OWNER’S MANUAL
www.lg.com
MFL69491103
Rev.07_062220
AIR CONDITIONER
Read this owner’s manual thoroughly before operating
the appliance and keep it handy for reference at all
times.
Copyright © 2018 - 2020 LG Electronics Inc. All Rights Reserved
ENGLISH
TYPE: WALL MOUNTED

TABLE OF CONTENTS
2 TABLE OF CONTENTS
3 SAFETY INSTRUCTIONS
3 IMPORTANT SAFETY INSTRUCTIONS
7 OPERATION
7 Notes for Operation
7 Parts and Functions
8 Wireless Remote Control
13 Restarting the Air Conditioner Automatically
13 Using the Mode Function
15 Using the Jet Mode Function
16 Using the Fan Speed Function
16 Using the Air Flow Direction Function
17 Setting the On/Off Timer
18 Using the Sleep Function (Optional)
18 Using the Simple Timer Function (Optional)
19 Using the Energy Display Function (Optional)
19 Using the Light Off Function (Optional)
19 Using the Comfort Air Function (Optional)
20 Using the Energy Saving Function (Optional)
20 Using the Energy Control Function (Optional)
21 Using Special Functions
24 SMART FUNCTIONS
24 LG ThinQ Application
26 Smart DiagnosisTM
27 MAINTENANCE
29 Clean the Air Filter
30 Clean the Micro Dust and Triple Filter (Optional)
31 TROUBLESHOOTING
35 WARRANTY (USA)
37 WARRANTY (CANADA)

3SAFETY INSTRUCTIONS
ENGLISH
FRANÇAIS ESPAÑOL
SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USE
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always
read and follow all safety messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or injure you and others.
All safety messages will follow the safety alert symbol and either the word WARNING, or
CAUTION.
WARNING
If you do not follow instructions, it could result in death or serious injury.
CAUTION
If you do not follow instructions, it could result in minor or moderate injury or damage to the
product.
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of
injury, and tell you what may happen if the instructions are not followed.
IMPORTANT SAFETY INSTRUCTIONS
WARNING
To reduce the risk of explosion, fire, death, electric shock, injury or scalding to persons
when using this product, follow basic precautions, including the following:
•Installation or repairs made by unauthorized persons can pose hazards to you and others.
•Installation MUST conform to the local building codes or, in the absence of local codes, the
National Electrical Code NFPA 70/ANSI C1-1003 or current edition and Canadian Electrical Code
Part1 CSA C.22. 1.
•The information contained in the manual is intended for use by a qualified service technician who
is familiar with the safety procedures and equipped with the proper tools and test instruments.
•Failure to read and follow all instructions in this manual can result in equipment malfunction,
property damage, personal injury and/or death.
•When the power cord is to be replaced, the replacement work shall be performed by authorized
personnel using only genuine replacement parts.
•This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.

4SAFETY INSTRUCTIONS
Installation
•Do not install the air conditioner on an unstable surface or in a place where there is danger of it
falling.
•Contact an authorized service center when installing or relocating the air conditioner.
•Install the panel and the cover of the control box safely.
•Do not install the air conditioner in a place where flammable liquids or gases such as gasoline,
propane, paint thinner, etc., are stored.
•Make sure that the pipe and the power cable connecting the indoor and outdoor units are not
pulled too tight when installing the air conditioner.
•Use standard circuit breaker and fuse that conform to the rating of the air conditioner.
•Do not input air or gas into the system except with the specific refrigerant.
•Use non-flammable gas (nitrogen) to check for leak and to purge air; using compressed air or
flammable gas may cause fire or explosion.
•The indoor/outdoor wiring connections must be secured tightly, and the cable should be routed
properly so that there is no force pulling the cable from the connection terminals. Improper or
loose connections can cause heat generation or fire.
•Install dedicated electric outlet and circuit breaker before using the air conditioner.
•Do not connect the ground wire to a gas pipe, a lightning rod, or a telephone ground wire.
•If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or
similarly qualified person in order to avoid a hazard.
Operation
•Be sure to use only those parts listed in the service parts list. Never attempt to modify the
equipment.
•Make sure that children do not climb on or hit the outdoor unit.
•Dispose of the batteries in a place where there is no danger of fire.
•Use only the refrigerant specified on the air conditioner label.
•Cut off the power supply if there is any noise, smell, or smoke coming from the air conditioner.
•Do not leave flammable substances such as gasoline, benzene, or thinner near the air conditioner.
•Contact an authorized service center when the air conditioner is submerged by flood waters.
•Do not use the air conditioner for an extended period of time in a small place without proper
ventilation.
•In the event of a gas leak (such as Freon, propane gas, LP gas, etc.) ventilate sufficiently before
using the air conditioner again.
•To clean the interior, contact an authorized service center or dealer. Using harsh detergents may
cause corrosion or damage to the unit.

