have the ability to automatically assign an IP address. Auto-IP is the ability for individual devices to
assign themselves a unique IP address. Most networks use DHCP to assign addresses.
During the Direct IP printing installation of printer software, the IP address is visible in the printer list only as it is
being assigned. The print object that is created in the Printers folder of the operating system will reference the MAC
address of the printer in the port name.
If the IP address is not automatically assigned, you can try manually entering an address after selecting your printer
from the available list.
Configure IP address
If you have lost communication with the printer over a network, select Use DHCP to reestablish communication with
the printer.
You must assign an IP address in any of the following situations:
•You manually assigned IP addresses for the other network devices.
•You want to assign a specific IP address.
•You move the printer to a remote subnet.
•The printer is listed as Unconfigured in the Configuration Utility.
Contact your system support person for more information.
Finding the signal strength
Wireless devices have built-in antennas that transmit and receive radio signals. The signal strength listed on the
printer network setup page indicates how strongly a transmitted signal is being received. Many factors can affect
the signal strength. One factor is interference from other wireless devices or even other devices such as microwave
ovens. Another factor is distance. The farther two wireless devices are from each other, the more likely it is that the
communication signal will be weaker.
Installing the printer on a network
Follow the instructions for the networking method you want to use. Make sure the selected network is set up and
working properly, and that all relevant devices are turned on. For more information on your specific network, see
your network documentation or consult the person who set up the network.
Sharing the printer on a network
Sharing the printer on the network (on the host computer)
Windows Vista users only:
1For more information, see the setup information that came with your printer.
2Click Start icon Control Panel Printers.
3Right-click your printer icon, and select Sharing.
4Click Change sharing options.
5Click Continue.
36

6Click Share this printer, and assign a name to your printer.
7Follow the directions on the computer screen until installation is complete.
Windows 2000 or Windows XP users only:
1For more information, see the setup information that came with your printer.
2Click Start Settings Printers.
3Right-click your printer icon, and select Sharing.
4Click Shared as, and assign a name to your printer.
5Follow the directions on the computer screen until installation is complete.
Installing the shared printer on other network computers (on the client computers)
Using the peer-to-peer method Using the point-and-print method
1Go to a network computer that you want to enable
to print to the shared printer.
2Insert the printer software CD.
3Agree to the license agreement, and then click
Next.
4Select Manual Setup.
5From the Network Printer Setup dialog, select the
Peer-to-Peer client option, and then click Next.
6Select the appropriate printer from the list, and then
click Next.
7Select the software you want to install, and then click
Next.
8When setup is complete, click Finished.
9Repeat this procedure for each network computer
you want to access the shared printer.
1Go to a network computer that you want to enable to
print to the shared printer.
2Browse the Network Neighborhood until you find the
name of the shared printer assigned in step 4 on
page 37.
3Right-click the printer icon, and select Open or
Connect.
4This will copy a subset of the printer software from
the host computer. A printer object will be created in
the Printers folder of the client.
Configure network printers
Configure
To configure a network printer, select a printer from the list in the window. Click Configure to assign the printer an
Internet Protocol (IP) address. Contact your system support person for more information.
Add printers
Specify remote subnets that may have direct network attached printers. If the software detects a direct network
attached printer, you must first highlight the printer in the window, and then click Configure to manually assign an
IP address to the printer. Contact your system support person for more information.
Note: The software does not automatically configure printers found on remote subnets.
Refresh
Click Refresh to have the Configuration Utility automatically search to find and configure newly added printers.
37

