LG LS240HEV User manual

Date:
JobName/Location:
PONo.:
Architect:
Engr:
GC:
Rep:
For: File
A
pp
roval
Mech:
Resubmit
Other
Tag#:
(Company) (ProjectManager)
MegaSingleZoneInverter
LS240HEV
Performance:
Capacity(Btu/h) 22,000
SEER 17.0
EER 10.75
Cooling:
Heating:
Capacity(Btu/h) 22,000
HSPF 8.5
CoolingNominalTestConditions: HeatingNominalTestConditions:
Indoor: 80°FDB/67°FWB Indoor: 70°FDB/60°FWB
Outdoor: 95°FDB/75°FWB Outdoor: 47°FDB/43°FWB
Electrical:
MCA(A) 14
MOP(A) 20
Compressor(A) 10.8
FanMotor(A) 0.48
OutdoorUnit:
CoolingRatedAmps(A) 11.3
HeatingRatedAmps(A) 10.1
IndoorUnit:
CoolingPowerInput(kW) 2.05
HeatingPowerInput(kW) 1.94
Piping:
LiquidLine(in,OD) 1/4
AdditionalRefrigerant(oz/ft) 0.33
MaxElevation(ft) 32.8
PipingLength(noadd'lrefrigerant,ft) 24.6
ControlsFeatures:
Page1of2DFS‐SB‐AL‐004‐US013D23
Forcontinualproductdevelopment,LGreservestherighttochangespecificationswithoutnotice.
©LGElectronicsU.S.A.,Inc.,EnglewoodCliffs,NJ.Allrightsreserved.“LGLife’sGood”isaregisteredtrademarkofLGCorp./www.lghvac.com.
PowerSupply(V¹/Hz/Ø) 208‐230/60/1
PowerSupply(V¹/Hz/Ø) 208‐230/60/1
VaporLine(in,OD) 5/8
MaxPipeLength(ft)² 65.6
OperatingRange:
OutdoorUnit:
Cooling(°FDB) 64‐118
Heating(°FDB) 23‐75
Cooling(°FDB) 64‐90
Heating(°FDB) 61‐86
IndoorUnit:
UnitData:
RefrigerantType R410A
RefrigerantCharge(lbs) 2.58
Fan:
Notes:
1.Acceptableoperangvoltage:187V‐253V.
2.Pipinglengthsareequivalent.
3.SoundPressurelevelsaretestedinananechoicchamberunderISOStandard1996.
4.Allpower/communicaoncabletobeminimum18AWG,4‐conductor,stranded,shielded
andmustcomplywithapplicablelocalandnationalcode.
5.SeeEngineeringManualforsensibleandlatentcapacies.
6.Powerwiringcablesizemustcomplywiththeapplicablelocalandnaonalcode.
7.Theindoorunitcomeswithadryheliumcharge.
8.Thisdataisrated0abovesealevel,with24.6ofrefrigerantlineanda0leveldifference
betweenoutdoorandindoorunits.
9.MustfollowinstallaoninstruconsintheapplicableLGinstallaonmanual.
ODUType Propeller
IDUType CrossFlow
Motor/Drive BrushlessDigitallyControlled/Direct
Dehumidification(pts/hr) 4.88
RefrigerantControl CapillaryTube
HeatExchangerCoating GoldFin™
ODUSoundPressure(±3dB(A))³ 53
ODUNetUnitWeight(lbs) 92
ODUShippingWeight(lbs) 104
IDUShippingWeight(lbs) 34
FanSpeeds(Fan/Cooling/Heating) 3/4/3
Quantity(ODU+IDU) 1+1
IDUAirFlowRateH/M/L(CFM) 600/494/388
ODUMaxAirFlowRate(CFM) 1,766
IndoorUnit(IDU)‐LSN240HEVOutdoorUnit(ODU)‐LSU240HEV
SEER‐SeasonalEnergyEfficiencyRatio EER‐EnergyEfficiencyRatio
HSPF‐HeatingSeasonalPerformanceFactor
MOP‐MaximumOvercurrentProtection MCA‐MinimumCircuitAmpacity
IDUSoundPressure±3(H/M/L/Sleep)dB(A)³ 45/40/35/29
IDUNetUnitWeight(lbs) 28
•24‐Houron/offmer
•2‐Way(up/down)auto
swing
•Autochangeover
•Autorestart
•Condensatesensor
connection
•Energysaving
•Inverter(variablespeed
compressor)
•Jetcool
•Self‐cleaningindoorcoil
•Sleepmode
•Ultraquietoperaon

JobName/Location:
Tag#:
Date:
PONo.:
MegaSingleZoneInverter
Page2of2DFS‐SB‐AL‐004‐US013D23
Forcontinualproductdevelopment,LGreservestherighttochangespecificationswithoutnotice.
©LGElectronicsU.S.A.,Inc.,EnglewoodCliffs,NJ.Allrightsreserved.“LGLife’sGood”isaregisteredtrademarkofLGCorp./www.lghvac.com.
OutdoorUnit(ODU)‐LSU240HEV

JobName/Location:
Tag#:
Date:
PONo.:
MegaSingleZoneInverter
Page3of3DFS‐SB‐AL‐004‐US013D23
Forcontinualproductdevelopment,LGreservestherighttochangespecificationswithoutnotice.
©LGElectronicsU.S.A.,Inc.,EnglewoodCliffs,NJ.Allrightsreserved.“LGLife’sGood”isaregisteredtrademarkofLGCorp./www.lghvac.com.
IndoorUnit
(
IDU
)
‐LSN240HEV
