LG LC240CP User manual

Submittal Data :
Job Name :
Purchaser :
Engineer :
Submitted To :
Submitted By :
Unit Designation : Schedule No.:
Location :
P.O. No. :
Architect :
Date :
For : □Reference □Approval □Construction
Model No.:
37 13/32
1 3/16
37 13/32
R 1 3/8
33 1/16
3
5 5/16
8 7/8
31 23/32
33 1/16
27 3/32 (hanging bolt)
33 1/16
35 7/16 (ceiling opening)
37 13/32
27 3/32 (hanging bolt)
33 1/16
35 7/16 (ceiling opening)
33 1/16
27 3/32
12 5/8
13 1/8
15 7/16
31 1/2
30 13/16
1
34 5/16
21 1/2
12 5/8
13/3213 3/8
14 3/16
2 5/32
6 5/16
3 5/32
1 31/32
LCN240CP
LCU240CP
Capacities :
Cooling
Outdoor Design Temp.(℉,DB/WB)
Cooling
SEER
EER
Indoor Unit :
Power Supply (V,Ph,Hz)
Maximum Fuse Size
Minimum Ampacity
Weight (lbs)
Sound (dB(A),H/M/L Cool)
Air Circulation (CFM)
Dehumidification (pts/hr)
Outdoor Unit :
Power Supply (V,Ph,Hz)
Maximum Fuse Size
Minimum Ampacity
Weight (lbs)
Sound (dB(A), High Cool)
Refrigerant Piping :
Maximum Length (ft)
Maximum Height Difference (ft)
Liquid Side (O.D)
Gas Side (O.D)
Standard Features :
• Five Year Compressor Warranty
• Two Year Functional Parts Warranty
• R-410a Refrigerant
• Multi Power System TM
• Internal Condensate Pump
• Plasma Air Purifying System
• Swirl Wind Air Circulation
• Temperature Display on Wired Thermostat Controller
and LCD Wireless Remote Controller
• Auto Restart
• 24 Hour On/Off Timer
24,000/23,500 Btu/h
95/75
13
9.6
230/208,1,60
Powered by Outdoor Unit
Powered by Outdoor Unit
57.3
38/35/32
650
6.3
230/208,1,60
30
11.5/12.4
160
55
100
50
1/4”
1/2”
Front Panel Assembly : PT-CDC1
Weight (lbs) 6.6
PT-CDC1
LC240CP
Note :
ⒸLG Electronics USA 2006 SD-LC240CP-VER1