Types of wireless networks
Networks can operate in one of two modes: infrastructure or ad hoc. Lexmark recommends setting up a network in
infrastructure mode using the installation CD that came with the printer.
A wireless network where each device communicates with others through a wireless access point (wireless router)
is set up in infrastructure mode. All devices must have valid IP addresses and share the same SSID and channel.
In addition, they must share the same SSID and channel as the wireless access point (wireless router).
A simple type of wireless network is one where a PC with a wireless adapter communicates directly with a printer
equipped for wireless networking. This mode of communication is called ad hoc. A device in this type of network
must have a valid IP address and be set to ad hoc mode. The wireless print server must also be configured with the
same SSID and channel.
Infrastructure Ad hoc
Characteristics
Communication Through wireless access point (wireless
router)
Directly between devices
Security More security options
Range Determined by range and number of
access points
Restricted to range of individual devices
on network
Speed Usually faster Usually slower
Requirements for all
devices on the network
Unique IP address for each
device
Yes Yes
Mode set to Infrastructure mode Ad hoc mode
Same SSID Yes, including the wireless access point
(wireless router)
Yes
Same channel Yes, including the wireless access point
(wireless router)
Yes
Infrastructure mode is the recommended setup method because it has:
•Increased network security
•Increased reliability
•Faster performance
•Easier setup
Tips for using network adapters
•Make sure the adapter connections are secure.
•Make sure the computer is turned on.
•Make sure you entered the correct IP address.
38

Advanced wireless setup
Creating an ad hoc wireless network using Windows
The recommended way to set up your wireless network is to use a wireless access point (wireless router). A network
set up this way is called an infrastructure network. If you have an infrastructure network in your home, you should
configure your printer for use on that network.
If you don't have a wireless access point (wireless router) or would like to set up a standalone network between your
printer and a computer with a wireless network adapter, you can set up an ad hoc network.
For Windows Vista users
1Click Control Panel Network and Internet.
2Under Network and Sharing Center, click Connect to a Network.
3In the Connect to a Network dialog, click Set up a wireless ad-hoc (computer-to-computer) network, and
then click Next.
4Follow the instructions in the “Set up a wireless ad hoc network” wizard. As part of the setup:
aCreate a network name or SSID for the network between the computer and your printer.
bWrite the name of your network in the space provided. Be sure to use the exact spelling and capitalization.
cGo to the Security Type drop-down, choose WEP, and create a security key (or password).
Note: WEP passwords must be either 5 or 13 characters.
dWrite the password for your network in the space provided. Be sure to use the exact spelling and
capitalization.
Windows Vista will enable the ad hoc network for you. It will appear in the “Connect to a network” dialog under
available networks, indicating that the computer is configured for the ad hoc network.
5Close the Control Panel and any remaining windows.
6Insert the printer CD into the computer and follow the direction for wireless installation.
7When the available networks are displayed, provide the network name and the security information you created
in step 4. The installer will configure the printer for use with the computer.
8Store a copy of your network name and security information in a safe place for future reference.
For Windows XP users
1Click Start Settings Control Panel Network Connections.
2Right-click Wireless Network Connections.
3If Enable appears in the pop-up menu, click it.
Note: If Enable does not appear, your wireless connection is already enabled.
4Right-click the Wireless Network Connection icon.
5Click Properties.
6Click the Wireless Networks tab.
Note: If the Wireless Networks tab does not appear, your computer has third-party software that controls your
wireless settings. You must use that software to set up the ad hoc wireless network. For more information, see
the documentation for that software to learn how to create an ad hoc network.
39

7Select the Use Windows to configure my wireless network settings check box.
8Under Preferred Networks, delete any existing networks.
aClick the network to be removed.
bClick the Remove button.
9Click Add to create an ad hoc network.
10 In the Network Name (SSID) box, type the name you want to give your wireless network.
11 Write down the network name you chose so you can refer to it when running the wireless setup. Make sure you
copy it down exactly, including capital letters.
12 If Network Authentication appears in the list, select Open.
13 In the Data encryption list, select WEP.
14 If necessary, deselect the The key is provided for me automatically check box.
15 In the Network Key box, type in a security code.
16 Write down the security code you chose so you can refer to it when running the wireless setup. Make sure you
copy it down exactly, including any capital letters.
Note: For more information about passwords (security keys), see “Check your security keys” in the “Wireless
troubleshooting” section of the “Troubleshooting” chapter.
17 Type the same security code in the Confirm network key box.
18 Select the This is a computer-to-computer (ad hoc) network; wireless access points are not used. check
box.
19 Click OK twice to close the two open windows.
20 It may take a few minutes for your computer to recognize the new settings. To check on the status of your
network:
aRight-click the Wireless Network Connections icon.
bSelect View Available Wireless Networks.
•If the network is listed but the computer is not connected, select the ad hoc network and then click the
Connect button.
•If the network does not appear, wait a minute and then click the Refresh network list button.
21 Click Programs or All Programs Lexmark 4800 Series.
22 Click Wireless Setup Utility.
Note: You may be prompted to connect the printer to the computer again using the installation cable as part of
the setup process.
23 Follow the prompts on the computer screen.
24 Store your network name and security code in a safe place for future reference.
Adding a printer to an existing ad hoc wireless network using Windows
1Click Programs or All Programs Lexmark 4800 Series.
2Click Wireless Setup.
3Follow the instructions on the computer screen.
40

