Lexmark 20T3600 - T 620 B/W Laser Printer User manual

Lexmark T620 and T622
High-Capacity Output Stacker
Installation Instructions
Instruções de instalação do
empilhador de saída de alta capacidade
Instructions pour l'installation
du réceptacle haute capacité
Installationsanweisungen für das
AblagefachmithoherKapazität
Istruzioni per l'installazione del
raccoglitore ad alta capacità
Instrucciones de instalacióndela
unidad de salida de alta capacidad




 


English

First Edition (January 2001)
The following paragraph does not apply to any country where such provisions are inconsistent with local law:
LEXMARK INTERNATIONAL, INC., PROVIDES THIS PUBLICATION “AS IS” WITHOUT WARRANTY OF ANY KIND,
EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. Some states do not allow disclaimer of express
or implied warranties in certain transactions; therefore, this statement may not apply to you.
This publication could include technical inaccuracies or typographical errors. Changes are periodically made to the
information herein; these changes will be incorporated in later editions. Improvements or changes in the products or
the programs described may be made at any time.
References in this publication to products, programs, or services do not imply that the manufacturer intends to make
these available in all countries in which it operates. Any reference to a product, program, or service is not intended to
state or imply that only that product, program, or service may be used. Any functionally equivalent product, program, or
service that does not infringe any existing intellectual property right may be used instead. Evaluation and verification of
operation in conjunction with other products, programs, or services, except those expressly designated by the
manufacturer, are the user’s responsibility.
Lexmarkis a trademark of Lexmark International, Inc., registeredin the United States and/or other countries.
©Copyright 2001 Lexmark International, Inc.
All rights reserved.
UNITED STATES GOVERNMENT RESTRICTED RIGHTS
This software and documentation are provided with RESTRICTED RIGHTS. Use, duplication or disclosure by the
Government is subject to restrictions as set forth in subparagraph (c)(1)(ii) of the Rights in Technical Data and
Computer Software clause at DFARS 252.227-7013 and in applicable FAR provisions: Lexmark International, Inc.,
Lexington, KY 40550.

High-Capacity Output Stacker Installation Instructions 1
Introduction
The Lexmark High-Capacity Output Stacker gives your printer
additional output capacity by allowing you to print and stack up to
approximately 1,500 sheets of 20 lb paper.
To ensure reliable paper feeding, it is important that you select paper
recommended for use with the printer and that you load it properly.
Refer to the Reference section of your printer
User’s Guide
for information
pertaining to safety and warranty.

High-Capacity Output Stacker Installation Instructions
2
Unpacking the high-capacity output
stacker
1Remove all items from the box as shown. If any items are missing, contact
the place where you bought the high-capacity output stacker.
2Remove all packing material and tape from each item.
Note: Save the carton and packing material in case you need to repack
the option for service or storage.
3Install the high-capacity output stacker immediately; otherwise, the edges
of the mounting brackets could damage tabletops or fabrics.
Labels
Bracket
Paper
bail High-capacity
output stacker
label
(colored triangle)
bottom side

High-Capacity Output Stacker Installation Instructions 3
Installing the high-capacity output
stacker
1Turn the printer power off and unplug the power cord.
2Remove any previously installed output options or the top cover from the
printer.
3Slide the plastic bracket onto the static brush holder located near the
bottom of the high-capacity output stacker.

High-Capacity Output Stacker Installation Instructions
4
4Install the high-capacity output stacker on the printer.
Note: The high-capacity output stackermust be installed directly onto the
printer, below any other output options.
5Reinstall any output options previously removed.
6Attach the top cover to the topmost output option.

High-Capacity Output Stacker Installation Instructions 5
Installing the wire paper bail
Place the tips of the wire paper bail into the ends of the plastic bracket so that
the bail curves downward. The bail should rest in the approximate center of
the printer output bin.

High-Capacity Output Stacker Installation Instructions
6
Attaching labels to the high-capacity
output stacker
Labels are provided so that you may identify your various output bins. You
may attach the labels to the output bin tray, side cover, or wherever best suits
your application. For easy identification, you may write your own personal
output bin designation onto the label before attaching.
Output bin tray
Side cover