5SAFETY INSTRUCTIONS
ENGLISH
FRANÇAIS ESPAÑOL
•Be sure to ventilate sufficiently when the air conditioner and a heating appliance such as a heater
are used simultaneously.
•Do not block the inlet or outlet of air flow.
•Do not insert hands or other objects through the air inlet or outlet while the air conditioner is
operating.
•Make sure that the power cable is neither dirty, loose, nor broken.
•Never touch, operate, or repair the air conditioner with wet hands.
•Do not place any objects on the power cable.
•Do not place a heater or other heating appliances near the power cable.
•Do not modify or extend the power cable. Scratches or peeling insulation on the power cables
may result in fire or electric shock, and should be replaced.
•Cut off the power supply immediately in the event of a blackout or a thunderstorm.
•Take care to ensure that power cable could not be pulled out or damaged during operation.
•Do not touch refrigerant pipe, water pipe and any internal parts while the unit is operating or
immediately after operation.
Maintenance
•Do not clean the appliance by spraying water directly onto the product.
•Before cleaning or performing maintenance, disconnect the power supply and wait until the fan
stops.
CAUTION
To reduce the risk of minor injury to persons, malfunction, or damage to the product or
property when using this product, follow basic precautions, including the following:
Installation
•Do not install the air conditioner in an area where it is directly exposed to sea wind (salt spray).
•Install the drain hose properly for the smooth drainage of water condensation.
•Exercise caution when unpacking or installing the air conditioner.
•Do not touch the leaking refrigerant during installation or repair.
•Transport the air conditioner with two or more people or use a forklift.
•Install the outdoor unit such that it is protected from direct sunlight. Do not place the indoor unit in
a place where it is directly exposed to sunlight via the windows.
•Safely dispose of packing materials such as screws, nails or batteries using proper packaging
after installation or repair.
•Install the air conditioner in a place where the noise from the outdoor unit or the exhaust fumes will
not inconvenience the neighbors. Failure to do so may result in conflict with the neighbors.

6SAFETY INSTRUCTIONS
Operation
•Remove the batteries if the remote control is not to be used for an extended period of time.
•Make sure that the filter is installed before operating the air conditioner.
•Be sure to check if there is a refrigerant leak after installing or repairing the air conditioner.
•Follow the standards of the corresponding region or country for handling the refrigerant and the air
conditioner and for disassembling the air conditioner.
•Do not place any object on the air conditioner.
•Never mix different types of batteries, or old and new batteries for the remote control.
•Do not let the air conditioner run for a long time when humidity is very high or when a door or a
window has been left open.
•Stop using the remote control if there is a fluid leak in the battery. If your clothes or skin are
exposed to the leaking battery fluid, wash off with clean water.
•Do not expose people, animals, or plants to the cold or hot wind from the air conditioner for
extended periods of time.
•If the leaking battery fluid has been swallowed, rinse the inside of the mouth thoroughly and
consult a doctor.
•Do not drink the water drained from the air conditioner.
•Do not use the product for special purposes, such as preserving foods, works of art, and etc. It
is an air conditioner for consumer purposes, not a precision refrigeration system. There is risk of
damage or loss of property.
•Do not recharge or disassemble the batteries.
Maintenance
•Never touch the metal parts of the air conditioner when removing the air filter.
•Use a sturdy stool or ladder when cleaning, maintaining, or repairing the air conditioner at a
height.
•Never use strong cleaning agents or solvents when cleaning the air conditioner or spray water.
Use a smooth cloth.