Troubleshooting
If you set up your printer on a wireless network, make sure:
•The wireless network is working properly.
•The computer and printer are both connected to the same wireless network.
•The printer is within the range of the wireless network. The effective range for optimal performance is generally
100–150 feet.
•The printer is located away from other electronic devices that may interfere with the wireless signal.
•The power supply is connected to the printer, and is lit.
•The Wi-Fi indicator light is green.
•The printer driver is installed on the computer from which you are performing a task.
•The correct printer port is selected.
Setup Troubleshooting
Incorrect language appears on the display
These are possible solutions. Try one of the following:
Change the language selection during initial setup
After you select a language, Language appears again on the display. To change the selection:
1Press or repeatedly until the language you want appears on the display.
2Press to save.
Select a different language after initial setup
1From the control panel, press or repeatedly to choose Setup.
2Press .
3Press or repeatedly to choose Change Printer Default Settings.
4Press .
5Press or repeatedly to choose Language.
6Press .
7Press or repeatedly until the language you want appears on the display.
8Press to save and exit.
Note: If you cannot understand the language on the display, see “Resetting the printer to factory default settings”
on page 57.
Power button is not lit
These are possible solutions. Try one or more of the following:
Press power button
Make sure the printer is on by pressing .
101

Disconnect and reconnect the power cord
1Disconnect the power cord from the wall outlet, and then from the printer.
2Plug the cord all the way into the power supply on the printer.
1
2
3Plug the cord into an electrical outlet that other electrical devices have been using.
4If the light is not on, press .
Software does not install
These are possible solutions. Try one or more of the following:
Check your operating system
The following operating systems are supported: Windows Vista, Windows XP, Windows 2000, and Mac OS X
versions 10.34 and 10.4 (not versions 10.0, 10.1, or 10.2).
Note: Windows 2000 users should use Service Pack 3 or later.
Check your system requirements
Check that your computer meets the minimum system requirements listed on the printer box.
Check USB connection
1Check the USB cable for any obvious damage.
2Firmly plug the square end of the USB cable into the back of the printer.
3Firmly plug the rectangular end of the USB cable into the USB port of the computer.
The USB port is marked with the USB symbol.
Check wireless connection
Check that the Wi-Fi indicator light is on. For more information, see “Understanding the parts of the printer” on
page 16.
Reinstall the software
1Turn off and then restart your computer.
2Click Cancel on all New Hardware Found screens.
3Insert the CD, and then follow the instructions on the computer screen to reinstall the software.
102

Reconnect power supply
1Press to turn the printer off.
2Disconnect the power cord from the wall outlet.
3Gently remove the power supply from the printer.
4Reconnect the power supply to the printer.
5Plug the power cord into the wall outlet.
6Press to turn the printer on.
Disable anti-virus programs
1Close all open software applications.
2Disable any antivirus programs.
3Double-click the My Computer icon.
In Windows XP, click Start to access the My Computer icon.
4Double-click the CD–ROM drive icon.
5If necessary, double-click setup.exe.
6Follow the instructions on the computer screen to install the software.
Uninstall and reinstall software
Uninstall the printer software, and then reinstall it. For more information, see “Removing and reinstalling the software”
on page 105.
Page does not print
These are possible solutions. Try one or more of the following:
Check messages
If an error message is displayed, resolve the error before trying to print again.
Check power
If the light is not on, make sure the printer is plugged into a properly grounded outlet. Make sure the power cord
is properly connected to the printer.
Reload paper
Remove and then load paper.
Check ink
Check the ink levels, and install new print cartridges if necessary.
103

