Lexmark E320/E322 Printer
Print servers connect printers to networks. This lets many users access printers from their
own workstations, a very cost effective way to share powerful and expensive printers. It is not
necessary to buy an extra personal computer to attach each printer to the network. You use
the print server instead.
Environments we support
Print servers support an extraordinarily wide range of network environments.
Any single print server on any given physical network can accept and process print jobs from
any or all of these logical networks concurrently. For example, if a MarkNet XI physically
attaches a printer to an Ethernet network, then a NetWare client and an AppleTalk user can
send print jobs to the printer simultaneously. The print jobs are processed on a first-come,
first-served basis.
Connect the hardware
Instructions on connecting the Ethernet cable to your Lexmark E320n Printer can be found in
the printer Setup Book. To view the Setup Book from this CD, click the Home icon Other
Resources PDFs for Printing Setup Guide.

Setting up the network printer
Paper handling
Maintenance
Troubleshooting
Administration
Index
2
Printing
www.lexmark.com
Lexmark E320/E322 Printer
Print a network setup page
Push the operator panel button with a brief button press to print a network setup page
showing the physical address of the network printer. A printer settings page prints first and
after a few moments a network setup page prints. Save the network setup page because you
will use it later.
Configure and print
TCP/IP
Step 1: Set the IP address, netmask and gateway
You must assign an IP address, netmask and gateway to the print server in order for other
network devices to find it on the network.
•If you have DHCP, the proper addresses are automatically assigned. To verify the
assignment has happened, print a network setup page and make sure the IP address,
netmask and gateway appear as non-zero.
•If you don’t have DHCP, there are other methods you can use to manually assign the
address, such as static ARP and telnet, or a setup utility.