7OPERATION
ENGLISH
FRANÇAIS ESPAÑOL
OPERATION
Notes for Operation
Suggestion for Energy Saving
•Do not over-cool the space. This may be harmful for your health and may consume more electricity.
•Block sunlight with blinds or curtains while you are operating the air conditioner.
•Keep doors or windows closed tightly while you are operating the air conditioner.
•Adjust the direction of the air flow vertically or horizontally to circulate indoor air.
•Speed up the fan to cool or warm indoor air quickly, within a short period of time.
•Open windows regularly for ventilation. The indoor air quality may deteriorate if the air conditioner is used for
long durations.
•Clean the air filter once every 2 weeks. Dust and impurities collected in the air filter may block the air flow or
reduce the unit performance.
Parts and Functions
Indoor Unit Outdoor Unit
1
Air Filter
2
Air Intake
3
Front Cover
4
Air Outlet
5
Air Deflector (Horizontal Vane)
6
Air Deflector (Vertical Louver)
7
On/Off Button
1
Air Intake Vents
2
Air Outlet Vents
NOTE
•The number and location of operation lamps may vary according to the model of the air conditioner.
•The feature may be changed according to the type of model.

8OPERATION
Wireless Remote Control
Inserting Batteries
If the display screen of the remote control begins
to fade, replace the batteries. Insert AAA (1.5 V)
batteries before using the remote control.
1Remove the battery cover.
2Insert the new batteries and make sure that the
+ and - terminals of the batteries are installed
correctly.
Installing the Remote Control Holder
To protect the remote control, install the holder where
there is no direct sunlight.
1Choose a safe and easily accessible location.
2Fix the holder by fastening 2 screws firmly with a
screwdriver.
Operating Method
Point the remote control towards the signal receiver
at the right side of the air conditioner to operate it.
NOTE
•The remote control may operate other electronic
devices if it is directed towards them. Make sure to
point the remote control towards the air conditioner
signal receiver.
•For proper operation, use a soft cloth to clean the
signal transmitter and receiver.
•In case of a function not provided in the product,
no buzzer sound occurs from the product when
a button for such function on the remote control
is pressed except for Air Flow Direction (
SWING
),
Energy Display (
kW [3 s]
), Air Purification function ( ).

9OPERATION
ENGLISH
FRANÇAIS ESPAÑOL
Setting the Current Time
1Insert batteries.
•The icon below blinks at the bottom of the
display screen.
2Press or button to select the minutes.
3Press SET/CANCEL button to finish.
NOTE
•The On/Off Timer is available after setting the
current time.
Using the °C/°F Conversion Function
(Optional)
This function changes unit between °C and °F
•Press and hold
℃↔℉ [5 s]
SWING
button about 5 seconds.
Operating the Air Conditioner without
the Remote Control
You can use the ON/OFF button of the indoor unit to
operate the air conditioner when the remote control is
unavailable.
1Open the front cover (Type2) or horizontal vane
(Type1).
2Press the ON/OFF button.
Type1
ON/OFF
Type2
ON/OFF
NOTE
•The stepping motor may be broken, if the horizontal
vane opens rapidly.
•The fan speed is set to high.
•The feature may be changed according to the type
of model.
•The temperature cannot be altered when using this
emergency ON/OFF button.
•For cooling-only models, the temperature is set to
22 °C
•For cooling & heating models, the temperature is
set from 22 °C to 24 °C

10 OPERATION
Using Wireless Remote Control
You can operate the air conditioner more conveniently with the remote control.
SWING
kW [3 s]
℃↔℉ [5 s] DIAGNOSIS [5 s]
SWING
SET UP
ROOM
TEMP
JET
MODE
MODE
TEMP
FAN
SPEED
FUNC.
TIMER CANCEL
SET
CANCEL
*
*
1
2
*
RESET
Button Display
Screen Description
-To turn on/off the air conditioner.
To adjust the desired room
temperature in cooling, heating or
auto changeover mode.
MODE
To select the cooling mode.
To select the heating mode.
To select the dehumidification mode.
To select the fan mode.
To select the auto changeover/auto
operation mode.
JET
MODE To change room temperature quickly.
FAN
SPEED To adjust the fan speed.
SWING
SWING
To adjust the air flow direction
vertically or horizontally.
NOTE
•* buttons may be changed according to the type of model.