Check cartridges
1Remove the print cartridges.
2Make sure the sticker and tape have been removed.
1
2
3Reinsert the cartridges.
Check printer default and pause settings
1Do one of the following:
•In Windows Vista, click Control Panel.
•In Windows XP, click Start.
2Click Printers Printers and Faxes.
3Double-click the printer queue device.
4Click Printer.
•Make sure no check mark appears next to Pause Printing.
•If a check mark does not appear next to Set As Default Printer, you must select the print queue device for
each file you want to print.
Reconnect power supply
1Press to turn the printer off.
2Disconnect the power cord from the wall outlet.
3Gently remove the power supply from the printer.
4Reconnect the power supply to the printer.
5Plug the power cord into the wall outlet.
6Press to turn the printer on.
Remove and reinstall the software
Uninstall the printer software, and then reinstall it.
Understanding Warning levels
•A green check indicates system requirements were met.
•A yellow question mark indicates system requirements were not met. Most major functions will work, but you
may experience some performance impact.
•A red question mark indicates system requirements were not met. Most major functions may not work.
•A red X indicates system requirements were not met. Installation will not continue.
For proper installation, make sure the computer supports all system requirements. System requirements are located
on the printer box.
104

Removing and reinstalling the software
If the printer is not functioning properly, or if a communications error message appears when you try to use the
printer, you may need to remove and reinstall the printer software.
1In Windows Vista, click . In Windows XP or earlier, click Start.
2Click Programs or All Programs Lexmark 4800 Series.
3Select Uninstall.
4Follow the instructions on the computer screen to remove the printer software.
5Restart the computer before reinstalling the printer software.
6Click Cancel on all New Hardware Found screens.
7Insert the CD, and then follow the instructions on the computer screen to reinstall the software.
Note: If the install screen does not appear automatically after you restart your computer, click Start Run, and
then type D:\setup, where Dis the letter of your CD-ROM drive.
If the software still does not install correctly, visit our Web site at www.lexmark.com to check for the latest software.
1In all countries or regions except the United States, select your country or region.
2Click the links for drivers or downloads.
3Select your printer family.
4Select your printer model.
5Select your operating system.
6Select the file you want to download, and then follow the directions on the computer screen.
Enabling the USB port
To confirm that the USB port is enabled on the computer:
1Open the Device Manager.
In Windows Vista:
aClick Control Panel.
bClick System and MaintenanceSystem.
cClick Device Manager.
In Windows XP:
aClick Start.
bClick Control PanelPerformance and MaintenanceSystem.
cFrom the Hardware tab, click Device Manager.
In Windows 2000:
aClick Start.
bClick SettingsControl PanelSystem.
cFrom the Hardware tab, click Device Manager.
2Click the plus sign (+) beside Universal Serial Bus Controller.
If USB Host Controller and USB Root Hub are listed, then the USB port is enabled.
105