11OPERATION
ENGLISH
FRANÇAIS ESPAÑOL
SWING
kW [3 s]
℃↔℉ [5 s] DIAGNOSIS [5 s]
SWING
SET UP
ROOM
TEMP
JET
MODE
MODE
TEMP
FAN
SPEED
FUNC.
TIMER CANCEL
SET
CANCEL
*
*
1
2
*
RESET
Button Display
Screen Description
TIMER
To turn on/off air conditioner
automatically at desired time.
SET/
CANCEL -To set/cancel the special functions and timer.
CANCEL
-To cancel the timer settings.
-To adjust time.
*LIGHT
OFF -To set the brightness of the display on the indoor unit.
ROOM
TEMP To display the room temperature.
°C↔°F [5 s] To change unit between °C and °F
*ENERGY
SAVING To minimize power consumption.
*COMFORT
AIR To adjust the air flow to deflect wind.
kW [3 s] -To set whether or not to display
information regarding energy.
*ENERGY
CTRL
To bring the effect of the power
saving.
*COMFORT
SLEEP
To make a comfortable sleeping
environment.
DIAGNOSIS
[5 s] -To conveniently check maintenance information of a product.

12 OPERATION
SWING
kW [3 s]
℃↔℉ [5 s] DIAGNOSIS [5 s]
SWING
SET UP
ROOM
TEMP
JET
MODE
MODE
TEMP
FAN
SPEED
FUNC.
TIMER CANCEL
SET
CANCEL
*
*
1
2
*
RESET
Button Display
Screen Description
FUNC.
The Ion generator uses millions of
ions to help improve indoor air quality.
To reduce noise from outdoor units.
To keep your skin moisturized by
generating ion clusters.
To lower indoor humidity quickly.
To maintain a minimum room
temperature and prevent objects in
the room from freezing.
To scare away a mosquito.
To remove moisture generated inside
the indoor unit.
To make a comfortable sleeping
environment.
RESET - To initialize the remote control
settings.
NOTE
•Some functions may not be supported, depending on the model.
•* buttons may be changed according to the type of model.
•Press the SET/CANCEL button to operate the selected FUNC.

13OPERATION
ENGLISH
FRANÇAIS ESPAÑOL
Restarting the Air Conditioner
Automatically
When the air conditioner is turned on again after
a power failure, this function restores the previous
settings.
Disabling Auto Restart
1Open the front cover (Type2) or horizontal vane
(Type1).
2Press the ON/OFF button and hold it for 6
seconds, then the unit will beep twice and the
lamp will blink twice 4 times.
•To re-enable the function, press the ON/OFF
button and hold it for 6 seconds. The unit will
beep twice and the lamp will blink 4 times.
Type1
ON/OFF
Type2
ON/OFF
NOTE
•The feature may be changed according to the type
of model.
•If you press and hold the ON/OFF button for 3 – 5
seconds, instead of 6 seconds, the unit will switch
to the test operation. In the test operation, the unit
blows out strong cooling air for 18 minutes and
then returns to factory default settings.
Using the Mode Function
This function allows you to select the desired
function.
Cooling Only Model
Cooling Mode
Auto Operation(AI) Mode
Dehumidification Mode
Fan Mode
Cooling & Heating Model
Cooling Mode
Auto Changeover Mode
Dehumidification Mode
Heating Mode
Fan Mode
Cooling Mode
1Turn the appliance on.
2Press MODE button repeatedly to select the
Cooling Mode.
•is displayed on the display screen.
3Press or button to set the desired
temperature.

14 OPERATION
Auto Operation (Artificial
Intelligence)
Cooling Only Model
This mode automatically sets the fan speed and
temperature depending on the room temperature.
1Turn the appliance on.
2Press MODE button repeatedly to select the Auto
Operation.
•is displayed on the display screen.
3Press or button to select the desired
operation code if the temperature is higher or
lower than the desired temperature.
Code Description
2 Cold
1 A little cold
0 Maintain room temperature
-1 A little hot
-2 Hot
NOTE
•In this mode, you cannot adjust the fan speed, but
you can set the air deflector to rotate automatically.
Auto Changeover Mode
Cooling & Heating Model
This mode changes the mode automatically to
maintain the set temperature at ±2 °C
1Turn the appliance on.
2Press MODE button repeatedly to select the Auto
Changeover Mode.
•is displayed on the display screen.
3Press or button to set the desired
temperature.
4Press FAN SPEED button to adjust the fan
speed.
Dehumidification Mode
This mode removes excess moisture from a highly
humid environment or during the rainy season,
in order to prevent mildew from setting in. This
mode adjusts the room temperature and the fan
speed automatically to maintain the optimal level of
humidity.
1Turn the appliance on.
2Press MODE button repeatedly to select the
Dehumidification Mode.
•is displayed on the display screen.
NOTE
•In this mode you cannot adjust the room
temperature, it is adjusted automatically.
•The room temperature is not displayed on the
display screen.
•In the dehumidification mode, compressor and
indoor fan may not operate when the room
temperature is below 24 °C