For more information, see the computer documentation.
Solving printer communication problems
The printer and the computer cannot exchange data.
These are possible solutions. Try one or more of the following:
Establish bidirectional communication between the printer and the computer
For more information, see “Bidirectional communication is not established” on page 135.
Make sure the printer is not in sleep mode
If the power light is blinking on and off slowly, the printer is in sleep mode.
1Unplug the power cable from the wall outlet.
2Wait ten seconds, and then insert the power cable into the wall outlet.
3Press to turn the printer on.
Wireless troubleshooting
How do I find out what type of security my network is using?
You must know the security key and security mode in order to properly set up the printer for use on the wireless
network. To obtain this information, see the documentation that came with your wireless router, see the Web page
associated with the router, or consult the person who set up your wireless network.
Check your security keys
A security key is like a password. All devices on the same network share the same security key.
Note: Make sure you copy down the security key exactly, including any capital letters, and store it in a safe place
for future reference.
The security key must follow the following criteria.
WEP key
•Exactly 10 or 26 hexadecimal characters. Hexadecimal characters are A–F and 0–9.
•Exactly 5 or 13 ASCII characters. ASCII characters are letters, numbers, and symbols found on a keyboard.
WPA-PSK or WPA2-PSK key
•Up to 64 hexadecimal characters. Hexadecimal characters are A–F and 0–9.
•Between 8 and 64 ASCII characters. ASCII characters are letters, numbers, and symbols found on a keyboard.
Printer is configured correctly, but cannot be found on the network
Make sure:
•The printer has power and the light is on.
•The printer is within range of the wireless network.
•The printer is located away from other electronic devices that may interfere with the wireless signal.
•Your wireless network is using a unique network name (SSID). If not, it is possible that the printer/print server
is communicating over a different, nearby network that uses the same network name.
•The printer has a valid IP address on the network.
106

Wireless network printer does not print
These are possible solutions. Try one or more of the following:
Check power
Make sure the light is on.
Check cable
•Make sure the power cable is connected to the printer and to the electrical outlet.
•Make sure the USB cable or the installation cable is not connected.
Check Wi-Fi indicator light
Make sure the Wi-Fi indicator light is green. If it is not green, see “Wi-Fi indicator light is orange” or “Wi-Fi indicator
light is blinking orange during installation” in “Wireless troubleshooting.”
Check if printer driver is installed
Make sure the printer driver is installed on the computer from which you are sending the print job.
1Do one of the following:
•In Windows Vista, click: Control Panel Printers.
•In Windows XP, click:Start Settings Printers and Faxes.
•In Windows 2000 and earlier, click: Start Settings Printers.
If you cannot find the icon for your printer, then the printer driver is not installed.
2If the printer driver is not installed, insert the installation software CD into your computer.
3Follow the instructions on the computer screen.
Note: You must install the printer driver on each computer that uses the network printer.
Check if printer is connected to the wireless network
1Print a network setup page. For more information, see “Printing a network setup page.”
2Check to see if “Status: Connected” appears under Network Card.
Reboot the computer
Turn off and restart the computer.
Check printer ports
Make sure the correct printer port is selected.
1Click:
•In Windows Vista: Control Panel Printers.
•In Windows XP: Start Settings Printers and Faxes.
•In Windows 2000 and earlier: Start Settings Printers.
2Right-click the Lexmark 4800 Series icon.
3Click Properties Ports.
107

4Verify that XXXX_Series_nnnnnn_P1 is selected, where XXXX is the model series number of your printer and
nnnnnn is the last six numbers of the MAC address of your printer.
Note: The MAC address is located at the back of the printer beside the serial number.
5If USB is selected instead:
aSelect the port name from step 4.
bClick Apply.
cClose the window, and try printing again.
Reinstall software
Uninstall and then reinstall the printer software.
Note: If more than one printer appears in the ”Select your printer” list, pick the printer with the MAC address that
matches the address on the back of your printer.
Wi-Fi indicator is not lit
These are possible solutions. Try one or more of the following:
Check power
Make sure the printer power light is on. For more information, see “Power button is not lit”.
Remove and reinstall the optional internal print server
Note: This solution does not apply to printers that came with the internal wireless print server already installed.
Reinstall the internal wireless print server. For more information, see “Installing an optional internal wireless print
server”.
Wi-Fi indicator light is blinking orange during installation
When the Wi-Fi indicator light is blinking orange, it indicates that the printer has been set up for wireless networking
but cannot connect to the network for which it has been configured. The printer may be unable to join the network
because of interference or its distance from the wireless access point (wireless router), or until its settings are
changed.
These are possible solutions. Try one or more of the following:
Make sure the access point is on
Check the access point and, if necessary, turn it on.
Move your wireless access point (wireless router) to minimize interference
There may be temporary interference from other devices such as microwave ovens or other appliances, cordless
phones, baby monitors, and security system cameras. Make sure your wireless access point (wireless router) is not
positioned too closely to these devices.
Try adjusting external antennas
Generally, antennas work best if they are pointing straight up. You may find, however, that reception improves if you
experiment with different angles for your printer and/or wireless access point (wireless router) antennas.
108

Move your computer and/or printer
Move the computer and/or printer closer to the wireless access point (wireless router). Although the possible distance
between devices in 802.11b or 802.11g networks is 300 feet, the effective range for optimal performance is generally
100–150 feet.
You can find the signal strength of the network on the network setup page. For information on how to print a setup
page, see “Printing a network setup page” on page 34.
Check security keys
Make sure security keys are correct. For more information, see “Check your security keys” on page 106.
Check MAC address
If your network uses MAC address filtering, provide the MAC address for the printer to your network. If you need
help finding the MAC address, see “Finding the MAC address” on page 33.
Ping the wireless access point (wireless router) to make sure the network is working
1If you do not already know it, find the IP address of the access point.
aClick:
•In Windows Vista: All Programs Accessories Command Prompt.
•In Windows XP and earlier: Start Programs or All Programs Accessories Command
Prompt.
bType ipconfig.
cPress Enter.
•The “Default Gateway” entry is typically the wireless access point (wireless router).
•The IP address appears as four sets of numbers separated by periods, such as 192.168.0.100. Your IP
address might also start with the numbers 10 or 169. This is determined by your operating system or
wireless network software.
2Ping the wireless access point (wireless router).
aClick:
•In Windows Vista: All Programs Accessories Command Prompt.
•In Windows XP and earlier: Start Programs or All Programs Accessories Command
Prompt.
bType ping followed by a space and the IP address of the wireless access point (wireless router). For
example:
ping 192.168.0.100
cPress Enter.
3If the wireless access point (wireless router) responds, you will see several lines appear that start with “Reply
from”. Turn off and restart the printer.
4If the wireless access point (wireless router) does not respond, it will take several seconds and then you will see
“Request timed out.”
Try the following:
aClick:
•In Windows Vista: Control Panel Network and Internet Network and Sharing Center
•In Windows XP and earlier: Start Settings or Control Panel Network Connection
109

bSelect the appropriate connection from the ones shown.
Note: If the computer is connected to the access point (router) by an Ethernet cable, the connection may
not include the word “wireless” in its name.
cRight-click the connection, and then click Repair.
Run the wireless setup again
If your wireless settings have changed, you must run the printer wireless setup again. Some reasons your settings
may have changed include your having manually changed your WEP or WPA keys, channel, or other network
settings; or the wireless access point (wireless router) having been reset to factory defaults.
Notes:
•If you change network settings, change them on all the network devices before changing them for the wireless
access point (wireless router).
•If you have already changed the wireless network settings on your wireless access point (wireless router), you
must change the settings on all the other network devices before you can see them on the network.
1Click:
•In Windows Vista: .
•In Windows XP and earlier: Start.
2Click Programs or All Programs Lexmark 4800 Series.
3Click Wireless Setup.
Note: You may be prompted to connect the printer to the computer again using the installation cable as part of
the setup process.
4Follow the instructions on the computer screen.
Wi-Fi indicator light is orange
These are possible solutions. Try one or more of the following:
Check cable
Make sure the installation cable is not connected to the printer.
Configure the optional internal wireless print server
Note: This solution does not apply to printers that have a pre-installed internal wireless print server.
If you purchased the optional internal wireless print server after your printer was already set up, see “Configuring
the optional internal wireless print server” in the “Setting up the printer” chapter.
Check network name
Make sure your network does not have the same name as another network near you. For example, if you and your
neighbor both use a manufacturer's default network name, your printer could be connecting to your neighbor's
network.
If you are not using a unique network name, consult the documentation for your wireless access point (wireless
router) to learn how to set a network name.
If you set a new network name, you must reset the printer and computer SSID to the same network name.
For more information, see “Checking your network name” in the “Wireless troubleshooting” section.
110