15OPERATION
ENGLISH
FRANÇAIS ESPAÑOL
Heating Mode
1Turn the appliance on.
2Press MODE button repeatedly to select the
Heating Mode.
•is displayed on the display screen.
3Press or button to set the desired
temperature.
NOTE
•will be displayed on the indoor unit when
defrosting is operating.
•Furthermore, this indication will be displayed on the
indoor unit:
−When preheating is operating.
−When the room temperature has been reached
to the set temperature.
Fan Mode
This mode only circulates the indoor air without
changing the room temperature.
1Turn the appliance on.
2Press MODE button repeatedly to select the Fan
Mode.
•is displayed on the display screen.
3Press FAN SPEED button to adjust the fan
speed.
Using the Jet Mode Function
Changing Room Temperature
Quickly
This function allows you to cool indoor air quickly
during the summer or warm it quickly during winter.
•Cooling & Heating model : The Jet Mode
function is available with Cooling, Heating and
Dehumidification Mode.
•Cooling Only model : The Jet Mode function is
available with Cooling, Dehumidification, Fan, Auto
Operation Mode and Air Purification function.
1Turn the appliance on.
2Press MODE button repeatedly to select the
desired mode.
3Press JET MODE button.
•is displayed on the display screen.
NOTE
•Jet Heating Mode is not available on some models.
•In Jet Cooling Mode, strong air blows out for 30
minutes.
•After 30 minutes later, setting temperature is
maintaining 18 °C
If you want to change the temperature, Press
or button to set the desired temperature.
•In Jet Heating Mode, strong air blows out for 30
minutes.
•After 30 minutes later, setting temperature is
maintaining 30 °C
If you want to change the temperature, Press
or button to set the desired temperature.
•This function may operate differently from the
remote control display.

16 OPERATION
Using the Fan Speed
Function
Adjusting the Fan Speed
•Press FAN SPEED button repeatedly to adjust the
fan speed.
Display Screen Speed
High
Medium - High
Medium
Medium - Low
Low
- Natural Wind
NOTE
•The fan speed of Natural Wind adjusts
automatically.
→ →
•The fan speed icons are displayed on some indoor
units.
→ → → →
•Indoor unit display is displayed only 5 seconds and
return to the setting temperature on some models.
Using the Air Flow Direction
Function
This function adjusts the direction of the air flow
vertically (horizontally).
•Press
SWING
(
SWING
) button repeatedly and select the
desired direction.
−Select ( ) to adjust the direction of the air
flow automatically.
NOTE
•Adjusting the air flow direction horizontally may not
be supported, depending on the model.
•Adjusting the air deflector arbitrarily may cause
product failure.
•If you restart the air conditioner, it starts to operate
with the previously set direction of air flow, so the
air deflector may not match the icon displayed on
the remote control. When this occurs, press
SWING
or
SWING
button to adjust the direction of the air flow
again.
•This function may operate differently from the
remote control display.

17OPERATION
ENGLISH
FRANÇAIS ESPAÑOL
Setting the On/Off Timer
This function sets the air conditioner to turn on/off
automatically at desired time.
On/Off Timer can be set together.
Setting the On Timer
1Press
TIMER
button repeatedly.
•The icon below blinks at the bottom of the
display screen.
2Press or button to select the minutes.
3Press SET/CANCEL button to finish.
•After setting the timer, current time and icon
are displayed on the display screen indicating
that the desired time is set.
Canceling the On Timer
1Press
TIMER
button repeatedly.
•The icon below blinks at the bottom of the
display screen.
2Press SET/CANCEL button to cancel the setting.
Setting the Off Timer
1Press
TIMER
button repeatedly.
•The icon below blinks at the bottom of the
display screen.
2Press or button to select the minutes.
3Press SET/CANCEL button to finish.
•After setting the timer, current time and icon
are displayed on the display screen indicating
that the desired time is set.
NOTE
•This function is disabled when you set Simple
Timer.
Canceling the Off Timer
1Press
TIMER
button repeatedly.
•The icon below blinks at the bottom of the
display screen.
2Press SET/CANCEL button to cancel the setting.
Canceling the Timer Setting
•Press
CANCEL
button to cancel all timer settings.

18 OPERATION
Using the Sleep Function
(Optional)
This function turns off the air conditioner
automatically when you go to sleep.
1Turn the appliance on.
2Press
TIMER
button repeatedly.
•The icon below blinks at the bottom of the
display screen.
3Press or button to select the hour (up to
7 hours).
4Press SET/CANCEL button to finish.
•is displayed on the display screen.
NOTE
•is displayed on some indoor units.
•Indoor unit display is displayed from 1H to 7H
which is displayed only 5 seconds and then return
to the setting temperature.
•In the Cooling and Dehumidification Mode, the
temperature increases by 1 °C after 30 minutes
and additional 1 °C after another 30 minutes for a
more comfortable sleep.
•The temperature increases up to 2 °C from the
preset temperature.
•Although the remark for fan speed on the display
screen may be changed, the fan speed is adjusted
automatically.
Using the Simple Timer
Function (Optional)
This function turns off the air conditioner
automatically when you go to sleep.
1Turn the appliance on.
2Press
TIMER
button repeatedly.
•The icon below blinks at the bottom of the
display screen.
3Press or button to select the hour (up to
7 hours).
4Press SET/CANCEL button to finish.
•is displayed on the display screen.
NOTE
•This function is disabled when you set Off Timer.

19OPERATION
ENGLISH
FRANÇAIS ESPAÑOL
Using the Energy Display
Function (Optional)
This function displays the amount of electricity
generated on the indoor display as the product
operates.
Display the Current Energy Usage
1Turn the appliance on.
2Press
kW [3 s]
button and hold it about 3 seconds.
•The instantaneous power consumption ( or
kW
kWh
) is displayed for a while on some indoor
units.
Display the Cumulative Energy
Usage (Optional)
1Turn the appliance on.
2Press
kW [3 s]
button and hold it about 3 seconds
twice.
•The cumulative power consumption (
kW
kWh
) is
displayed for a while on some indoor units.
NOTE
•It is not displayed on the wireless remote control.
•kW refers to instantaneous power consumption.
•kWh refers to cumulative power consumption.
•If it is more than 99 kWh, which is the range of
expression, maintain it as 99 kWh.
•Power off resets its value.
•Display wattage under 10 kW(h) with 0.1 kW(h)
unit, and display one over 10 kW(h) with 1 kW(h)
unit.
•The actual power may differ from the power
displayed.
Using the Light Off Function
(Optional)
Display Screen Brightness
You can set the brightness of the indoor unit display
screen.
•Press LIGHT OFF button.
NOTE
•Turn on/off the Display screen.
Using the Comfort Air
Function (Optional)
Comfort Vane Operation
This function conveniently sets the vane to a preset
position to deflect the supply air away from blowing
directly onto the occupants in the room.
1Turn the appliance on.
2Press COMFORT AIR button repeatedly and
select the desired direction.
•or is displayed on the display screen.
NOTE
•or is displayed on some indoor units.
•This function is disabled when you press MODE or
JET MODE button.
•This function is disabled and auto swing of vertical
direction is set up when you press
SWING
button.
•When this function is off, the horizontal vane
operates automatically depending on the set mode.

20 OPERATION
Using the Energy Saving
Function (Optional)
This function minimizes power consumption during
Cooling and increases the set temperature to the
optimal level for a more comfortable environment.
The temperature automatically settles at 22 °C if
desired temperature is below 22 °C The temperature
remains constant if it is above 22 °C
1Turn the appliance on.
2Press MODE button repeatedly to select the
Cooling Mode.
3Press ENERGY SAVING button.
•is displayed on the display screen.
Using the Energy Control
Function (Optional)
1Turn the appliance on.
2Press ENERGY CTRL button.
•Press ENERGY CTRL button repeatedly to
select each step.
NOTE
•1 step : The power Input is decreased by 20 %
compared to rated power input.
−is displayed on the display screen.
•2 step : The power Input is decreased by 40 %
compared to rated power input.
−is displayed on the display screen.
•3 step (Optional) : The power Input is decreased by
60 % compared to rated power input.
−is displayed on the display screen.
•(1 step), (2 step) is displayed on some indoor
units.
•This function is available with Cooling Mode.
•Capacity may decrease when Energy Control mode
is selected.
•Desired temperature is displayed about 5 seconds
if you press FAN SPEED, or button.
•Room temperature is displayed about 5 seconds if
you press ROOM TEMP button.
